Wildpix Pro 1.0 User manual

Instruction MANUAL I Handleiding
WILDPIX Pro 1.0
English I Nederlands

- 1 -
1. Introduction
Thank you for choosing the Wildpix Pro 1.0. We’re talking about almost every main features
you may care about; like the trigger speed, battery life, image quality day & night, etc. Believe
this camera will bring you much more joyful experience daily. It was totally R&D by our diligent,
smart, and experienced engineers based on feedbacks and requirements from customers
globally. May this camera bring you safety and great trail trip experience ever. Also take a look
at www.wildpixcamera.com
1.1 Fully Functionality Introduction
Besides all the functions you may experience from any other similar cameras. This one is
aimed to offer you stable quality product using experience with many extraordinary features,
like 15 meters (50 ft) invisible real night vision ability, 0.4 seconds trigger time, and 1 photo/sec
(up to 5 photos per trigger) multi-shot to capture the whole track of object (anti-theft evidence),
user friendly operational menu, etc.
1.2 Application
This camera is an ideal product for security surveillance and wild animals tracking with its
hidden camouflage housing.
Accurate fast trigger with 12MP crystal clear image quality and FHD video will get your heart
pumping ever.
a. Instant alert surveillance camera for home, office, back yards, and warehouse, etc
b. Accurate PIR motion-triggered infra-red night vision image/video shooting;
c. Animal tracking and plant growth observation;
1.3 Power Supply
A. Batteries
Camera runs on 6 or 12 AA size batteries (9-12V power supply to ensure camera well
performance of all functions); can work with alkaline and high-quality NiMH rechargeable
batteries. But we suggest to run camera with NiMH batteries only as performance of alkaline
batteries is much poorer than NiMH batteries. Pls also choose the battery type you’re using in
the menu option “Battery Type”to reach longer operation time.
Batteries should be inserted with correct electrode position as marked on the housing. Upside
down batteries electrode may cause device malfunction. Also, we strongly recommend
changing the batteries when power icon on camera screen or photo stamp is empty.
Note: Don’t mix batteries types! Different batteries to be used in camera may cause
permanent damage which also violates warranty policy!

- 2 -
Due to different settings, objects activities within camera detection zone, different brands and
quality of batteries, and using environment, etc; we’re not able to list out exact number of
photos and videos that camera can achieve. So given table below only shows approximate
number of photos or videos camera can take with 12AA alkaline batteries; better performance
can be given by 12 AA rechargeable NiMH batteries.
Test Condition: LCD screen off. Mode: “Power On” _PIR intelligent automatically monitoring
12AA Alkaline Batteries
Photos shot per day
Working time
Video clips shot per day
Working time
IR LEDs On
Max.Range
100 pics
81 days
10secs video clips
10 clips
75 days
Balanced
100 pics
76 days
Min. Blur
100 pics
70 days
IR LEDs Off
100 pics
113 days
10secs video clips
10 clips
228 days
B. Solar Panel
To bring users better using experience, our engineers designed this camera to be able to work
with most standard 12V/2A lithium battery build-in solar panels. However, as rechargeable AA
NiMH batteries need higher voltage for charging that solar panel can’t charge the batteries in
using in camera batteries cases.
C. Power Adaptor—Security Surveillance Purpose
This camera can also be powered by an external 12V/ 2A DC adapter. Recommend to remove
the AA size batteries when power adapter is used. Electrical power is recommended for
security purposes.
1.4 SD Card Selection
Using a memory card is required to operate the camera. When the camera is "ON" and
no memory card is used, the screen displays "No card". The SD slot of the camera has a 32
GB memory capacity. Before inserting or removing the memory card, the camera must be
turned "OFF". Failing to do so may cause loss of or damage the pictures/ videos already
recorded from the memory card. When the SD card is full, the viewing screen shows "Memory
Full". The following data shows an approximate quantity of photos which can be recorded by
the camera depending on the memory card capacity.
Chart below will show you the approximate capacity of different size SD cards. Pls check
to see which size card can fit your needs best.
SD
Size
Capacity
1GB
2 GB
4 GB
8 GB
16 GB
32 GB
Photo (pictures)
5MP
869
1631
3585
7492
15307
30936
8 MP
556
1041
2294
4798
9794
19795
12 MP
391
733
1613
3371
6887
13919
Video (hours)
640x480
00:05:27
00:10:13
00:22:28
00:46:57
01:35:56
03:13:52

- 3 -
HD
00:03:56
00:07:23
00:16:13
00:33:53
01:09:14
02:19:56
FHD
00:02:04
00:03:53
00:08:31
00:17:48
00:36:20
01:13:21
1.5 USB Connection
When camera is connected via USB cable; screen display “MSDC”, press “Menu”once,
“MSDC”turns to “PC Cam”, camera now can be used as a PC camera; press “Menu”again,
camera exits PC camera mode.
1.6 Attention
1. Insert the SD memory card correctly, camera does not support SD card hot swap (insertion).
2. Please use high-quality AA batteries in order to prevent battery cells from corrosion of leaked
acid.
3. Use right adaptor (12V/2A) of this camera to supply power, and do not invert the electrode
when put in batteries.
4. In Test mode, camera will automatically power off in 3 mins if there is no keypad touching.
5. Don’t interrupt power supply during system upgrade, please deliver it back to factory if the
device doesn’t work after upgrading.
6. Do not frequently insert or pull out SD card and battery or plug in and out the adaptor when
the camera is on.
7. Do not have any floating objects, such as leaves, strings, or ribbons in the 3M motion
detection zone of cameras, to avoid mistaking photograph or videos.
8. Do not keep camera next to hot irrelevant objects, air conditioner exhaust vents, and light,
etc. to avoid mistaking photos or videos.
9. Camera is with a 100° FOV lens which means more flash is needed to get better night time
images than the average 52° FOV lens from market; that’s why 58pcs 60° IR LEDs are used
on this camera. But ensure these 58pcs IR LEDs can give enough flash to back the wide angle
lens up that high qualified AA batteries must be applied accordingly to deliver enough
amperage to power the illuminator consistently in dark environments.
10. Programmed Date/Time can be saved in camera for 12 hours as long as camera was
powered 1 hour above.
1.7 Key Features
1. 0.4 seconds trigger speed;
2. Wide lens model: 100 degrees FOV lens; 80 degrees PIR angle;
3. 12MP/ 1080P@30FPS;
4. Programmable 5/8/12 Megapixel high-quality resolution;
5. 58pcs invisible IR LEDs, offer 20 meters (65 feet) real night vision distance;
6. crystal clear day & night photo/video quality;
7. 1 photo burst per second to get full moving track of object;
8. Support multiple functions: adjustable PIR sensitivity, Multi-shot (1~5 photos per trigger),
programmable delay between motions, Time Lapse, Timer, stamp of (camera ID, date/time,
temperature, moon phase) on every single photo;
9. Available operation temperature: -25℃to 60℃;
10. Built-in 2.0" TFT color screen;

- 4 -
2. Whole View and Details of Camera
2.1 Figure 1: Front View of Camera;
28 IR LEDs
PIR Sensor
Indicator Light
Light Sensor
(day/night)
58 IR LEDs
in Total
Lens
30 IR LEDs

- 5 -
2.2 Figure 2: Bottom View of Camera;
SIM CARD Golden Part Faces Front Housing Side
SD Card Slot Battery Slot
DC in USB Port
2.3 Figure 3: Internal, Side and Back View of Camera
MENU Button LCD Colorful Screen
Navigation Buttons/ OK Button
Power Switch
(ON/ OFF/ SETUP Test Mode) Battery Slot

- 6 -
3. Quick Start
3.1 How to Start the Camera?
Turn “Power Switch” to SETUP position.
Note: Camera comes pre-programmed with factory default settings. So for test purpose,
user only needs to insert a SD card and batteries to start test by powering on.
3.2 How to Set the Functions?
a. Turn “Power Switch” to SETUP position to enter test mode, then press button “Menu” once to
enter camera setting menu;
Use navigation buttons“←”, “↑”, “→”, or “↓”to obtain favored settings, press
“OK”for confirmation and save the preferred change, press “Menu”to exit current page;
b. Turn “Power Switch” to ON position to enable camera to work on PIR.
c. Camera LED indicator flashes 5 times before it gets into PIR auto working mode.
Note: For some settings, user needs to press “Menu” to save & exit the configuration
after pressing “OK”to confirm; (Cam ID, Delay, Time Lapse, Timer, Password)

- 7 -
3.4 Camera Default Settings in Red Letter
Cam
Cam ID
OFF/ ON
Cam Mode
Photo/ Video
PIC + VIDEO
IR LEDs
All/ Part
Image Size
5MP/8MP/12MP
Night Mode
Balanced
Min. Blur
Max Range
Multi-shot
IP/2/3/4/5P
PIC+Video/ Video ON
Video Size
1080P/720P/D1
Video Length
05~59Secs
PIR
Sensitivity
High/Middle/Low
Delay
OFF/ON
Time Lapse
OFF/ON
Timer
OFF/ON
3G
3G Switch
ON/OFF
SIM Auto Match
Auto/Manual
Manual Setup
MMS/3G
MMS
ON/OFF
SMTP
Default/Manual/OFF
FTP
ON/OFF
Send To
Phone/Email
SIM PIN
ON
SMTP/FTP Pic Size
640*480/1920*1440
Max Num/Day
Unlimited/1~99
SMS Ctrl
By Trigger/All the Time
Daily Report
OFF/ON
Other
Language
English…
Date/Time
Month : date : year;
hour : minute : second
Time Stamp
OFF/ON
Battery Type
Alkaline/NI-MH
Frequency
50Hz/60Hz
SD Cycle
OFF/ON
Reset
Yes/No
Password
OFF/ON(6 digits)
About
Ver: /IMEI: /MCU:

- 1 -
4. Operation List
4.1 Video/Photo Playback
Turn “Power Switch” to SETUP position to enter test mode, press arrow button “↑” to enter
Playback; press “←” and “→” for selection, “OK” to play photo/video.
1) Press button “↑” again to exit.
2) In Playback Mode, press “Menu” button to delete files, or format SD card; press “Menu”
again to exit.
4.2 Delete
a. Delete one: delete selected photo/video;
Press “OK” to choose, press“↑” and “↓”for selection, “Yes” to confirm, “No” to exit to previous
page.
b. Delete All.
4.3 Format of SD Card
a. No
b. Yes: to format SD card via camera.
Press “←” and “→” for selection, “Yes” to confirm, “No” to exit to previous page.
4.4 Auto Power Off
In Test mode, camera will automatically power off in 3 mins if there is no keypad touching.
Please manually turn ON it as if you want to do some further configuration.
Note: camera stay in “Test” mode if camera is in Menu configuration pages.
4.5 Operation Menu
Test mode, Press “Menu” once to enter camera setting menu; to navigate setting interface by
pressing “←”, “↑”, “→”, or “↓”, press “OK” for selection, “Menu” to exit to previous page, and
“Menu” to switch alpha/ digits/ symbols.
Note: For some settings, user needs to press “Menu” to save & exit the configuration
after pressing “OK” to confirm; (Cam ID, Deley, Time Lapse, Timer, Password)

- 2 -
Cam
Settings
Programmable Options
Cam ID
Select “ON”, press “OK”, to set 4 digits/ alphabets for each camera. Such
function can help user to identify photos are from where and which camera.
Cam Mode
Photo, PIC+VIDEO, Video
1) Photo: camera shoots photos only based on configured Multi-shot &
Image Size;
2) “PIC+VIDEO”, camera shoots photo(s) first, then video upon same
trigger event based on Video Length/Size and Multi-shot/ Image Size
user configured;
3) Video: camera shoots videos only based on configured Video
Length/Size;
IR LEDs
All/Part
All: all 58pcs IR LEDs will work in dark environment;
Part: Bottom 30pcs IR LEDs will be turned off.
Image Size
5MP (2560*1920), 8MP (3264*2448), 12MP (4032*3024)
Night Mode
1) Min. Blur: Short exposure time to minimize motion blur for better image
quality; shortened IR flash range;
2) Max. Range: Longer exposure time to extend IR flash range for better
night vision; lower image quality;
3) Balanced: combination of above 2 options;
Multi-shot
Programmable 1~5 photos per trigger
Video On
Video Size
1280*720, 640*480, 1920*1080,
Video length
05~59 Secs
PIR
Settings
Programmable Options
Sensitivity
High, Middle, Low
Higher sensitivity is 1) more sensitive to movements by smaller subjects; 2)

- 3 -
longer detection distance; 3) easier for sensor to detect difference between
body heat and outdoor temperature; 4) easier to trigger camera to record. In
high temperature environment, body heat of subjects and environment
temperature is hard to tell by camera, suggest setting High.
Delay
Select “ON”, press “OK”, to set a time interval that you desire between
photos/videos upon motion. This option avoid camera taking too many
photos or videos.
Example: Camera will wait 1 minute between photo/video recordings with
motion if pre-set time interval is 00:01:00
Configurable delay time: 00:00:05~23:59:59.
Note: Pls don’t turn ON Time Lapse and Delay simultaneously!
Time Lapse
Select “ON”, press “OK”, to set the interval; PIR sensor of camera will be
turned off; camera will shoot pics or video clips automatically upon the
interval user set.
Configurable interval: 00:00:05~23:59:59.
Note: Pls don’t turn ON Time Lapse and Delay simultaneously!
Timer
Select “ON”, press “OK”, to set the beginning time and end time
(hour/minute); camera will only work during the time period user set.
i.e.: 15:00 –18:00; camera only works during 15:00 –18:00
Other
Language
English…
Date/Time
Month : date : year; hour : minute : second
Note: Pls adjust camera date/time to ensure some functions work as expected.
Stamp
Imprints of programmed camera ID, moon phase, temperature, date, and
time on photo
Battery Type
Alkaline/ NI-MH
Choose correct battery type of used batteries in camera makes camera
perform better.

- 4 -
Frequency
50HZ, 60HZ; improper setting may cause camera screen flicker
SD Cycle
Select “ON”, press “OK”, camera will continue to record photos/videos by
deleting earliest photos or video clips.
Reset
Select “Yes” to reset camera back to factory default settings.
Password
Select “ON”, press “OK”, to enable password protection for your camera;
support totally 6 digits/ alphabets long password access.
About
Firmware version in camera (Version: / IMEI: / MCU:)
5. Specification
Image Sensor
5 Mega Pixels Color CMOS
Effective Pixels
2560x1920
Day/Night Mode
Yes
IR range
20m
IR Setting
Top: 28 LED, Foot: 30 LED
Memory
SD Card (4GB –32GB)
Operating keys
7
Lens
F=3.0; FOV=100°; Auto IR-Cut-Remove (at night)
LCD Screen
2” TFT, RGB, 262k
PIR distance
20m (65feet)
PIR Angle
80 degree
Picture size
5MP/8MP/12MP = 2560x1920/3264x2448/4032x3024
Picture Format
JPEG
Video resolution
FHD (1920x1080), HD (1280x720), VGA(640x480)
Video Format
AVI
Video Length
05-59sec. programmable
Shooting Numbers
1-5
Trigger Time
0.4s
Trigger Interval
4s-7s
Camera + Video
Yes
Device Serial No.
Yes
Time Lapse
Yes
SD Card cycle
ON/OFF
Operation Power
Battery: 9V; DC: 12V
Battery Type
12AA
External DC
12V
Stand-by Current
0.135mA
Stand-by Time
5~8 months (6×AA~12×AA)
Auto Power Off
In Test mode, camera will automatically power off in 3 mins if
there is no keypad touching.

- 5 -
Power Consumption
(Test condition: 9V power
supply, PIR auto mode)
IR LEDs Off
Photo: 170mA;
Video: 160mA
IR LEDs On
Max.Range: 1150mA
Balanced: 1250mA
Min.Blur: 1500mA
Video: 900mA
Power Off Voltage
Alkaline battery: 6.3V
NI-MH battery: 6.0V
DC power: 6.8V
Interface
USB/SD Card/DC Port
Mounting
Strap; Tripod
Operating Temperature
-25°C to 60°C
Storage temperature
-30°C to 70°C
Operation Humidity
5%-90%
Waterproof spec
IP54
Dimensions
148.25*117.37*78.25 mm
Weight
367 g
Certification
CE FCC RoHs
6. Trouble Shooting
6.1 Photos Do Not Capture Subject of Interest
1. Check the “Sensor Level” (PIR sensitivity) parameter setting. For warm environmental
conditions, set the Sensor Level to “High” and for cold weather use, set the sensor for “Low”.
2. Try to set your camera up in an area where no heat resources are in the camera’s field of
view.
3. In some cases, set the camera near water will make the camera take images with no subject
in them. Try to aim the camera over ground.
4. Try to set camera on stable and immovable objects, i.e.: large trees.
5. At night, motion detector may detect beyond range of the IR illumination. Reduce
distance setting by adjusting sensor sensitivity.
7. Rising sun or sunset can trigger sensor. Camera must be reoriented.
8. If person/animal moves quickly, it may move out of the camera’s field of view before
photo is taken. Move camera further back or redirect camera.
6.2 Camera Stops Taking Images or Won’t Take Images
1. Please make sure that the SD card is not full. If the card is full, camera will stop taking
images. Or user can turn on Cycle Recording to avoid such problem.
2. Check batteries to make sure that alkaline, or NiMH AA batteries left power is enough for
camera to work.
3. Make sure that the camera power switch is in the “On” position and not in the “Off” or “Test”
modes.
5. Please format the SD card with camera before using or when camera stops taking images.

- 6 -
6.3 Night Vision Flash Range Doesn’t Meet Expectation
1. Please check to make sure that batteries are fully charged or left power is enough;
2. “Max Range”offers better IR flash range. Given IR flash range values are based on Max
Range setting; so please adjust Night Mode to Max Range for better night vision flash range;
3. High-quality 1.5V NiMH rechargeable AA batteries can also offer much better IR flash range;
alkaline batteries cannot deliver enough amperage to power the illuminator consistently at
night;
4. To ensure accuracy and quality of night time image, please mount camera to dark
environment without any obvious light sources;
5. A certain surroundings (like trees, walls, ground, etc.) within flash range can get you better
night time images; please do not aim camera to total open field where there is nothing within IR
flash range to reflect flash back; it’s like shinning a flashlight into sky in night, you just can’t see
anything; same does camera;
6.4 Photos Do Not Capture Subject of Interest
1. Check the “Sensor Level” (PIR sensitivity) parameter setting. For warm environmental
conditions, set the Sensor Level to “High” and for cold weather use, set the sensor for “Low”.
2. Try to set your camera up in an area where there is not a heat source in the camera’s line of
sight.
3. In some cases, set the camera near water will make the camera take images with no subject
in them. Try aiming the camera over ground.
4. Try to avoid setting the camera up on small trees that are prone to being moved by strong
winds.
5. Remove any limbs which are right in front of the camera lens.

- 7 -
7. Warranty
With great pride and full confidence in our products, we always keep our words which are
given to our customers as specified warranty terms and services below. Based on a strict QC
system, we initially offer all our customers one year long time limited warranty, come along with
selectable chargeable renewal policy of warranty as one, two, three, or four years.
Our products are warranted against defects in materials and workmanship for a period of one
year from the date of original purchase. If a defect exists, we will, at our option and to extent
permitted by law will (1) repair the product at no charge using new or refurbished parts; (2)
exchange the product with a functionally equivalent product that is new or refurbished.
Provided the product is returned freight charge paid.
This warranty excludes damage resulting from abuse, accident, modifications or other causes
that are not defects in materials and workmanship, or by someone other than our authorized
technicians. This warranty only covers failures due to defects in materials or workmanship
under normal usage.
To obtain warranty service, please contact us to determine the nature of problem before return
the product under this warranty (with a written description of the problem and print samples) for
repairing or exchanging.

- 8 -
1. Introductie
Bedankt dat u gekozen hebt voor de Wildpix Pro 1.0. Wij van Wildpix willen de hoogste
kwaliteit aanbieden voor de beste prijs, dit is ook weer gelukt met onze Pro serie.
Omdat wij een Nederlands merk zijn, willen wij ook graag een Nederlandse handleiding kunnen
aanbieden. Deze Nederlandse handleiding biedt de basis om te kunnen starten. Wilt u een
uitgebreidere handleiding of een instructievideo? Kijk dan op www.wildpixcamera.nl
1.1 Gebruik
De Wildpix Pro 1.0 is de ideale camera om wild te observeren en te onderzoeken, maar de
camera is ook ideaal voor het bewaken van uw huis, bedrijf of magazijn. De Wildpix Pro 1.0 is
zeer onopvallend door zijn gecamoufleerde uiterlijk. De Wildpix Pro 1.0 is makkelijk en snel te
installeren, bekijk de installatievideo’s op www.wildpixcamera.nl.
1.2 Voeding
1. Batterijen;
De Camera werkt op 6 of 12AA Batterijen. Gebruik hiervoor alkaline of (goede kwaliteit) NI-MH
batterijen. Gebruik AUB geen Lithium batterijen!
Plaats de batterijen altijd zoals aangegeven op de batterijhouder, bij het verkeerd plaatsen van
de batterijen kunnen storingen optreden. Wij adviseren om altijd de batterijen te vervangen
zodra de camera dit aangeeft.
Belangrijk: Combineer geen batterij types! Het gebruik van verschillende batterij types
kan permanente schade aan de camera toebrengen! Schades door verschillende batterij
types kunnen niet op de garantie verhaald worden.
Onderstaande tabel toont een indicatie van het aantal Foto’s en Video’s wat gemaakt kan
worden met 12AA alkaline batterijen. Dit is slechts een indicatie en hangt af van de gekozen
instellingen, aantal triggers, kwaliteit van de batterijen, de omgeving, enz.
Met 12AA NI-MH oplaadbare batterijen van goede kwaliteit kunnen nog betere resultaten
behaald worden.
Test Conditie: LCD scherm uit. Modus: “Power On” _PIR intelligent automatically monitoring
12AA Alkaline Batterijen
Foto’s per dag
Werkingduur
Videoclips per dag
Werkingstijd
IR LEDs On
Max.Bereik
100 fotos
81 dagen
10 seconden video clips
10 clips
75 dagen
Gebalanceerd
100 fotos
76 dagen
Min.Vervaging
100 fotos
70 dagen
IR LEDs Uit
Foto
100 fotos
113 dagen
10 seconden video clips
10 clips
228 dagen

- 9 -
2. Zonnepaneel;
Voor een nog betere ervaring hebben onze engineers de Wildpix Pro 1.0 zo ontworpen, dat de
meest standaard 12V/1~2A zonnepanelen aangesloten kunnen worden. Omdat oplaadbare
NI-MH batterijen een hogere laadspanning hebben, zal het zonnepaneel de batterijen niet
opladen, maar de camera wel van voeding voorzien.
3. Voedingsadapter;
De camera kan ook voorzien worden van een 12V/1~2A DC-adapter. Als u een adapter
gebruikt adviseren wij om de AA Batterijen te verwijderen. De 12V adapter is aan te raden als
de camera voor bewakingsdoeleinden gebruikt wordt..
1.3 SD Kaart
Een SD geheugenkaart is vereist om de camera te laten werken. Wanneer de camera AAN
staat en er geen geheugenkaart geplaatst is, zal de camera op het scherm “Geen SD Kaart”
weergeven. De camera ondersteund SD kaarten tot 32GB. Als u een SD kaart wilt plaatsen of
verwijderen, moet u de camera altijd uitzetten, als u dit niet doet kan dit leiden tot beschadiging
of verlies van de bestanden op de SD Kaart. Wanneer de SD Kaart vol is zal de camera
“geheugen vol”aangeven.
De volgende tabel toont een Indicatie van de geheugencapiciteit bij verschillende
geheugenkaarten.
SD
1GB
2 GB
4 GB
8 GB
16 GB
32 GB
Aantal Foto’s
5MP
869
1631
3585
7492
15307
30936
8 MP
556
1041
2294
4798
9794
19795
12 MP
391
733
1613
3371
6887
13919
Video (Uren)
640x480
00:05:27
00:10:13
00:22:28
00:46:57
01:35:56
03:13:52
HD
00:03:56
00:07:23
00:16:13
00:33:53
01:09:14
02:19:56
FHD
00:02:04
00:03:53
00:08:31
00:17:48
00:36:20
01:13:21
1.4 USB Connectie
Wanneer de camera aangesloten is via een USB kabel zal de camera “MSDC” weergeven op
het scherm, druk 1 keer op de “Menu” knop, “MSDC”zal veranderen in “PC Cam”, de camera
kan nu gebruikt worden als PC camera, druk nog een keer op de “Menu” knop om de camera
weer van “PC Cam” af te halen.

- 10 -
1.5 Belangrijk!
1. Let op dat de SD kaart altijd op de juiste manier geplaatst wordt.
2. Gebruik altijd AA Batterijen van goede kwaliteit.
3. Als u een adapter wilt gebruiken, zorg dan dat u een 12V/1-2A adapter gebruikt. Verwijder bij
gebruik van een adapter de batterijen.
4. Wanneer de camera in testmodus staat, en het toetsenbord wordt langer als 3 minuten niet
gebruikt zal de camera zichzelf uitschakelen.
5. Verbreek de voeding nooit tijdens een update. Als de camera problemen ondervindt na een
UPDATE, neem dan contact met ons op.
6. Plaats of verwijder de SD kaart, batterijen en adapter niet als de camera aan staat.
7. Zorg ervoor dat er bij het installeren van de camera geen losse objecten voor de sensor
hangen, denk hierbij aan taken, bladeren, linten enz.
8. Zorg ervoor dat u de camera niet op plaatsen installeert waar ventilatieopeningen zitten die
luchtstromen genereren of op plaatsen waar het warm is door apparatuur.

- 11 -
2.0 De Camera
2.1 De Details van de Camera
28 IR LEDs
PIR Sensor
Indicator Lamp
Licht Sensor
(dag/nacht)
58 IR LEDs
in Totaal
Lens
30 IR LEDs
SD Kaart Slot Batterijen Compartiment
DC in USB Poort
