Worcester GB162 Configuration guide

Worcester Commercial Boiler Series
GB162 - 65/100
Addendum: Australia / New Zealand
Important Information about this document.
This addendum should be read in conjunction with the attached Installation and Servicing
Instructions. For Australia and New Zealand, information in this addendum takes
precedence over information provided in the Installation and Servicing Instructions. In
particular, AU/NZ contact telephone numbers and AU/NZ standards.
GENERAL INFORMATION
Please read these instructions carefully before starting installation.
This boiler must be installed by an authorized person only.
Failure to install this boiler correctly could lead to prosecution.
If you are in any doubt contact the Robert Bosch technical
hotline on: 1300 30 70 37 AU or 0800 54 33 52 NZ
Please leave these Instructions, completed Commissioning
Record Log Book and User Manual with the customer after
installing the boiler. The Commissioning Record Log Book is
part of the installation manual.
3 This appliance is only certified for use with Natural Gas in
AU/NZ
3 This appliance can only be connected to the electrical supply
by a qualified electrician
3 Prior to the installation of this appliance, isolate the appliance
and all other BUS connections from the 240V supply.
3 For sealed systems an expansion vessel must be fitted.
3 This appliance is not to be used as a pool heater.
Safety Precautions
If you smell gas:
3 Turn off the ECV (emergency control valve) at the meter
3 Do not turn electrical switches on or off
3 Do not strike matches or smoke
3 Put out naked flames
3 Open doors and windows
3 Keep people away from the affected area
Combustion and corrosive materials
3 Do not store or use combustible materials (paper, thinners,
paints, etc. ) inside or within the vicinity of the boiler
3 Chemically aggressive substances can corrode the boiler and
invalidate any warranty.
Fittings and modifications
Fitting the boiler and any controls may only be carried out by
an authorized person.
Flue systems must not be modified in any way other than as
described in the fitting instructions. Any misuse or unauthorized
modifications to the boiler, flue or associated components
and systems could invalidate the warranty. The manufacturer
accepts no liability arising from any such actions, excluding
statutory rights.
Servicing
Advise the user to have the system serviced annually by an
authorized person. Approved spares must be used to help
maintain the economy, safety and reliability of the boiler.
Important
The service engineer must complete the service record at the
rear of this manual after each service
Standards
Where no specific instruction is given, reference should be
made to the following standards:
3 AS5601 Gas Installations
3 AS4552 Gas fired water heaters for hot water supply and / or
central heating
3 AS/NZS 3000 Electrical Installations
3 AS 1697 Installation and maintenance of steel pipe systems
for gas
3 AS4032 Water supply - valves for the control of hot water
supply temperatures
3 AS3498 Authorisation requirements for plumbing
3 AS1910 Water supply - float control valves for use in hot and
cold water, AS 3500 National plumbing and drainage code.
Nominal specifications are summarised in the table below:
Model GB162 65kW GB162 100kW
Gas Type NATURAL NATURAL
Gas / air ratio pressure (Pa)
@Max -11 -14
@Turndown -7 -3
Gas valve intel pressure (kPa)
@Max 0.85 0.83
@Turndown 1.10 1.08
Appliance inlet pressure (kPa) 1.13 1.13
Injector Size Nominal / (Measured) (mm) N/A ø8.4/ 8.39
(Verified by Vemier Calliper)
Nominal gas consumption (MJ/h) 248 386
Turndown gas consumption (MJ/h) 60.6 78.4
Note: The pressure valves stated during appliance commissioning were with the appliance door open

Horizontal and vertical flue
terminal positioning
Flue terminal positions
for boilers in accordance
with AS5601
3 Pluming will occur at the terminal so terminal
positions where this could cause a nuisance should
be avoided.
3 The air supply and the flue gas exhaust must meet
the applicable general regulations. Please consult
the instructions provided with the flue terminal kits
prior to installation.
3 The boiler must be installed so that the terminal is
exposed to the external air.
3 It is important that the position of the terminal
allows the free passage of air at all times
3 Minimum acceptable spacing from the openings
are specified above, for domestic situations in
accordance with AS 5601.
Key to illustration
Balanced flue terminal position
Terminal Position Minimum
Spacing
ADirectly below, above or alongside an opening
window, air vent or other ventilation opening 1,500mm
B Below guttering, drain pipes or soil pipes 75mm
C Below eaves 300mm
D Below balconies or a car port roof* 300mm
E From vertical drain pipes or soil pipes 75mm
F From internal or external corners 300mm
G Above adjacent ground, roof or balcony level 300mm
H From a surface facing the terminal 1500mm
I From a terminal facing the terminal 1,200mm
K Vertically from a terminal on the same wall 1,500mm
L Horizontally from a terminal on the wall 300mm
M Adjacent to opening 1,500mm
N Above intersection with roof 500mm
O For a vertical structure on the roof 500mm
*Installations in car ports are not recommended
A
FM
G
M
B,C
F
B,C
K
G
C
L
A
N
N
O
E
J
K
D
F
K
GG
G
H, I
K
L
