BRIEF DESCRIPTION
MPR30-ENG is a compact true diversity receiver designed for professional ENG, broadcast, and
field production applications. This receiver features a real TRUE DIVERSITY configuration along
with a unique wide-band tuning range up to 232 MHz.
A double stages input filters assure an excellent selectivity even in broad-band operations.
All audio processing is managed by a powerful DSP allowing:
- multicompanding,
- audio enhancement
- digital control data.
It is very easy and versatile thanks to its:
Oled display,
navigation button controls,
infrared interface (for sync and remote configuration),
micro-usb interface (for remote configuration and battery recharge),
automatic scan.
MPR30-ENG is designed to be:
“easy & quick to use” thanks to
oautomatic setup functions (i.e. frequencies, scan for best channels),
oremote configuration utilities (thru infrared or USB interface) using Wisycom ENG
RX Manager application
oOLED display with intuitive context menu navigation
“extremely flexible”, with an incredible frequency agility up to 232MHz
oMPR30-ENG-L: 470/700 MHz (TV ch 21/49)
oMPR30-ENG-H:566/798 MHz (TV ch 33/61)
“best in class performances”, thanks to the latest Wisycom technology the unit has
extreme RF sensitivity and immunity and superb audio quality
“a durable & upgradable investment”, thanks to the very robust design (aluminum
housing) and the possibility to upgrade/enhance units performances.

Rev. 14
MPR30-ENG User Manual

Above a schematic with an overview of main receiver functions.
SAFETY INSTRUCTION
Read this safety instruction and the manual first
Follow all instructions and information.
Do not lose this manual.
Do not use this apparatus under the rain or near the water.
Do not install the apparatus near heaters or in hot environments, do not use outside the
operating temperature range.
Do not open the apparatus, only qualified service technician are enabled to operate on it.
The apparatus needs servicing when it is not properly working or is damaged by liquids,
moisture or other objects are fallen in the apparatus.
Use only accessories or replacement parts authorized or specified by the manufacturer.
Clean the apparatus only with dry cloths, do not use liquids.
Report the serial number and the purchasing date in front of the manual. It is needed to
have proper replacement parts or accessories from the manufacturer.
When replacement parts are needed, use only replacement parts authorized from the
manufacturer. Substitution with not authorized parts could result in electric shock, hazards
or fire.
Keep attention on all the labels with warnings or hazards on the apparatus.
The apparatus is intended for professional use; anyway the manufacturer alerts the
user that the headphone output power of the apparatus could exceed the level of 85 dB(A) of
sound pressure level and this could be dangerous for the hearings. Do not use the headphone
with high power level or for long time. Reduce the power or suspend the hearing in case of any
kind of hearing problem.

MPR30-ENG User Manual
Rev. 14

BATTERIES
MPR30-ENG works with standard camera battery:
-2xIEC-LR6 1.5 size-AA alkaline or NiMh rechargeable
-KLIC 8000 (lithium-ion, rechargeable)
-DB50 (lithium-ion, rechargeable)
-DR9708 Duracell (lithium-ion, rechargeable)
Battery status can be checked on OLED display or looking the status of LED indicator ON.
Charging of lithium-ion rechargeable batteries can be done with
A. dedicated charger
B. thru the integrated micro-usb-B connector
C. thru 5 pin mini-XLR male connector (only for MPR30-ENG-5PW model)
For B and C items, the charging status can be checked looking the status of LED indicator ON.
For MPR30-ENG and MPR30-ENG-5PW models
We don't recommend to use the device during the batteries charging with lithium-ion
rechargeable batteries inside. Don’t use the receiver without batteries . The receiver powered
thru micro-USB or mini-XLR connector (MRP30-ENG-5PW model) without batteries doesn't
work correctly.
For MPR30-ENG-5BY model
The receiver can be used also without batteries inside.
DO NOT operate the device with some new and some old batteries. Always
replace ALL BATTERIES.
Remember to remove the batteries when the device is not in use.
