Williams Sound PKT 2.0 User manual

English
1
Pocketalker®2.0
Personal Amplifier Model PKT 2.0
USER Manual
MAN 181H
Read and understand all instructions and warnings before using this
product. Keep these instructions for future reference.

English
2
Contents
Safety Warnings .....................................................................3
Overview ................................................................................5
Overview Diagram ..................................................................6
Getting Started.......................................................................7
Recharging NiMH Batteries ..................................................11
Extending the External Microphone ......................................15
Using an Optional Neckloop.................................................17
Using the Lanyard ................................................................18
LED Indicators......................................................................19
Hints & Tips / Troubleshooting..............................................20
Cleaning Instructions............................................................21
Specications.......................................................................22
Included Items......................................................................25
Limited Warranty ..................................................................26

English
3
Safety Warnings
CAUTION!
The Pocketalker 2.0 is capable of producing very loud sound levels. To
prevent sound levels greater than 132 dB that can potentially damage
hearing with long-term exposure, use only earphones and headphones
supplied by Williams Sound. The Williams Sound Headphone model
HED 026 should not be used with the Pocketalker as it can produce
sound levels greater than 132 dB.
CAUTION!
This product is an assistive listening device designed to amplify sounds
to a high volume level which could potentially cause hearing damage if
used improperly. To protect your hearing and the hearing of others, the
product should be used as directed. Misuse or improper adjustment
may cause harm.
1. Make sure the volume is turned o before putting on the earphone or
headphone. While wearing the earphone or headphone, adjust the volume
to a comfortable level.
2. Set the volume level at the minimum setting that you need to hear.
3. If you experience feedback (a squealing or howling sound), reduce
the volume setting and move the microphone away from the earphone or
headphone.
CAUTION!
1. Before using this product with a pacemaker or other medical device,
consult your physician or the manufacturer of your pacemaker or other
medical device.
2. If you have a pacemaker or other medical device, make sure that you are
using this product in accordance with safety guidelines established by your
physician or the pacemaker manufacturer.
CAUTION!
Do not allow children or other unauthorized persons to have access to
this product.

English
4
WARNING!
1. To prevent injury, do not use this product near water or expose to
moisture, steam, shower, rain or liquids.
2. Clean your Pocketalker 2.0 and it’s parts as recommended in the
“Cleaning Instructions” section in this manual (or reference Technical Bulletin
TCH 020 “Pocketalker Cleaning Instructions” by visiting our website).
3. To prevent injury, do not use or store this product near any heat sources
such as radiators, heat registers, stoves, or other product that produce heat.
4. To prevent injury, use only attachments/accessories specied by Williams
Sound.
5. To prevent strangulation or choking hazard, do not use the product with
a neckloop or lanyard in areas where they could get pulled or caught in
machinery or other objects.
6. To prevent injury, do not operate the product with broken or missing
parts or with frayed or broken cords.
7. To prevent injury, never attempt to dry the product with a hair dryer, oven or a
microwave oven.
8. To prevent injury, do not use the product while doing contact-related
activities or while sleeping.
9. To prevent injury, do not disassemble the product.
10. To prevent injury, the Pocketalker 2.0, it’s parts and batteries should be
kept out of reach of infants, children, pets and anyone who might swallow
these items or otherwise cause themselves injury.
11. To avoid battery leakage hazard, remove batteries if product will not be
used for a period of 2 months or longer.
12. To prevent injury, never attempt to recharge non-rechargeable batteries.
13. Be aware of the possibility that your Pocketalker 2.0 may stop
functioning without notice. Keep this in mind while you circulate in trac or
otherwise depend on warning sounds.
14. The use of headphones or earphones while driving a car (or any other
vehicle) may limit or prevent the perception of surrounding noises and
thereby cause an accident.
15. To prevent injury, do not use in the presence of pure oxygen, or while
using pure oxygen.

English
5
NOTICE!
SERVICING OR ATTEMPTING TO SERVICE THIS DEVICE WILL VOID
THE WARRANTY.
Refer servicing to qualied personnel. Servicing is required when
the unit has been damaged in any way; if liquid has been spilled into
the unit, it has been exposed to rain or moisture, does not operate
normally, or has been dropped or broken in any way.
Overview
The Pocketalker®2.0 is a versatile, high quality assistive
listening device designed to improve communications in
dicult listening situations. The Pocketalker delivers clear,
distinct sound, while its large, manageable controls provide for
easy operation.
Use the Pocketalker to improve listening on a one-to-one
basis, in small group situations, while listening to your favorite
TV or radio programs, or while riding in the car.
The Pocketalker is not sold, advertised, or intended for use
as a personal hearing aid. Williams Sound recommends that
any individual experiencing hearing loss be examined by a
physician/audiologist to determine the cause before using an
amplication device like the Pocketalker.
The Pocketalker is oered with rechargeable options.
Call Williams Sound for more information at
1-800-328-6190.

English
6
Included Items
PKT 2.0
(1) PKT 2.0 Personal Amplier
(1) BAT 010-2 Two AAA Alkaline Batteries
(1) MIC 014-R Plug-Mount Microphone, Omnidirectional
(1) EAR 042 Dual Stereo Isolation Earphones
(1) HED 024 Stereo Headphones
(1) RCS 003 Lanyard
All accessories can be purchased separately

English
7
Overview Diagram
A653
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
Battery
Compartment
Lanyard Slot
Clip
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Rotary
Dial
Front Right Side
Back Left Side
More
treble
More
bass

English
8
Getting Started
1. Open the battery cover: Using your thumb, apply rm pressure on the
ridges of the cover and slide it down and away from the Pocketalker 2.0.
2. Switch the Battery Type Switch to the position for the battery type
that will be used (Rechargeable/NiMH or Alkaline).
Battery Installation
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View
*NOTE: If using rechargeable NiMH AAA batteries, the battery switch
MUST be switched to the NiMH position to allow charging!
3. Press 2 AAA batteries into place in the battery compartment, being
careful to observe correct placement of (+) and (–) terminals.
4. Your Pocketalker system is supplied with the headphone
and earphone for best performance. Williams Sound oers
additional options - visit www.williamssound.com.
WARNING!
Recharge only batteries recommended by Williams Sound. To prevent injury,
do not attempt to charge Alkaline or other non-rechargeable batteries!

English
9
Headphone/Earphone Jack
Left Side View:
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack
Left Side
Back View
5. Wear the earphone or headphone so it ts comfortably.
Note: If using a single/mono headphone/earphone or a neckloop, turn
the balance fully left (counter-clockwise) - this will maximize volume
and help to maximize battery life.
Balance Adjustment - Single/Dual Earphones
Battery Compartment:
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+
–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View
6. Adjust the balance for the type of headphone or earphone being used.
Using a small screwdriver, turn left (or right) to increase (or decrease)
the volume level on the left or right side of the headphones.
7. Close the battery compartment cover: align the cover on the
back of the unit and slide it upwards until it snaps into place.
8. Optional: If the external microphone (MIC 014-R) will be used,
plug it into the External Microphone Jack on the top of the unit.

English
10
Microphone Use / Installation
Top View:
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View
9. Turn ON the Pocketalker by rolling the “Power On/O Volume
Adjust” rotary dial (located on the front) towards the top. The power
“on” green LED indicator on the front of the unit should light up. As
the knob is rotated towards the top, the volume will get louder.
Power On / Volume Adjustment Dial
Front View:
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View
10.Adjust the volume up or down according to your preferences
by rotating the volume dial towards the top (for more volume) or
towards the bottom (for less volume).
Note: The Power “On” Green LED will blink fast when the battery is low.
11.Adjust the tone according to your preferences. Turning the tone
control towards the top (+) boosts the treble (high frequency).
Turning the tone control towards the bottom (-) boosts the bass
(low frequency). The white dot on the dial indicates the normal
position (no treble or bass boost).

English
11
Tone Adjustment Dial
Left Side View: Front View:
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View
Adjust
Tone
Adj.
Dial
Normal
position
(dot in
center)
More
bass
More
treble
More
treble
More
bass
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View
Adjust
Tone
Adj.
Dial
Normal
position
(dot in
center)
More
bass
More
treble
More
treble
More
bass
Using the built-in T-coil with a Loop System
The Pocketalker can be used with loop systems. When the T-coil
switch on the Pocketalker is enabled, the Pocketalker disables
the microphone input, picks up the loop signal, and sends the
audio through the headphone jack.
To use this feature:
Follow the “Getting Started” instructions and instead of step 8,
ip the T-coil switch to the “T-coil” position (up towards the T-coil
symbol). The T-coil “On” LED indicator above the switch will light up.
Internal T-Coil Switch and Indicator LED
Right Side View:
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Belt
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance Control
(Fully counter-
clockwise = Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Front Right SideBack Left Side
Back View

English
12
Note: For best performance when using the T-coil feature, the
Pocketalker must be in a vertical orientation. This ensures the
best magnetic coupling to the loop system. When the T-coil
switch on the Pocketalker is enabled, the Pocketalker disables the
microphone input.
Recharging NiMH Batteries
BATTERY RECHARGING KITS MODEL BAT KT8:
SAFETY WARNINGS
1. To prevent injury, never charge batteries when the Pocketalker 2.0 is in
enclosed spaces such as handbags, cases, or other closed storage bags.
2. To prevent injury, unplug the charger during lightning storms, or when
charging is complete and the device is unused for 2 months or more.
3. To prevent injury, be advised that dierent AC operating voltages
require the use of dierent types of wall outlet adapters. Check the
line voltage in your area and use the correct prong type.
4. To prevent injury, use only the power supply provided by
Williams Sound. Other power supplies may have similar
specications, but may not be equivalent. Use of an
unapproved power supply may present a safety hazard or
leave the device partially or completely inoperable, and may
void the warranty.
5. Do not use the power supply or cords if they have been damaged
in any way.
6. Do not recharge the batteries for longer than 24 hours. After 24
hours, unplug the charger power supply from the wall outlet.
FOR CUSTOMERS IN THE UNITED STATES
This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to part 15 of the FCC rules.
CAUTION
RISK OF ELECTRICAL SHOCK — DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR SIDES). NO USER-SERVICABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
!
AVIS
RIQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR
ATTENTION: POUR RÉDUIRE LE RISQUE DE DÉCHARGE ÉLECTRIQUE, NE
RETIREZ PAS LE COUVERCLE (OU CÔTÉS). IL NE SE TROUVE AL’INTÉRIEUR
AUCUNE PIECE POUVANT ETRE RÉPARÉE PAR L’USAGER. S’A DRESSER A
UN RÉPARATEUR COMPÉTENT.
!

English
13
FOR CUSTOMERS IN CANADA
This Class B digital device meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigencies
du Règlement sur le matériel brouilleur du Canada.
CAUTION
RISK OF ELECTRICAL SHOCK — DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR SIDES). NO USER-SERVICABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
!
AVIS
RIQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR
ATTENTION: POUR RÉDUIRE LE RISQUE DE DÉCHARGE ÉLECTRIQUE, NE
RETIREZ PAS LE COUVERCLE (OU CÔTÉS). IL NE SE TROUVE AL’INTÉRIEUR
AUCUNE PIECE POUVANT ETRE RÉPARÉE PAR L’USAGER. S’A DRESSER A
UN RÉPARATEUR COMPÉTENT.
!
Charging Instructions
The Pocketalker can recharge NiMH batteries when used with an
optional BAT KT8 (International) charging kit.
1. Verify or change battery switch (located in the battery
compartment) to the NiMH position.
2. Verify or insert NiMH batteries into battery compartment.
Observe battery polarity when inserting the batteries.
3. Using the included USB A to USB Micro-B cable, plug the
USB Micro-B end into the USB Micro-B charging port on
the Pocketalker. Plug the USB A end into the USB A port
on the power supply included with the charging kit. Plug
the power supply into a wall outlet.
4. The charging indicator will blink slow while charging, and
then will stay on solid when the unit is charged.
WARNING!
To prevent injury, do not attempt to recharge Alkaline batteries! Only
recharge NiMH batteries recommended by Williams Sound (BAT 022-2).

English
14
Charging Connections
BAT KT8 (International) Charging Kit
A651
USB “Micro-B”
Port
USB “Micro-B”
Plug (small)
USB “A”
Plug (large)
USB “A”
Port plug into
wall outlet
Charging Indicator
PockeTalker 2.0 Power Supply
Adapter for
country of use
installed
USB charging cord
Listening during conversations with others
The Pocketalker picks up sounds and boosts them according to the
volume you’ve set. For best results, place or hold the Pocketalker’s
microphone as close as possible to the person who is speaking.
Seated
Many users set the Pocketalker on a table if they’re in a restaurant
or small group situation. Aim the microphone in the direction of the
person speaking.
Standing Or Walking
Many users use the Pocketalker “Clip” and attach it to their pocket, pants
or skirt. The lanyard may also be used (see section “Using the Lanyard”).
In The Car
For conversations in the car, you can use the External Microphone
(MIC 014-R) with the optional 3.5 mm - 3.5 mm Microphone Extension
Cord (WCA 007 WC) and optional Lapel Clip (CLP 014) to attach the
microphone to the shirt or blouse of your fellow rider (see “Extending
the Microphone” on pg 15).
WARNING!
To prevent injury, route the WCA 007 WC cord such that it will not cause
entanglement and/or interfere with the safe driving of a car (or other
vehicle), or cause entanglement in other locations.

English
15
Extending the External Microphone
When the Pocketalker’s internal microphone is too far away
from the desired sound to be eective, the optional 3.5mm 12ft
extension cord (WCA 007 WC) can be used to extend an external
microphone to a television or another person.
WARNING!
To prevent injury, route the WCA 007 cord in a manner that
prevents it from becoming a tripping or entanglement hazard.
To extend the Microphone:
1. Plug the external microphone into the female end of the
extension cord. Arrange the cord to reach the loudspeaker of
the TV or other person. Plug the male end of the extension
cord into the microphone jack on the Pocketalker.
Using the Optional 3.5mm 12ft Extension Cord
Pocketalker: Front View
A544
External
Microphone
(included)
Optional 3.5mm 12ft
extension cord (WCA 007 )
Microphone plug/jack
Headphone
jack
Earphone or
Headphone
Microphone Clip
(included with
WCA 007 WC)
MIC 014-R
External Microphone
(included)
3.5mm
12 ft Extension Cord
(WCA 007, optional)
TV Speaker
2. For a TV: Attach one of the plastic clips (two PLC 004 clips
are included with the WCA 007 WC kit) to the TV, near the
loudspeaker, as shown in the illustration.

English
16
3. For a TV: Press the microphone into the plastic clip.
4. For a TV: Turn on the TV and the Pocketalker. Adjust the volume
on both as needed.
5. To use as a lapel microphone, place MIC 014-R into optional
clip CLP 014 and attach to collar. Begin speaking and adjust
the volume as necessary.
Placement of Mic Clip on TV
A544
External
Microphone
(included)
Optional 3.5mm 12ft
extension cord (WCA 007 )
Microphone plug/jack
Headphone
jack
Earphone or
Headphone
Microphone Clip
(included with
WCA 007 WC)
MIC 014-R
External Microphone
(included)
3.5mm
12 ft Extension Cord
(WCA 007, optional)
TV Speaker
Using an Optional Neckloop
Williams Sound’s optional neckloop (NKL 001) can be used with the
Pocketalker in situations where the user has a hearing aid with a T-coil.
WARNING! To prevent strangulation, the neckloop should
not be used if there is a risk of getting it lodged or stuck in machin-
ery or other objects.
How it works: The Pocketalker picks up the sound with the
internal or external microphone, and sends it into the neckloop.
The neckloop magnetically couples with the T-coil in the listener’s
hearing aid(s). With the hearing aid T-coil switch on, the listener
can hear the sound directly in their hearing aid(s).

English
17
To use the neckloop: Place the neckloop around your neck as
shown below. While holding the housing with one hand, pull up on
the cord lock bead with the other hand to tighten for comfort. Plug
the neckloop into the headphone jack on the Pocketalker. Turn on
the T-coil in the hearing aid(s). Turn on the Pocketalker and adjust
the volume to a comfortable listening level.
Using a Neckloop
A547
Adjusting
Neckloop
Cord Lock “Bead” Pull up to tighten
Neckloop “Housing” Hold down while tightening
The NKL 001 neckloop has a safety breakaway feature
that disconnects when too much tension is applied to
the neckloop.
Operating the
Pocketalker at
a table using the
Lanyard as a
wrist strap
Pocketalker worn
hanging around
the neck with the
supplied lanyard
Note:
The RCS 003 Lanyard has a safety
breakaway feature that disconnects
when too much pressure is applied
to the lanyard.
Using the Lanyard
The supplied Pocketalker Lanyard (RCS 003) provides a convenient
way of transporting the Pocketalker from place to place; it protects your
investment from accidental dropping, and provides quick and easy access
for operation whenever it is needed.
WARNING! To prevent strangulation, the lanyard should not be
used if there is a risk of getting it lodged or stuck in machinery or other objects.

English
18
A547
Adjusting
Neckloop
Cord Lock “Bead” Pull up to tighten
Neckloop “Housing” Hold down while tightening
The NKL 001 neckloop has a safety breakaway feature
that disconnects when too much tension is applied to
the neckloop.
Operating the
Pocketalker at
a table using the
Lanyard as a
wrist strap
Pocketalker worn
hanging around
the neck with the
supplied lanyard
Note:
The RCS 003 Lanyard has a safety
breakaway feature that disconnects
when too much pressure is applied
to the lanyard.
Installing the Lanyard (RCS 003)
Step 1 Step 2 Step 3
Step 1 Step 2 Step 3

English
19
LED Indicators
Power
LED Charge LED T-Coil LED Condition Indicated
On Off Operating normally; battery level
sufficient
Fast
blinks Off Battery is low
Slow blinks Battery is charging
On (charger
plugged in) Battery charging complete
Off (charger
plugged in) No batteries detected or charger not detected
On T-coil in use; internal and external
mic jack disabled
Off T-coil not in use; internal mic enabled
(or external mic if plugged in)
Off Off Battery too low to operate
Fast blinks
Batteries are too low to charge.
PockeTalker is attempting to
recondition batteries. If fast blinks
persist for more than 2 hours,
batteries are bad; replace with new
batteries. If recondition attempt is
successful, Charge LED will change
to slow blinks, indicating that normal
charging is now occuring.
LED Blink Rates
Slow: On 1 sec, Off 1 sec
Fast: On 0.1 sec, Off 0.4 sec
Fast
Slow
0.5 Sec
0.4 Sec
Fast
Slow
1 Sec 2 Sec
0.1 Sec
3 Sec
Slow: 1 blink every 2 seconds
Fast: 4 blinks every 2 seconds

English
20
Hints & Tips / Troubleshooting
The Pocketalker has been designed to be as easy to use as
possible. However, if you have trouble, check the following:
1. If using an external microphone, make sure the microphone is
plugged into the “External Mic” jack and the T-Coil switch is
set to “O”. Make sure the earphone or headphone is plugged
into the “Headphone” jack . If using the T-Coil on the
Pocketalker, make sure the T-Coil Switch is on and verify
that the T-Coil indicator LED is lit.
2. Make sure the batteries are not depleted and have been
inserted correctly (observing correct polarity ±) into the battery
compartment.
3. If using rechargeable batteries, make sure the batteries
are suciently charged and that the battery switch is set
appropriately to the NiMH position.
4. If you experience a howling or squealing sound, this is called
feedback. Depending on the earphone or headphone used, you
can sometimes get feedback when the volume control is turned
higher than 3 or 31⁄2.
To reduce feedback, turn down the volume, or move the
microphone (internal or external) farther away from the
earphone or headphone.
Also, try turning the Tone Control down (counter-clockwise)
to reduce the high frequency.
5. The Pocketalker headphone jack is a stereo jack, designed for
use with stereo earphones or headphones. However, if you use
mono earphones or headphones with the Pocketalker, turn the
balance control (located in the battery compartment) fully to the
left, or “mono” position. While this maximizes volume, this will
also help in maximizing battery life.
6. Observe what the LED indicators on the unit are doing:
Power ON LED (on front)
Charging LED (on right side)
T-Coil LED (on right side)
See the chart under “LED Indicators” to determine unit status
and problem resolution.
7. If the steps above don’t solve the problem, contact your
Williams Sound Dealer for further instructions.
