Wine Master WineARM15 User manual

–
Installation lift pump WINEARM15
Installation guide lift pump WINEARM15
07-2019

2
I.Installation
1.1. Step 1 : Acces from the bottom opening or
dismount one side of the appliance
Disassemble the side indicated herewith by removing the screws
1.2. Step 2 : Fix the lifting pump on the sheet
For fixing the pump you need :
•the lifting pump
•The rubber bracket
•A sheet 50.1369
•Two screws W1015
Assemble the 3 components using screws W1015.
W1369

3
1.3. Step 3 : Installation of the brackets in the
appliance
To fix the brackets you need :
•The parts assembly
•4x W10151
1.4. Step 4 : Sensor installation
•Reverse the cap position to open the front water
outlet of the sensor
•Cut the 90° connection part with a cutter
•Use this tube piece to connect the sensor

4
•• Cut a piece of PVC tube D 6MM
•• Connect the sensor to the lift pump with this tube
•• Use the rest of the tube to drive the liquid from the
pump to the outside of the machine. (you can extend this pipe
with the following constraints )
REAL FLOW TABLE
TOTAL PIPE LENGTH (INT 6MM, 1/4")-(C)
SUCTION
HEIGHT
DELIVERY
HEAD
5 m
10 m
20 m
30 m
0 m
0 m
20
18
18
17
2 m
16
15
14
13,5
4 m
11,5
11
10,5
10
6 m
8,5
7,5
6,5
8 m
6
5
4
10 m
4
3,5
2,5
1 m
0 m
14
13
12
11
2 m
11
10
9
8
4 m
7,5
7
6
5
6 m
4,5
4
2 m
0 m
11
10
9
8
2 m
9
8
7
6
4 m
5,5
5
4,5
3 m
0 m
10,5
9
8
7
2 m
8
7
6
5
4 m
5
4
Pipes passageway

5
