Winco SPECTRUM ECT-300 Supplement

ELECTRIC COUNTERTOP
CONVEYOR TOASTER
Installation and Operating Instruction Manual
BEFORE OPERATING ANY EQUIPMENT, READ AND FAMILIARIZE YOURSELF WITH THESE USE AND SAFETY INSTRUCTIONS
Congratulations on your purchase of this SPECTRUM commercial equipment. When used as intended, and with
proper care and maintenance, you are sure to experience years of reliable operation from this equipment. To ensure
best results, it is important that you read and follow the instructions in this manual carefully. It is important to
keep these instructions in a safe place for future reference.
Model Voltage Frequency Power Amperage P lu g Ty pe
Overall Dimensions
Weight
Width Depth Height
ECT-300 120V 50/60 1800W 15A
NEMA 5-15P
14-5/8"
(370mm)
16-9/16"
(420mm)
16-3/8"
(415mm)
40.5 lbs
18.3 kgs
NEMA 5-20P
(Canada)
ECT-700 208/240V 50/60 Hz 1800/2400W 8.6/10A NEMA 6-15P
Form No. ECT-Series Manual - 03/21
ECT-700
ECT-300
For California Customers
WARNING:

CAUTION:

ATTENTION:

300
700
SLICES
PER
HOUR
SLICES
PER
HOUR
Visit www.wincous.com for manuals in English & Spanish
Visite www.wincous.com para ver manuales en inglés y español.

2
Electric Countertop Conveyor Toaster
Important For Future Reference
Introduction
Congratulations on the purchase of your SPECTRUM™ Commercial
Conveyor Toaster. Please take time to carefully read through this
manual to ensure the machine is operated and maintained properly, to
ensure the best possible performance from the product for many years.
SPECTRUM will not accept liability for the following if:
• The instructions in this manual have not been followed correctly.
• Non-authorized personnel have tampered with the machine.
• Non-original spare parts are used.
• The machine has not been handled and cleaned correctly.
• There is any use damage to the unit.
Immediately Inspect for Shipping Damage
All containers should be examined for damage before and during
unloading. The freight carrier has assumed responsibility for its safe
transit and delivery. If equipment is received damaged, either apparent
or concealed, a claim must be made with the delivering carrier.
A. Apparent damage or loss must be noted on the freight bill
at the time of delivery. It must then be signed by the carrier
representative (Driver). If this is not done, the carrier may refuse
the claim. The carrier can supply the necessary forms.
B. If concealed damage or loss is not apparent until after equipment
is uncrated, a request for inspection must be made to the carrier
within 15 days. The carrier should arrange an inspection. Be certain
to keep all contents and packaging material.
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or parts, this information is required.
Model Number Serial Number Date Purchased
! !
WARNING: IMPROPERINSTALLATION,ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE
PROPERTY DAMAGE, INJURY, OR DEATH. READ THE
INSTALLATION, OPERATION, AND MAINTENANCE
INSTRUCTIONS THOROUGHLY BEFORE INSTALLING
OR SERVICING THIS EQUIPMENT.
AVERTISSEMENT: TOUTE INSTALLATION, RÉGLAGE,
MODIFICATION, RÉPARATION OU ENTRETIEN
INCORRECT PEUT OCCASIONNER DES DOMMAGES
MATÉRIELS, DES BLESSURES GRAVES OU LA MORT.
LIRE LES INTRUCTIONS D'INSTALLATION, D'UTILISATION ET
D'ENTRETIEN ATTENTIVEMENT AVANT D'INSTALLER OU DE
RÉPARER CET APPAREIL.
! !
CAUTION: THESEMODELSAREDESIGNED,BUILT,AND
SOLD FOR COMMERCIAL USE ONLY. IF THESE MODELS
ARE POSITIONED SO THE GENERAL PUBLIC CAN USE
THE EQUIPMENT, MAKE SURE THAT CAUTION SIGNS,
WARNINGS, AND OPERATING INSTRUCTIONS ARE
CLEARLY POSTED NEAR EACH UNIT SO THAT ANYONE
USING THE EQUIPMENT WILL USE IT CORRECTLY AND
NOTINJURETHEMSELVESORHARMTHEEQUIPMENT.
ATTENTION: CES MODÈLES SONT CONÇUS, FABRIQUÉS,
ET VENDUS POUR UN USAGE COMMERCIAL SEULEMENT.
SI CES MODÈLES SONT PLACÉS POUR QUE LE GRAND
PUBLICPUISSELESUTILISER,ASSUREZ-VOUSQUELESCONSIGNES
D’ATTENTION, D'AVERTISSEMENT, ET LES INSTRUCTIONS
D'UTILISATION SOIENT CLAIREMENT AFFICHÉES PRÈS DE
CHAQUEUNITÉDE SORTEQUEN'IMPORTEQUELUTILISATEURDE
L'APPAREIL L'EMPLOIE CORRECTEMENT ET NE SE BLESSE PAS OU
N'ENDOMMAGE PAS L'APPAREIL.
! !
WARNING: A FACTORY AUTHORIZED SERVICE
PROVIDER SHOULD HANDLE ALL MAINTENANCE
AND REPAIR. BEFORE DOING ANY MAINTENANCE
OR REPAIR, FOLLOW SERVICE SET UP ARRANGEMENT
ON PAGE 11.
AVERTISSEMENT: UN TECHNICIEN AUTORISÉ PAR
L'USINE DEVRA EFFECTUER TOUT L'ENTRETIEN ET LES
RÉPARATIONS. AVANT DE FAIRE TOUT ENTRETIEN OU
RÉPARATION, VEUILLEZ CONTACTER WINCO.

3
Electric Countertop Conveyor Toaster
Table of Contents
Specications .............................................................................. 1
Warnings ..................................................................................... 2
Introduction ................................................................................ 2
Packaging .................................................................................... 3
Installation .................................................................................. 4
Operation .................................................................................... 5
Cleaning, Care & Maintenance ................................................. 6
Safety ........................................................................................... 6
Troubleshooting ......................................................................... 7
Service & Repair .......................................................................... 7
Exploded View ........................................................................... 8
Spare Parts List............................................................................ 9
Electrical Diagram .................................................................... 10
Limited Warranty ......................................................................11
Package Contents
All units come with an Operating Instruction Manual and the following:
• SPECTRUM™ Commercial Conveyor Toaster
• Crumb Tray
• Four (4) Legs
• Feeder Rack
SPECTRUM prides itself on quality and service, ensuring that at the
time of packing, all products are supplied fully functional and free
of damage. Should you nd any damage as a result of freight, please
contact your SPECTRUM dealer immediately.
Unpacking the Equipment
DISPOSE OF ALL PACKAGING MATERIALS IN AN
ENVIRONMENTALLY RESPONSIBLE MANNER.
1. Remove all packing materials and tape, as well as any protective
plastic and cardboard, from the unit.
2. Clean any glue residue left over from the plastic or tape.
3. Place the unit in the desired position and height.
Please keep this manual in a safe place for future use!
Installation and start-up must be performed by a qualified installer who has thoroughly read, understands and follows these instructions.
NOTE
Please remember that this manual and the warning labels do not replace the need to be alert, to properly train and
supervise operators, and to use common sense when using this equipment.
• Return Chute
• Pass-Through Chute

4
Installation
2. Remove the SPECTRUM™ Commercial Conveyor Toaster from the
packaging. Be certain that all protective plastics and residues are
thoroughly cleaned from its surface.
3. Place the Conveyor Toaster on a rm level surface; the adjustable
feet can assist in leveling.
Local standards and regulations should be consulted in order to
abide by standards set in relation to positioning, spacing, and
ventilation. SPECTRUM recommends that you allow no less than 4”
for a ventilation gap around the perimeter of this unit. Common
sense should be used when choosing position and operation of this
product.
4. The installation of the unit must conform to the NATIONAL
ELECTRIC CODE, ALL LOCAL ELECTRIC CODES AND ORDINANCES, AND
ALL THE LOCAL ELECTRICAL COMPANY RULES AND REGULATIONS.
Additionally, we recommend a 4" spacing surrounding the unit in
order to provide adequate ventilation.
5. Proper connections and power supply are essential for ecient
performance. Supply the appropriate power and connect to
source; the Conveyor Toaster is now ready to turn on and operate.
(For power supply please see technical specification on page 1).
Fournir l'alimentation secteur appropriée et brancher l’appareil à la
source d'alimentation ; votre Grille-pain à Convoyeur est maintenant
prête à être allumée et à fonctionner. (Pour l’alimentation, veuillez
voir la che technique, page 1).
6. The ECT-300 units are wired to be used with a 120V, NEMA 5-15R or
5-20R receptacle on a dedicated circuit.
7. The ECT-700 units are wired to be used with a 208/240V,
NEMA 6-15R receptacle on a dedicated circuit.
8. The Conveyor Toaster can operate as a pass-through operation
or return operation. Please follow the instructions for the
appropriate/required method.
Votre Grille-pain à Convoyeur peut fonctionner avec un seul passage
ou avec aussi un passage de retour. Veuillez voir les schémas
ci-dessous et suivez les instructions pour la méthode appropriée
nécessaire.
These instructions should be followed at all times. Failure to follow
these instructions could result in injury to yourself and others.
TO REDUCE RISK OF INJURY OR DAMAGE TO THE UNIT:
1. Read this manual thoroughly before installation and operation.
DO NOT proceed with installation and operation if you have any
questions or do not understand anything in this manual. Contact
your representative or the manufacturer rst.
Fire Hazard.
Correct installation precautions,
procedures and regulations
must be followed. Operation
and safety training is necessary
for all users of this equipment.
Risque d'incendie
La surchaue des vapeurs d'huile ou de
l'huile peut s'enammer et provoquer
un incendie. Surveillez la température,
la qualité et le niveau d’huile. Utilisez et
entretenez le système d'élimination des
vapeurs d'huile.
The equipment must be
installed by qualied personnel
only. Correct installation
precautions, procedures and
regulations must be followed
in order to reduce the risk of
re. Hood and re suppression
systems must be maintained
per manufacturer's guidelines.
Only qualied and trained
personnel are to use this
equipment.
Faire chauer l'huile avec précaution. Si
l'huile fume, réduire le feu. Ne pas laisser
l'appareil sans surveillance. Si le feu se
produit, éteindre l'appareil, couvrir jusqu'à
refroidissement. Ne pas mettre l'eau dans
l'huile chaude ou enammée. Ne faites pas
fonctionner avec de l'huile sous la barre
d'huile. L’huile sale a un point d'éclair
plus bas. Remplacer l'huile sur une base
régulière. Maintenir le niveau d'huile
correct. Utiliser un système d'évacuation
de la vapeur d'huile (capot) pour réduire
l'accumulation de graisse et d'huile sur les
surfaces de paroi ou de plafond.
WARNING AVERTISSEMENT
ATTENTION
Proper Grounding · Mise à la terre correcte
This machine is provided with a three-pronged
grounding plug. The outlet to which this plug
is connected must be properly grounded. If the
receptacle is not the proper grounding type, contact an
electrician. DO NOT, under any circumstances, cut
or remove the third ground prong from the power cord
or use any adapter plug.
Cette machine est équipée d'une che à trois broches.
La prise sur laquelle cette che est branchée doit être
correctement mise à la terre. Si la prise n'est pas le type de
mise à la terre, contactez avec un électricien. NE PAS, en
aucun cas couper ou enlever la troisième broche de terre à
partir du cordon d'alimentation ou utiliser un adaptateur.
USE A GROUNDED OUTLET
DO NOT ADD AN ADAPTOR
TO THE PLUG
UTILISER UNE PRISE AVEC MISE
À LA TERRE NE PAS AJOUTER UN
ADAPTATEUR SUR LA FICHE
Electrical Shock Hazard
Keep water and other liquids
from entering the inside of the
unit. Liquid inside the unit could
cause an electrical shock.
Risque de choc électrique
Conserver l'eau et d'autres liquides
de pénétrer à l'intérieur de l'appareil.
Liquide à l'intérieur de l'appareil pourrait
provoquer un choc électrique.
Do not spray water or cleaning
products. Liquid could contact
the electrical components
and cause a short circuit or an
electrical shock. Do not use unit
if power cord is damaged or has
been modied.
Ne pas pulvériser de l'eau ou des produits
de nettoyage. Le liquide pourrait contacter
avec les composants électriques et causer
un court-circuit ou un choc électrique.
Ne pas utiliser l'appareil si le cordon
d'alimentation est endommagé.
ou a été modié.
WARNING AVERTISSEMENT
Do not position or operate near combustible materials/ammable
objects.
Ne pas placer ni faire fonctionner l'appareil près de
matériels combustibles ou d'objets inflammables.
Once the Conveyor Toaster has been placed in position, be sure that
the stainless steel waste tray is correctly positioned.
Une fois que votre Grille-pain à Convoyeur est mise en
place, veillez à ce que le bac à déchets en acier inoxydable
soit correctement placé.
CAUTION

5
Operation
Heating Elements & Doneness Selector
The Conveyor Toaster has upper and lower heating elements which can
be used together or alternatively; the top element can be used on its
own. This can provide exibility when toasting and grilling.
To operate, turn the HEATING ELEMENT Dial to the desierd selection
(see diagram below):
A. BOTH ELEMENTS: Provides full power to both the upper and
lower elements.
B. TOP ELEMENT: Provides full power to the upper element only.
C. ENERGY SAVER-HOLD: Reduces power to unit when not in use,
keeping it warm for fast heat up when required.
Additionally, the speed of the conveyor can be controlled using the
DONENESS SELECTOR Dial, to determine the darkness/lightness of the
toasted products.
• Adjusting the "DONENESS SELECTOR" to "LIGHT" will INCREASE the
conveyor speed, resulting in Lighter toasted products.
• Adjusting the "DONENESS SELECTOR" to "DARK" will SLOW the
conveyor speed, resulting in Darker toasted products.
Using the Pass-Through & Return Chutes
• To use the pass-through chute: 1) Attach the pass-through chute
to the screws below the rear discharge door, 2) Release the back
door chute to create a bridge from the conveyor belt to the rear
discharge.
• To use the return chute: 1) Attach the return crumb tray to
the ledge just below the rear discharge door, 2) Close the rear
discharge door - this will allow toast to slide toward the front of
the unit and down the front return chute (see diagram below).
A B C
NOTE
Please remember that this manual and the warning labels do not replace the need to be alert, to properly train and supervise
operators, and to use common sense when using this equipment.
Burn Hazard.
When in operation, the
Conveyor Toaster will be hot at
the entrance to the conveyor
cavity.
Please take extreme caution.
Risque de brûlure.
Ne touchez pas les surfaces chaudes ou
chauées liguid tout appareil chaue ou
en fonctionnement.
USE CAUTION WHEN
TOUCHING THE UNIT.
Ne touchez pas le liquide chaud
ou les surfaces de chauage
lorsque l’appareil chaue ou en
fonctionnement.
WARNING AVERTISSEMENT
HOT
Rear & Front Toast Return Chutes, Crumb Tray
Pass-Through
Toast Chute
Rear Discharge
Toast Door (closed)
Front
Crumb Tray
If the back catch tray is open the food
will come out the back.
If the back catch tray is closed the
food will go out the front.
Front Return
Toast Chute

6
Cleaning, Care & Maintenance
To maintain the appearance and increase the service
life, clean your unit daily. The SPECTRUM™ Commercial
Conveyor Toaster should be cleaned after each day’s
operation; however, the unit may require more frequent
cleaning, depending on the volume of production.
Safety
SAFETY PRECAUTIONS
Before installing and operating this equipment be sure
everyone involved in its operation are fully trained and
aware of all precautions.
Accidents and problems can result from a failure to follow
fundamental safety precautions.
• A WINCO® Approved Recommended Qualied Service Technician
should carry out repairs if necessary. Do not remove any
components or service panels on this product.
• Allow the Conveyor Toaster to cool down after use before
dismantling for cleaning; the unit will be too hot to handle
immediately after use.
• Before cleaning, switch o power and disconnect power cord from
the outlet.
• If the power cord is damaged, it must be replaced by a WINCO®
Approved Recommended Qualied Service Technician in order to
avoid a hazard.
1. Switch power o and disconnect from the outlet before cleaning.
2. Allow the Conveyor Toaster to cool down after use before
dismantling for cleaning; the unit will still be too hot to handle
immediately after use. Remove the return chutes, feeder and
catch trays and wipe clean with a damp cloth; be sure to dry before
returning them to the unit.
For detailed cleaning these non-electrical parts can be submerged
and washed thoroughly if needed.
3. The remainder of the Conveyor Toaster can be cleaned with a
damp cloth using hot, soapy water.
4. Do not immerse completely in water or use hose to clean.
5. Warm soapy water is recommended for cleaning; prolonged use of
cleaning agents may cause damage to stainless steel.
Burn Hazard.
When in operation, the
Conveyor Toaster will be hot at
the entrance to the conveyor
cavity.
Please take extreme caution.
Risque de brûlure.
Ne touchez pas les surfaces chaudes ou
chauées liguid tout appareil chaue ou
en fonctionnement.
USE CAUTION WHEN
TOUCHING THE UNIT.
Ne touchez pas le liquide chaud
ou les surfaces de chauage
lorsque l’appareil chaue ou en
fonctionnement.
WARNING AVERTISSEMENT
HOT
Electrical Shock Hazard
Keep water and other liquids
from entering the inside of the
unit. Liquid inside the unit could
cause an electrical shock.
Risque de choc électrique
Conserver l'eau et d'autres liquides
de pénétrer à l'intérieur de l'appareil.
Liquide à l'intérieur de l'appareil pourrait
provoquer un choc électrique.
Do not spray water or cleaning
products. Liquid could contact
the electrical components
and cause a short circuit or an
electrical shock. Do not use unit
if power cord is damaged or has
been modied.
Ne pas pulvériser de l'eau ou des produits
de nettoyage. Le liquide pourrait contacter
avec les composants électriques et causer
un court-circuit ou un choc électrique.
Ne pas utiliser l'appareil si le cordon
d'alimentation est endommagé.
ou a été modié.
WARNING AVERTISSEMENT
Please keep this manual in a safe place for future use!
Installation and start-up must be performed by a qualified installer who has thoroughly read, understands and follows these instructions.

7
If your SPECTRUM™ Commercial Conveyor Toaster does not operate, please check the following before placing a service call:
Troubleshooting
Service and Repair
THIS EQUIPMENT MUST ONLY BE SERVICED BY AN AUTHORIZED AGENT.
NOTE
Parts protected by the manufacturer or its agent are not to be adjusted by the installer unless the installer is an authorized service agent.
If you have any questions or problems DO NOT send unit to WINCO® without rst contacting our customer service department.
See "Limited Warranty" section on page 11 for details.
ISSUE MIGHT BE CAUSED BY RECOMMENDED SOLUTION
The unit is not working;
POWER indicator light is not on
Main power supply Check main power supply
Unit is not switched on Check that the unit is correctly plugged in and turned on; ensure that
you've read & understand the manual for correct operation
Faulty dial control Check that set screws on both knobs are correctly secured
Plug and lead are damaged Unplug the unit from power source and inspect cable for fraying or
damage.
Internal wiring fault Call WINCO to make service arrangements through its Service
Provider Network
The unit is heating up but POWER
indicator light is not on Power indicator light is faulty Replace Power indicator light
Slow heat up or no heat up, but
Power is ON
Incorrect operation Ensure that you have clearly read the manual, to understand the
operating functions
Warm up Allow ve (5) minutes for unit to warm up
Elements are faulty Replace faulty elements - Replacement must be done by an
authorized service provider
Faulty power selector switch Replace faulty power selector switch - Replacement must be done
by an authorized service provider
Incorrect voltage Make sure power is connected to correct voltage for this unit - see
name-plate on back of unit for correct voltage
The carry chain does not work
Unit is not on, or the power selector
switch is not activated Turn the unit on and adjust function control to required setting
Faulty speed control Replace faulty speed control - Replacement must be done by an
authorized service provider
Motor fault Check input power
Gear / Chain fault Inspect drive chain for any broken links
Incorrect voltage Make sure power is connected to correct voltage for this unit - see
name-plate on back of unit for correct voltage

8
Exploded View
MODELS: ECT300 & ECT700
1 2
14
16
17
18
19
24
15
22
25 26
21
27
23a
5
6
7 8 9
11
12
10
28
29
20
13
23b

9
Parts List
ECT-300 ECT-700
No. Description Part #
1Return Chute ECT700-P1
2Foot ECT700-P2
5Fan ECT300-P5 ECT700-P3
6Motor ECT300-P4 ECT700-P4
7Silicone Bushing ECT700-P5
8Shaft Bracket ECT700-P6
9Shaft Cover ECT700-P7
10 Gear 1" Dia, 12 Teeth ECT700-P8
11 Gear 1-3/4" Dia, 20 Teeth ECT700-P9
12 Chain ECT700-P10
13 Conveyor Belt ECT700-P11
14 Pass-Through Chute ECT700-P12
15 Back Bae Plate ECT700-P13
16 Plug & Lead ECT300-P1 ECT700-P14
Plug Socket ECT300-P7 n/a
Optional Power Cord, NEMA 5-20P ECT300-P8 n/a
17 Heating Element - UPPER ECT300-P2 ECT700-P15
18 Heating Element - LOWER ECT300-P3 ECT700-P16
19 Conveyor Drive Shaft Assembly - FRONT ECT700-P17
20 Conveyor Drive Shaft Assembly - BACK ECT700-P18
21 Indicator Light - GREEN ECT700-P19
22 Indicator Light - RED ECT700-P20
23a Control Knob - ON/OFF ECT700-P21
23b Control Knob - DONENESS ECT700-P22
24 OFF - 3-Position Heating Switch ECT700-P23
25 Conveyor Belt Speed Control Switch ECT300-P6 ECT700-P24
26 Temperature High Limiter ECT700-P25
27 Crumb Tray ECT700-P26
28 Feeder Rack ECT700-P27
29 Bushing - Power Cord ECT700-P28
Please contact factory for special order parts not listed.

10
Electrical Circuit Diagrams
These circuit diagrams have been provided to assist qualied electricians; Only SPECTRUM™
service agents, or qualied electricians should carry out repairs, if repair is required.
Do not remove any components or service panels on this product.
GEAR MOTOR
EL2 (N)L1
DIODE
VARISTOR
MALFUNCTION LIGHT
PILOT LIGHT
HI-LIMIT
BOTTOM ELEMENT
TOP ELEMENT
FAN
120V ~
208V/240V
MANUAL SHIFT SWITCH
GEAR MOTOR
EL2 (N)L1
DIODE
VARISTOR
MALFUNCTION LIGHT
PILOT LIGHT
HI-LIMIT
BOTTOM ELEMENT
TOP ELEMENT
FAN
120V ~
208V/240V
MANUAL SHIFT SWITCH
ECT700
ECT300
Manual Shift Switch
Manual Shift Switch
Gear Motor
Gear Motor
M
M
L1
L1
P3
P3
P1
P1
P2
P2
5
5
1
1
3
3
E
E
L2 (N)
L2 (N)
208V/240V
120V~
14 AWG
MF
MF
Diode
Diode
Varistor
Varistor
Fan
Fan
Pilot Light
Pilot Light
Hi-Limit
Hi-Limit
Bottom Element
Bottom Element (900 Watts)
Top Element
Top Element (900 Watts)
Malfunction Light
Malfunction Light

11
WINCO® warrants to the original purchaser of new equipment that said
equipment, when installed in accordance with our instructions within
North America and subjected to normal use, is free from defects in
material or workmanship for a period of 1 year. The labor warranty is
one year from original purchase date or 18 months from actual factory
shipment date, whichever date occurs rst.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
WHETHER EXPRESSED OR IMPLIED. WINCO EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR EXPRESSED OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE.
WINCO’S OBLIGATION AND LIABILITY UNDER THIS WARRANTY
IS EXPRESSLY LIMITED TO REPAIRING AND REPLACING
EQUIPMENT THAT PROVES TO BE DEFECTIVE IN MATERIAL OR
WORKMANSHIP WITHIN THE APPLICABLE WARRANTY PERIOD.
IN NO EVENT SHALL WINCO BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES TO BUYER OR ANY THIRD PARTY,
INCLUDING, WITHOUT LIMITATION, LOSS OF PROPERTY,
PERSONAL INJURY, LOSS OF BUSINESS OR PROFITS OR OTHER
ECONOMIC LOSSES, OR STATUTORY OR EXEMPLARY DAMAGES,
WHETHER IN NEGLIGENCE, WARRANTY, STRICT LIABILITY, OR
OTHERWISE.
This warranty is given only to the rst purchaser from a retail dealer.
No warranty is given to subsequent transferees.
Warranty does not cover product failures caused by: failure to maintain,
neglect, abuse, damage due to excess water, re, normal wear,
improper set up and use. Periodic maintenance is not covered.
This warranty is not in force until such time as a properly completed
and digitally signed Installation/Warranty Registration has been
received by WINCO within 30 days from the date of installation.
WARRANTY SERVICE
To initiate warranty service contact: EquipSer[email protected] or
call: 973-295-3899
DO NOT send unit to WINCO® without rst contacting our customer
service department.
Please provide or have the following information available:
• Model & Serial Number (located on the silver identication tag, on
side or rear of unit)
• Date of Purchase
• Purchase Dealer
• Operator / Installation Contact Information
• Business Name & Business Address
• Contact Name & Contact Telephone Number
REGISTER ONLINE AT: http://www.wincous.com
Proof of purchase is required to extend warranty more than 1 year from
date of shipment from the factory.
THE FOREGOING WARRANTY PROVISIONS ARE A COMPLETE
AND EXCLUSIVE STATEMENT BETWEEN THE BUYER AND SELLER.
WINCO®NEITHER ASSUMES NOR AUTHORIZES ANY PERSONS
TO ASSUME FOR IT ANY OTHER OBLIGATION OR LIABILITY IN
CONNECTION WITH SAID EQUIPMENT.
Examples of items not covered under warranty, but not limited to
just these items:
1. Natural disasters (ie: earthquakes, tornadoes, hurricanes, etc.), re,
water damage, burglary, accident, theft.
2. Freight damage.
3. Improper installation or alteration of equipment.
4. Use of generic or after-market parts.
5. Repairs made by anyone other than a WINCO® designated service
provider.
6. Lubrication.
7. Expendable wear parts, adjustable feet, blown fuses, lamps, etc.
8. Normal product maintenance.
9. Misuse or abuse.
10. Normal wear and tear items such as light bulbs, fuses, and exterior
nishes.
Warranty voided if:
1. Product is altered by user
2. Serial number plate is removed
3. Product is installed in a prison or any correctional facility.
Limited Warranty
Please keep this manual in a safe place for future use!



