Worcester danesmoor 50/70 User manual

WORCESTER BOSCH
50/70, 70/90 & 90/110
FLOOR-STANDING OIL-FIRED PRESSURE-JET BOILERS
USER INSTRUCTIONS &
CUSTOMER CARE GUIDE

2
EXCELLENCE COMES
AS STANDARD
Thank you for purchasing a Worcester Bosch oil-fired central
heating boiler.
Worcester Bosch oil boilers are made by Worcester Heat
Systems and the strictest quality control standards ever demanded
are applied throughout every stage of production.
Indeed, Worcester Heat Systems have led the field in
innovative boiler design and
performance for more than 30
years.
The result is that your new
Worcester Bosch boiler offers
you the very best of everything
- quality, efficiency, economical
running costs, proven reliability
and value for money.
What’s more, you also have the
assurance of our no-nonsense 2
year parts and labour
guarantee.
And it’s backed up by
Worcester Care Call - a
complete maintenance scheme
to keep your boiler operating at peak condition and efficiency.
No wonder that more and more people are agreeing that when
it has to be oil, it has to be Worcester Bosch.
Page No.
Operating Instructions
.................................... 3-8
Fault Finding Guide ...... 8
Maintenance and Extended
Warranty Information .... 9
Service Centres ............ 10
Guarantee Details ........ 11
CONTENTS

3
GENERAL
INFORMATION
To ensure you get the very best from your new Worcester
Bosch oil boiler, please read these notes and instructions carefully.
ELECTRICAL CONNECTION
A mains cable should be connected to a double pole isolator
with a contact separation of 3 mm on all poles and supplying the
appliance and controls only.
The mains supply for your boiler is 230/240 volts AC-50Hz.
Your boiler must be earthed and protected by a 5-amp fuse.
OPEN-FLUED BOILERS
Your installer will create airways (in walls or doors) to ensure
an adequate supply of fresh air to the boiler for combustion. Do
not block these airways, and never hang clothes or other
combustible materials over the boiler or against the flue pipe.
Never place anything on top of the boiler.
ROUTINE MAINTENANCE
It is essential that your boiler is installed and serviced by a
competent heating engineer, and Worcester Heat Systems will be
pleased to arrange regular servicing and a comprehensive
maintenance contract.
Alternatively, the Oil Firing Technical Association for the
petroleum industry (OFTEC) will gladly advise you of engineers
trained by and registered with OFTEC.
Servicing should be carried out at least once a year for boilers
which burn 28-second kerosene, and twice a year for boilers which
burn 35-second gas oil.

4
SERIAL NUMBER
Your boiler serial number and model number should always
be quoted in any contact with Worcester Heat Systems. This will
help identify spare parts and also avoid confusion and delays
during any service call-out. You will find these numbers on the
front of the electrical control box facia, and access can be gained by
removing the front panel of the boiler casing. (See section
“Accessing your boiler controls.”)
TECHNICAL INFORMATION
The Worcester Bosch range of oil-fired boilers can provide
both domestic hot water and full central heating, with outputs
ranging from 15kW to 32kW (50,000 to 109,000 Btu/h).
Domestic hot water must be supplied via a conventional indirect
hot-water system, utilising an indirect double-feed cylinder.
The appliance is supplied without a circulating pump, but
there is provision to locate a pump within the boiler casing. For
further details please consult your installer.
The temperature control knob, overheat reset button and
lockout reset button are all located behind the cabinet front panel.
To remove the front panel pull forwards at the bottom end to
release the lower two ball studs and repeat the procedure at the top
end to release the upper ones. Take care not to pull the bottom
end too far forwards as this may damage the spring clips.
TO START YOUR BOILER (See Fig. 1.)
(a) Switch on the electrical mains supply to the boiler.
(b) Ensure that any external controls connected to the boiler, such
as a room thermostat, are on a high setting.
(c) If a programmer is fitted, set it to the correct time of day and
position the selectors to ON.
(d) Turn the thermostat control knob to the desired position (see
Fig. 2: temperature control).
ACCESSING YOUR
BOILER CONTROLS
HOW TO START YOUR
BOILER

TEMP
Isolate
mains
supply
before
removing
Burner
or any
electrical
cover.
Temperature
Control Knob Serial Number
Label Overheat Thermostat
Reset Button
5
(e) Your boiler will now commence a start sequence, in which a
pre-ignition period of approximately 15 seconds is followed by
a supply of atomised oil being introduced into the combustion
chamber. Ignition then occurs, followed by a post-ignition
period of approximately 20 seconds.
(f) Your boiler is now in a steady run condition and will remain so
until the water temperature reaches the temperature set on the
control thermostat. At this point the burner will stop and the
boiler will shut down. The sequence will continue until the
boiler is programmed - either manually or by an automatic
programmer - for a period of shutdown.
During normal operation your boiler can be switched off at
the programmer, where fitted, or at the control switch provided by
your installer. When the heating system is not being used during
the winter period your boiler should be protected by a frost
thermostat. Consult your installer if you are unsure! If a frost
thermostat is not fitted, set the temperature control knob to
minimum and leave the boiler running on low output.
To switch off your boiler for long periods, turn off the mains
electricity at the isolator switch and, during periods of cold
weather, drain the heating system.
TO SWITCH OFF YOUR
BOILER
Fig. 1. Control Facia

6
The temperature control knob gives you control
over the water temperature in your central heating
radiators, and you can adjust it to any position
within the indicated range (as shown in Fig. 2.).
Higher settings obviously mean hotter
radiators and rooms will reach the required
temperature quicker. The ideal setting varies from
property to property, and can only be established
by trial and error and experience: a setting of
medium to high should serve as a good initial
guide.
PLEASE NOTE: The control knob must not be
set below the first indicating bar.
Your boiler is fitted with two high limit thermostats to protect
the appliance in the event of a control or system malfunction. The
first overheat thermostat is designed to cut out at a lower temperature
than the manual reset overheat thermostat, and will reset itself when
the boiler cools to a safe operating level.
The manual reset thermostat will operate if the boiler reaches a
dangerous temperature. This will have to be reset by pressing the
button located underneath the control box. (See fig 1.)
If the overheat thermostat persistently cuts out then your boiler
requires attention and you should call either your installer or a service
engineer.
A flame failure device is incorporated into the control system
of your boiler. So, should the flame fail for any reason, or should
ignition fail to initiate a satisfactory start, the boiler is automatically
locked out for safety. This lockout condition is indicated by a
signal lamp located on the burner control box.
To cancel the burner lockout condition, remove the boiler
front cover and allow two minutes before pressing the illuminated
lockout reset button, which is mounted on the burner control box.
HIGH-LIMIT THERMOSTAT
LOCKOUT
TEMPERATURE CONTROL
The control knob has a range of adjustment as
indicated by the symbols.
Fig. 2.
Low
Setting High
Setting
TEMP

7
Provided the system is still calling for heat, the burner will then
operate and commence another start cycle.
Persistent lockout indicates a fault and an engineer should be
called, so do not attempt to repeatedly restart the boiler.
Your Worcester Bosch pressure-jet boiler is set to burn 28-
second kerosene fuel. Some appliances can be converted to burn
35-second gas oil. If this conversion has been made your installer
will inform you.
PLEASE NOTE: Low-level discharge appliances MUST NOT
be used with 35-second gas oil.
Many calls made to Worcester Heat Systems to report boiler
faults or breakdowns prove to be false alarms, as there is often a
simple explanation for the apparent malfunction.
So, to help you save time and money - not to mention
frustration and inconvenience - a quick-reference fault finder is
included on page 8.
If, after checking through the points suggested, there is still a
fault you should call your Worcester Heat Systems Service Centre.
Arrangements will be made for an engineer to call as soon as
possible.
CALL-OUT CHARGES
All of Worcester Heat Systems’ field service engineers are
factory trained.
If you request a visit from an engineer and your boiler has been
installed within the last 24 months, no charge will be made for
parts and/or labour providing:
●The appliance was commissioned correctly on installation
and a completed Guarantee Registration card returned to
Worcester Heat Systems.
●An appliance fault is found and the appliance has been
installed within the past 24 months, provided that the first
annual service has been carried out on a boiler which is more
than 12 months old. Reasonable evidence of this must
be supplied on request.
FUEL
FAULTS & BREAKDOWNS

8
A call-out charge will be made where:
●The appliance has been installed for over 24 months
●The appliance has been installed for more than 1 year but less
than 2 years and has not had a first annual service by an
approved company.
OR
●Our Field Service Engineer finds no fault with the appliance
(see note).
OR
●The cause of breakdown is misuse or with other parts of your
plumbing/heating system, or with equipment not supplied by
Worcester.
NOTE: Invoices for attendance and/or repair work carried out
on your Worcester Bosch boiler by any third party will not be
accepted.
If your boiler is not operating, it is suggested that you go
through the following simple checks before either calling your
installer or Worcester Heat Systems.
FAULT FINDER
SYMPTOM POSSIBLE CAUSE CHECK/REMEDY
Boiler does not fire and
burner lockout lamp is
not illuminated
Boiler does not fire and
burner lockout lamp is
illuminated
There is no demand for heat
from external control
equipment
There is no demand for heat
from the boiler temperature
control thermostat.
The automatic reset overheat
thermostat has operated.
Manual reset overheat
thermostat has operated.
There is no electricity supply to
the boiler.
The boiler has attempted to fire,
but has gone to lockout.
• Check the programmer is programmed for
hot water and/or central heating and re-
programme if necessary.
(see programmer operating instructions).
• If the boiler is programmed for central
heating, check the room thermostat is
turned on.
• Check any other control devices fitted.
• Turn the temperature control knob to
maximum.
• If the boiler is hot allow time to self reset.
• Press the reset button
(see section ‘High-limit thermostat.)
• Check power supply is switched on.
• Check the external power supply fuse.
• Remove the appliance front cover and
depress the lockout reset button on the
burner. (See section ‘Lockout’.)
• Check the level in your oil tank and
replenish if necessary.

9
MAINTAINING YOUR
BOILER’S EFFICIENCY &
PERFORMANCE
Your new Worcester Bosch oil-fired boiler represents a long-
term investment in a reliable, high quality product.
In order to realise its maximum working life, and to ensure it
continues to operate at peak efficiency and performance, it is
essential that your boiler receives regular, competent servicing and
annual maintenance checks beyond the initial 24 month guarantee
period.
Regular service contracts can be arranged with your installer -
however if you have difficulty making a satisfactory arrangement
simply contact Worcester Heat Systems on
0345 256206 for help.
If you would like to know more about Worcester’s extended
warranty options please tick the appropriate box on your
Guarantee Registration card.

10
SERVICE CENTRES
CONTACT NUMBERS:
UK Call Centre Tel. [phone]
UK Call Centre Fax. [phone]
Scotland only Fax. [phone]
OPERATING HOURS:
Mon - Fri 8.00am to 6.00pm
Sat 8.30am to 1.00pm
Please contact our UK Call Centre number where our friendly operators
will book your call with one of our team of nationwide engineers.
NOTE:
Sunday and Bank Holiday cover is not available
IMPORTANT
Do not touch or adjust any sealed component

11
YOUR WORCESTER
BOSCH GUARANTEE
GUARANTEE
REGISTRATION
This appliance is guaranteed against faulty materials or
workmanship for a period of twenty four calendar months from the
date of installation subject to the following conditions and
exceptions.
1. That during the currency of this guarantee
any components of the unit which are
proved to be faulty or defective in
manufacture will be exchanged or repaired
free of material charges and free of labour
charges by Worcester Heat Systems
Limited.
2. That the householder may be asked to
prove the date of installation, that the
boiler was correctly commissioned and,
where appropriate, the first 12 month
service has been carried out to the
satisfaction of Worcester Heat Systems
Limited when requested.
3. That any product or part thereof returned
for servicing under the guarantee must be
accompanied by a claim stating the Model,
Serial Number, Date of Installation, proof
of commissioning, proof where
appropriate of the first 12 month service
and the address of the householder.
4. That Worcester Heat Systems Limited will
not accept responsibility for damage
caused by faulty installation, neglect,
misuse or accidental damage, the non-
observance of the instructions contained in
the Installation and Operating Instructions
leaflets.
5. That the appliance has been used only for
normal domestic purposes for which it was
designed.
6. That this guarantee applies only to
equipment purchased and used in
mainland Great Britain and Northern
Ireland.
You should complete and return the postpaid Guarantee
Registration Card within 14 days of purchase.
The card will register you as the owner of your new Worcester
Bosch boiler and, while this will not affect your statutory rights in
any way, it will assist us to maintain an effective and efficient
customer service by establishing a reference and permanent record
for your boiler.
FOR YOUR OWN RECORD
MODEL SERIAL NUMBER
(See identity label inside appliance casing)
TYPE/SIZE DATE OF INSTALLATION
This guarantee is given in addition to all your normal statutory rights.

Worcester Heat Systems Limited. Cotswold Way, Warndon, Worcester WR4 9SW.
Telephone: [phone]. Fax: [phone].
Technical Service Helpline 08705 266241.
www.worcester-bosch.co.uk 8 716 145 077c 11/00
