WIL-RICH QX2 User manual

03-2020 | 74377
July 2015
QX2 5 Section Field Cultivators
Assembly Instructions

AGCO-Amity JV LLC LIMITED WARRANTY TERMS AND CONDITIONS –UNITED STATES AND CANADA
EFFECTIVE FOR EQUIPMENT RETAILED AND DELIVERED AFTER JANUARY 1, 2020
WHAT IS WARRANTED AGCO Amity JV warrants its new equipment to be free of defects in material and workmanship at time of delivery to the first retail
purchaser, renter, or lessee. These terms apply to all 10K, Amity, Concord, Wil-Rich and Wishek brands of new equipment originally marketed in the United
States and Canada.
WARRANTY PERIOD
•12 Months from the date of delivery to the first retail purchaser, renter or lessee.
•483 Disk Chisel, Field Cultivator and Disk Cultivators: 3 years on main frames, wing frames, and shank assemblies
•Precision Shank Drill: 3 years on main frame, wing frame, and rockshafts.
EXCEPTIONS FROM THIS WARRANTY
•Freight Charges - This warranty does not cover freight charges.
•Improvements, Changes, or Discontinuance AGCO Amity JV reserves the right to make changes and improvements in design or changes in
specifications at any time to any product without incurring any obligations to owners of products previously sold.
•Repairs and Maintenance Not Covered Under Warranty - This warranty does not cover conditions resulting from misuse, natural calamities,
use of non-AGCO-Amity JV parts, negligence, alteration, accident, use of unapproved attachments, usage which is contrary to the intended
purposes, or conditions caused by failure to perform required maintenance. Replacement of Wear or Maintenance items (unless defective) such
as but not limited to, filters, hoses, belts, lubricants, light bulbs, wheel alignment, tightening of nuts, belts, bolts, and fittings, service tune-up,
computer parameter adjustments and general adjustments which may from time to time be required are not covered.
•Rubber Tire Warranty - Rubber tires are warranted directly by the respective manufacturer only and not by AGCO Amity JV.
•Satellite Outages - Interruptions in satellite interfaces and satellite communications are outside the control of this product and are not covered by
this warranty. The company is not responsible for issues or degradation of system performance resulting from such interruptions in satellite
interfaces and satellite communications where the issues are not related to defects in this product.
OWNER’S OBLIGATION
It is the responsibility of the Owner to transport the equipment or parts to the service shop of an authorized AGCO Amity JV Dealer or alternatively to
reimburse the Dealer for any travel or transportation expense involved in fulfilling this warranty. This Warranty does NOT cover rental of replacement
equipment during the repair period, damage to products which have been declared a total loss and subsequently salvaged, overtime labor charges, freight
charges for replacement parts, or special handling requirements (such as, but not limited to, the use of cranes).
EXCLUSIVE EFFECT OF WARRANTY AND LIMITATION OF LIABILITY
THIS WARRANTY IS IN LIEU OF ALL WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PURPOSE OR OTHER REPRESENTATIONS, WARRANTIES
OR CONDITIONS, EXPRESSED OR IMPLIED. The remedies of the Owner set forth herein are exclusive. The Company neither assumes nor authorizes any
person to assume for it any other obligation or liability in connection with the sale of covered machines. Correction of defects, in the manner and for applicable
period of time provided above, shall constitute fulfillment of all responsibilities of AGCO Amity JV to the Owner, and AGCO Amity JV shall not be liable for
negligence under contract or in any manner with respect to such machines. IN NO EVENT SHALL THE OWNER BE ENTITLED TO RECOVER FOR INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES SUCH AS BUT NOT LIMITED TO, LOSS OF CROPS, LOSS OF PROFITS OR REVENUE, OTHER COMMERCIAL
LOSSES, INCONVENIENCE OR COST OF RENTAL OR REPLACEMENT EQUIPMENT.
Some States or Provinces do not permit limitations or exclusions of implied warranties or incidental or consequential damages, so the limitations or exclusions in this warranty may
not apply.
“AGCO Amity JV” AS REFERRED TO HEREIN WITH RESPECT TO SALES IN: UNITED STATES and CANADA: AGCO Amity JV LLC
PO Box 1030
Wahpeton, ND 58074
Additional Warranty Information
New Equipment Warranty - Equipment is eligible for warranty service only if it qualifies under the provisions of the New Equipment Warranty. The selling
dealer will deliver this Warranty to the original retail purchaser at the time of sale, and the dealer will register the sale and Warranty with AGCO Amity JV
LLC.
Subsequent Owners - This Warranty covers the first retail purchaser and all subsequent owners of the equipment during the specified warranty period.
Should the AGCO Amity JV Dealer sell this equipment to a subsequent owner, the Dealer must deliver the warranty document to the subsequent owner so the
subsequent owner can register ownership with AGCO Amity JV and obtain the remaining warranty benefits, if available, with no intermission in the Warranty
Period. Subsequent Owner Procedure will apply. It is the responsibility of the subsequent owner to transport the equipment to the service shop of an
authorized AGCO Amity JV Dealer or alternatively to reimburse the Dealer for any travel or transportation expense involved in fulfilling this warranty. This
Warranty does NOT cover charges for rental or replacement equipment during the repair period, products which have been declared a total loss and
subsequently salvaged, overtime labor charges, freight charges for replacement parts, or units sold at auction.
Warranty Service - To be covered by Warranty, service must be performed by an authorized AGCO Amity JV Dealer. It is recommended that you obtain
warranty service from the Dealer who sold you the equipment because of that Dealer’s continued interest in you as a valued customer. In the event this is
not possible, warranty service may be performed by any other authorized AGCO Amity JV Dealers in the United States or Canada. It is the responsibility
of the Owner to transport the equipment to the service shop of an authorized AGCO Amity JV Dealer or alternatively to reimburse the Dealer for any travel or
transportation expense involved in fulfilling this warranty.
Maintenance Service - The Owner’s Manual furnished to you with the equipment at the time of delivery contains important maintenance and service
information. You must read the manual carefully and follow all the maintenance and service recommendations. Doing so will result in greater satisfaction with
your equipment and help avoid service and warranty problems. Please remember that failures due to improper maintenance of your equipment are not covered
by warranty.
Maintenance Inspections - To insure the continued best performance from your agricultural equipment, we recommend that you arrange to make your
equipment available to your selling Dealer for a maintenance inspection 30 days prior to warranty expiration.

1 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Introduction
Safety Alert Symbol
Safety Messages
The words DANGER, WARNING, or CAUTION are used with the safety alert symbol. Learn to recognize these safety
alerts and follow the recommended precautions and safety practices.
Informational Messages
The words important or note are not related to personal safety, but are used to give additional information and tips for
operating or servicing this equipment.
IMPORTANT: Identifies special instructions or procedures which, if not strictly observed, could result in damage
to or destruction of the machine, process, or its surroundings.
NOTE: Identifies points of particular interest for more efficient and convenient repair or operation.
Safety Signs
Keep signs clean by wiping off regularly. Use a cleaning solution if necessary.
If parts have been replaced or a used machine has been purchased, make sure all safety signs are in the correct location
and can be read. Illustrations of safety sign locations are located at the rear of this section.
Replace any safety signs that can not be read or are missing. Clean the machine surface thoroughly with a cleaning
solution before replacing signs. Replacement safety signs are available from a dealer.
This is the safety alert symbol. The safety alert symbol will direct the operator’s attention to information
that involves personal safety and the safety of others.
Indicates an imminently hazardous situation that, if avoided, will result in DEATH OR
VERY SERIOUS INJURY.
Indicates a potentially hazardous situation that, if not avoided, could result in DEATH OR
SERIOUS INJURY.
Indicates a potentially hazardous situation that, if not avoided, may result in MINOR
INJURY.
Do not remove or obscure Danger, Warning, or Caution signs. Replace any Danger,
Warning or Caution signs that are not readable or are missing. Replacement signs are
available from the dealer in the event of loss or damage. The actual location of the safety
signs is illustrated at the end of this section.

74377 | 03-2020 2
QX2 5 SECTION CULTIVATOR
Introduction (Cont’d)
A Word To The Operator
It is the operator’s responsibility to read and understand
the safety section in this manual and the manual for all
attachments before operating this machine.
Study the features in this manual and make them a
working part of a safety program. Keep in mind that this
safety section is written only for this type of machine.
Practice all other usual and customary safe working
precaution. The operator can prevent serious injury and
death.
This safety section is intended to point out some of the
basic safety situations that may be encountered during
the normal operation and maintenance of this machine.
This section also suggests possible ways of dealing with
these situations. This section is not a replacement for
other safety practices feature in other sections of this
manual.
Personal injury or death may result if these precautions
are not followed.
Learn how to operate the machine and how to use the
controls properly.
Do not let anyone operate the machine without
instruction and training.
For personal safety and the safety of others, follow all
safety precautions and instructions found in the manual
and on safety signs affixed to the machine and all
attachments.
Use only approved attachments and equipment
Make sure the machine has the correct equipment
needed by the local regulations.
WR0807
An operator should not use alcohol or drugs which can affect their alertness or
coordination. An operator on prescription or ‘over the counter’ drugs needs medical
advice on whether or not they can properly operate machines.
If any attachments used on this equipment have a separate Operator Manual, see that
manual for other important safety information.

3 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Introduction (Cont’d)
This Manual
Right-hand and left-hand, as used in this manual, are determined by facing the direction the machine will travel when in
use.
The photos, illustrations, and data used in this manual were current at the time of printing, but due to the possible in-line
production changes, your machine can vary slightly in detail. The manufacturer reserves the right to redesign and change
the machine as necessary without modification.
Operation
Prepare For Operation
Read and understand all operating instructions and precautions in this manual before operating or servicing the machine.
Know and understand the positions and operations of all controls. Make certain all controls are in neutral and the parking
brake is applied before starting the machine. Make sure the steering wheel is centered and locked.
Make certain all people are well away from the area of work before starting and operating the machine. Check and learn
all controls in an area clear of people and obstacles before starting work. Be aware of the machine size and have enough
space available to allow for operation. Never operate the machine at high speeds in crowded places.
Emphasize the importance of using correct procedures when working around and operating the machine. Do not let
children or unqualified persons operate the machine. Keep others, especially children, away for the area of work. Do not
permit others to ride on the machine.
Make sure the machine is in the proper operating condition as stated in the Operator’s Manual. Make sure the machine
has the correct equipment required by local regulations.
All equipment has a limit. Understand the speed, brakes, steering, stability and load characteristics of the equipment
before starting.
In some illustrations and photos used in this manual, shields or guards may have been
removed for clarity. Never operate the machine with any shields or guards removed. If
the removal of shields or guards is necessary to make a repair, they must be replaced
before operation.
Any time the engine is running and the parking brake is disengaged, the machine will
turn if the steering wheel is moved even though the travel control lever is in neutral.

74377 | 03-2020 4
QX2 5 SECTION CULTIVATOR
Operation (Cont’d)
Personal Protective Equipment
Wear all personal protective equipment (PPE) and
protective clothing issued or called for by job conditions
and county / local regulations. PPE includes, but is not
limited to, equipment to protect eyes, lungs, ears, head,
hands and feet when operating, servicing or repairing
equipment.
Agricultural Chemicals
Agricultural chemicals can be very hazardous. Improper
use of fertilizer, fungicides, herbicides, insecticides and
pesticides can injure people, plants, animals, soil and
other people’s property.
Always read and follow all manufacturers’ instructions
before opening any chemical container.
Read and follow instructions each time a chemical is
used.
Use the same precautions when adjusting, servicing,
cleaning or storing the machine as used when installing
chemicals into the hoppers or tanks.
Inform anyone who comes in contact with chemicals of
the potential hazards involved and the safety precautions
required.
Stand upwind and away from smoke from a chemical fire.
Store or dispose of all unused chemicals only in a
manner as specified by the chemical manufacturer.
WR0808

5 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Operation (Cont’d)
Traveling On Public Roads
Always walk around and visually inspect the machine before traveling on public roads. As a warning, honk the horn twice
before starting the engine. Check for damage and / or faulty components that can fail and create a hazardous condition.
Make sure all the machine systems operate properly. The following, including, but not limited to: front road lights, tail and
brake lights, hazard warning lights, parking brake, horn, windshield wiper and washer and rear view mirrors. Repair or
replace any component not in proper working order.
Never drive at a speed causing the machine to bounce or lose control.
Obey all traffic rules. Operate the machine with hazard warning lights on, unless prohibited by law. Use of road lights while
traveling on public roads is operator’s responsibility.
Machine was designed for apply chemicals and fertilizers in off-road use. Do not use the
machine for transporting product on public roads. Chemical spills result in
environmental damage. A loaded machine driven on public roads also runs a high risk of
tire failure. Personal injury could result.

74377 | 03-2020 6
QX2 5 SECTION CULTIVATOR
Maintenance
Fire Prevention And First Aid
Be prepared for emergencies.
Keep a first aid kit handy for treatment of minor cuts and
scratches.
Always carry one or more fire extinguishers of the correct
type. Check fire extinguishers regularly as instructed by
the manufacturer. Make sure the fire extinguishers are
properly charged and in operating condition.
Due to the nature of the crops this machine will operate
in, the risk of fire is of concern. Use a water type fire
extinguisher or other water source for a fire in crops.
For fires involving anything other than crops, such as oil
or electrical components, use a dry chemical fire
extinguisher with a ABC rating.
Mount fire extinguishers within easy reach of where fires
can occur.
Frequently remove accumulated crop material from the
machine and check for overheated components. Check
the machine daily for any noises that are not normal.
Such noises could indicate a failed component that can
cause excess heat.
If any flame cutting, welding, or arc welding is to be done
on the machine or attachments, make sure to clear any
crop material or debris from around the area. Make sure
the area below the work area is clear of any flammable
material as falling molten metal or sparks can ignite the
material.
If fire occurs stand upwind and away from the smoke
from the fire.
WR0809
WR0810

7 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Maintenance (Cont’d)
High Pressure Leaks
Fluid leaking from the hydraulic system or the fuel
injection system under high pressure can be very hard to
see. The fluid can go into the skin causing serious injury.
Fluid injected into the skin must be surgically removed
within a few hours. If not removed immediately, serious
infection or reaction can develop. Go immediately to a
doctor who knows about this type of injury.
Use a piece of cardboard or wood to search for possible
leaks. Do not use your bare hand. Wear leather gloves for
hand protection and safety goggles for eye protection.
Relieve all pressure before loosening any hydraulic lines.
Relieve the pressure by lowering raised equipment,
shutting off accumulator valve, if equipped, and shutting
off the engine. Tighten all connections securely before
apply pressure.
WR0811
WR0812

74377 | 03-2020 8
QX2 5 SECTION CULTIVATOR
Maintenance (Cont’d)
Tire Safety
Check the tires for cuts, bulges and the correct pressure.
Replace worn or damaged tires. When tire service is
needed, have a qualified tire mechanic service the tire.
Changing the tire can be very hazardous and must be
done by a qualified tire mechanic using the proper tools
and equipment. See the Specifications Sections for the
correct tire size.
Tire explosion and / or serious injury can result from over
inflation. Do not exceed the tire inflation pressures. See
the Specifications Section for the correct tire pressure.
Do not inflate a tire that is seriously under inflated or has
been run flat. Have the tire checked by a qualified tire
mechanic.
Do not weld on the rim when a tire is installed. Welding
can make an air / gas mixture that can cause an
explosion and burn with high temperatures. This danger
applies to all tires, inflated or deflated. Removing air or
breaking the bead is not enough. The tire must be
completely removed from the rim prior to welding.
When preparing a calcium chloride solution for fluid
ballasting the tractor tires, never pour water onto the
calcium chloride. A chlorine gas can be generated which
is poisonous and explosive. This can be avoided by
slowly adding calcium chloride flakes to water and stirring
until they are dissolved.
When seating tire beads onto the rims, never exceed 2.4
bars (35 psi) or the maximum inflation pressure specified
on the tire. Inflation beyond this maximum pressure may
break the bead, or even the rim, with explosive force.
WR0813

9 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Maintenance (Cont’d)
Replacement Parts
Where replacement parts are necessary for periodic
maintenance and servicing, genuine replacement parts
must be used to restore your equipment to original
specifications.
The manufacturer will not accept responsibility for
installation of unapproved parts and / or accessories and
damages as a result of their usage.
Torque Specifications
WR0513
WR0814
WR0815

74377 | 03-2020 10
QX2 5 SECTION CULTIVATOR
Marker Lamps
The machine is equipped with marker lamps that must be
used when transporting the machine on public roads.
The machine is equipped with two amber lamps (1) (4)
located on the outside edges of the rear wing rest frame.
The machine is equipped with two red lamps (2) (3)
located in the rear center of the machine.
Transport Stops
The machine is equipped with transport stops (1). Use
the transport stops when transporting the machine on
public roads. When not in use, keep the transport stops
on the storage brackets (2) on the main frame of the
machine.
Machines Equipped With A Level Lift Hitch
Install the transport stops (1) on the rods of the lift
cylinders (2) located at the rear of the machine.
WR0816
WR0817
WR0818

11 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Transport Stops (Cont’d)
Machines Equipped With Floating Hitch
Install the transport stops (1) on the rods of the lift
cylinders (2) located at the front of the machine.
WR0819

74377 | 03-2020 12
QX2 5 SECTION CULTIVATOR
Unbundling
STEP 1
While frame is still in shipping configuration, remove the
straps to allow access to the hubs.
STEP 2
Place the tire on the hub using six lug bolts.
Tighten the lug bolts in a star pattern to the torque specs.
103 ft-lbs (140 N•m) for the 8 bolt main frame wheels.
72 ft-lbs (98 N•m) for all other 6 bolt wheels.
NOTE: Tires on the main frame and wings are all
installed the same way.
The tires on the main frame use 63831 9/16 inch NF lug
bolts. The tires on the wings use 88142 1/2 inch NF lug
bolts.
WR0318
WR0195
5
3
6
1
4
2
Please refer to page 9 for torque specs.

13 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Unbundling (Cont’d)
Opening Bundle
STEP 3
Lay bundle down, supporting frame securely
36 to 40 inches off the ground.
WR0508
STEP 4
Unfold front frame and bolt into place using 3/4
inch grade 8 bolts as shown on main frame and
wing assembly pages.
WR0507
Please refer to page 9 for torque specs.

74377 | 03-2020 14
QX2 5 SECTION CULTIVATOR
Unbundling (Cont’d)
Opening Bundle (Cont’d)
STEP 5
After bundle is unfolded and two frame halves are bolted
together remove shipping stands (1) and brackets (2).
After the shipping stands (1) and brackets (2) are
removed the rest of the cultivator may be assembled as
shown in this book.
Lay the frame carefully down on the stands 24 1/2 inches
(62 cm) off the ground.
NOTE: 24 1/2 inches only if the tires were installed in
Steps 1, 2 and 3. If not installed the height will
be 30 - 40 inches (76 - 102 cm) to allow
clearance to install the tires after the frame is
resting on the stands.
WR0509
1
2
Please refer to page 9 for torque specs.

15 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Unbundling (Cont’d)
STEP 6
Cut the bands holding the front part of frame in place.
Loosen up the pivot bolts (1) for the front section of the
main frame.
Unfold the front part of the frame.
STEP 7
Align the flanges (1) on the front section of the frame and
main frame.
STEP 8
Use four 88290 3/4 x 2 inch grade 8 bolts (1), 88130 lock
washers and 88110 nuts to secure the frame flanges
making sure to align bolts front to back.
Use Steps 5 and 6 for all hinge flanges.
Tighten up the pivot bolts (2) that were loosened in Step
4.
WR0193
1
WR0319
1
WR0192
2
1
Please refer to page 9 for torque specs.

74377 | 03-2020 16
QX2 5 SECTION CULTIVATOR
Shank Assembly
Twin Spring Shank Assembly
REF. PART NO. DESCRIPTION
1 240560 TWIN SPRING FC SHK HOLDER ASSY
2 88838 BOLT, HEX: 5/8 - 11NC x 1-3/4 5ZP
3 88129 WASHER, Lock Helical: 5/8 ID (11/16 ACT) ZP
4 55655 HD EDGE FORM CULT SHNK (GRAY)
WR0500
1
2
3
4
Please refer to page 9 for torque specs.

17 74377 | 03-2020
QX2 5 SECTION CULTIVATOR
Shank Assembly (Cont’d)
Single Spring Shank Assembly
REF. PART NO. DESCRIPTION
1 240434 SINGLE SPRING SHK HOLDER ASSY
2 53408 EDGE FORMED SHANK (GRAY)
3 88129 WASHER, Lock Helical: 5/8 ID (11/16 ACT) ZP
4 88577 BOLT, Hex: 5/8 - 11NC x 1-1/2 5ZP
WR0501
1
2
3
4
Please refer to page 9 for torque specs.
