Winic IP-NC324-VBZ User manual

IP-NC324-VBZ
Quick Start Guide

1
1
Quick Start Guide
About this Manual
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
Please use this user manual under the guidance of professionals.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
IP-NC324-VBZ·Quick Start Guide

IP-NC324-VBZ·Quick Start Guide
2
2
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive 2014/30/EU, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as

3
3
unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is
marked with this symbol, which may include lettering to indicate
cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling,
return the battery to your supplier or to a designated collection
point. For more information see: www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards
requirements.
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent potential
injury or material damage.
IP-NC324-VBZ·Quick Start Guide

4
4
Warnings
●Proper configuration of all passwords and other security
settings is the responsibility of the installer and/or end-user.
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet both the SELV (Safety Extra Low
Voltage) and the Limited Power Source with 24 VAC or 12 VDC
according to the IEC60950-1 standard. Please refer to technical
specifications for detailed information.
●Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
●Please make sure that the plug is firmly connected to the power
socket. When the product is mounted on wall or ceiling, the
device shall be firmly fixed.
●If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
IP-NC324-VBZ·Quick Start Guide

5
5
●Do not touch sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period,
please replace the lens cap to protect the sensor from dirt.
●Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of sensor at the same
time.
●The sensor may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of
sensor will not be exposed to the laser beam.
●Do not place the camera in extremely hot, cold (the operating
temperature shall be-30°C ~to 60°C , or -40°C ~ to 60°C if the
camera model has an “H” in its suffix), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
●To avoid heat accumulation, good ventilation is required for
operating environment.
●Keep the camera away from liquid while in use.
●While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
●Regular part replacement: a few parts (e.g. electrolytic
capacitor) of the equipment shall be replaced regularly
according to their average enduring time. The average time
varies because of differences between operating environment
and using history, so regular checking is recommended for all
the users. Please contact with your dealer for more details.
IP-NC324-VBZ·Quick Start Guide

6
6
●Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.
●If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)
0504051070109
IP-NC324-VBZ·Quick Start Guide

7
7
Table of Contents
1 Appearance Description ................................................................. 9
1.1 Type I Camera ................................................................. 9
1.2 Type II Camera .............................................................. 10
1.3 Type III Camera ............................................................. 12
1.4 Type IV Camera ............................................................. 14
1.5 Type V Camera .............................................................. 16
2 Installation.................................................................................... 18
2.1 Memory Card Installation.............................................. 18
2.2 Type I Camera Mounting ............................................... 21
2.2.1 Wall Mounting......................................................... 21
2.2.2 Pendant Mounting................................................... 23
2.3 Other Types Camera Mounting ..................................... 26
2.3.1 Direct Mounting ...................................................... 26
2.3.2 Mounting with a Junction Box ................................. 29
2.3.3 Mounting with a Gang Box ...................................... 30
2.4 Zoom and Focus Adjustment......................................... 31
2.4.1 Type I, Type II and Type IV........................................ 31
2.4.2 Type III and Type V................................................... 33
2.5 Installation of Network Cable Water-proof Jacket
(Optional) ................................................................................. 33
3 Setting the Network Camera over the LAN .................................. 36
3.1 Wiring ........................................................................... 36
3.2 Activating the Camera................................................... 37
3.2.1 Activation via Web Browser..................................... 37
3.2.2 Activation via SADP Software................................... 38
3.3 Modifying the IP Address .............................................. 40
IP-NC324-VBZ·Quick Start Guide

8
8
4 Accessing via Web Browser .......................................................... 44
5 Operating via Guarding Vision App .............................................. 46
5.1 Enable Guarding Vision Service on Camera................... 46
5.1.1 Enable Guarding Vision Service via SADP Software.. 46
5.1.2 Enable Guarding Vision Service via Web Browser .... 47
5.2 Guarding Vision Setup................................................... 49
5.3 Adding Camera to Guarding Vision................................ 49
5.4 Initializing the Memory Card......................................... 51
IP-NC324-VBZ·Quick Start Guide

9
9
1Appearance Description
1.1 Type I Camera
The overview of Type I camera is shown below.
5
10
3
6
9
8
7
4
1
2
11
1213
Overview of Type I CameraFigure 1-1
DescriptionTable 1-1
No.
Description
1
Sun Shield
2
Front Cover
3
Zoom and Focus Lever
IP-NC324-VBZ·Quick Start Guide

10
10
No.
Description
4
IR LED
5
Lens
6
Air Vent
7
Video Output Interface
8
Reset Button
9
Memory Card Slot
10
Audio Cable
11
Alarm Cable
12
Power Cord
13
Network Cable
Note:
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.
1.2 Type II Camera
The overview of Type II camera is shown below.
IP-NC324-VBZ·Quick Start Guide

11
11
5
11
3
8
6
4
1
2
7
9
10
12
13
14
Figure 1-2 Overview of Type II Camera (1)
15
Overview of Type II Camera (2)Figure 1-3
DescriptionTable 1-2
No.
Description
1
Sun Shield
2
Front Cover
3
Zoom and Focus Lever
IP-NC324-VBZ·Quick Start Guide

12
12
No.
Description
4
IR LED
5
Lens
6
Air Vent
7
Video Output Interface
8
Bracket
9
Reset Button
10
Memory Card Slot
11
Audio Cable
12
Alarm Cable
13
Power Cord
14
Network Cable
15
Grounding
Note:
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.
1.3 Type III Camera
The overview of Type III camera is shown below.
IP-NC324-VBZ·Quick Start Guide

13
13
7
3
5
8
6
4
1
2
11
910
12
13
Overview of Type III Camera (1)Figure 1-4
14
Overview of Type III Camera (2)Figure 1-5
DescriptionTable 1-3
No.
Description
1
Sun Shield
2
Front Cover
IP-NC324-VBZ·Quick Start Guide

14
14
No.
Description
3
IR LED
4
Lens
5
Air Vent
6
Bracket
7
Reset Button
8
Memory Card Slot
9
Video Cable
10
Network Cable
11
Power Cord
12
Alarm Cable
13
Audio Cable
14
Grounding
Note:
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.
1.4 Type IV Camera
The overview of Type IV camera is shown below.
IP-NC324-VBZ·Quick Start Guide

15
15
2
1
3
4
5
67
8911 10
12
Overview of Type IV CameraFigure 1-6
DescriptionTable 1-4
No.
Description
1
Sun Shield
2
Front Cover
3
IR LED
4
Lens
5
Zoom and Focus Lever
6
Memory Card Slot
7
Reset Button
8
Camera Body
IP-NC324-VBZ·Quick Start Guide

16
16
No.
Description
9
Bracket
10
Video Cable
11
Network Cable
12
Power Cord
Note:
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.
1.5 Type V Camera
The overview of Type V camera is shown below.
2
1
3
4
56
789
10
Overview of Type V CameraFigure 1-7
IP-NC324-VBZ·Quick Start Guide

17
17
DescriptionTable 1-5
No.
Description
1
Sun Shield
2
Front Cover
3
IR LED
4
Lens
5
Memory Card Slot
6
Reset Button
7
Camera Body
8
Bracket
9
Network Cable
10
Power Cord
Note:
Press RESET about 10s when the camera is powering on or rebooting
to restore the default settings, including the user name, password, IP
address, port No., etc.
IP-NC324-VBZ·Quick Start Guide

18
18
2Installation
Before you start:
●Make sure the device in the package is in good condition and all
the assembly parts are included.
●The standard power supply is 12V DC or PoE (802.3af). Make
sure your power supply matches with your camera.
●Make sure all the related equipment is power-off during the
installation.
●Check the specification of the products for the installation
environment.
●Make sure that the wall is strong enough to withstand four
times the weight of the camera and the bracket.
For the camera that supports IR, you are required to pay attention to
the following precaution to prevent IR reflection:
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing reflection.
2.1 Memory Card Installation
This series of cameras support memory card installation. Different
camera types share the similar installation steps, and we take type I
camera as the example.
Steps:
1. Rotate the lock screw counterclockwise to loosen it.
IP-NC324-VBZ·Quick Start Guide

19
19
Lock Screw
Loosen the Lock ScrewFigure 2-1
2. Remove the sun shield.
Figure 2-2 Remove the Sun Shield
3. Remove the front cover by rotating it counterclockwise.
4. Insert the memory card into the memory card slot.
IP-NC324-VBZ·Quick Start Guide
