Vented
Fireplace Logs
Enhance and revitalize the
appeal of your fireplace
with the charming realism
of handcrafted logs!
Enhance and revitalize the
appeal of your fireplace
with the charming realism
of handcrafted logs!
Design Features
Easy operation – No fuss or mess,
no creosote buildup
Eliminates costly firewood
No electricity required
Remote control sets available
Burner assemblies and logs may
be ordered separately
Natural and propane gas units
Capture the essence of a living fire in your hearth,
with a new Williams’ gas log set from our series
of handcrafted models. Each set has been
created to be indistinguishable from a log fire and
includes saw-marked ends, axe-split marks and
natural knotty wood barks around which flickering
flames surround.
Classic Split Oak
Classic BirchClassic Designer Oak
Classic Oak

* Safety Pilot Kit may be added. Model 4235 for natural gas. Model 4236 for propane gas.
** Add 6” to minimum width (front and rear) if the Gas Valve Safety Pilot Kit is used.
©2002 Williams Furnace Company Printed in U.S.A. All Rights Reserved L1140 6/02
Vented Fireplace Logs
Model
Number Log Size Btu/hr Input Dimensions Front Width/Depth Shipping Weight
WH-18R* 18” 75,000 ** 21”/16” 30 lbs.
WH-24R* 24” 90,000 ** 27”/16” 35 lbs.
WH-30R* 30” 90,000 33”/16” 40 lbs.
BURNER ASSEMBLIES
WH-18AN 18” 60,000 27”/16” 32 lbs.
WH-24AN 24” 72,000 33”/16” 37 lbs.
WH-30AN 30” 72,000 39”/16” 42 lbs.
WH-18AP 18” 40,000 27”/16” 32 lbs.
WH-24AP 24” 45,000 33”/16” 37 lbs.
WH-30AP 30” 45,000 39”/16” 42 lbs.
WH-18RMVN 18” 45,500 ** 27”/16” 32 lbs.
WH-24RMVN 24” 55,500 ** 33”/16” 37 lbs.
WH-30RMVN 30” 55,500 39”/16” 42 lbs.
WH-18RMVP 18” 40,000 ** 27”/16” 32 lbs.
WH-24RMVP 24” 45,000 ** 33”/16” 37 lbs.
WH-30RMVP 30” 45,000 39”/16” 42 lbs.
WH-18AMVN 18” 45,000 27”/16” 32 lbs.
WH-24AMVN 24” 55,500 33”/16” 37 lbs.
WH-30AMVN 30” 55,500 39”/16” 42 lbs.
WH-18AMVP 18” 40,000 27”/16” 32 lbs.
WH-24AMVP 24” 45,000 33”/16” 37 lbs.
WH-30AMVP 30” 45,000 39”/16” 42 lbs.
A = CSA; R = RADCO; N = Natural; P = Propane; MV = Millivolt
LOG SETS
Model
Number Log Size No. Logs Shipping Weight
CSA Listed - Propane Gas, Millivolt Valve (Remote Control Kit Optional)
CSA Listed - Natural Gas, Millivolt Valve (Remote Control Kit Optional)
RADCO Listed - Propane Gas, Millivolt Valve (Remote Control Kit Optional)
RADCO Listed - Natural Gas, Millivolt Valve (Remote Control Kit Optional)
CSA Listed - Propane Gas - Equipped with Pilot Safety Kit
CSA Listed - Natural Gas - Equipped with Pilot Safety Kit
RADCO Listed - Pilot Safety Kit Optional
CO-18 18” 5 20 lbs.
CO-24 24” 6 21 lbs.
Classic Oak
DO-18 18” 6 30 lbs.
DO-24 24” 7 40 lbs.
DO-30 30” 8 52 lbs.
Classic Designer Oak
SO-18 18” 6 31 lbs.
SO-24 24” 7 37 lbs.
SO-30 30” 8 50 lbs.
Classic Split Oak
CB-18 18” 6 49 lbs.
CB-24 24” 7 56 lbs.
CB-30 30” 8 75 lbs.
Classic Birch
Lava Rock
To cover the metal floor of the fireplace. Model 4222. Shipping weight
5 lbs.
Decorative Ceramic Pine Cones (set of four)
Can be placed beside the fire path. Model 4223. Shipping weight 3 lbs.
Gas Valve Safety Pilot Kit
Field converts to propane gas. Model 4236. Field converts to natural
gas. Model 4235. Shipping weight 3 lbs.
Remote Control Kit (MillivoltValveOnly)
RemoteControlKitforyourconvenience. Model 4261.
ACCESSORIES
IMPORTANT
• Read owner’s manual before using.
• Photographs are representative only.
• Check local codes and ordinances for
permitted uses.
• Consult installation manual for clearances
prior to installation.
• We reserve the right to amend product
specifications without notice.
• Installation and servicing recommended by
a qualified service person.
• Please read the warranty for any limitations
or disclaimers. All parts carry a one-year
limited warranty.
• Specify propane or natural gas when
ordering. Units are not intended for
conversion between fuel types.
•Burner assemblies are interchangeable
with all log sets. Both CSA and RADCO
burner assemblies include: Heavy gauge
steel burner pan, steel bar grate, sand
(natural gas models), lava rock, burning
embers, complete hardware for gas
connection and damper clamp.
•CSA listed models are equipped with a
safety pilot or millivolt control system.
CSA approved propane models include
vermiculite instead of sand.
FEATURES
250 West Laurel Street • Colton, CA 92324 • U.S.A .
[phone]
Fax [phone] or [phone]
24 Hour Homeowner Assistance: 909-426-0978
www.williamscomfortprod.com
