Wildfire WF-CART30-CG-BSS User manual

FOR OUTDOOR USE ONLY
072023_V2
AFFIX SERIAL NUMBER
LABEL HERE
Stainless Steel Cart - Griddle
Instructional Guide
Outdoor Cart
WF-CART30-CG-BSS

When properly cared for, your Wildfire griddle cart will provide safe, reliable service for many years. However,
extreme care must be used since the griddle produces intense heat, which can cause serious injury or even death
if the instructions are not followed carefully. When using this appliance, basic safety practices must be followed as
outlined below.
1. NEVER LEAVE THE GRIDDLE UNATTENDED WHILE COOKING.
2. Children should not be left alone or unattended in an area where the griddle is being used. Never allow them to
sit, stand, or play on or around the griddle. Do not store items of interest to children around or below the griddle
or in the cart. Never allow children to crawl inside of the cart.
3. The griddle and cart shall be used only outdoors and shall not be used in buildings, garages, sheds, breezeways,
or any enclosed areas. Do not operate the griddle under unprotected, combustible construction. Use only in well
ventilated areas.
4. Do not use the griddle unless a leak check has been performed on all gas connections.
5. Portable LP cylinders - Always shut off the main valve on the liquid propane (LP) cylinder after each use. Never
use a dented or rusted LP cylinder. Never attach or disconnect an LP cylinder, or move or alter gas fittings when
the griddle is in operation or is hot.
6. Inspect LP gas supply hose prior to each use of the griddle. The hose must be kept away from heated areas of the
griddle. If there is evidence of excessive abrasion or wear, or the hose is cut, it must be replaced before using the
griddle. The hose and LP regulator are supplied as a complete assembly and must be replaced together. Do not
attempt to repair or replace the hose itself.
7. Keep any electrical supply cord away from the heated areas of the griddle. The cord is provided with a 3-prong
grounding plug which should not be removed or altered. Do not use this appliance with an ungrounded,
2-prong adapter. The cord must be plugged into a properly grounded GFCI-protected outlet.
8. Keep the areas surrounding the griddle free from combustible materials, trash, or combustible fluids and vapors
such as gasoline or charcoal lighter fluid. Do not obstruct the flow of combustion gases (rear) and ventilation
airways (front). Keep the rear area free and clear of debris, extra LP cylinders, etc. Do not block the ventilation
louvers of the cart.
9. If your griddle is stored indoors, ensure that it is cool before moving. If propane is used, the LP cylinder must be
disconnected and stored OUTSIDE in a well-ventilated area, out of the reach of children. A griddle cover is
recommended, even when stored indoors.
10. Never move the griddle when hot. When in use, portions of the griddle are hot enough to cause severe burns.
11. Do not repair or replace any part of the cart unless specifically recommended in this manual. All other warranty
and non-warranty service should be referred to and performed by a qualified technician.
12. Clean the griddle and cart with caution. Avoid steam burns - do not use a wet sponge or cloth to clean the
griddle or cart while it is hot. Some cleaners produce noxious fumes or can ignite when applied to a hot
surface. Be sure all griddle controls are turned off and the griddle and cart are cool before using any type of
aerosol cleaner on or around the griddle and cart. The chemical that produces the spraying action could, in
the presence of heat, ignite or cause metal parts to corrode. Clean and perform general maintenance on the
griddle and cart twice a year. Watch for corrosion, cracks, or insect activity.
13. Do not overload the side shelves of the cart as this may result in damage to the unit, or personal injury. Do not sit,
step, or push down on the side shelves. The maximum load rating of the side shelf is 25 lbs. (11.3 kg).
Precautions -
Before You Use Your Griddle Cart

Please notice that certain parts of the grill are covered in protective wrapping on stainless
steel surface. It is a protective plastic coating. We put it on certain parts of the stainless
steel to help protect them from getting scratched during shipping.
the protective coating, by waving a hair dryer over the area will loosen up the plastic
and make it easier to remove.
REMOVING PROTECTIVE FILM
Stainless Steel Care and Maintenance (Not for cooking surface)
It is a common misconception that stainless steel will maintain its original factory shine with little help from
the consumer. Unfortunately, this is not true. Stainless steel will not stain, discolor, corrode, or rust as fast
as other types of steel, but it is not fully stain or weather proof. If it is not properly maintained, all grades
of stainless steel can face surface discoloration, corrosion and eventually rust. Any stainless steel that is
exposed to the environment will require attention and care throughout its life to ensure that it keeps its shine
and structural integrity.
Cleaning the Stainless Steel and Polishing (Not for cooking surface)
1. Allow griddle to cool before cleaning/polishing stainless steel. Do not clean or polish your griddleʼs
stainless steel when the griddle is in operation or still hot.
2. To clean the stainless steel, wash off all dirt and debris from the steel with warm water. If you have tough
spots to clean, then a third-party degreaser product can be used.
3. Next, rinse and dry the steel thoroughly with a clean towel. Do not allow the steel to air dry as the
standing water can cause surface discoloration.
4. The last step is to protect the unit with a good third-party polish. There are several third-party polishes
on the market that will help keep your griddle protected from the elements for a longer period of time.
Most of these polishes are toxic, so only use these on the exterior of the griddle. Follow instructions
provided on any third-party polish products. Do not use such products on cooking grates or Flame
Tamers.
a. Apply the polish to a clean paper towel and wipe with the direction of the grain in the stainless
steel.
b. There should be no excess liquid on the surface but it is acceptable for it to be a little oily,
as that will dissipate.
5. If your griddle has developed surface discoloration or surface rust, clean the unit as stated above and
use a good third-party polish to remove or reduce the spots. Follow instructions provided on any third-
party polish products. Wildfire does not insure or guarantee the performance of or results from such
products.
Care & Maintenance

WF-CART30-CG-BSS - Parts List
WF-CART30-CG-BSS
No. Name Qty Part No.
1 Side Shelf 2 02-00910
2 Transformer Holder 1 02-00911
3 Left Bracket 2 02-00912
4 Right Bracket 2 02-00913
5 Cable Holder 4 02-00914
6 Middle Plate 1 02-00915
7 Back Plate 1 02-00916
8 Left Plate 1 02-00917
9 Bottom Plate 1 02-00918
10 Right Plate 1 02-00919
11 Left Bracket for Slide 1 02-00920
12 Right Bracket for Slide 1 02-00921
13 Tank Holder 1 02-00922
14 Slide 2 02-00923
15 Handle for Door & Drawer 3 02-00924
16 Door Panel 1 02-00925
17 Wheels 4 02-00926
18 Door Stopper 1 02-00927
19 Drawer 2 02-00928
20 Left Slide for Drawer 2 02-00929
21 Right Slide for Drawer 2 02-00930
22 Middle Panel 1 02-00931
23 Door Magnet 2 02-00932
For further instructions
check out page “attach
handle(s) to Doors and
Drawers” page.
STEP 1 STEP 2
Attach wheels to cart.
Wheels with brakes
in the front.
Screw (4) M6 screws,
(4) spring washers
and (4) flat washer
for each wheel
Screw M4*30 pan
head screw on each
side of the control
panel
Remove (1) bottom
screw on each side
of control panel
Placel head
in cart.
STEP 3
STEP 4
Attach side
shelves.
Attach door
handles.

1
4
2
3
6
7
5
8
9
11
10
12
13
14
16
17
15
18
19 20 21
22
23
WF-CART30-CG-BSS - Exploded Parts View

Attach Handle(s) to Doors and Drawers
Attach Handle to the Door and Drawer Handles to the Drawers
The door handle and hardware come packaged separately from the rest of the hardware. Two screws hold
handle to the door. Take care as to not scratch the door by laying them on a soft surface. Hint: While on
a soft surface on a work area like a table, hang the door off the edge just to the point where the holes are
exposed for door handle. Place the screw in your screw driver then guide the screw into the hole on the
door. Once in place, move the handle to the screw and get it started a small amount. This gives flexibility
when attaching the second screw. Once both screws are in place, tighten completely.

Limited Lifetime Warranty
TO THE MAXIMUM EXTENT PERMITTED BY LAW, THIS LIMITED LIFETIME WARRANTY AND THE
REMEDIES SET FORTH BELOW ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES,
REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE
MAXIMUM EXTENT PERMITTED BY LAW, WILDFIRE OUTDOOR LIVING ALSO SPECIFICALLY
DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
WILDFIRE OUTDOOR LIVING PRODUCTS LIMITED LIFETIME WARRANTY – Wildfire Outdoor
Living warrants to the original purchaser at the original site of delivery with proof of purchase of
each outdoor gas griddle/side griddle/side burner that when subject to normal residential use, it
is free from defects in workmanship and materials. This warranty excludes griddles used in rental
and commercial applications. This warranty excludes surface corrosion, scratches and discoloration
which may occur during normal use.
It does NOT cover labor or labor related charges. There will be shipping and handling charge for
the delivery of the warranty part(s).
This product has a limited lifetime warranty that starts at date of purchase and continues throughout
the life of the product.
Under this warranty, Wildfire has the option to repair or replace any defective part of the product
during the warranty period. This warranty does not cover normal wear of parts, damage resulting
from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply,
use contrary to operating instructions, or alteration by any person other than a factory service
center. The warranty period is not extended by such repair or replacement.
WARRANTY CLAIM PROCEDURE: If you require service or parts for your Wildfire side griddle,
please contact our Warranty Service Center for factory direct assistance. Our hours of operation
are 8 am to 4:30 pm MST. The phone number is 602-344-4840 and the email address is
[e-mail]. Please have your model number, serial number and
proof of purchase available for any warranty claim.
Wildfire Outdoor Living may require the return of defective parts for examination before issuing
replacement parts. If you are required to return defective parts, shipping charges must be prepaid
by the customer. Upon examination and to Wildfire Outdoor Living determination, if the original
part is proven defective, Wildfire Outdoor Living may approve your claim and elect to replace
such parts without charge. In every instance, the customer is responsible for shipping and handling
of replacement parts. Component repair or replacement is the exclusive remedy under this limited
warranty and Wildfire Outdoor Living shall not be liable for any incidental or consequential
damages.

DO NOT RETURN TO STORE!
STOP
CALL US FIRST
For immediate help with installation, product information or
if your product arrives damaged, please call our toll free number at:
(Monday - Friday, 8:00AM - 5:00PM, AZ Mountain Time)
Or email us at:
OUR STAFF IS READY TO PROVIDE ASSISTANCE
The product images shown are for illustration purposes only and may not be an exact representation of the product.
