134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 1 of 24
Drive Assembly
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 2 of 24
Drive Assembly
Ref # Part Number Qty DescriptionS/P/F
1 717-0983 Electric Clutch1 S
2 710-3008 Hex Bolt 5/16-18 x 3/4" Lg. (Gr. 5)1 /P
3 736-0242 Bell-Wash. .345" I.D. x .88" O.D.1 /P
4 731-1053B Index Bracket1 S
5 710-0924 Pan Hd. Mach. Scr. 1/4-20 x .75" Lg.1 /P
6 710-0599 Hex Wash. Hd. TT-Tap Scr. 1/4-20 x .5" Lg.1 /P
7 712-0138 Hex Nut 1/4-28 Thd.1 S
8 736-0329 L-Wash. 1/4" I.D.1 S/F
?9 750-0777 Shld. Spacer .38" I.D.1
10 710-0412 Hex Bolt 1/4-28 x .75" Lg.1 /P
11 683-0065 Lower Frame Ass'y.1 S
12 710-1035 Hex Tap Scr. 3/8-16 Thd.1 /P
13 736-0247 Fl-Wash. .406" I.D. x 1.25"1 /P
14 725-1426 Solenoid1 S
15 736-0222 Ext. L-Wash. 1/4" I.D.1 S
16 17358D Belt Guard Brkt. Ass'y. Code: N notates a
new part (not previously existing).
1 S
17 714-0128 Sq. Key 1/4" x 1" Lg.1 /P
18 756-0576 Engine Pulley1
19 17418 Torque Brkt.1 S
20 738-0785 Shld. Spacer .445" I.D.1 S
21 736-0171 L-Wash. 7/16" I.D.1 S/F
22 710-1067 Hex Bolt 7/16-2O x .5" Lg.1 /P
23 735-0196 Foot Pad1 S
24 683-0049 Brake Lockout Brkt. Ass'y.1 S
25 783-0091A Foot Pedal Brkt. Code: N notates a new part
(not previously existing).
1
26 732-0728 Foot Pedal Return Spring1
27 738-0296 Shld. Bolt .437" Dia. x .268"1 S
28 736-0406 Fl-Wash. 7/16" I.D. x 1-3/8" O.D.1 S
29 747-0608 Lock-up Rod Code: N notates a new part (not
previously existing).
1 S
30 17755A Bracket1
31 736-0119 L-Wash. 5/16" I.D.1 S/F
32 712-0267 Hex Nut 5/16-18 Thd.1 S/F
33 720-0166 Ball Knob1 /P
34 732-0727 Neutral Return Spring1 S
35 712-0273 Hex Nut 5/16-24 Thd.1 S
36 736-3078 Fl-Wash. .344" I.D. x 1" O.D.1 /P
37 783-0092 Scissor-Flat1
38 736-0362 Fl-Wash. .33" I.D. x 1.25" O.D.1 /P
39 750-0808 Spacer1 /P
40 736-0219 Bell-Wash. .4" I.D. x 1.13" O.D.1 S
41 761-0196 Friction Washer1 S
42 750-0918 Centering Gauge Spacer1
43 783-0095 Neutral Return Mtg. Brkt.1
44 736-0270 Bell-Wash. .265" I.D. x .75" O.D.1 /P
45 732-0718 Comp. Spring 1.19" Lg.1
46 736-3008 Fl-Wash. .312" I.D. x .75" O.D.1 S
47 712-0123 Hex Nut 5/16-24 Thd.1 /P
48 710-0299 Hex Bolt 1/4-28 x 1" Lg. (Gr. 5)1
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 3 of 24
Drive Assembly
Ref # Part Number Qty DescriptionS/P/F
49 710-1012 Rib Neck Bolt 5/16-24 x .84" Lg.1 /P
50 783-0093 Scissor-Offset1
51 747-0887 Neutral Return Rod1
52 738-0879 Friction Disc Stud1 S
53 748-0368 Shld. Spacer1
54 783-0096 Neutral Return Lever1
55 736-3092 Fl-Wash. .265" I.D. x 1" O.D.1 /P
56 736-0329 L-Wash. 1/4" I.D.1 S/F
57 712-0287 Hex Nut 1/4-20 Thd.1 S/F
58 714-0104 Hairpin Clip1 S
59 736-0262 Fl-Wash. .375" I.D. x .87" O.D.1 /P
60 736-0413 Spring Wash. .39" I.D.1 /P
61 712-0116 Hex L-Nut 3/8-24 Thd.1 S
62 712-0711 Hex Jam Nut 3/8-24 Thd.1 /P
63 783-0097 Neutral Return Brkt.1
64 711-0832 Ferrule 3/8-24 Thd.1 S
65 747-0365 Control Rod1 S
66 723-0351 Ball Joint 3/8-24 Thd.1 S
67 748-0234 Shld. Spacer .5" Dia. x .27" Lg.1 /P
68 736-0159 Fl-Wash. .349" I.D. x .879" O.D.1 S
69 710-3007 Hex Wash. Hd. Tap Scr. #12 x 3/8" Lg.1 /P
70 731-1449 Fan1 S
71 712-0333 Hex Nut 1/2-20 Thd.1 S
72 736-0921 L-Wash. 1/2" I.D.1 S/F
73 712-0241 Hex Nut 3/8-24 Thd.1 /P
74 736-0169 L-Wash. 3/8" I.D.1 S
75 756-0975 Transmission Pulley1
76 732-0729 Wire Ring1 /P
77 754-0441 "V" - Belt1 S
78 756-0981 Fl-Idler Pulley 2.75" O.D.1 S
79 720-0238 Rod End Grip1
80 747-0894 Bypass Control Lever1
81 783-0085 Transaxle Support Brkt. - L.H.1 S
82 710-0528 Hex . Bolt 5/16-18 x 1.25" Lg.1 /P
83 732-0384 Ext. Spring 6.121 S
84 683-0048 Idler Brkt. Ass'y.1
85 710-0116 Hex Bolt 5/16-18 x 2.5" Lg.1 S/F
86 710-0118 Hex Bolt 5/16-18 x .75" Lg.1 S/F
87 748-0234 Shld. Spacer .5" Dia. x .27" Lg.1 /P
88 783-0086A Transaxle Support Brkt. - R.H. Code: N
notates a new part (not previously existing).
1 S
89 747-0886 Brake Rod 24.94" Lg.1
90 732-0716 Ext. Spring1 S
91 747-0893 Bypass Actuator Rod1
92 736-0142 Fl-Wash. .281" I.D. x .5" O.D.1 S
93 783-0098 Bypass Adjustment Brkt.1
94 736-0222 External L-Wash. 1/4" I.D.1 S
95 731-1086A Sleeve .758" I.D. x 1" O.D.1 /P
96 710-0604 Hex . Wash. TT-Tap Scr. 5/16-18 x .62" Lg.1 S
97 17994 Retainer Brkt.-Transaxle1 S
98 710-1266 Hex Bolt 5/16-18 x 3.5" Lg.1 /P
99 732-0250 Tension Spring1 S
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 4 of 24
Drive Assembly
Ref # Part Number Qty DescriptionS/P/F
100 710-0888 Hex Bolt 5/16-24 x 1" Lg. (Special)1 /P
101 710-0224 Hex Wash. Hd. AB-Tap Scr. #10 x .5" Lg.1 S
103 712-3019 Hex Nut 7/16-14 Thd. (Gr. 5)1 S
104 736-3015 Fl-Wash. .469" I.D. x .875" O.D.1 S
105 736-0439 Bell-Wash. .46" I.D. x 1.13" O.D.1
106 710-0505 Hex Bolt 7/16-14 x 1" Lg.1 /P
107 647-0008A Speed Control Lever Ass'y. Code: N notates
a new part (not previously existing).
1 /P
108 17668 Axle Support Brkt. - R.H.1 S
17669 Axle Support Brkt. - L.H. Not shown1 S
109 732-0433 Ext. Spring 2.75" Lg.1
110 736-0141 Spr-Wash. .445" I.D. x .75" O.D.1 S
111 17840 Transaxle Mtg. Brkt.1 S
112 725-1657 Safety Switch (Clutch) Code: N notates a
new part (not previously existing).
1 S
115 710-0650 Hex Wash. TT-Tap Scr. 5/16-18 x .75" La.1 /P
116 17715B Clutch/Brake Pedal Ass'y.1
117 750-0802 Spacer .63" I.D.1
118 17860 Pedal Bracket1 S
119 736-0264 Fl-Wash. .344" I.D. x .62" O.D.1 S
120 714-0111 Cotter Pin 3/32" Dia.1 S
121 714-0470 Cotter Pin 1/8" Dia.1 S
122 736-0256 Fl-Wash. .64" I.D. x .94" O.D.1 S
123 710-0227 Hex Wash. Hd. AB-Tap Scr. #8 x .5" Lg.1 /P
124 726-0320 Insulator Nut Plate1 S
125 725-1643 Reverse Safety Switch1
126 725-1399 Extension Wire1
127 710-0344 Hex Bolt 3/8-16 x 1.5" Lg.1 /P
128 756-0116 Idler Pulley1 S
130 712-0798 Hex Nut 3/8-16 Thd.1 /P
131 720-0218 Shift Knob1 /P
132 783-0014 Hitch Plate Extension1
133 783-0099 Idler Brkt.1
134 731-1480 Plastic Vent1 /P
135 726-0324 Clamp1 S
136 721-0330 "O" - Ring1
137 731-1485 Hose Fitting1
138 751-0588-18 Fuel Line 18" Lg.1
139 710-0627 Hex Bolt 5/16-24 x .75" Lg.1 /P
140 736-0242 Bell-Wash. .345" I.D. x .88" O.D.1 /P
141 734-0255 Air Valve1 S
142 634-0070 Rim Only1 /P
143 734-1675 Wheel Ass'y. Comp.1
734-1596 Tire Only1
144 734-1784 Hub Cap1 S
145 727-0425A Spring Clip1 S
146 731-1481 Vent Cap1
147 750-0258 Spacer .315" I.D. x .75" O.D.1 /P
148 710-3195 Hex Bolt 5/16-18 x 4.5" Lg.1
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 5 of 24
Electrical System
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 6 of 24
Electrical System
Ref # Part Number Qty DescriptionS/P/F
1 725-1635 Battery1 S
2 725-1426 Solenoid1 S
3 725-1381 Fuse 20 Amps1 S
4 725-0634 Light Switch1 S
5 725-0925 Ammeter1 S
6 725-1396 Ignition Switch1 S
7 725-1657 Safety Switch1 S
9 629-0206 Wire Harness1
12 725-1643 Safety Switch (Reverse)1
13 725-1649 Socket1 S
14 725-0963 Bulb (Headlight)1 S
15 725-1303 Safety Switch (Seat)1 S
16 725-0980 Ground Wire 7.5" Lg.1
17 725-1439 Safety Switch (Seat)1
19 629-0130 Harness Adapter Code: N notates a new part
(not previously existing).
1
20 629-0133 Monitor Harness Code: N notates a new part
(not previously existing).
1
21 725-1365 Monitor Bulb1 S
22 725-1648 Relay1 S
23 725-0893 Safety Switch (PTO)1 S
24 725-1380 Taillight Harness1
25 725-3018 Taillight1
26 725-3020 Taillight Bulb1 S
27 629-0134 Taillight Adaptor Harness1
28 751-0537 Oil Pressure Switch1
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 7 of 24
Engine Assembly
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 8 of 24
Engine Assembly
Ref # Part Number Qty DescriptionS/P/F
1 726-3009 Clamp1
2 727-0434 Hydraulic Hose 13" Lg.1
3 16877 Front Heat Shield Ext.1
4 712-0147 Speed Nut #10-24 Thd.1 /P
5 710-0429 Hex B-Tap Ser. #10 x .38" Lg.1 S
6 16876A Front Heat Shield1
7 710-0599 Hex Wash. Hd. TT-Tap Scr. 1/4-20 x .5" Lg.1 /P
8 16874 Muffler Heat Shield Code: N notates a new
part (not previously existing).
1
9 751-0469A Muffler Ass'y. Comp.1
10 Engine1
11 726-0240 Cable Tie1 S
12 726-0268 Cable Clip1
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 9 of 24
Hood Assembly
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 10 of 24
Hood Assembly
Ref # Part Number Qty DescriptionS/P/F
1 731-1429 Hood1 S
2 710-0896 Hex Wash. B-Tap Scr. 1/4 x .62" Lg.1 /P
3 726-0233 Bolt Retainer 1/4" I.D.1 /P
4 17782 Retainer Clip1
5 736-3078 Fl-Wash. .34" I.D. x 1"1 /P
6 710-0351 Truss Mach. B-Tap Scr. #10 x .5" Lg.1 /P
8 16903A Hood Plate1 S
11 746-3021 Choke Control (134A606F190)1
746-0614A Choke Control (134T696H190)1 /P
12 712-3014 Hex Nut 1/2-27 Thd. For model
134T696H190 only
1
13 725-0893 Toggle Switch For model 134T696H190 only1 S
14 16902A Hood Hinge Code: N notates a new part (not
previously existing).
1
15 725-0963 Lamp1 S
16 725-1649 Twist Lock - Lamp Socket1 S
17 777-8516 Reflector - Headlight1
18 710-0227 Hex Wash. Hd. AB-Tap Scr. #8 x .5" Lg.1 /P
20 710-0118 Hex Bolt 5/16-18 x .75" Lg.1 S/F
21 731-1430 Grille1 S
22 17300D Dash Support Bracket1
23 723-0416 Screen1
24 712-0267 Hex Nut 5/16-18 Thd.1 S/F
25 736-0176 Fl-Wash. 1/4" I.D. x .93" O.D.1 S
26 710-0603 Hex Wash. Hd. B-Tap Scr. 5/16-18 x .5" Lg.1 /P
?27 710-0429 Hex B-Tap Scr. #10 x .38" Lg.1 S
28 736-0267 Fl-Wash. 3/8" I.D. x .875" O.D.1 S
29 711-1002 Adj. Ferrule 3/8-8 Thd. Code: N notates a
new part (not previously existing).
1
?33 736-0242 Bell-Wash. .345" I.D. x .88"1 /P
32 UNKNOWN1
34 714-0101 Hairpin Clip1 S
35 716-0125 "E" - Ring .375" Dia.1 S
36 712-0287 Hex Nut 1/4-20 Thd.1 S/F
37 736-0270 Bell-Wash. .265" I.D. x .75"1 /P
38 747-0898 Adjustment Rod Code: N notates a new part
(not previously existing).
1
39 712-0449 Hex Nut 3/8-8 Twin Thd. Code: N notates a
new part (not previously existing).
1
40 710-3015 Hex Bolt 1/4-20 x .75" Lg. Code: N notates a
new part (not previously existing).
1 /P
41 720-0236 Plastic Knob1 S
42 732-0732 Ext. Spring 3.21" Lg.1
43 17324B Rear Fender1
44 750-0755 Spacer .33" I.D. x .625" O.D.1
45 710-0167 Carriage Bolt 1/4-20 x .50" Lg.1 /P/F
46 736-0278 Fl-Wash. .328" I.D. x .68" O.D.1
47 710-0599 Hex Wash. Hd. Scr. 1/4-20 x .5" Lg.1 /P
48 727-0460 Indicator Strip1 S
49 783-0120 Indicator Bracket1 S
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 11 of 24
Hood Assembly
Ref # Part Number Qty DescriptionS/P/F
50 736-0119 L-Wash. 5/16" I.D.1 S
52 750-0754 Shld. Spacer .33" I.D.1
53 736-0142 Fl-Wash. .281" I.D. x .5" O.D.1 S
54 712-0158 Hex Cent. L-Nut 5/16-18 Thd.1 S
55 731-1432A Side Cover - R.H. Code: N notates a new
part (not previously existing).
1 S
731-1431A Side Cover - L.H. Code: N notates a new part
(not previously existing).
1
56 710-1034 Double Ended Stud 1/4-20 Thd.1
59 831-0823A Throttle Control Box Ass'y.1 /P
60 746-0905 Throttle Control Wire 22" Lg. (134A606F190)1
746-0634 Throttle Control Wire 35" Lg. (134T696H190)1 S
61 710-0258 Hex Bolt 1/4-20 x .62" Lg.1 S/F
62 736-0173 Fl-Wash. .281" I.D. x .73" O.D.1 /P
63 725-1341B Ignition Key1 /P
64 725-1396 Ignition Switch1 S
65 731-1510 Dash Panel Code: N notates a new part (not
previously existing).
1 S
66 725-0634 Light Switch1 S
67 725-0925 Ammeter1 S
68 731-1038 Lens1 S
69 725-1347 Ignition Switch Cap1 /P
71 725-3018 Taillight For model 134T696H190 only1
73 725-1346 Ignition Switch Nut1 S
74 710-0779A Truss Mach. AB-Tap Scr. #10 x .5" Lg.1 /P
75 710-0936 Truss Hd. AB-Tap Scr. #6 x .62" Lg. For
model 134T696H190 only
1
77 710-0642 Hex Wash. Hd. Tap Scr. 1/4 x .75" Lg.1 /P
80 712-0291 Hex L-Nut 1/4-20 Thd.1 S
?94 712-0147 Speed Nut #10-24 Thd.1 /P
103 17633A Gasoline Tank Support1 S
105 710-0599 Hex Tap Scr. 1/4-20 x .5" Lg.1 /P
111 712-0185 Speed Nut 1/4-20 Thd.1
113 710-0176 Hex Bolt 5/16-18 x 2.75"1 /P
114 730-3000 Reflector (134A606F190)1 S
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 12 of 24
Linkage
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 13 of 24
Linkage
Ref # Part Number Qty DescriptionS/P/F
1 783-0103 Connecting Rod1 S
2 683-0029 Pivot Link Ass'y. - L.H.1 S
3 683-0028 Pivot Link Ass'y. - R.H.1
4 17710 Deck Hanger Link Ass'y.1 S
5 14800A Deck Hanger Link Ass'y.1 S
6 14804A Deck Hanger Link Ass'y.1
7 748-0331 Shld. Spacer .318" I.D.1 S
8 736-0264 Fl-Wash. .344" I.D. x .62" O.D.1 S
9 736-0119 L-Wash. 5/16" I.D.1 S/F
10 712-0267 Hex Nut 5/16-18 Thd.1 S/F
12 714-0470 Cotter Pin 1/8" Dia.1 S
13 736-0256 Fl-Wash. .635" I.D. x 1.0" O.D.1 S
16 710-0604 Hex Wash. TT-Tap Scr. 5/16-18 x .75" Lg.1 S
18 710-1238 Hex Wash. Hd. Scr. 5/16-18 x .875" Lg.1 /P
19 710-0118 Hex Bolt 5/16-18 x .75" Lg.1 S
20 783-0118 Index Brkt.1 F
783-0185 Index Brkt.1 F
21 783-0042 Upper Frame - R.H.1 S
23 736-0267 Fl-Wash. .385" I.D. x .87" O.D.1 S
24 736-0160 Fl-Wash. .531" I.D. x .93" O.D.1 S
25 726-0272 Clamp1 /P
26 738-0526 Running Board Rod1
27 710-3007 Hex Wash. Hd. Tap Scr.1 /P/F
28 14802A Link Deck Lift Ass'y.1 S
29 711-0723A Adj. Ferrule 3/8-24 Thd.1 S/F
30 17712 Adj. Deck Lift Link1 S
31 712-3066 Hex Nut 1/2-20 Thd. (Gr. 5)1 S
32 711-0841 Lift Link Adjuster1 S
33 683-0059 Lift Shaft Ass'y.1 S
34 725-1657 Safety Switch (Deck)1 S/F
35 714-0145 Inter. Cotter Pin 3/8" Dia.1 S
36 732-0637 Extension Spring1 S
37 17636B Stabilizer Bracket1 S
38 738-0670 Shaft 1/2" Dia. x 10.28" Lg.1 S
39 732-0638 Extension Spring1
40 720-0233 Grip (Lift Handle)1 S
41 17675 Deck Lift Handle Ass'y.1 S
42 738-0669 Shaft 3/8" Dia. x 9.34" Lg.1
43 747-0598 Disengagement Rod1 F
44 17624 Stabilizer Shaft Ass'y.1 S
45 732-0556 Extension Spring 7.58" Lg.1 S
46 783-0043 Upper Frame - L.H.1 /P
47 741-0313 Flange Brg. .632" I.D.1 S
48 17128 Spring Retainer Brkt.1 S
49 716-0104 "E" - Ring1 S
50 736-0425 Bell-Wash. .325" I.D.1 S
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 14 of 24
Mowing Deck
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 15 of 24
Mowing Deck
Ref # Part Number Qty DescriptionS/P/F
1 618-0111 Blade Spindle Ass'y.1 S
2 683-0046B 46" Deck Ass'y.1
813-06413 46" Deck Ass'y. Comp. (For Service)1
3 710-0298 Hex Bolt 5/8-18 x 3.5" Lg.1
4 710-0428 Hex Bolt 1/4-28 x 1.25" Lg.1
5 710-0459 Hex Bolt 3/8-24 x 1.5" Lg.1 S
6 710-0152 Hex Bolt 3/8-24 x 1" Lg.1 S
8 710-0599 Hex Wash. Hd. TT-Tap Scr. 1/4-20 x .5" Lg.1 /P
9 710-0151 Hex Bolt 3/8-24 x 2" Lg.1 /P
10 710-1260 Hex Flange Bolt 5/16-24 x .75" Lg.1 S
11 710-1262 Hex Patch L-Bolt 7/16-20 x 1" Lg.1 /P
12 711-0993 Belt Guard Pin1 S
13 712-0138 Hex Nut 1/4-28 Thd.1 S
14 712-0273 Hex Ins. L-Nut 5/16-24 Thd.1 S
15 712-0241 Hex Nut 3/8-24 Thd.1 /P
16 712-0287 Hex Nut 1/4-20 Thd.1 S
17 712-0181 Hex Top Jam Nut 3/8-16 Thd.1 S
18 712-3068 Hex Patch L-Nut 5/16-18 Thd.1 S
19 716-3020 Int. Snap Ring1 S
20 732-0594A Ext. Spring .88" O.D. x 6.17"1 S
21 732-0723 Ext. Spring .788" O.D. x 15.5"1
22 734-0973 Deck Wheel1 /P
23 736-0290 Fl-Wash. .635" I.D. x 1" O.D. x .06"1 /P
24 736-0329 L-Wash. 1/4" I.D.1 S/F
25 736-0331 Bell-Wash. 3/8" x 1.125" x .062"1 /P
26 736-0105 Bell-Wash. 3/8" x .87" x .064"1 /P
27 736-0510 Bell-Washer1 S
28 738-0347 Shoulder Spacer .625" I.D. x .169"1 S
29 738-0373 Shld. Bolt .498" x 1.525"1 S
30 741-0524 Ball Brg. .625" I.D. x 1.574" O.D. x .47"1 S
31 742-0543 High Lift Blade 14.88" Lg.1 S
32 742-0542 High Lift Blade 16.28" Lg.1 S
33 748-0234 Shoulder Spacer1 /P
34 750-0932 Spacer .635" I.D. x .088" O.D.1 S
36 754-0440 V-Belt1 S
37 754-0439 V-Belt1 S
38 756-0638 Pulley Double Deck 5" O.D.1
39 756-0627 Flat Idler Pulley 3.5 O.D.1 S
40 783-0046 Idler Deck Bracket1 S
41 783-0063 Belt Cover L.H.1 S
42 17116 Deck Brake Brkt. Ass'y.1 S
43 17258A Belt Cover Brkt. R.H.1 S
44 710-0258 Hex Bolt 1/4-20 x .62" Lg.1 S
45 711-0792 Hinge Pin1 S
46 736-0270 Bell-Wash. 1/4" I.D.1 /P
47 732-0602 Torsion Spring1 S
48 703-1693 Hinge Mtg. Brkt.1 S
49 726-0106 Push Nut1 S
50 731-1032 Chute Ass'y. Comp. Includes items 45, 47,
48, 49 & 50
1 S
51 750-0960 Spacer .635" I.D. x 1" O.D.1 S
52 736-0158 L-Wash. 5/8" I.D.1 S
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 16 of 24
Mowing Deck
Ref # Part Number Qty DescriptionS/P/F
53 712-0337 Hex Nut 5/8-18 Thd.1
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 17 of 24
Steering Assembly
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 18 of 24
Steering Assembly
Ref # Part Number Qty DescriptionS/P/F
1 731-1509 Steering Wheel Cap Code: N notates a new
part (not previously existing).
1 S
2 712-0411 Hex L-Nut 5/16-24 Thd.1 S
3 736-0242 Belleville Wash. .345" I.D.1 /P
4 631-0019 Steering Wheel Code: N notates a new part
(not previously existing).
1
5 731-0954 Steering Bellow - 9"1 S
6 737-0280 Grease Fitting1 S
9 17198A Retainer Plate1 S
10 738-0141 Shoulder Bolt .437" Dia. x .35" Lg. - 5/16-18
Thd.
1 S
11 710-0152 Hex Bolt 3/8-24 x 1.0" Lg. (Grade 5)1 S
13 750-0535 Spaeer .380" I.D. x .625" O.D. x .2271 S
14 736-0217 L-Wash. 3/8" I.D. (H.D.)1 S
15 710-0726 Hex Wash. Hd. Self-Tap Scr.1 /P
16 711-1001 Steering Drag Link1 S
17 783-0041 Pivot Bar Brkt.1 S
18 738-0527 Shoulder Bolt .498" Dia. x 2.04" Lg. - 3/8-16
Thd.
1 S
19 712-0798 Hex Nut 3/8-16 Thd.1 /P/F
20 736-0169 L-Wash. 3/8" I.D.1 S/F
21 712-0411 Hex L-Nut 5/16-24 Thd.1 S
22 683-0055 Steering Arm Front Axle1 S
23 710-0772 Hex Bolt 5/16-24 x 2.00" Lg. (Grade 5)1 /P
24 741-0487A Hex Flg. Brg. .632 I.D.1 S
25 683-0002 Pivot Bar Ass'y.1 S
26 17585 Front Axle Ass'y. - L.H. (134A606F190)1 /P
683-0041 Front Axle Ass'y. - L.H. (134T7696H190)1 S
27 712-0241 Hex Nut 3/8-24 Thd.1 /P/F
28 736-0169 L-Wash. 3/8" I.D.1 S/F
29 723-3018 Ball Joint 3/8-24 Thd.1 S
30 747-0753 Tie Rod1
31 712-0711 Hex Jam Nut 3/8-24 Thd.1 /P/F
32 17584 Front Axle Ass'y. - R.H. (134A606F190)1 /P
683-0040 Front Axle Ass'y. - R.H. (134T696H190)1 /P
33 634-0059 Wheel Ass'y. Comp.1
734-0864 Tire Only1 /P
734-0255 Air Valve1 S
34 634-0051A Front Wheel Rim Only1 S
35 741-0569 Bearing1 S
36 736-0285 Fl-Wash. .635" I.D. x 1.59" O.D.1 /P
37 734-1783 Front Wheel Hub Cap1
38 714-0470 Cotter Pin 1/8" Dia. x 1.25"1 S/F
39 736-0187 Fl-Wash. .640" I.D. x 1.24" O.D.1 /P
40 726-0214 Push Cap 5/8" Dia. Rod1 /P
42 712-0446 Hex Jam Nut 3/8-24 Thd.1 S
43 710-0538 Hex L-Bolt 5/16-18 x .62"1 /P/F
44 736-0119 L-Wash. 5/16" I.D.1 S/F
45 736-0343 Fl-Wash. .33" I.D. x 1.25" O.D.1 /P
46 750-0532 Spacer (Plastic)1 S
47 712-0214 Hex Cent. L-Nut 3/8-24 Thd.1 S
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 19 of 24
Steering Assembly
Ref # Part Number Qty DescriptionS/P/F
48 736-0169 L-Wash. 3/8" I.D.1 S/F
49 712-0158 Hex Cent. L-Nut 5/16-18 Thd.1 S
50 736-0119 L-Wash. 5/16" I.D.1 S/F
51 717-0622A Steering Gear Segment1 S
52 741-0225 Hex . Flg. Brg. .634 I.D.1 S
53 736-0187 Fl-Wash. (Hardened)1 /P
54 738-0743 Steering Shaft (134A606F190)1 /P
58 736-0271 Wave-Wash. .32" I.D. x .62" O.D.1 S
59 736-0187 Fl-Wash. (Hardened)1 /P
60 723-3018 Drag Link Ball Joint 3/8-24 Thd.1 S
61 736-0607 Ext. L-Wash. 5/16" I.D.1 /P
63 727-0425A Spring Clip1 S
64 736-0356 Bell-Wash. .39" I.D. x 1.38" O.D.1 S
65 731-1291 Pivot Bar End Cap1 S
67 737-0280 Grease Fitting1 S
72 738-0886 Upper Steering Shaft (134T696H190)1
73 650-0001 Lower Steering Shaft (134T696H190)1 S
74 710-0958 Hex Bolt 1/4-20 x 1.25" Lg.1 /P
75 712-0324 Hex L-Nut 1/4-20 Thd.1 /P 36" Single Stage Snow Thrower Optional
Equipment. For model 190-491-000
1
42" Dozer Blade Optional Equipment. For
model 190-485-000
1
Mulching Kit for 38" Deck Optional
Equipment. For model 190-096-000
1
Twin Bag Grass Collector for 38" Deck
Optional Equipment. For model 190-063-000
1
Front Counterweight Optional Equipment. For
model 190-745-000
1
Tire Chains - 20 x 8 Optional Equipment. For
model 190-658-000
1
31 Lb. Wheel Weights Optional Equipment.
For model 190-215-000
1
Gang Reel (Set of three) Optional
Equipment. For model 45-0195
1 F
38" Lawn Sweeper Optional Equipment. For
model 45-0222
1 F
Heavy Duty Lawn Roller Optional Equipment.
For model 45-0179
1 F
Heavy Duty Dump Cart Optional Equipment.
For model 45-0171
1 F
Tine De-Thatcher Optional Equipment. For
model 45-0186
1 F
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983

134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 20 of 24
Transmission
www.mymowerparts.com
For Discount White Outdoor Parts Call 606-678-9623 or 606-561-4983
