Winic Roline NC303 Series User manual

RED|LINE
NC303 Series
Network Camera
User Manual

User Manual of Network Camera
1
Thank you for purchasing our product. If there are any questions, or requests, please
do not hesitate to contact the dealer.
This manual may contain several technical incorrect places or printing errors, and the
content is subject to change without notice. The updates will be added to the new
version of this manual. We will readily improve or update the products or procedures
described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability
of the security or signaling aspects of this product. UL has only tested for fire, shock
or casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the security or signaling
aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR
RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS
OF THIS PRODUCT”.

User Manual of Network Camera
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to comply with the
limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may
cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the Low Voltage
Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS
Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European
Union. For proper recycling, return this product to your local
supplier upon the purchase of equivalent new equipment, or dispose
of it at designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that
cannot be disposed of as unsorted municipal waste in the European
Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may
include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to your supplier or to
a designated collection point. For more information see:
www.recyclethis.info.

User Manual of Network Camera
3
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly to
avoid danger or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are
neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are
neglected.
Warnings Follow these safeguards to
prevent serious injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings:
Please adopt the power adapter which can meet the safety extra low voltage
(SELV) standard. And source with 12 VDC or 24 VAC (depending on models)
according to the IEC60950-1 and Limited Power Source standard.
If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the camera yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
maintenance.)
To reduce the risk of fire or electrical shock, do not expose this product to rain or
moisture.
This installation should be made by a qualified service person and should conform
to all the local codes.
Please install blackouts equipment into the power supply circuit for convenient
supply interruption.
Please make sure that the ceiling can support more than 50(N) Newton gravities if
the camera is fixed to the ceiling.
If the product does not work properly, please contact your dealer or the nearest
service center. Never attempt to disassemble the camera yourself. (We shall not
assume any responsibility for problems caused by unauthorized repair or
maintenance.)

User Manual of Network Camera
4
Cautions:
Make sure the power supply voltage is correct before using the camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is necessary, use a clean
cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an
extended period of time, put on the lens cap to protect the sensor from dirt.
Do not aim the camera lens at the strong light such as sun or incandescent lamp.
The strong light can cause fatal damage to the camera.
The sensor may be burned out by a laser beam, so when any laser equipment is
being used, make sure that the surface of the sensor not be exposed to the laser
beam.
Do not place the camera in extremely hot, cold temperatures (the operating
temperature should be between -30°C ~ 60°C, or -40°C ~ 60°C if the camera
model has an “H” in its suffix), dusty or damp environment, and do not expose it
to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for a proper operating
environment.
Keep the camera away from water and any liquid.
While shipping, the camera should be packed in its original packing.
Improper use or replacement of the battery may result in hazard of explosion.
Please use the manufacturer recommended battery type.
Notes:
For the camera supports IR, you are required to pay attention to the following
precautions to prevent IR reflection:
Dust or grease on the dome cover will cause IR reflection. Please do not remove
the dome cover film until the installation is finished. If there is dust or grease on
the dome cover, clean the dome cover with clean soft cloth and isopropyl alcohol.
Make certain the installation location does not have reflective surfaces of objects
too close to the camera. The IR light from the camera may reflect back into the
lens causing reflection.
The foam ring around the lens must be seated flush against the inner surface of
the bubble to isolate the lens from the IR LEDS. Fasten the dome cover to camera
body so that the foam ring and the dome cover are attached seamlessly.

User Manual of Network Camera
5
Table of Contents
Chapter 1 System Requirement................................................................................8
Chapter 2 Network Connection................................................................................9
2.1 Setting the Network Camera over the LAN......................................................... 9
2.1.1 Wiring over the LAN........................................................................................................9
2.1.2 Detecting and Changing the IPAddress .........................................................................10
2.2 Setting the Network Camera over the WAN.......................................................11
2.2.1 Static IP Connection .......................................................................................................11
2.2.2 Dynamic IP Connection..................................................................................................12
Chapter 3 Access to the Network Camera.............................................................15
3.1 Accessing by Web Browsers................................................................................ 15
3.2 Accessing by Client Software.............................................................................. 17
Chapter 4 Wi-Fi Settings.........................................................................................19
4.1 Configuring Wi-Fi Connection in Manage and Ad-hoc Modes ....................... 19
4.2 Easy Wi-Fi Connection with WPS function....................................................... 23
4.3 IP Property Settings forWireless Network Connection ................................... 26
Chapter 5 Live View.................................................................................................27
5.1 Live View Page ..................................................................................................... 27
5.2 Starting Live View................................................................................................ 28
5.3 Recording and Capturing Pictures Manually ................................................... 29
5.4 Operating PTZ Control....................................................................................... 29
5.4.1 PTZ Control Panel..........................................................................................................29
5.4.2 Setting / Calling a Preset.................................................................................................30
5.4.3 Setting / Calling a Patrol.................................................................................................32
Chapter 6 Network Camera Configuration...........................................................33
6.1 Configuring Local Parameters............................................................................ 33
6.2 Configuring Time Settings .................................................................................. 35
6.3 Configuring Network Settings ............................................................................ 37
6.3.1 Configuring TCP/IP Settings ..........................................................................................37
6.3.2 Configuring Port Settings ...............................................................................................38
6.3.3 Configuring PPPoE Settings...........................................................................................39
6.3.4 Configuring DDNS Settings...........................................................................................39
6.3.5 Configuring SNMP Settings...........................................................................................43
6.3.6 Configuring 802.1X Settings..........................................................................................44
6.3.7 Configuring QoS Settings...............................................................................................45
6.3.8 Configuring UPnP™ Settings.........................................................................................46

User Manual of Network Camera
6
6.3.9 Email Sending Triggered by Alarm ................................................................................47
6.3.10 Configuring NAT (Network Address Translation) Settings............................................49
6.3.11 Configuring FTP Settings...............................................................................................50
6.3.12 HTTPS Settings..............................................................................................................51
6.4 Configuring Video and Audio Settings............................................................... 53
6.4.1 Configuring Video Settings ............................................................................................53
6.4.2 Configuring Audio Settings............................................................................................55
6.4.3 Configuring ROI Encoding.............................................................................................55
6.4.4 Display Info. on Stream..................................................................................................57
6.5 Configuring Image Parameters .......................................................................... 57
6.5.1 Configuring Display Settings .........................................................................................57
6.5.2 Configuring OSD Settings..............................................................................................62
6.5.3 Configuring Text Overlay Settings .................................................................................64
6.5.4 Configuring Privacy Mask..............................................................................................65
6.6 Configuring and Handling Alarms..................................................................... 66
6.6.1 Configuring Motion Detection........................................................................................66
6.6.2 Configuring Video Tampering Alarm .............................................................................72
6.6.3 Configuring Alarm Input ................................................................................................73
6.6.4 Configuring Alarm Output..............................................................................................74
6.6.5 Handling Exception........................................................................................................75
6.6.6 Configuring Line Crossing Detection.............................................................................76
6.6.7 Configuring Intrusion Detection.....................................................................................77
Chapter 7 Storage Settings......................................................................................79
7.1 Configuring NAS Settings................................................................................... 79
7.2 Configuring Recording Schedule........................................................................ 81
7.3 Configuring Snapshot Settings ........................................................................... 85
Chapter 8 Playback..................................................................................................88
Chapter 9 Log Searching.........................................................................................90
Chapter 10 Others......................................................................................................91
10.1 Managing UserAccounts..................................................................................... 91
10.2 Authentication...................................................................................................... 93
10.3 Anonymous Visit .................................................................................................. 94
10.4 IPAddress Filter................................................................................................... 95
10.5 Security Service.................................................................................................... 96
10.6 Viewing Device Information................................................................................ 97
10.7 Maintenance ......................................................................................................... 98
10.7.1 Rebooting the Camera ....................................................................................................98
10.7.2 Restoring Default Settings..............................................................................................98

User Manual of Network Camera
7
10.7.3 Exporting / Importing Configuration File.......................................................................98
10.7.4 Upgrading the System.....................................................................................................99
10.8 RS-232 Settings................................................................................................... 100
10.9 RS-485 Settings................................................................................................... 101
10.10 Service Settings................................................................................................... 101
Appendix ................................................................................................................102
Appendix 1 SADP Software Introduction..................................................................... 102
Appendix 2 Port Mapping.............................................................................................. 104

User Manual of Network Camera
8
Chapter 1 System Requirement
Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 /
Server 2003 / Server 2008 32bits
CPU: Intel Pentium IV 3.0 GHz to Core i7-4000 series or higher, depending on
different video resolutions
RAM: 1G or higher
Display: 1024×768 resolution or higher
Web Browser: Internet Explorer 7.0 and above version, Safari 5.02 and above
version, Mozilla Firefox 3.5 and above version and Google Chrome8 and above
versions.

User Manual of Network Camera
9
Chapter 2 Network Connection
Before you start:
If you want to set the network camera via a LAN (Local Area Network), please
refer to Section 2.1 Setting the Network Camera over the LAN.
If you want to set the network camera via a WAN (Wide Area Network), please
refer to Section 2.2 Setting the Network Camera over the WAN.
2.1 Setting the Network Camera over the LAN
Purpose:
To view and configure the camera via a LAN, you need to connect the network
camera in the same subnet with your computer, and install the SADP or CMS
software to search and change the IP of the network camera.
Note: For the detailed introduction of SADP, please refer to Appendix 1.
2.1.1 Wiring over the LAN
The following figures show the two ways of cable connection of a network camera
and a computer:
Purpose:
To test the network camera, you can directly connect the network camera to the
computer with a network cable as shown in Figure 2-1.
Refer to the Figure 2-2 to set network camera over the LAN via a switch or a
router.
Figure 2-1 Connecting Directly
