Whirlpool LXR7144EQ2 User manual

1
TOP AND CABINET PARTS
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
AUTOMATIC WASHER
3−00 Litho In U.S.A. (rcg) Part No. 881645 Rev.A

TOP AND CABINET PARTS
2
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Use And Care Guide
LIT3363573 English
LIT3951073 French
Installation
Instructions
LIT3952817 English
LIT3951578 French
LIT3953932 Wiring Diagram
LIT3953891 Energy Label
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT4313896 Automatic Washer
2 Top
3949310 White
3949311 Almond
3 62750 Spacer, Cabinet To
Top (4)
4 357213 Nut, Push−In (2)
5 Cabinet
63424 White
63425 Almond
6 62780 Clip, Top & Cabinet
& Rear Panel (2)
8 3356311 Screw & Washer,
Lid Switch (2)
9 3949237 Switch, Lid
13 3351355 Screw, Lid Hinge
Mounting (4)
15 54584 Hinge, Lid (L.H.)
16 54583 Hinge, Lid (R.H.)
17 19119 Bumper, Lid Hinge
18 21258 Bearing, Lid
Hinge (2)
19 Lid
3361400 White
3361401 Almond
20 358684 Strike, Lid Switch
22 9724509 Bumper, Lid (2)
28 62863 Screw 10−16 x 3/8
31 90016 Clip, Harness

CONTROLS AND REAR PANEL PARTS
3
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

CONTROL AND REAR PANEL PARTS
4
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3976300 Washer, Water
Inlet Hose (4)
(1−1/16 x 5/8)
2 9740848 Screw 8−18 x 1/2
3 Hose, Water
Inlet (2)
3949374 Hose (Inlet)
3949375 Hose (Inlet)
4 3357027 Nozzle−Drain
Hose
5 387402 Hinge, Console (2)
6 3357978 Panel, Rear
7 62747 Pad, Rear Panel
8 3951609 Hose, Drain
(4’− 8")
661577 Hose, Drain
(9’−9")
(Not Included)
3357090 Extension,
Drain Hose
(21 Inches)
(Not Included)
9 3948323 Timer, Control
(60 Hz.)
(Motor Not A
Service Part)
10 3400064 Screw 10−32 x 5/16
11 90767 Screw, 8A x 3/8
12 3366847 Switch, Water Level
13 3948608 Bracket, Control
14 3948063 Cord, Power
15 3952821 Strain Relief,
Power Cord
16 End Cap (L.H.)
3358528 White
3358529 Almond
18 3952164 Valve, Water
Mixing
19 90864 Screw,
10−24 x 3/8 (2)
21 370451 Clamp, Hose
272846 (Alt.)
353367 (Alt.)
22 3357328 Hose, Vacuum
Break
23 371503 Clamp, Hose
24 3347034 Break, Vacuum
25 63290 Support, Rear
Panel
26 3361805 Hose−Corrugated
Assy.
27 356138 Clamp, Hose
30 3363366 Clamp, Hose
31 660628 Clamp, Hose
32 3951449 Hose, Pump To Tub
(Includes #30)
35 3949184 Switch, Water
Temperature
39 Panel, Console
3948257 White
3948258 Almond
44 Knob, Timer
3364291 White
3364293 Almond
45 Dial, Timer
3951053 White
3951054 Almond
47 Knob, Control
3950759 White
3950760 Almond
49 388326 Screw, 8−18
(Panel to Top)
50 62863 Screw, 10−16 x 3/8
51 End Cap (R.H.)
3358513 White
3358514 Almond
55 3390647 Screw 8−18 x 1/2
58 3366913 Clamp, Drain
Hose
59 3952568 Harness, Wiring
(For Detail See
Page 9.)

AGITATOR, BASKET AND TUB PARTS
5
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

6
AGITATOR, BASKET AND TUB PARTS
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645
Illus. Part
No. No. DESCRIPTION
1 3355758 Cap, Agitator
2 358237 Screw & Washer
(5−16−24 x 1)
3 3349019 Clothes Mover
4 3350830 Agitator
5 3360611 Tub Ring & Gasket
6 3359586 Gasket, Tub Ring
7 387868 Balance Ring
8 387867 Clip, Balance
Ring (8)
9 3363663 Cam Driven
10 3366877 Dog, Agitator
Clutch (4)
11 3363661 Bearing−Driven
Cam
12 21366 Nut, Spanner
13 8271639 Basket & Balance
Ring Assembly
(Also Order #14)
14 3952746 Filter, Plate
16 63125 Tub
17 389140 Block, Basket
Drive
18 383727 Gasket, Centerpost
19 3347780 Hose, Pressure
Switch
20 3350829 Agitator
(Complete Asy.)
22 3350389 Spacer, Thrust
23 3347290 Cap, Barrier
24 3348855 Seal, Inner Cap

7
BRAKE, CLUTCH, GEARCASE, MOTOR AND PUMP PARTS
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 388951 Brake & Drive
Tube (Complete)
(Refer to Page 12
For Further
Breakdown)
2 63292 Washer, Spin
Tube Thrust
3 62697 Ring, Spin
Tube Support
4 63283 Ring, Retainer
5 3951311 Clutch (Complete)
6 3951308 Band & Lining,
Clutch (Includes
Illus. 7 & 8)
7 62646 Cap, Clutch
Spring (2)
8 Spring, Clutch
9 3360630 Gearcase
(Complete)
(Refer To Page 13
For Further
Breakdown)
10 3357334 Screw, Gearcase
To Base (3)
11 62611 Plate, Motor
Mount To
Gearcase
12 62691 Grommet, Motor (4)
13 3364003 Coupling, Motor
& Isolation
15 3355454 Clip,
Anti−Rattle
16 3400516 Screw (2)
17 3349637 Retainer, Motor (2)
18 3362089 Shield, Tub
To Motor
19 661599 Motor, Main
Drive
20 62850 Switch, Main
Drive Motor
21 62700 Retainer, Pump (2)
22 3363394 Pump (Complete)
23 3387485 Screw, 10−16 x 5/8
24 3946532 Shield, Motor
25 62863 Screw,
10−16 x 3/8
26 357021 Capacitor
27 357030 Clamp, Capacitor
3946792

8
MACHINE BASE PARTS
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645
Illus. Part
No. No. DESCRIPTION
1 3387485 Screw, Bracket
Mounting
(10−16 x 5/8)
2 64067 Bracket, Spring
Outer (2)
3 63907 Spring
Suspension,(3)
4 3362087 Support & Brake,
Tub
5 64065 Bracket, Spring
Outer (L.F.)
6 63466 Link, Leveling
Mechanism (2)
7 62597 Spring, Leveling
Mechanism
8 62837 Pin, Knurled
9 62596 Foot, Rear (2)
13 3347047 Bearing,
Centerpost (2)
14 357409 Seal, Centerpost (3)
15 388492 Spring,
Counterweight
16 62568 Pad, Plate
17 3946509 Plate, Suspension
(Includes Illus. 16)
18 3363660 Pad, Base
19 3946512 Base Assembly
(Includes Items 6,
7, 8, 9, 16, 17,
18 & 26)
21 3359452 Nut, Lock
(3/8−16)
22 389102 Foot, Front (2)
23 356934 Seal, Centerpost (2)
24 285203 Centerpost
Bearing Kit
(Includes Items
13, 14 & 23)
25 63134 Ring, Sound
Deadening
26 63806 Retainer,
Suspension Spring

WIRING HARNESS PARTS
WH2G
9
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

WIRING HARNESS PARTS
WH2G
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
FOR COMPLETE WIRING HARNESS REFER TO
CONTROL AND REAR PANEL PARTS PAGE
1 3349557 Clip, Harness
2 388498 Clip, Harness
3 3347812 Clip, Harness
4 3352501 Clip, Harness
5 90016 Clip, Harness
6 3390496 Clip, Harness
7 389379 Retainer,
(Suds Models)
8 352090 Timer, Block
Disconnect
(White)
9 352089 Timer, Block
Disconnect
(Black)
10 62889 Receptacle,
Terminal
(3−Way)
(Lid Switch)
(Use Term.94613)
Or 94614.)
11 353424 Plug, Terminal
(3−Way)
(Power Cord)
(Use Term.94613)
12 62505 Block, Disconnect
(Motor 2 Speed)
(Use Term.352088)
13 3348075 Block, Disconnect
(Motor 3 Speed)
(Use Term. 94613
Or 94614.)
14 3347243 Block, Disconnect
(Use Term. 352088)
15 63523 Protector
16 717252 Connector
(2−Way)
(Use Term.94614)
17 387566 Plug, Terminal
(4−Way)
(Power Cord)
(Use M3 Screws)
18 3352944 Clip, Harness
19 3390423 Block, Disconnect
(12−Way)
(Timer)
(Use Term. 94613)
20 3347730 Receptacle
(6−Way)
(Use Term. 94613)
21 388818 Plug, Terminal
(12−Way)
(Use Term. 94613
Or 94614.)
22 3369366 Timer, Block
Disconnect
(Black) (Amp)
(Use Term.3369365)
23 3349494 Connector, Etc
24 60687 Connector, Relay
(Use Term.308569)
25 3407125 E.T.C. Control
26 3948617 Connector (T.P.A.)
(3−Circuit)
(Lid Switch)
(Use Term. 3948619
OR 3948620.)
27 3360056 Connector (T.P.A)
(3−Circuit)
(Pressure Switch)
(Use Term.3948619
OR 3948620.)
28 3354925 Block, Connector
(Cold Valve)
(Use Term.693217)
29 3354926 Block, Connector
(Hot Valve)
(Use Term.693217)
30 3948615 Connector (T.P.A.)
(6−Circuit)
(Temp. Switch)
(Use Term.3948619
OR 3948620.)
10
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

WATER SYSTEM PARTS
1 285442 Connector Kit,
Plastic Drain
Hose
2 285321 Sleeve Kit,
(Contains 2
Sleeves)
3 370447 Clamp, Hose
4 16272 Connector,
Straight
5 285320 Siphon Break
Kit
(Not Included)
6 65349 Clamp, Hose
7 367031 Drain Protector
(Not Included)
Illus. Part
No. No. DESCRIPTION
11
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

BRAKE AND DRIVE TUBE PARTS
1 388951 Brake And Drive
Tube (Complete)
2 62658 Ring, Thrust
3 91939 Seal, Oil
4 356427 Seal, Drive Tube
5 356937 Spacer, Drive
Tube
6 64027 Tube, Basket
Drive (Includes
Illus. 3, 4, 5 & 9)
7 64035 Ring, Retaining
8 64232 Brake Shoe
9 62703 ‘‘T’’ Bearing,
Spin Tube
10 62648 Cap, Brake
Spring (2)
11 62647 Spring, Brake
12 62909 Sleeve, Brake
Spring
13 63023 Cam, Brake
Release
14 63022 Sleeve, Cam
15 64194 Driver, Brake
Cam
16 90368 Ring, Retaining
FOLLOWING PARTS
NOT ILLUSTRATED
285208 Lubricant
(Use Only In
Brake Shoe
Assembly On
Roller & Pin)
Illus. Part
No. No. DESCRIPTION
12
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

GEARCASE PARTS
Illus. Part
No. No. DESCRIPTION
GC−215C
1 3360630 Gearcase
(Complete)
2 285202 Cover, Gearcase
3 3349985 Seal, Gearcase
Cover
4 285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
5 63320 Pinion, Spin
(Includes Illus. 25)
6 356427 Seal, Spin
Pinion
7 389387 Shaft, Agitator
(Complete)
8 90369 Ring, Retaining (2)
9 62677 Retainer, Spring
10 62676 Spring, Agitate
11 63273 Gear, Agitate
(Includes 15 and 29)
12 62619 Washer, Agitate
Gear
13 62580 Cam Follower
(Includes 14)
14 62581 Cam, Agitate
(Includes 13)
15 285509 Shaft, Agitator
(Includes 11 and 29)
16 62618 Washer, Cam Thrust
17 16018 Bearing, Thrust
18 85529 Ball, Bearing
19 389230 Bottom and Pinion,
Gearcase
21 285352 Seal, Thrust Plug
22 3351614 Screw, Gearcase
Cover, Mounting (8)
(10−24 x 3/8)
23 3362552 Ring, Retaining
24 285735 Washer Kit,
Thrust
25 62570 Gear, Spin
26 388253 Neutral Assembly
27 3349296 Rack, Connecting
28 62621 Actuator, Shift
29 388815 Washer,
Intermediate
13
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645

MISCELLANEOUS PARTS
OPTIONAL PARTS (NOT INCLUDED)
14
For Models: LXR7144EQ2, LXR7144EZ2
(Designer White) (Designer Almond)
881645
Illus. Part
No. No. DESCRIPTION
1 3976263 Miscellaneous
Parts Bag
2 3976300 Washer, Inlet
Hose
(1−1/16 x 5/8) (4)
4 3359452 Nut, Lock
(3/8−16)
5 389102 Foot, Front (2)
7 3366912 Clamp, Hose
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72107 Almond
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
350956 Almond
PAINT, BULK (1 qt.)
799344 White (Uncut)
978883 Almond (Uncut)
OIL
350572 Oil, Gearcase
(16 Oz.)
LUBRICANT
285208 Lubricant (Use
Only in Brake
Shoe Assembly
On Roller and
Pin)
SEALER
285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
SHIPPING KIT
3348675 Shipping Kit
ACCESSORY PARTS
63580 Fabric Dispenser
367031 Drain Protector
285320 Siphon Break Kit
