Williams-Sonoma TG46P4368L01 User manual

MADE IN CHINA
1
ASSEMBLY INSTRUCTIONS
MADE IN CHINA
2
ASSEMBLY INSTRUCTIONS
Thank you for purchasing your Christmas tree.The instructions below will help you quickly and easily set up
your new tree.
1. Find a level surface near an electrical outlet and assemble the tree stand as shown in Fig. A.
2. Each tree section is numbered with a tag. Identify all sections before assembling.
3. Assemble the tree from the bottom to the top. Insert the pole of Section 1 into the assembled stand.
Make sure the pole is firmly inserted and secured into the stand.
Note: Do not step on the tree legs during the setup.This may deform the tree stand and may result in an
unbalanced tree.
4. Follow the direction of the arrow marked on the adapter to insert. Ensure that all poles are firmly secure.
Continue this step until the entire tree is set up. Be sure that all wires are free of branch hinges.
5. Plug the adapter into the wall outlet (See Fig. B).Your tree should now be lit. If some bulbs do not light or
flicker, search for any loose plugs and/or broken, loose or missing bulbs. Connect the plugs or replace the bad
bulbs promptly in order to maintain the performance and life expectancy of your pre-lit tree.
6. Begin to shape the branches and tips in the bottom section inserted into the tree stand. Start with the tips
closest to the middle of the tree; pull the individual tips alternately upward and outward working your way
to the tip of the branches (See Fig. C).Work row by row to the upper part of the tree section leaving no tip
untouched. Continue to shape each branch as described above as you set up each tree section.
Top view
Side view
Fig. C
For pre-lit trees, if the tree does not illuminate:
1. Check to make sure that all plugs and adapter are properly connected as indicated in Fig. B.
(If the tree comes with a foot pedal, try stepping on the on/off button).
2. Turn the poles gently to make sure pole-to-pole connection is secured.
3. Check for loose, broken or missing bulbs, and replace as needed.
TROUBLESHOOTING TIPS
This tree includes spare hinge pins, washers and bulbs.
SPARE PARTS
Fig. D
Loose Branches
1. Extra hinge pins are included for repairing the hinges of
the branches. Place the branch into the slot of the bracket.
2. Insert a new hinge pin through the hole and secure using
the retainer washer. (See Fig. D)
STORAGE INSTRUCTIONS
1. Unplug cord from the wall outlet first and then remove all ornaments and decorations.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove
from section below and fold all branches toward the pole.
3. Continue by gently lifting straight up each section(s) from the section below and fold all branches toward
the pole until the bottom section is removed from the tree stand.
4. Carefully place all tree sections into shipping box and tape it shut.
5. When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to
excessive heat or humidity may damage your tree.
CAUTION
To reduce the risk of fire and electric shock:
a) Use only the power supply that was provided with this product. Using a different adapter will damage the lights
and may cause fire, or electrical shock hazards.
b) Do not install on trees having needles, leaves or branch coverings of metal or materials which look like metal.
c) Do not mount or support strings in a manner that can cut or damage wire insulation.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: AC 120V, 60Hz, 0.16A
Output: DC 28V, 0.28A
Fig. B - Tree and Lights Assembly
Align both arrows
in a straight line
before sliding
down to insert
Do Not Tamper
Internal Parts
LIGHT ASSEMBLY DIAGRAM
7.84 Watts
ITEM #: TG46P4368L01
Adapter
To Be Plugged
Into Wall
Outlet
1
2
Fig. A - Tree Stand Assembly 1. Pull apart the legs of the stand so
that they are x-shaped.
2.When inserting the bottom section
of the tree into the assembled stand,
thread the eyebolt into the stand
and tighten until the pole is firmly
secured.
Eye Bolt
