Willhi WH7016E User manual

WH7016E
Thermostat Product
Manual
Shenzhen WillhiElectronics Co., Ltd.
Tel:[phone]Fax :[phone]
Technicalsupport: EngineerTian
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

220v
load
heat
eg mat
1 2 3L
Power NTC
4N 7 865
dont touch
Installation opening size:
②Wiring diagram
Terminals 1 and 2: Normally opened contact of relay
Terminals 3and 4:Connect the power
Terminals 5and 6:The factory parameter settings of thermostat can be
locked after a short circuit, the user can not modify.
Terminals 7and 8:Temperature connection sensor
Note: The load refers to the heating or cooling equipment on control.
③
Electrical performance:
Temperature measurement range: -9.9 ~ 99.9
Temperature control range: -9.9 ~ 99.9
Temperature measurement error: 0.5
Sensor Type: NTC (10K/3435)
Control accuracy: 1
Working voltage:AC/DC12V AC220V AC110V
Working current: <2W
Relay contact point current: AC 7A/220V
Data storage : Yes
Working temperature: 0 ~ 50
Storage temperature: -10 ~ 60
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn
SENSOR

KeyInstructions:④
1.RST:Press RSTkeytoswitchonand off,press the RSTkeyon the
power-offstateoncetoturnon,onthe power-on state,press the RSTkey
forthree secondsandholdon, thenit willbe off.
2. SET:
A: Press theSETkeyoncetoenterthetemperaturecontrolsetting,press
▲or ▼buttontoadjust, press ▲or ▼buttonforthreesecondsandhold
toenterthefastadjusting mode,pressthe SETkeyagaintoexitsetting
mode.
B:Press and holdSETkeyforthreesecondstoenterthe systemmenu
settings,pressthe ▲or ▼keytoselecttheadjustmentmenu,pressSET
keyoncetoentertheappropriateparametersettings,press ▲or ▼to
adjustthe parametersneededtobemodified,afterbeingadjusted,press
the RSTkeytoexit, orexit asthesystemdelayfor5seconds.
▲: Upkey
▼: Downkey
OperatingInstructions:⑤
LEDStatusDescription:
The WORK lightsat the left side of thescreenisused asworking indicator
lights, flashing istoindicatethe delayof cooling orheating,ifthe LEDis
always on ,itindicatesitison the statusof cooling orheating .
The SET light at the left side of the screen lightsisused assetting indicator
lights,if the LEDisalways on ,itindicatesitison the statusof setting.
.
FunctionInstructions:
Press RST keytoopen thethermostat, on the runningstatus, press thiskey
for3seconds, then thethermostat can be turned off.
◆Cooling,heatingfunction:
CoolingMode: Whenthe measured temperatureishigherthan orequalto
the set value+hysteresis, the relaypicks up tostart theoutput; When the
measured temperaturebelowthe set value, therelayoffand closethe output.
Heatingmode: When the measured temperatureishigherthan orequalto
the set value, the relayoff, turnoff theoutput; Whenthe measured
temperaturebelowthe set value-hysteresis, the relaypicks up tostart the
output.
ExampleforSetting:Ifitissettoheatingmode,setthetemperatureto25
degrees, hysteresisissetto5, thenwhenthemeasuredtemperatureis
higherthanorequal to25 degrees,therelay isoff, close theoutput.
Whenthetemperatureisbelow 20degrees, pick uptherelayagain, to
starttheoutput.
ExampleforSetting:Ifitissettocoolingmode,setthetemperatureto25
degrees, hysteresisissetto5, thenwhenthemeasuredtemperatureis
below25 degrees,therelayisoff, close theoutput. Whenthe
temperatureishigherthanorequalto30 degrees,pick uptherelayagain,
tostarttheoutput.
◆Cooling,heatingmodesetting:
Press "SET"keyand holdmorethan 3secondstoenterthemenu display,the
screen appears"HC"code, pressthe "SET"keytodisplaythe workingmode,
press the "▲"or"▼"toadjust the display, Cmeanscoolingmode; Hmeans
heating mode.
◆Hysteresisfunction:
Hysteresissettinglimitsthe maximumintervalbetween the opening and
stopping, thismachine minimumintervalbetween the opening and stopping is
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

1, the maximumis15 .
◆Hysteresissettings:
Press "SET"keyandholdmorethan 3secondstoenterthemenu display,
with"▲"or"▼"keyadjusted tothescreen, appearing"D"code, press the
"SET"keytodisplaythe hysteresisset value,press "▲"Or"▼"keytoadjust
the parameters.
◆Temperaturecalibrationfuntion:
Whenthereisdeviation between the measuring temperatureandstandard
temperature,usethe temperaturecalibrationfunction,makethe machine
measurementsvalue consistentwiththe standardtemperature,theafter
calibration temperature=the beforecalibrationtemperature+calibration value
(calibrationvalue canbe positivenumber, negativenumber, and 0).
◆Temperaturecalibrationsettings:
Press "SET"keyandholdmorethan 3secondstoenterthemenu display,
with"▲"or"▼"keyadjusted tothescreen, appearing"CA"code,press the
"SET"keytodisplaythe temperaturecalibration settings,press "▲"Or"▼"key
toadjust the parameters.
Forexample:Whenwemeasuretheprobetemperaturewas 25degrees,it
displays25 degrees as theCAis0, itdisplays26 degreesas theCAis1,
itdisplays24 degrees as theCAis-1.Thisfunctionisgenerallyapplied
whentheprobecannotmeasuredirectlythemeasuredobject. For
example, weplace theprobeattheoutsideofacuptomeasureitswater
temperature, weneedtoadjusttheCAparametersbecause oftheheat
loss ofthecup,sothatthedisplaytemperaturecanbeinaccordance
withcuptemperature.
DelayProtectionFuntion:◆
Inthe cooling mode,the firstpoweron,whenthe measured valueabovethe
setvalue+hysteresisvalue,themachine will notimmediatelystartcooling,it
needstosetthedelaytime,then themachine can run tostart cooling;oncethe
intervalbetween twocooling islargerthanthe delaytime,the machine
immediatelystartscooling,oncethe intervalbetween twocooling islessthan
the delaytime, the machine must run the remainingdelaytimetostart cooling.
The delaytimeisstartedtocalculatefromstopping the machine.The delay
timeof heating mode isassameasthe coolingmode.
Note:Itisrecommended thatonlythedevicethatusecompressorcooling can
usethe delaystartfunction,the userwho don'tneeddelaystartfunction
pleaseset thisparameterto0.
◆DelayProtectionSetting:
Press "SET"keyandholdmorethan 3secondstoenterthemenu display,
with"▲"or"▼"keyadjusted tothescreen, appearing"PT"code, press the
"SET"keytodisplaythe delaysettingvalue, then pressthe "▲"or"▼"keyto
adjust the parameters.
◆Upperandlowerlimitfunctions:
The settingof HSandLSlimit the set range of controltemperaturepoint , for
example:HSissetto+15,LSissetto-10,thecontroltemperaturecan onlybe
adjusted between -10 and +15,when the controltemperatureto-10 then press
"▼"key, the displaywillremainon the statusof -10 and notdecrease; when
the controltemperatureto+15 thenpress "▲"key, the displaywillonthe
statusof 15 and notincease.If theset point outside thisrange,it needsto
firstlychangethe valueof HSandLS, then it can be achieved.
◆Upperand lowerlimitsettings:
Press "SET"keyandholdmorethan 3secondstoenterthemenu display,
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

with"▲"or"▼"keyadjusted tothescreen, appearing"HS"or"LS"code,
press the "SET"keytodisplaytheupperorlowerlimit set value,Then press
"▲"or"▼"keytoadjust the parameters. HSmeansupperlimit. LSmeans
lowerlimit.
Forexample: the upperand lowerlimitsareused tolimit the range of control
temperaturethatcan beset, suchas:LSis10, HS20, thenpressthe SETkey
toadjust the temperaturecontrol,itcan onlybevaried between 10 and20.
◆High temperaturealarm:
Ifthe measured temperature>set temperature+AHalarmoutput relay. Thermostat alarm
will sound, the displayalternatelyshowsHand thecurrent temperature.Alarm,press any
keytostopthealarmand relayoutput.
◆Hightemperaturealarm settings:
Press "SET"button and holdmorethan 3secondstoenterthemenu display, with"▲"or
"▼"button transferred tothescreen appears"AH"code, press the "SET"keytodisplay
the high-temperaturealarmsettings,press "▲"or" ▼"keytoadjust theparameters
◆Lowtemperaturealarm function:
Ifthe measured temperature"set temperature-ALwhen thealarmoutput relay.
Thermostat alarmwill sound, thedisplayalternatelyshowsLand the currenttemperature.
Alarm, press anykeytostopthe alarmand relayoutput.
◆lowtemperaturealarm settings:
Press "SET"button and holdmorethan 3secondstoenterthemenu display, with"▲"or
"▼"button transferred tothescreen appears"AL"code, press the "SET"keytodisplay
the lowtemperaturealarmsettings, press "▲"or" ▼"keytoadjust the parameters
◆Menu code selection:
Symbol Details Setting
range Factory settings Units
HC Heating/
cooling H/C C
D Hysteresis 0.1～15 1.0
LS The minimum
set limit -9.9～99.9 -9.9
HS The maximum
set limit -9.9～99.9 99.9
CA Temperature
calibration -5.0～+5.0 0.0
PT Delaytime 0～10 1 Minutes
AH
Hightemperature alarm 0～15 1.0
AL lowtemperature
alarmsettings 0～15 1.0
faulttips:⑥
1)When thesensordisconnected, the screendisplays---and closethe
heating wire
2)When the sensordetectsthetemperatureisbelow-9.9degrees,the screen
displays LLL
3)When thesensordetectsatemperaturehigherthan 99.9degrees, the
screen displaysHHH
Cautionforusing:⑦
Cooling, heating loadmust not exceed the output contact capacity, orit◆
mayresult inmachine damage and causeafire.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

Variousconnectingwiremust be well connected withthe terminal,◆
otherwise,it wouldresultinreducing the reliabilityofmachine.
Whenconnecting thewire, pleaseseparatepowersupply, relays,sensors,◆
otherwiseit willdamage the machine.
