WilTec TMHT230B User manual

Operation Manual
Hedge Trimmer
61493
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

© by WilTec Wildanger Technik GmbH Item 61493 Page 2
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
The information contained in this document may alter at any time without previous notice. It is prohibited
to copy or spread any parts of this document in any way without prior written allowance. All rights re-
served.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
Do you wish to pick goods up? Our pick-up address is:
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
Germany
To shorten the waiting time and allow for a rapid on-site transaction, we ask you to call us previously or
placing your order via the webshop.
E-mail: [e-mail]
Tel:[phone]
Fax: [phone]
To return orders for exchange, repair or for other purposes, please use the following address. Attention!
To allow for a smooth execution of your complaint or return, it is important to contact our customer
service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [email protected]o
Tel:[phone]
Fax: [phone]

© by WilTec Wildanger Technik GmbH Item 61493 Page 3
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Safety first
Instructions contained in warnings within this manual marked with the symbol concern critical
points which must be taken into consideration to prevent possible serious injury, and for this reason you
are requested to read all such instructions carefully and strictly follow them.
Warnings in the manual
WARNING –This mark indicates instructions which must be followed in order to prevent
accidents which could lead to serious bodily injury or death.
IMPORTANT –This mark indicates instructions which must be followed, or mechanical fail-
ure, breakdown, or damage may result.
NOTE –This mark indicates hints or directions useful in the use of the product.
Parts list
№
Name
№
Name
1
Fuel tank
6
Muffler
2
Starter
7
Blade
3
Throttle lever
8
Front handle
4
Ignition switch
9
Rear handle
5
Throttle cable

© by WilTec Wildanger Technik GmbH Item 61493 Page 4
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Specifications
Model
TMHT230B/TMHT260B/TMHT230B-2/TMHT260B-2
Type
Reciprocating double-sided dual blades
Dry weight (㎏)
6.5
Blade size (㎜)
550 / 620
Blade pitch (㎜)
28
Transmission
Centrifugal clutch, cam-crank
Engine
Type
Air-cooled 2-stroke gasoline
Model
1E32F/1E34F
Displacement (㎤)
22.5 / 25.4
Max. output (㎾)
0.9 at 7500 rpm
Idle speed (rpm)
2800 ± 200
Fuel
Mixture (gasoline : oil = 40 : 1)
Fuel tank capacity (ℓ)
0.58
Sound pressure level (dB (A))
97.7; K = 3
Sound power level (dB (A))
107.7; K = 3
Sound power level LwA (dB)
110
Vibrations front handle (㎧²)
6.984
Vibrations rear handle (㎧²)
8.293; K = 1.5
Warning labels on the machine
Symbols
Meaning
Read owner’s manual before operating this machine.
Wear head, eye, and ear protection.
Handling this machine improperly could result in accidents causing serious injury or
death. Read this manual carefully and practice using the hedge trimmer until you are
fully acquainted with all operations and have learned to use it correctly.
Device is extremely sharp and can easily cause cuts.
IMPORTANT: If warning labels peel off or become soiled and impossible to read, you should con-
tact the dealer who you purchased the product from to order new labels and fix them in the required
location(s).

© by WilTec Wildanger Technik GmbH Item 61493 Page 5
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
WARNING: Never modify your hedge trimmer. We shall not warrant the machine if you modify the
hedge trimmer or if you do not observe the proper usage described in this manual.
Symbols on the machine
For safe operation and maintenance, symbols are carved on the machine. According to these indica-
tions, please be careful not to take a mistake.
(a) Port to refuel the “MIX GASOLINE”
Position: FUEL TANK CAP
(b) The direction to close the choke
Position: AIR CLEANER COVER
(c) The direction to open the choke
Position: AIR CLEANER COVER
For safe operation
THIS MACHINE CAN CAUSE SERIOUS INJURIES. Read this manual carefully
until you completely understand and follow all safety and operating instructions.
Know how to stop the machine quickly in an emergency, too.
1. Keep this manual handy so that you may refer to it later whenever any
questions arise. Note as well that, if you have any questions which can-
not be answered herein, you should contact the dealer from whom you
purchased the product.
2. Always be sure to include this manual when selling, lending, or other-
wise transferring the ownership of this product.
3. Never allow children or anyone unable to fully understand the directions
given in the manual to use the machine.
Working condition
1. When using the product, you should wear proper clothing and protective
equipment:
◦Helmet
◦Ear protectors
◦Protection goggles or face protector
◦Thick work gloves
◦Non-slip-sole work boots

© by WilTec Wildanger Technik GmbH Item 61493 Page 6
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
2. And you should carry with you
◦Attached tools
◦Properly reserved fuel
◦Spare blade
◦Things to notify your working area (rope, warning signs)
◦Whistle (for collaboration or emergency)
◦Hatchet or saw (for removal of obstacles)
◦First-aid kit
3. Do not wear loose clothing, jewellery, short trousers, sandals, or go
barefoot. Do not wear anything which might be caught by a moving part
of the unit. Secure hair so it is above shoulder length.
Working circumstance
•Never start the engine inside a closed room or building. Exhaust gases
contain dangerous carbon monoxide.
•Never use the product,
◦when the ground is slippery or when you cannot maintain a steady
posture.
◦at night, at times of heavy fog, or at any other times when your
field of vision might be limited and it would be difficult to gain a
clear view of the working area.
◦during rain storms, during lightning storms, at times of strong or
gale-force winds, or at any other times when weather conditions
might make it unsafe to use the product.
Working plan
•You should never use the product when under the influence of alcohol
or drugs, when suffering from exhaustion or lack of sleep, when suf-
fering from drowsiness as a result of having taken cold medicine or at
any other time when there is a possibility that your judgment might be
impaired or that you might not be able to operate the product properly
and in a safe manner.
•When planning your work schedule, allow plenty of time to rest. Limit
the amount of time over which the product is to be used continuously
to somewhere around 30–40 min per session, and take 10–20 min of
rest between work sessions. Also try to keep the total amount of work
performed in a single day under 2 hours or less.
WARNING
1. If you do not observe the working time, or working manner (See “US-
ING THE PRODUCT”), Repetitive Stress Injury (RSI) could occur. If
you feel discomfort, redness and swelling of your fingers or any other
part of your body, see a doctor before getting worse.
2. To avoid noise complaints, in general, operate the product between
8 a. m. and 5 p. m. on weekdays and 9 a. m. to 5 p. m. on weekends.
NOTE: Check and follow the local regulations as to sound level and
hours of operations for the product.

© by WilTec Wildanger Technik GmbH Item 61493 Page 7
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Before starting the engine
1. The area within a perimeter of 15 m (50 ft) of the person using the product should be considered
a hazardous area into which no one should enter. If necessary, yellow warning rope and/or
warning signs should be placed around the perimeter of the area. When work is to be performed,
care should also be taken to constantly look around or otherwise check for the presence and
locations of other people working so as to maintain a distance between each person sufficient
to ensure safety.
2. Check the condition of working area to avoid any accident by hitting hidden obstacles such as
stumps, stones, cans, or broken glass.
IMPORTANT: Remove any obstacle before beginning work.
3. Inspect the entire unit for loose fasteners and fuel leakage. Make sure that the cutting attach-
ment is properly installed and securely fastened.
Starting the engine
1. Keep bystanders, especially children, and animals at least 15 m (50 ft) away from the operating
point. If you are approached, immediately stop the engine.
2. The product is equipped with a centrifugal clutch mechanism; so the cutting attachment might
begin to rotate as soon as the engine is started. When starting the engine, place the product
onto the ground in a flat clear area and hold it firmly in place so as to ensure that neither the
cutting part nor the throttle come into contact with any obstacle when the engine starts.
WARNING: Never place the throttle into the high-speed position when starting the en-
gine. Never start the engine at the cutting attachment side.
3. After starting the engine, check to make sure that the cutting attachment stops rotating when
the throttle is moved fully back to its original position. If it continues to rotate even after the
throttle has been moved fully back, turn off the engine and take the unit to your authorized
servicing dealer for repair.
Using the product
IMPORTANT: Cut only materials recommended by the manufacturer, and only use the device for
tasks explained in the manual.
1. Grip the handles firmly with both hands using your whole hand. Place your feet slightly apart
(slightly further apart than the width of your shoulders) so that your weight is distributed evenly
across both legs, and always be sure to maintain a steady, even posture while working.
2. Maintain the speed of the engine at the level required to perform cutting work, and never raise
the speed of the engine above the level necessary.
3. If the unit starts to shake or vibrate, turn off the engine and check the whole unit. Do not use
it until the trouble has been properly corrected.
4. Keep all parts of your body away from rotating cutting attachment and hot surfaces.
5. Never touch the muffler, spark plug, or other metallic parts
of the engine while the engine is in operation or immedi-
ately after shutting down the engine. Doing so could result
in serious burns or electrical shock.

© by WilTec Wildanger Technik GmbH Item 61493 Page 8
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
5. While operating the machine, be always sure of a safe and secure operating position especially
when using steps or a ladder.
If someone comes
1. Guard against hazardous situations at all times. Warn adults to
keep pets and children away from the area. Be careful if you are
approached. Injury may result from flying debris.
2. If someone calls out or otherwise interrupts you while working,
always be sure to turn off the engine before turning around.
(1) Check if everything is
alright!
Maintenance
1. In order to maintain your product in proper working order, perform the maintenance and check-
ing operations described in the manual at regular intervals.
2. Always be sure to turn off the engine before performing any maintenance, checking procedures,
or working on the machine.
WARNING: The metallic parts reach high temperatures immediately after stopping the engine.
3. When replacing the cutting attachment or any other part, or when replacing the oil or any lubri-
cant, always be sure to use only products which have been certified for use with the product.
4. In the event that any part must be replaced or any maintenance or repair work not described in
this manual must be performed, please contact a qualified workshop for assistance.
5. Do not use any accessory or attachment other than those bearing the mark and recommended
for the unit.
6. Under no circumstances should you ever take apart the product or alter it in any way. Doing so
might result in the product becoming damaged during operation or the product becoming unable
to operate properly.
Handling fuel
1. The engine of the product is designed to run on a mixed fuel, which con-
tains highly flammable gasoline. Never store cans of fuel or refill the tank
of the unit in any place where there is/are a boiler, stove, wood fire, elec-
trical sparks, welding sparks, or any other source of heat or fire which might
ignite the fuel.
2. Never smoke while operating the unit or refilling its fuel tank.
3. When refilling the tank, always turn off the engine and allow it to cool down.
Take a careful look around to make sure that there are no sparks or open
flames anywhere nearby before refuelling.
4. Wipe spilled fuel completely using a dry rag if any fuel spillage occurs dur-
ing refuelling.
5. After refuelling, screw the fuel cap back tightly onto the fuel tank and then
carry the unit to a spot 3 m or more away from where it was refuelled before
turning on the engine.
6. Do not inhale fuel fumes as they are toxic.
(1) Refill after the
engine has cooled
down!

© by WilTec Wildanger Technik GmbH Item 61493 Page 9
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Transportation
1. When you hand-carry the product, covers over the cutting part are necessary; lift up the product
and carry it paying attention to the blade.
2. Never transport the product over rough roads over long distances by vehicle without removing
all fuel from the fuel tank. If doing so, fuel might leak from the tank during transport.
Fuel
WARNING: Gasoline is very flammable. Avoid smoking or bringing any
flame or sparks near fuel. Make sure to stop the engine, and allow it cool down
before refuelling the unit. Select outdoor bare ground for fuelling, and move at
least 3 m (10 ft) away from the fuelling point before starting the engine.
Gasoline requirements
•All 2-stroke products are powered by professional-commercial duty, hi-performance, hi-RPM,
air cooled 2-stroke engines.
•Hi-performance 2-stroke engines produce higher HP outputs as compared to standard home
owner duty or light commercial duty production engines offered by most manufacturers. Exhaust
emission are controlled by the fundamental engine parameters and components (eq., carbure-
tion, ignition timing and port timing) without addition of any major hardware or the introduction
of an inert material during combustion.
Gasoline/oil mixture storage recommendations
Store your gasoline or gasoline/oil mixture in a cool dry area in a tightly sealed approved container to
limit the entry of moisture and additional air (oxygen). Moisture and air cause the development of varnish
and gum, making the fuel stale. Stored gasoline and gasoline/oil mixture ages and loses its octane rating
and volatility. Do not mix more gasoline/oil than you intend to use in 30 days, and 60 days when fuel
stabilizer is added.
How to mix fuel
Recommended mixing ratio gasoline/oil 40:1. Pay attention to agitation.
1. Measure out the quantities of gasoline and oil to be mixed.
2. Put some of the gasoline into a clean, approved fuel container.
3. Pour in all of the oil and agitate well for 10 s.
4. Pour in the rest of gasoline and agitate again for at least 1 min. As some oils may be difficult to
agitate depending on oil ingredients, sufficient agitation is necessary. Be careful that, if the ag-
itation is insufficient, there is an increased danger of early piston seizure due to abnormally lean
mixture.
5. Place a clear indication on the outside of the container to avoid mixing up with gasoline or other
containers that do not contain oil.
6. Indicate the contents on outside of container for easy identification.
Fuelling the unit
1. Untwist and remove the fuel cap. Put the cap on a clean surface.
2. Put fuel into the fuel tank to 80 % of the full capacity.
3. Fasten the fuel cap securely and wipe up any fuel spillage around the unit.

© by WilTec Wildanger Technik GmbH Item 61493 Page 10
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
WARNING
1. Select flat and bare ground for fuelling.
2. Move at least 3 m (10 ft) away from the fuelling point before starting the engine.
3. Stop the engine before refuelling the unit (this time to be sure to sufficiently agitate the mixed
gasoline in the container).
For the service life of your engine, avoid
1. fuel with no oil (raw gasoline), which will cause severe damage to the internal engine parts
very quickly.
2. gasohol, which can cause deterioration of rubber and/or plastic parts and disruption of engine
lubrication.
3. oil for 4-stroke engine use, which can cause spark plug fouling, exhaust port blocking, or
piston ring seizure.
4. mixed fuels which have been left unused for a period of one month or more may clog the
carburettor and result in the engine failing to operate properly.
5. In the case of storing the product for a long period of time, clean the fuel tank after emptying it
. Next, start the engine and run the carburettor dry of residual fuel.
6. In the case of scrapping the used mixed oil container, scrap it only at an authorized depository
site.
NOTE: Normal wear and change in product with no functional influence are not covered by the
warranty. Also, be careful that, if the usage in the instruction manual is not observed as to the mixed
gasoline, type of oil or fuel to be used described therein, it may not be covered by the warranty.
Operation
Starting engine
WARNING: Keep the blades clear of the surrounding as they will start moving upon starting of
the engine.
1. When first starting up after putting fuel into the machine, push the priming
pump until fuel runs out in the clear tube. Then close the choke. Choking
may not be necessary when re-starting right after stopping the engine
(OP1).
(1) primer pump,
(2) choke lever,
(3) CLOSE,
(4) OPEN
2. Pull the throttle lever and push the lock button to set the lever in the
START position (OP2).
(1) throttle lever,
(2) lock button

© by WilTec Wildanger Technik GmbH Item 61493 Page 11
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
3. Slide the ignition switch to the engine side to set it in the ON position
(OP3).
4. Rest the unit on a firm place. Pull the starter knob quickly (OP4).
NOTE: Avoid pulling the rope to its end or returning it by releasing the knob.
Such actions can cause starter failures.
5. When the engine has started, gradually open the choke.
6. Allow the engine to warm up for half a minute before starting operation.
NOTE: If the engine would not start after several attempts, open the choke
and repeat pulling the rope or remove the spark plug and dry it.
Stopping the engine
1. Release the throttle lever and run the engine at idling speed for half a minute.
2. Slide the ignition switch to the STOP position.
IMPORTANT: Except for an emergency, avoid stopping the engine while pulling the throttle lever.
NOTE: If the engine would not stop when setting the ignition switch to the stop position, close the
choke lever and stop the engine. In this case, please have the machine repaired at a qualified workshop.
Adjusting idling speed
When the engine tends to stop frequently at idling mode, turn the idle set screw clockwise.
NOTE
1. Idle set screw is (1).
2. When the cutting blades keep moving after releasing the throttle trigger, turn the idle set screw
counter-clockwise. Warm up the engine before adjusting the idling speed.

© by WilTec Wildanger Technik GmbH Item 61493 Page 12
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
How to use
•The blades spacing is 28 mm. Cutting too thick twigs or metal wires can not only break the blade
teeth but also give damage to the drive mechanism. When trimming leaves and thin twigs, guide
the blades as drawing a half circle on the surface, and you will get a better finish.
•Running the engine at high speed with the blades jammed up can shorten the life of clutch parts.
When the blades have been jammed by thick twigs, stop operation at once and draw your unit
off the objects after stopping the engine. When clipping comparatively thick twigs, move your
unit slowly back and forth like a saw, and they can be cut to a fine finish.
NOTE: When a new unit is first operated, in the first few minutes grease may come out of the gear
case. But, since this is excess grease, there is no cause for alarm. For next use, just wipe it off with the
engine stopped.
Hedge trimming techniques
Trim sides of a hedge first and then top.
Vertical cut:
With the 2-sided blade model CHT2250, perform an arcing cut from the bottom
upwards, then downwards to use both sides of the blades (OP7).
Horizontal cut:
In order to get the best cutting results, slightly tilt the blade (5°–10°) towards the
cutting direction (OP8). Cut slowly, especially with thick hedges.
WARNING: Always follow the safety precautions. The hedge-trimmer must only be used to trim
hedges or small bushes. It is forbidden to cut other types of material. Do not use the hedge-trimmer as
a lever to lift, move, or break objects, nor lock it on fixed supports. It is forbidden to apply tools or
applications that are not the ones indicated by the manufacturer onto the power take-off of the hedge-
trimmer. Do not use it for pruning trees or cutting grass.

© by WilTec Wildanger Technik GmbH Item 61493 Page 13
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Maintenance
Maintenance chart
System/components
Procedure
Be-
fore
use
After every
Note
25
50
100
hours of use
E
N
G
I
N
E
Fuel leaks, fuel spillage
Wipe out
X
Fuel tank, air filter, fuel filter
Inspect/clean
X
X
Replace, if necessary
Idle adjusting screw
See adjusting
idling speed
X
Replace carburettor if
necessary
Spark plug
Clean and read-
just plug gap
X
GAP: 0.65 mm
Replace, if necessary
Cylinder fins, intake air cooling
vent
Clean
X
Muffler, spark arrester, cylin-
der exhaust port
Clean
X
T
R
I
M
M
E
R
Throttle lever, ignition switch
Check operation
X
Cutting parts
Replace if some-
thing is wrong
X
Gear case
Grease
X
Screws/nuts/bolts
Tighten/replace
X
X
Not adjusting screws
Debris guard
Make sure to at-
tach
X
WARNING: Make sure that the engine has stopped and cooled down before performing any ser-
vice to the machine. Contact with moving cutting head or hot muffler may result in a personal injury.
Air filter (MA1)
The air filter, if clogged, will reduce the engine performance. Check and clean the filter
element in warm, soapy water as required. Dry completely before installing. If the ele-
ment is broken or shrunk, replace with a new one (MA1).
(1) air filter
Fuel filter (MA2)
When the engine runs short of fuel supply, check the fuel cap and the fuel filter for
blockage.
(1) fuel filter
Spark plug
Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark
plug and check that the plug gap is in the correct range. For a replacement plug, use
the correct type. REPLACEMENT PLUG IS LD L8RTF!
IMPORTANT: Note that using any spark plug other than those designated may result in the engine
failing to operate properly or in the engine becoming overheated and damaged. To install the spark plug,

© by WilTec Wildanger Technik GmbH Item 61493 Page 14
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
first turn the plug until it is finger tight, then tighten it a quarter turn more with a socket wrench. TIGHT-
ENING TORQUE IS: 9.8–13.7 Nm (87–121 in-lbs)!
WARNING: Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any
sign of exhaust leakage is found, stop using the machine and have it repaired immediately. Note that
failing to do so may result in the engine catching on fire.
Spark arrester (MA4)
The muffler is equipped with a spark arrester to prevent red hot carbon from flying
out of the exhaust outlet. Periodically inspect and clean as necessary with a wire
brush. In some countries, it might under certain circumstances be required by law
to equip a spark arrester.
(1) spark arrester
Intake air cooling vent (MA5)
WARNING: Never touch the cylinder, muffler, or spark plugs with your bare
hands immediately after stopping the engine. The engine can become very hot
when in operation, and doing so could result in severe burns. Clean the cylinder
fins with compressed air or a brush.
(1) cylinder, (2) in-
take air cooling
vent (back)
IMPORTANT: If waste gets stuck and causes blockage around the intake air cooling vent or be-
tween the cylinder fins, it may cause the engine to overheat, and that in turn may cause mechanical
failure on the part of the hedge-trimmer.
Blades (MA6)
Oil blades each gas tank filling.
WARNING: Make sure that the blade bolts are well tightened. The blade as-
sembly is designed to automatically compensate for any play between the blades.
Sharpening (MA7)
Always keep the file or sharpener at an angle of 45° to the blade, and always grind
in the direction of the cutting edge.
Note: Files cut only in one direction. Lift the file from the blade when returning
to start a new pass. Remove every burr from the edge of the blade with a slip stone.
Remove as little material as possible. Before refitting the sharpened blades, re-
move filings and then apply grease. Do not try to sharpen a damaged blade:
change it or take it to a qualified workshop.

© by WilTec Wildanger Technik GmbH Item 61493 Page 15
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Reduction gearbox (MA8)
Refill gear housing every 25 working hours. Use grease pump. Feed grease until
it comes out of the base of blades.
Procedures to be performed after every 100 hours of use (M9)
1. Remove the muffler, insert a screwdriver into the vent, and wipe away any
carbon build-up. Wipe away any carbon build-up on the muffler exhaust
vent and cylinder exhaust port at the same time.
2. Tighten all screws, bolts, and fittings.
3. Check to see if any oil or grease has worked its way in between the clutch
lining and drum, and if so, wipe it clean.
Storage
1. Oil the blade to prevent rust.
2. Empty the fuel tank and put the cap back on.
3. Remove the spark plug and pour a small amount of oil into the cylinder.
4. Rotate the crankshaft several times using the starting rope in order to distribute the oil. Put the
spark plug back in.
5. Wrap the engine with a plastic sheet.
6. Store the trimmer in a dry place, preferably not in direct contact with the floor and away from
heat sources.
Disposal
When disposing your machine, fuel or oil for the machine, be sure to respect all local regulations.

© by WilTec Wildanger Technik GmbH Item 61493 Page 16
http://www.WilTec.de
http://www.aoyue.eu 06 2021-1
http://www.teichtip.de
Troubleshooting
Case 1: Starting failure
CHECK
PROBABLE CAUSES
ACTION
Fuel tank
Incorrect fuel
Drain it and fill in correct fuel.
Fuel filter
Fuel filter is clogged
Clean.
Carburettor adjustment screw
Out of normal range
Adjust to normal range.
Sparking (no spark)
Spark plug is fouled/wet
Clean/dry.
Sparking (no spark)
Plug gap is incorrect
Correct (gap: 0.65 mm).
Spark plug
Disconnected
Re-tighten.
Case 2: Engine starts but does not keep running/re-starting is very hard
CHECK
PROBABLE CAUSES
ACTION
Fuel tank
Incorrect fuel or staled fuel
Drain it and fill in correct fuel.
carburettor adjustment screw
Out of normal range
Adjust to normal range.
Muffler, cylinder (exhaust port)
Carbon is built-up
Wipe away.
Air cleaner
Clogged with dust
Wash.
Cylinder fin, fan cover
Clogged with dust
Clean.
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part, of this instruction
manual require the written permission of WilTec Wildanger Technik GmbH.
