WiSilica lumos controls SENOR E User manual

WARNING AND GUIDELINES!!!
DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that
no parts should have been damaged during transit. Inspect to confirm. Any part
damaged or broken during or after assembly should be replaced.
WARNING : TURN THE POWER OFF AT THE CIRCUIT
BREAKER BEFORE WIRING
REQUIRED TOOLS &
SUPPLIES
Read and follow all safety instructions!!
Do’s
Installation should be performed by a
qualified electrician
Don'ts
Don't use outdoors
Installation shall be in accordance with
all applicable local and NEC codes
Avoid input voltage exceeding
maximum rating
Don't dissemble the productsObserve the correct polarity of output
terminal
Do not modify the product
Do not mount near gas or electric heater
Do not use product for anything other than its intended use
WARNING: Risk of Product Damage
Screwdriver
Verify that supply voltage is correct by comparing it with the product information
WARNING - Risk of Electric Shock
INSTALLATION AND QUICK START SHEET
PRODUCT OVERVIEW
Senor E is a USB powered Beacon & range extender with
external antenna. It is a part of Lumos Controls ecosystem,
which includes controllers, sensors, switches, modules, drivers,
gateways, and analytical dashboards.
Beacon & Range Extender
SENOR E
Specifications Value Remarks
Input voltage 5VDC
15mA
2402-2480MHz
8dBm
-92dBm
USB Type-A
Typical current
Input current
Frequency range
Tx Output power Conductive
Rx sensitivity
Antenna
_
_
_
Storage temperature
Operating temperature _
_
_
Dimensions
Mounting
L x W x H
Stick or 600mm wire antenna
-40 to 50°C(-40 to 122°F)
-40 to 85°C(-40 to 185°F)
Relative humidity 85%
2.56 x 1.15 x 0.9in(66.7 X 29.2 X 22.4mm)
Wall/Surface mounting
Place devices as far away as possible
from metallic materials
Devices work best in when there is a
clear LOS between them
When placing devices inside metallic
boxes, please ensure the antenna
comes out of the boxes
Screws Wall plug

Once powered up, the device will be ready to be commissioned via the Lumos Controls
mobile app, available for free download on iOS and Android. To begin commissioning,
click the ‘+’ icon from the top of the ‘Devices’ tab. The app allows you to preset certain
configurations which will be loaded after the device is added. The pre-configurations
made using 'Commissioning Settings' will be sent to the devices being commissioned.
Once commissioned, the device will be displayed in the ‘Devices’ tab.
COMMISSIONING
5-year limited warranty
Please find warranty terms and conditions
Note: Specifications may change without notice
Actual performance can vary due to end-user environment and application
WARRANTY
INSTALLATION INSTRUCTIONS
Installation Steps
Place the repeater between the Lumos Controls Bluetooth devices
Make a hole to install the device
Screw the repeater on the wall/surface via the mounting flanges on the device
Connect the USB port to the *power adapter
Plug in the adapter and power ON the repeater device
Power
adapter
USB cable
If paring of devices are getting failed continuously then it may be due to BLE trac. To reduce the trac, power OFF other devices in the vicinity and pair again.
RF GUIDELINES
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by WiSilica Inc. is under license. Other trademarks and trade names are those of their respective owners.
All Rights Reserved WiSilica Inc
www.lumoscontrols.com
20321 Lake Forest Dr D6,
Lake Forest, CA 92630
[phone]
Ver 1.1 Mar 2023
Please visit Help center
for more details
LUMOS CONTROLS APPLICATION
Download the ‘Lumos Controls’ application from
Play Store or App Store
OR
Scan the QR codes to download the
‘Lumos Controls’ application
