Worcester 12/18 User manual

INSTRUCTION MANUAL
INSTALLATION COMMISSIONING
& SERVICING
GB
GREENSTAR CAMRAY UTILITY & UTILITY SYSTEM
12/18, 18/25, 25/32
FLOOR STANDING OIL FIRED CONDENSING BOILER
CONVENTIONAL FLUE & ROOM SEALED FLUE
FOR FULLY PUMPED OPEN VENT OR SEALED CENTRAL HEATING SYSTEMS AND DOMESTIC
HOT WATER CYLINDERS
THE APPLIANCE IS FOR USE WITH 28 SECOND KEROSENE
ONLY
INSTRUCTION MANUAL
GB
THE APPLIANCE IS FOR USE WITH 28 SECOND KEROSENE
ONLY

INSTALLATION &
SERVICING INSTRUCTIONS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
1
SYMBOLS USED IN THIS MANUAL:
Domestic hot water
Central heating
INSTALLATION & SERVICING INSTRUCTIONS
Electricity supply
IMPORTANT HANDLING INSTRUCTIONS:
It is advised that more than one person is
involved in the transfer of the packaged
appliance from the van to the point of installation.
It is advised that no attempt should be made to
move the packaged appliance without the use of
a suitable truck.
At all times the correct method for handling
heavy objects should be strictly observed.
GENERAL HANDLING GUIDELINES:
• Lift only a manageable weight, or ask for
help.
• When lifting, bend the knees, and keep the
back straight and feet apart.
• Do not lift and twist at the same time.
• Lift and carry items close to the body.
• Wear protective clothing and gloves to
protect from any sharp edges.
Check List
Item Qty
Greenstar Camray Utility & Utility System Installation/Servicing
Instructions............ ...........................................................................................1
Users Instructions ...........................................................................................1
Warranty Return Envelope ............................................................................1
Guarantee Registration Card........................................................................1
Condensate Trap Kit........................................................................................1
Return Pipe Kit..................................................................................................1
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE STARTING INSTALLATION.
THESE INSTRUCTIONS ARE APPLICABLE TO THE WORCESTER APPLIANCE MODEL(S)
STATED ON THE FRONT COVER OF THIS MANUAL ONLY AND MUST NOT BE USED WITH
ANY OTHER MAKE OR MODEL OF APPLIANCE.
THE INSTRUCTIONS APPLY IN THE UK ONLY AND MUST BE FOLLOWED EXCEPT FOR ANY
STATUTORY OBLIGATION.
THIS APPLIANCE MUST BE INSTALLED BY A COMPETENT PERSON. FAILURE TO INSTALL
CORRECTLY COULD LEAD TO PROSECUTION.
COMPLYING WITH THE BUILDING REGULATIONS:
This heating appliance forms part of the controlled services for the building. It is law that all controlled
services for buildings must comply with building regulations. You must be able to satisfy your Local
Authority Building Control Body (LABC) that the work carried out concerning the installation and
commissioning of this heating appliance has been carried out to a satisfactory standard.
OFTEC operate a competent persons scheme and registered installers are able to certify that their
work complies with building regulations. Under the scheme;
OFTEC must be informed about every installation.
OFTEC will issue a building regulations compliance certificate to the householder and will
notify the LABC.
OFTEC provide controlled document forms CD10 and CD11 for use during installation and com-
missioning respectively.
Other organisations operate self-certification schemes e.g. NAPIT and BESCA Ltd. and it may be
possible for installers who are members of these organisations to self certify their work.
Alternatively you must submit a building control notice to the LABC before installing any boiler. The
LABC will then arrange regular inspection visits during the work to ensure that the installation
complies with the regulations.
IF YOU ARE IN ANY DOUBT CONTACT THE WORCESTER TECHNICAL HELPLINE.
DISTANCE LEARNING AND TRAINING COURSES ARE AVAILABLE FROM WORCESTER.
PLEASE LEAVE THESE INSTRUCTIONS WITH THE COMPLETED COMMISSIONING FORM
AND THE USER MANUAL WITH THE OWNER OR WITH THE APPLIANCE AFTER
INSTALLATION OR SERVICING. THE SERVICE INTERVAL RECORD CAN BE FOUND ON
THE BACK PAGE OF THIS MANUAL.
ABBREVIATIONS USED IN THIS MANUAL:
Ø Diameter
CH Central Heating
DHW Domestic Hot Water
TRV Thermostatic Radiator Valve
IP Ingress Protection
CF Conventional flue
BF Balanced flue
N/A Not allowed
SEDBUK Seasonal Efficiency of Domestic Boilers in the United Kingdom
OFTEC Oil Firing Technical Association for the Petrolium Industry
IEE Institute of Electrical Engineers
LABC Local Authority Building Control Body
STORE THE APPLIANCE IN A DRY AREA PRIOR TO INSTALLATION.

SAFETY & REGULATIONS
IMPORTANT INFORMATION AND SYMBOLS 1
SAFETY PRECAUTIONS AND INSTALLATION REGULATIONS 3
APPLIANCE INFORMATION
GENERAL INFORMATION 4
TECHNICAL DATA 5
LAYOUT & COMPONENTS UTILITY 6
LAYOUT & COMPONENTS UTILITY SYSTEM 7
PRE-INSTALLATION
CLEANING PRIMARY SYSTEMS 8
MAINS SUPPLY 9
OIL SUPPLY 10
WATER SYSTEMS & PIPEWORK 11-12
CONDENSATE PIPEWORK 13
PRESSURE RELIEF PIPEWORK 13
BOILER LOCATION & CLEARANCES 14-15
FLUE TERMINAL POSITIONS 16
CONVENTIONAL FLUE 17
ROOM SEALED FLUE OPTIONS 18
INSTALLATION
UNPACKING THE BOILER 19
PIPEWORK POSITIONS / FLUE OPENING 20
BOILER INSTALLATION 21
FLUE INSTALLATION 22
COMBUSTION CHAMBER 23
PIPEWORK CONNECTIONS 24
OIL BURNER AND PUMP 25
REFITTING COMPONENTS 26
ELECTRICS 27-31
COMMISSIONING
PRE-COMMISSIONING CHECKS - APPLIANCE 32
FILLING THE SYSTEM 33
STARTING THE APPLIANCE 34-37
WATER TREATMENT 38
FINISHING COMMISSIONING - APPLIANCE 39
SERVICING & SPARES
INSPECTION AND SERVICE 40-43
SHORT PARTS LIST 12/18 44
SHORT PARTS LIST 18/25 45
SHORT PARTS LIST 25/32 46
FAULT FINDING & DIAGNOSIS
FAULT FINDING 47-48
FAULT FINDING LOGIC FOR 535 SE/LD RDB CONTROL BOX 49
COMBUSTION RECORD 50
SERVICE INTERVAL RECORD 51
BAFFLE ARRANGEMENT DIAGRAM BACK PAGE
CONTENTS
CONTENTS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
2
SAFETY &
REGULATIONS
APPLIANCE
INFORMATION
PRE -
INSTALLATION
INSTALLATIONCOMMISSIONING
SERVICING
& SPARES
FAULT FIN DI NG
& DIAGRAMS
NOTES

SAFETY PRECAUTIONS
& INSTALLATION REGULATIONS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
3
SAFETY &
REGULATIONS
SAFETY PRECAUTIONS INSTALLATION REGULATIONS
OIL SMELLS, LEAKS OR FUMES FROM THE APPLIANCE:
 Extinguish any naked flames.
 Open windows and doors.
 Isolate the electrical supply.
 Isolate the fuel supply to the boiler.
 Rectify fault.
HEALTH & SAFETY:
The appliance contains no asbestos and no substances have been used in the construction
process that contravene the COSHH Regulations (Control of Substances Hazardous to Health
Regulations 1988). Where applicable, the CE mark indicates compliance with relative EU
Directives.
COMBUSTIBLE AND CORROSIVE MATERIALS:
Do not store or use any combustible materials (paper, thinners, paints etc.) inside or within the
vicinity of the appliance.
The combustion air must be kept clear of chemically aggressive substances which can corrode
the appliance and invalidate any warranty.
FITTING & MODIFICATIONS:
Fitting the appliance and any controls to the appliance may only be carried out by a competent
engineer in accordance with these instructions and the relevant Installation Regulations.
Flue systems must not be modified in any way other than as described in the fitting instructions.
Any misuse or unauthorised modifications to the appliance, flue or associated components and
systems could invalidate the warranty. The manufacturer accepts no liability arising from any
such actions, excluding statutory rights.
SERVICING:
Advise the user to have the system regularly serviced by a competent, qualified engineer (such
as OFTEC registered personnel) using approved spares, to help maintain the economy, safety
and reliability of the appliance.
Failure to install appliances correctly could lead to
prosecution.
The appliance should be installed by a competent
person. The person installing the appliance should
be aware of the Health and Safety at Work Act and
take appropriate action to ensure that the
regulations are adhered to. In order to give
optimum efficiency and trouble free operation the
appliance must be commissioned by a qualified
OFTEC engineer.
The compliance with a British Standard does not,
in itself, confer immunity from legal obligations. In
particular the installation of this appliance must be
in accordance with the relevant requirements of the
following British Standards and regulations in
respect of the safe installation of equipment:
BS 5410: part 1: Code of practice for Oil Fired
Boilers.
BS 799: part 5: Specification for Oil Storage
Tanks.
BS 7593: Code of Practice for treatment of water
in domestic hot water central heating systems.
BS 5449: part 1: Specification for forced
circulation hot water central heating for domestic
premises.
BS 5955: part 8: Specification for the installation
of thermoplastic pipes and associated fittings for
use in domestic hot and cold water services and
heating systems.
BS 7291: Thermoplastic pipes and associated
fittings for hot and cold water for domestic
purposes and heating installations in buildings.
BS 7074: part 1: Application, selection and
installation of expansion vessels and ancillary
equipment for sealed water systems.
BS 7671: IEE Wiring Regulations, current edition.
BS 1362: Specification for general purpose fuse
links for domestic and similar purposes.
The Building Regulations Part J and L1 England
and Wales; Part F and Part J Section III Scotland;
Part L and Part F Northern Ireland.
Local water company bye-laws.
The Control of Pollution (Oil) Regulations.
OFTEC Standards.
Where no specific instruction is given, reference
should be made to the relevant codes of practice.

GENERAL INFORMATION
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
4
APPLIANCE
INFORMATION
GENERAL INFORMATION
STANDARD PACKAGE:
A - Floor standing oil fired condensing boiler.
B - Literature pack.
C -Condensate trap kit.
D - Return pipe.
855mm
600mm
A
370mm
C
B
D
Check List
Item Qty
Greenstar Camray Utility & Utility System Installation/Servicing
Instructions............ ...........................................................................................1
Users Instructions ...........................................................................................1
Warranty Return Envelope ............................................................................1
Guarantee Registration Card........................................................................1
Condensate Trap Kit........................................................................................1
Return Pipe Kit..................................................................................................1

TECHNICAL DATA INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
5
TECHNICAL DATA
Central Heating
Primary water capacity (total) Utility litres
Primary water capacity (total) Utility System litres
Maximum static head metres
Minimum static head metres
Water side resistance (20°C difference) Utility mbar
Max. available pumphead (20° difference) Utility System mH2O
Max. permissible sealed system operating pressure bar
in accordance with WRAS guidelines
Flue
Exit flue gas mass flow kg/hr
Pipework connections
Fuel line (compression) mm
Utility System flow mm
Utility flow/optional vent BSP
Primary drain BSP
Condensate (polypropylene) mm
Pressure relief valve outlet - Utility System mm
Electrical
Electrical power supply voltage AC...V
Frequency Hz
Max. power consumption Utility W
Max. power consumption Utility System W
Thermostats
Boiler flow temperature range (cut in/cut out) °C
Control thermostat differential °C
Boiler high limit thermostat set point °C
Boiler manual reset overheat thermostat set point °C
Flue manual reset overheat thermostat set point °C
General Data
Maximum hearth temperature °C
SEDBUK (Band A) %
Appliance protection rating IP
Weight (excluding packaging) Utility kg
Weight (excluding packaging) Utility System kg
Emissions class for NOx and CO class
DESCRIPTION UNITS 12/18 18/25 25/32
APPLIANCE
INFORMATION
23
30
30
1
26
5.7
2.5
29
10
22
1
3/4
21.5
15
230
50
150
255
55/81
5
95
105
110
<100
93.1
20
101
109
3
23
30
30
1
52
4.9
2.5
40
10
22
1
3/4
21.5
15
230
50
160
265
55/81
5
95
105
110
<100
93.2
20
103
111
3
21
28
30
1
69
4.1
2.5
51
10
28
11/4
3/4
21.5
15
230
50
160
265
55/81
5
95
105
110
<100
94.2
20
110
118
3

1
25
34
8
11
18
19
12
30
29
28
31
26
25
22
23
16
27
6
9
7
10
13
14
15
17
20
21
24
LAYOUT & COMPONENTS
UTILITY
LAYOUT & COMPONENTS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
6
APPLIANCE
INFORMATION
The diagram opposite excludes the top, front
and RH side casing panels.
1 CONTROL BOX ASSEMBLY
2 CASING SIDE PANEL
3 FLUE GAS SAMPLING POINT
4 FLUE MANIFOLD ACCESS COVER
5 FLUE OVERHEAT THERMOSTAT PHIAL
6 POWER CABLE CLIP
7 FIRE VALVE SENSOR CLIP
8 AIR INLET CASING
9 FLEXIBLE AIR DUCT (CONNECTING TO
AIR INTAKE ON BURNER)
10 SECONDARY HEAT EXCHANGER
BLEED POINT (ONE ON EITHER SIDE)
11 SECONDARY HEAT EXCHANGER
12 SECONDARY HEAT EXCHANGER
DRAIN
13 CONDENSATE OUTLET
14 BAFFLE RETAINER ACCESS DOOR
15 HEAT EXCHANGER FLOW PIPE
16 CONTROL & MANUAL RESET
OVERHEAT THERMOSTAT PHIAL
17 AUTO-RESET HIGH LIMIT
THERMOSTAT PHIAL
18 PRIMARY HEAT EXCHANGER
19 COMBUSTION CHAMBER ACCESS
DOOR
20 BASE PLATE AND OIL DRIP TRAY
21 BURNER AIR INTAKE (CONNECTED
BY FLEXIBLE DUCT (9) TO AIR
INLET CASING (8) )
22 BURNER MOTOR (BEHIND PLASTIC
COVER)
23 OIL PUMP (BEHIND PLASTIC COVER)
24 LOCKOUT RESET BUTTON (ON FRONT
OF BURNER CONTROL BOX)
25 BURNER CONTROL BOX (BEHIND
PLASTIC COVER)
26 RIELLO RDB BURNER
27 OIL SUPPLY ISOLATING VALVE
28 DEFLECTOR PLATE
29 BOILER OVERHEAT RESET BUTTON
30 FLUE OVERHEAT RESET BUTTON
31 TEMPERATURE CONTROL KNOB

LAYOUT & COMPONENTS
UTILITY SYSTEM
LAYOUT & COMPONENTS INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
7
PRE -
INSTALLATION
1
2
16
17
15
11
5
34
8
13
19
21
20
14
34
25
35
23
24
12
32
31
30
26
18
10
33
67
9
27
28
29
22
The diagram opposite excludes the top, front
and RH side casing panels.
1 CONTROL BOX ASSEMBLY
2 CASING SIDE PANEL
3 FLUE GAS SAMPLING POINT
4 FLUE MANIFOLD ACCESS COVER
5 FLUE OVERHEAT THERMOSTAT PHIAL
6 POWER CABLE CLIP
7 FIRE VALVE SENSOR CLIP
8 AIR INLET CASING
9 FLEXIBLE AIR DUCT (CONNECTING TO
AIR INTAKE ON BURNER)
10 SECONDARY HEAT EXCHANGER
BLEED POINT (ONE ON EITHER SIDE)
11 SECONDARY HEAT EXCHANGER
12 SECONDARY HEAT EXCHANGER
DRAIN
13 CONDENSATE OUTLET
14 BAFFLE RETAINER ACCESS DOOR
15 AUTO-RESET HIGH LIMIT
THERMOSTAT PHIAL
16 HEAT EXCHANGER FLOW PIPE
17 CONTROL & MANUAL RESET
OVERHEAT THERMOSTAT PHIAL
18 CIRCULATING PUMP
19 PRIMARY HEAT EXCHANGER
20 COMBUSTION CHAMBER ACCESS
DOOR
21 BASE PLATE AND OIL DRIP TRAY
22 BURNER AIR INTAKE (CONNECTED
BY FLEXIBLE DUCT (9) TO AIR
INLET CASING (8) )
23 BURNER MOTOR (BEHIND PLASTIC
COVER)
24 OIL PUMP (BEHIND PLASTIC COVER)
25 LOCKOUT RESET BUTTON (ON FRONT
OF BURNER CONTROL BOX)
26 EXPANSION VESSEL BRACKET
27 BURNER CONTROL BOX (BEHIND
PLASTIC COVER)
28 DEFLECTOR PLATE
29 RIELLO RDB BURNER
30 EXPANSION VESSEL
31 SYSTEM PRESSURE GUAGE
32 PRESSURE RELIEF VALVE
33 BOILER OVERHEAT RESET BUTTON
34 FLUE OVERHEAT RESET BUTTON
35 TEMPERATURE CONTROL KNOB
NOTE: OIL SUPPLY ISOLATING
VALVE LOCATION IS ILLUSTRATED
ON PREVIOUS PAGE ITEM 27.

CLEANING PRIMARY SYSTEMS
BEFORE CLEANING THE SYSTEM:
ENSURE THE SYSTEM AND PIPEWORK IS
IN GOOD WORKING ORDER.
FLUSH THE EXISTING SYSTEM WITH A
POWER FLUSHING MACHINE OR WITH A
CHEMICAL CLEANER BEFORE
INSTALLING NEW COMPONENTS.
CLEANING THE PRIMARY SYSTEM:
Cleanse the system in accordance with
BS 7593.
Fill the system with cold mains water to the
recommended pressure and check for leaks.
Open all drain cocks and drain the system.
Close drain cocks and add a suitable flushing
agent at the correct strength for the system
condition in accordance with the manufacturer's
instructions.
Circulate the flushing agent before the boiler
is fired up.
Run the boiler and system at normal operating
temperature in accordance with the
manufacturer's instructions.
Drain and thoroughly flush the system to
remove the flushing agent and any debris.
IMPORTANT: All the following Pre-Installation sections must be read and
requirements met before starting boiler or flue installation.
CAUTION: ISOLATE THE MAINS SUPPLIES BEFORE STARTING ANY WORK AND
OBSERVE ALL RELEVANT SAFETY PRECAUTIONS.
IMPORTANT: Debris from the system can
damage the boiler and reduce efficiency.
Failure to comply with the guidelines for
the use of water treatment with the
appliance will invalidate the appliance
warranty.
CLEANING PRIMARY SYSTEMS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
8
PRE -
INSTALLATION

MAINS SUPPLY
ELECTRIC SUPPLY:
• Supply: 230V - 50Hz.
• Cable: PVC insulated 0.75mm2(24 x
0.2mm) temperature rated to 90°C.
• Protection IP20.
• External 5A fuse to BS1362.
• The appliance must be earthed.
• All pipes to the boiler must be
cross-bonded.
• It must be possible to isolate the appliance
from the electric supply with at least a 3mm
contact separation in both poles supplying
the appliance.
• Wiring between the appliance and the
electrical supply must comply with IEE wiring
regulations and any local regulations which
may apply for fixed wiring to a stationary
appliance.
• Any system connected to the boiler must not
have a separate electrical supply.
MAINS SUPPLY INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
9
PRE -
INSTALLATION

OIL SUPPLY
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
10
PRE -
INSTALLATION
OIL SUPPLY
OIL SUPPLY :
•This appliance is suitable for 28 second
kerosene only, no other fuel must be used.
• Plastic or steel tanks should be installed to
BS 5410. A steel tank should conform to
BS 799: part 5 and have a slope of 1 in 24
away from the outlet valve with a sludge cock
at its lower end.
• Do not use galvanised steel tanks or
pipework for the oil supply system.
• Do not use soldered joints on the oil
supply pipework.
a) Single pipe gravity feed system:
The oil storage tank (A) must be positioned so
that the oil level does not exceed 4 metres above
the level of the burner oil pump (J) and in addi-
tion the oil level must be at least 300mm above
the oil pump (J). Where the maximum oil level in
the oil storage tank exceeds 4 metres, a head
breaking device must be installed between the
tank (A) and the burner oil pump (J).
b) Double pipe sub-gravity feed system:
Maximum suction height 3.5 metres. Non-return
valves must be fitted to the inlet and return oil line
between the oil pump (J) and oil storage tank (A).
c) Single pipe suction lift with de-aerator
Maximum suction height 3.5 metres. The oil
tank (A) must be positioned below the oil pump
(J). Create an inlet and return loop between the
de-aerator (M) and oil pump (J).
A non-return valve must be incorporated within
the de-aerator or fitted to the oil line between
the oil storage tank (A) and the de-aerator (M).
A top feed oil tank fitted with a de-aerator
using an internal non-return valve should have
any non-return valves fitted in the base of the
tank to the suction line removed to assist
purging air from the oil line.
Pipework
Use copper pipe of the correct diameter
according to the information shown opposite.
Use flexible hoses to connect to the oil pump (J).
Lay the oil supply pipe (H) as straight and
level as possible to avoid air pockets and
unnecessary friction losses. Route away
from the boiler access door or other hot
surfaces.
Install a manual isolating valve (B) to the oil
supply pipe (H), as close to the oil storage
tank (A) as possible.
Fit an oil strainer and water seperator (C) to
the oil supply pipe, near the oil storage tank.
Fit an additional oil filter (N, 16µmmax
filtration size) close to the boiler, but not
inside the boiler casing.
Fit a fire valve in accordance with BS 5410.
The fire valve (D) should be fitted externally
to the building with the fire valve sensor (F)
located within the appliance case.
A fire valve with a shut off temperature of
85°C or higher is recommended to avoid
the possibility of nuisance shut offs.
A capillary type valve provides a neat and
simple installation. Alternatively, a fusible
link or electrical system may be used.
Under no circumstances should a
combination isolating/fire valve be used
as the sole fire protection device.
AF
BN GJ
4m (13ft) max.
K
a)
H
300mm min.
B DB C
MAXIMUM PIPE RUN FOR SINGLE PIPE GRAVITY FEED SYSTEM
B
A
DB
C
E
K
3.5m (11.5ft) max.
L
L
b)
H
FG
B
150mm
MAXIMUM PIPE RUN FOR DOUBLE PIPE SUB-GRAVITY FEED SYSTEM
NJ
B
A
M
B
F
C
G
J
3.5m (11.5ft) max.
E
D
c)
MAXIMUM PIPE RUN FOR SINGLE PIPE SUCTION LIFT WITH DE-AERATOR
H
FUEL FLOW RATE FUEL FLOW RATE
K
E
A - Oil storage tank.
B - Isolating valve.
C - Oil strainer & water seperator.
D - Fire valve to BS 5410.
E - External wall.
F - Fire valve sensor.
G - Oil burner.
H - Oil supply pipe.
J - Oil pump.
K - Full base (plastic tanks).
L - Non-return valve.
M - De-aerator.
N - Oil filter (16µmmax filtration size)
NOTE: All dimensions are in metres unless stated otherwise.
The maximum pipe run figures are based on using copper pipe with an inside diameter of
2mm less than the Ø.
HEAD 10mmØ 12mmØ
0.5 12 30
1.0 25 69
1.5 37 91
2.0 49 100
HEAD 10mmØ 12mmØ
2.5 62 100
3.0 74 100
3.5 87 100
4.0 99 100
HEAD 10mmØ 12mmØ
050 100
0.5 44 100
1.0 38 95
1.5 32 80
HEAD 10mmØ 12mmØ
2.0 26 66
2.5 20 50
3.0 14 37
3.5 8 22
HEAD 2.5kg/h 5kg/h 10kg/h 10kg/h
8mmØ 8mmØ 8mmØ 10mmØ
0 100 55 26 100
0.5 95 45 23 100
1.0 80 40 20 90
1.5 70 35 17 75
HEAD 2.5kg/h 5kg/h 10kg/h 10kg/h
8mmØ 8mmØ 8mmØ 10mmØ
2.0 60 30 14 65
2.5 45 25 11 50
3.0 35 15 8 35
3.5 25 10 5 20
The table and illustration above is a guide only and does not in any way override the de-
aerator manufacturers instructions.

WATER SYSTEMS & PIPEWORK INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
11
PRE -
INSTALLATION
R
TYPICAL OPEN VENT SYSTEM:
A - Appliance.
B - Expansion vessel.
C - Automatic bypass valve.
D - Drain cock.
E - Feed and expansion cistern.
F - Feed and expansion
15mmØ min.
G - Pressure gauge.
H - Open vent 22mmØ min.
J - Circulating pump.
K - Zone valve.
L - Lockshield valve.
M - Hot water cylinder.
N - Automatic air vent.
P - Pressure relief
discharge.
R - Radiators.
S - Static head.
T - Thermostatic radiator
valve (TRV).
U - To filling system.
E
1000mm min.
FH
A
R R
R R
D
C
TLTL
TL TL
JK
M
150mm max.
K
TYPICAL SEALED SYSTEM:
A
D
R R
R
B
P
D
C
TLTL
TL TL
G
JK
M
N
D
U
S
WATER SYSTEMS & PIPEWORK
PRIMARY SYSTEM PLASTIC PIPEWORK:
•Do not use plastic pipework on sealed
systems, *apart from underfloor heating
correctly installed as detailed below.
• Any plastic pipework used on an open vented
system must have a polymeric barrier with
1000mm (minimum) length of copper or steel
pipe connected to the boiler.
•*Plastic pipework used for underfloor heating
must be correctly controlled with a
thermostatic blending valve limiting the
temperature of the circuits to approx. 50°C.
The pipework from the boiler to the blending
valve must be in copper or steel (protected
from corrosion).
PRIMARY SYSTEM/CONNECTIONS/VALVES:
•Do not use galvanised pipes or radiators.
• All system connections, taps and mixing
valves must be capable of sustaining a
pressure of 3 bar.
• Radiator valves should conform to
BS 2767:10.
• All other valves should conform to BS 1010.
• On new installations TRVs must be used on
all radiators except the radiator where the
room thermostat is sited, this must be fitted
with lockshield valves and left open. All
installations should have TRVs fitted to
radiators within the sleeping accommodation.
• An automatic bypass valve must be connected
between the heating flow and return where
TRVs are used on all radiators, fitted to give
at least a 3 metre circuit when activated.
• Drain cocks are required at all the lowest
points on the system.
• Air vents are required at all high points on the
system.
OPEN VENT PRIMARY SYSTEM
•Utility System models: The feed and
expansion pipe (F) and the open vent pipe
(H), (or the combined feed and vent pipe),
must be connected to the BSP outlet/s on
the side of the primary heat exchanger.
• The feed and expansion cistern (E) must be
positioned to provide a static head (S) of at
least 1 metre above the highest point in the
heating system to the water level in the feed
and expansion cistern (E).
• No valve shall be fitted in the open vent pipe
(H) or the feed and expansion pipe (F).
• The open vent pipe (H) must be at least
22mmØ.
FULLY PUMPED SEALED PRIMARY SYSTEM
Utility System models:
• A pressure relief valve (P), spring loaded
safety valve set to operate at 3bar, must be
fitted to the heating flow pipe as close as
possible to the boiler or onto one of the boiler
top 1” / 11/4” BSP outlets.
• An expansion vessel (B) must be fitted to the
heating return pipe as close as possible to
the boiler and pressurised for the system
volume according to the instructions supplied
with the vessel.
• A pressure gauge (G), 3 bar minimum, must
be fitted to the heating flow pipe or one of the
boiler 1” / 11/4” BSP outlets.
• An automatic air vent (N) must be fitted (all
models).
IMPORTANT: The boiler should not be
allowed to operate with a return
temperature of less than 40°C when the
system is up to operating temperature.

WATER SYSTEMS & PIPEWORK
FILLING PRIMARY SEALED SYSTEMS:
• Filling the system must comply with one of
the methods shown opposite.
• The filling point must be at low level and must
never be a permanent direct fixing to the
mains water supply.
• Filling loops must be WRAS approved.
Heating return
Hose
return
Non return
valve Non return valve
Test cock
Stop
cock
Water main
supply
Stop
cock
Temporary hose
Heating return Auto air
vent Non return
valve
Stop
cock
Make up
vessel
1000mm above
the highest point
of the system
Fill Point
INSTALLATION
COMMISSIONING
WATER SYSTEMS & PIPEWORK
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
12
PRE -
INSTALLATION

CONDENSATE & PRESSURE
RELIEF PIPEWORK
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
13
PRE -
INSTALLATION
CONDENSATE &
PRESSURE RELIEF PIPEWORK
CONDENSATE PIPEWORK:
• All national and, where appropriate, local
regulations for the discharge and
neutralisation of condensate should be
followed.
• The condensate pipe must be a minimum of
21.5mmØ polypropylene pipe.
• The condensate pipework must fall at least
50mm per metre towards the outlet and
should take the shortest practicable route
and not exceed 3 metres outside the building.
If a run greater than 3m is required, 32mmØ
polypropylene pipe must be used.
• The pipework must follow one of the options
shown opposite:
a - Internal waste drainage system
b - Soil/vent stack
c - External drainage system
d - External condensate absorption point
• Use waterproof pipe insulation in exposed
positions and for external pipework
IMPORTANT: Condensate pipework must not
leak and the condensate trap must be filled
with water before the boiler is started to
prevent the possibility of potentially harmful flue
products escaping via the condensate route.
A - Condensate from the boiler condensate
trap (supplied) which has a 75mm
minimum water seal.
B - Sink.
C - 21.5mm Ø polypropylene condensate pipe.
D - Gully.
E - Internal soil and vent stack.
F - 300mm x 100mm Ø sealed plastic tube.
G - Ground level.
H - Drainage holes 50mm from base of tube
(12mm Ø at 25mm centres) facing away
from building.
I - Limestone chippings.
PRESSURE RELIEF PIPEWORK:
IMPORTANT: The pressure relief valve is a
safety device for the boiler and if activated may
discharge boiling water or steam through the
relief valve drain pipe.
Care should be taken when siting the outlet
pipe so that it does not cause an obstruction or
discharge above a window, entrance or other
public access where it could cause a hazard.
• The pressure relief drain pipe (K) should be
at least 15mm diameter copper pipe and run
downwards away from the boiler and discharge
away from any electrics or other hazard,
preferably to an external drain or soakaway.
• Pipe (K) should be finished with a partial
bend, near the outlet to face the external wall
(as shown) to help prevent freezing.
J - Outside wall.
K - Drain pipe.
L - External drain.
b
E
C
Invert
450 min.
A
c
D
A
C
75mm
min.
a
A
BC
D
400mm
min.
500mm min.
d
F
I
H
G
A
C
25mm
min.
200mm min.
K
L
J
K

BOILER LOCATION &
CLEARANCES
• This boiler is only suitable for installing
internally within a property at a suitable
location onto a fixed rigid surface of the same
size as the boiler and capable of supporting
the boiler weight.
• The boiler must be installed on a flat level
surface to ensure condensate does not enter
the primary heat exchanger.
• The boiler is not suitable for external
installation unless a suitable enclosure is
provided.
• Roof space installations must fully conform to
BS5410 part 1 section 4.6.9.
Open flue model (CF):
• In order to ensure clean and efficient
combustion an adequate supply of air must
be delivered to the combustion chamber.
• To provide sufficient air a suitable inlet must
be provided into the room or space in which
the boiler is situated.
An air brick or other form of continuous air
supply may have to be built into the installation
in order to ensure an adequate supply of air.
• If the appliance is to be installed in a confined
space or compartment two air vents are
required, one at high level and one at low level.
The minimum free area of each vent is
shown opposite and depends whether the
air is taken from another room or from
outside the building.
• Where the air is taken from another room that room
must contain an air inlet as described above.
Room sealed balanced flue model (RS):
The appliance does not require a separate vent
for combustion air.
• Installation in cupboards or compartments
require permanent vents for cooling purposes,
one at high level and one at low level, either
direct to outside air or to a room.
• Both vents must pass to the same room or be
on the same wall to the outside air.
The minimum air vent free area is given in the
table opposite.
a: INSTALLATION CLEARANCES:
Diagram (a) shows the minimum space
recommended to install the boiler only.
b: ANNUAL SERVICE CLEARANCES:
Diagram (b) shows the minimum space
required to carry out an annual service.
c: MAINTENANCE & REPAIR CLEARANCES:
Diagram (c) shows the minimum space required
for maintenance and repair to the boiler. The
appliance is suitable for an under worktop
installation providing that the worktop above the
boiler (min.10mm clearance) is removable for
maintenance and repair and the front of the
boiler is not enclosed.
MINIMUM AIR VENT AREA (cm2) FOR APPLIANCES INSTALLED IN A COMPARTMENT:
1Internal air to and from a space/room inside the building. 2External air to and from directly outside the building.
Conventional flue:
Internal1ventilation
High Low
Model Level Level
12/18 143 214
18/25 220 330
25/32 275 413
External 2ventilation
High Low
Level Level
72 143
110 220
138 275
Room Sealed flue:
Internal1ventilation
High Low
Model Level Level
12/18 143 143
18/25 220 220
25/32 275 275
External 2ventilation
High Low
Level Level
72 72
110 110
138 138
12/18
CF minimum air inlet sizes
72 110 138
18/25 25/32
Model
Size cm2
BOILER LOCATION & CLEARANCES
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
14
PRE -
INSTALLATION
600mm
300mm
100mm
100mm
570mm
1200mm
1155mm
a: RECOMMENDED
INSTALLATION CLEARANCES
b: ANNUAL SERVICE CLEARANCES
600mm
10mm
5mm*
5mm*
380mm
1200mm
1155mm
c: MAINTENANCE & REPAIR CLEARANCES
600mm
300mm
5mm*
5mm*
380mm
1200mm
1155mm
* Remove the flue 'knock-out'
panel sections if this clearance
is less than 75mm.

600mm
2250mm
600mm
750mm
1 1 23
2
3
A
0
600mm
2250mm
600mm radius
750mm
A
A - Bath or shower cubicle (zone 0)
1 1 22 3
0
3
BOILER LOCATION &
CLEARANCES
BOILER LOCATION & CLEARANCES INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
15
PRE -
INSTALLATION
COMPARTMENTS:
Follow the requirements of BS 5410 and note:
• Minimum clearances must be maintained.
• An access door is required to install, service
and maintain the boiler and any ancillary
equipment.
• If fitting the boiler into an airing cupboard
use a non-combustible material (if perforated,
maximum hole sizes of 13mm) to separate
the boiler from the airing space.
Venting compartments:
There must be sufficient clearance around the
appliance to allow proper circulation of
ventilation air. The clearances required for
installation and servicing will normally be
adequate for ventilation.
• Ventilation must be provided for boilers
fitted into compartments as described in
BS 5410.
• Combustion air must not be taken from a
room or internal space containing a bath or
shower and must not communicate with a
protected area such as a hall, stairway,
landing, corridor, lobby, shaft etc.
• Air vents must allow access for clean free
air and must be sited to comply with the flue
terminal position requirements.
• Air ducting runs must not exceed 3m.
• Low level air vents must be less than
450mm from the floor.
• A warning label must be added to the vents
with a statement to the effect: ''Do not block
this vent. Do not use for storage.”
SHOWER / BATHROOMS:
The boiler must not be installed in zones 0, 1
or 2 (the shaded areas shown on the diagrams oppo-
site).
IMPORTANT: conventional flued boilers must
not be fitted in a bathroom.
IMPORTANT: any appliance control using
mains electricity must not be able to be
touched by a person using the bath or shower.
Electrical switches, fused spur and socket
outlets must not be fitted in the bathroom.
In all cases the IEE wiring regulations must be
consulted.
All pipework in bathrooms and shower rooms
must be cross bonded.

PRE -
INSTALLATION
FLUE TERMINAL POSITIONS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
16
Minimum dimensions of flue terminal positions for oil-fired appliances:
TERMINAL POSITION CF RS(H) RS(V)
A1 2 Directly below an opening, air brick, opening window, etc N/A 600mm N/A
B1 2 Horizontally to an opening, air brick, opening window, etc N/A 600mm N/A
C Below a plastic/painted gutter, drainage pipe or eaves if N/A 75mm N/A
combustible material protected
D3Below a plastic/painted gutter, drainage pipe or eaves without N/A 600mm N/A
protection to combustible material
E From vertical sanitary pipework N/A 300mm N/A
F From an external or internal corner or from a surface or boundry N/A 300mm N/A
alongside the terminal
G Above ground or balcony level N/A 300mm* N/A
H From a surface or boundary facing the terminal N/A 600mm** N/A
J From a terminal facing the terminal — 1200**mm —
K Vertically from a terminal on the same wall N/A 1500mm N /A
L Horizontally from a terminal on the same wall — 750mm —
M Above the point of highest intersection with the roof 600mm — 600mm
N From a vertical structure on the side of the terminal 750mm — 750mm
O Above a vertical structure less than 750mm from the side of the terminal 600mm — 600mm
P From a ridge terminal to a vertical structure on the roof 1500mm — N/A
Q Above or to the side of any opening on a flat or sloping roof 300mm — 300mm
R Below any opening on a sloping roof 1000mm — 1000mm
Key: — Not applicable, N/A Not allowed, CF Conventional flue, RS(H) Room Sealed Horizontal flue, RS(V) Room Sealed Vertical
flue.
Notes:
1. Terminals should be positioned so as to avoid products of combustion accumulating in stagnant pockets around the building or
entering into buildings.
2. Vertical structure in N, O and P includes tank or lift rooms, parapets, dormers etc.
3. Terminating positions should be at least 1.8m from an oil storage tank unless a wall with at least 30 min fire resistance and
extending 300mm higher and wider than the tank is provide between the tank and the terminating position.
4. Where a flue is terminated less than 600mm away from a projection above it and the projection consists of plastics or has a
combustible or painted surface, then a heat shield of at least 750mm wide should be fitted.
5. If the lowest part of the terminal is less than 2m above the ground, balcony, flat roof or other place to which any person has
access, the terminal should be protected by a guard.
6. Notwithstanding the dimensions given above, a terminal should not be sited closer than 300mm to combustible material. In the
case of a thatched roof, double this separation distance should be provided. It is also advisable to treat the thatch with a fire
retardant material and close wire in the vicinity of the flue.
7. It is essential that a flue or chimney does not pass through the roof within the shaded area delineated by dimensions Q and R.
8. Where protection is provided for plastic components, such as guttering, it is essential that this is to the standard specified by the
manufacturer of the plastic components.
FLUE TERMINAL POSITIONS
• Flue terminals must be positioned to avoid
combustion products entering into buildings.
• The flue must be fitted and terminated in
accordance with the recommendations of
BS5410.
• The flue must not cause an obstruction.
• Discharge from the flue outlet must not be a
nuisance.
• Flue gases have a tendency to plume and in
certain weather conditions a white plume of
condensation will be discharged from the flue
outlet which could be regarded as a
nuisance, for example, near security lighting.
• There should be no restriction preventing the
clearance of combustion products from the
terminal.
• The air inlet/outlet duct and the terminal of
the boiler must not be closer than 25mm to
any combustible material. Detailed
recommendations on protection of
combustible materials are given in BS 5410:1
• A protective terminal guard must be fitted if
the terminal is 2m or less above a surface
where people have access.
The guard must be spaced equally (minimum
50mm) around the flue and fixed to the wall
with plated screws.
See 'Contact Information' on the back cover
for flue guard information.
• The following additional guidelines (from part
L Exceptions Guidance Document) are
recommended when determining the flue
outlet position:
• Avoid discharging flue gases into car ports
or narrow passageways.
• *Minimum distance of the flue terminal from
above ground is 2100mm where directed to a
public footpath, private access route or a
frequently used area and 2500mm from a
car parking area.
• **Minimum distance of the flue terminal to a
facing wall, fence, building or property
boundary is 2500mm.
O
P
boundary
F
J
H
B
A
G
E
M
C, D
N
F
F
K
L
boundary
Q
Q
Q
R
Q
Q
Q
Q
Pitched roof
Flat roof

CONVENTIONAL FLUE
C
B
A
D
E
A - Boiler
B - Flue
C - Max. 2 bends at 135°
D - Anti down-draught terminal
E - Chimney
CONVENTIONAL FLUE INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
17
PRE -
INSTALLATION
• Open (conventional) flued appliances must
not be installed in a bedroom, bathroom or
bedsitting room.
• The flue system must be in accordance with
BS 5410 : Part 1 and the current Building
Regulations.
• The flue must be constructed of materials
suitable for use with condensing combustion
products.
• External flue systems must be of the insulated
type.
• Brick and masonry chimneys must be lined
with a suitable non-combustible material and
properly jointed to withstand the effects of
the working temperature (minimum rating of
material 120°C) of the appliance and any
condensate which may form.
• All flue joints must be sealed to prevent the
leakage of condensate and combustion
products.
• Ensure that joints are made so that the
condensate runs away and is not collected
within the joint.
NOTE: The flue can be increased in size from
the boiler take off point providing the joint is
correctly sealed. Never reduce the flue diameter
from the boiler take off point.
CF Sizing:
• 12/18 and 18/25 = 100/103mmØ
25/32 = 130mmØ
• Because the flue operates at a lower
temperature on a condensing boiler
compaired to that of a conventional
appliance, the flue draught will be lower.
Typically the draught will be between
0.5mmwg and 4.4mmwg, measured with the
flue warm but the burner not firing. The actual
figure will vary depending on weather
conditions, flue height and position.
• The flue should be vertical and contain as few
bends as possible, a maximum of two 135°
bends should be used.
• The flue outlet must be extended beyond the
eaves of the building and where possible,
above the apex.
• Fit a suitable anti down-draught terminal
where down draughts are experienced.
Manufacturers of conventional flue systems
suitable for this appliance are listed under
'Contact Information' on the back cover.

PRE -
INSTALLATION
ROOM SEALED FLUE OPTIONS
INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
18
ROOM SEALED FLUE OPTIONS
The diagrams (opposite) show the components
used and the maximum flue length (L) for
each flue configuration.
In all cases L is measured from the outside of
the boiler casing.
• To achieve the maximum flue length (L), a flue
section will have to be reduced in length.
• Only the flue terminal or straight flue
extensions can be reduced in length by
cutting.
• The flue terminal end can be fitted from the
inside or outside of the building.
IMPORTANT:
All horizontal sections must rise away
from the boiler by 52mm per metre (3°) to
allow the condensate to drain back to the
boiler.
A - Horizontal terminal
B - Straight flue extension
C - Flue bend 90°
D - Flue bend 45°
E - Vertical Terminal Kit (incl. 90° elbow)
Calculating the flue length:
Measure the total flue length required, noting
that the maximum straight flue length including
the terminal is:
Horizontal 80/125mm Ø: 4000mm (excluding
120mm of terminal extending outside the building)
Vertical 80/125mm Ø & 100/150mm Ø:
8000mm (measured from the boiler top panel).
Then reduce the total straight flue length for
each extra flue bend (excluding the vertical flue
kit 90° elbow) by:
1000mm for 90°
500mm for 45°
Flue Extension lengths:
Horizontal & Vertical 80/125mm Ø: 1000mm
overall length.
Effective length when engaged into sockets
within the flue run is 950mm.
Flue Terminal lengths:
Horizontal 80/125mm Ø: 720mm
Vertical 80/125mm Ø: 1080mm + cage
Vertical 100/150mm Ø: 1290mm + cage
* to outside wall.
** The 80/125 to 100/150mmØ vertical
adaptor must be fitted vertically at the lowest
point of the vertical section of the flue.
Failure to fit the adaptor vertically will cause
the condensate to pool within the flue and
will adversely affect the flue’s performance.
L = 7000mm
L
B
L = 7000mm
L
D
D
B
L = 8000mm
12/18 & 18/25
125mm Ø
L
B
L
L = 2000mm
125mm Ø
C
B
A
L = 140 - 335mm L
A
L = 4000mm
125mm Ø
L
B
A
L
L = 3000mm
125mm Ø
C
B
A
L = 3000mm
125mm Ø
L = 3000mm
D D
B
AL
125mm Ø
B
A
CL
B
CD
A
E
E
E
E
25/32
150mm Ø**
12/18 & 18/25
125mm Ø
25/32
150mm Ø**
12/18 & 18/25
125mm Ø
25/32
150mm Ø**
4 x
3 x
3 x
C
2 x
8 x
7 x
7 x
3 x

Unpacking:
It is advised that at least two or more persons are
involved in the transfer of the packaged boiler from
the van to the point of delivery.
1 Once the packaged boiler has been
delivered, the outer carton is removed first.
Care should be taken when releasing the
straps. If a sharp implement is used make
sure the outer carton is not pierced and that
the implement is used in such a way so that it
may not cause personal injury. All sharp
objects must be covered or the blade
retracted after use and put away in a safe
place.
2Lift carton up and away from the boiler.
Remove the plastic bag and upper front
protection cover from the boiler and place
safely aside.
At least two or more persons are required
to move the boiler taking care not to damage
the boiler, panels or the floor.
At all times the correct method for handling
heavy objects should be strictly observed.
UNPACKING THE BOILER
LIFTING AND CARRYING PRECAUTIONS:
• Lift only a manageable weight, or ask for
help.
• When lifting or putting things down, bend
the knees, and keep the back straight
and feet apart.
• Do not lift and twist at the same time.
• Lift and carry objects close to the body.
• Wear protective clothing and gloves to
protect from any sharp edges.
IIMPORTANT: All the previous Pre-Installation sections must be read
and requirements met before starting boiler or flue installation.
1
2
INSTALLATION
UNPACKING THE BOILER INSTALLATION & SERVICING INSTRUCTIONS FOR WORCESTER GREENSTAR CAMRAY UTILITY 12/18-18/25-25/32
8 716 113 004b (05.07)
19
