INTRODUCTION
SAFETY & PRECAUTIONS
Thank you for purchasing this amazing World Tech Toys product. This drone is suitable for indoor and
outdoor flight. Please carefully read the entire manual before operating this drone and keep it for
reference in the future.
1. Important Instructions
2. Safety Instructions
3. Flight Environment
4. Attention Before Flying
1) This product is not a toy. It is a precision piece of equipment with integrated mechanical
technologies, electronic, aero dynamics and radio frequencies. To avoid accidents, the
operator must read these instructions carefully prior to operation. If operated incorrectly,
serious physical injury and/or property loss may occur.
2) This product is suitable for operators with previous hobby flying experience, age 14 and up.
3) Only fly in a safe environment that is legal for remote control flying.
4) We are not responsible for the operation and control of this device and related safety
responsibilities.
1) The minimum recommended flying area is 25ft x 25ft x 15ft.
2) Be sure that the transmitter and drone batteries are fully charged.
3) Be sure that the throttle is at its lowest position to avoid premature flight.
4) Always turn on the drone first, then turn on the transmitter. Incorrect operation may result in
failure and the possible influencing of other devices in the area.
5) Ensure that all plugs and wires are secure and in place as they may loosen over time.
The inside of this drone is integrated with precision electronic and mechanical parts. Avoid
contact with water and wet environments as it may result in parts breakdowns and accidents
may occur.
1) Always operate far away from obstacles and crowds. This drone has uncertain flying speeds
and conditions which present potential danger. Fly away from people, animals, high buildings,
high voltage wiring, etc. To ensure a safe and fun flying environment avoid bad weather
conditions like wind, rain, and thunder.
2) Avoid high temperatures. This drone is made of metal, plastic, electronic components and
other materials. Keep away from any heat source and avoid using in high temperatures to
prevent transformation and broken parts resulting from the heat.
3

DRONE DIAGRAM
TRANSMITTER DIAGRAM
Power Light
Power Button
Flip Stunt ModeSpeed Modes
Turn Left/Right Trim
Ascend/Descend
(Turn Left/Right)
Forward / Backward
(Move Left / Right)
Forward / Backward Trim
Move Left / Right Trim
4
Headlight
BOTTOM OF DRONE
FRONT
BACK
Battery
Compartment
Rotor
Shell
Power
Switch
Rotor Guards
Landing Skids
Red LED
Lights
Green LED
Lights
Landing
Skids

Battery Cover
4 AA Batteries
(Not included.)
First remove the screw on
the battery cover and then
remove the battery cover
itself. Next, install 4 AA
batteries with the correct
polarity. Finally, replace the
battery cover and screw it
in place.
CAUTION:
1. Make sure the polarity of the
batteries are correctly installed.
2. Do not mix old and new
batteries.
3. Do not mix different types
of batteries.
INSTALLING THE TRANSMITTER BATTERIES
INSTALLING THE DRONE BATTERY
CAUTION WHILE CHARGING:
Do not charge with the batteries still installed. Do not charge the battery unsupervised. Do not immediately
charge after use. Do not overcharge the battery. Ideal charge time is 45-60 minutes. Overcharging can cause
a catastrophic failure. Always charge on dry and ventilated areas away from any heat source or flammable
materials. Always use the original USB charging cable provided. Promptly change and replace old or defective
batteries.
Battery Type Battery Specification Usage Duration Charge Time
BATTERY PACK SPECIFICATIONS
LiPo Battery 3.7V 380mAh Flight Duration 6 - 7 minutes Charging Time 45 -60 minutes
5
1 3
Connect the batteries power cable
to the drones power port as shown.
Test the drone by flipping the power
switch toward the front of the drone
body. The LED lights should turn on.
Make sure the drone is turned off by
flipping the switch on the side of the
drone towards the drones rear.
CHARGING THE DRONE BATTERY
Completely remove the battery from
the drone by sliding it out toward the
rear of the drone.
Connect the battery pack to the
included USB charger then plug the
USB to any powered USB port. The
USB Charger LED light will turn on
during charging and will turn off
once charging is complete.
Make sure the drone is turned off by
flipping the switch on the side of the
drone toward the rear. Disconnect
the battery power cable from the
drone power port as shown.
Insert the battery from the rear of
the drone into the space under the
drone shell. Make sure the battery
power cable is sticking out of the
back of the drone.
3
2
12

6
PREFLIGHT PREP / SYNCING THE DRONE TO THE REMOTE
1. Make sure the battery pack is connected properly and the drone shell is secure.
2. Flip the power switch on the side of the drone and place the drone on a flat surface with no
obstructions in its flight path. The drone’s LED lights will begin to flash.
3. Turn on the transmitter by pressing the button at the center. The power indicator on the
transmitter will start flashing.
4. Push the left joystick on the transmitter all the way down, then all the way up and then all the way
back down again. The remote will beep twice and the LED lights on the drone and the power
indicator light on the remote will stop flashing. This means the drone is paired. (If this does not
occur, turn off the remote and drone and try again.
5. Once paired, the drone is ready to fly. All you need to do is gently push up on the transmitter’s
throttle stick and the rotors will start to spin. Continue slowly pushing up on the throttle stick to take
off. It is STRONGLY recommended that you use the drone outdoors during initial flights.
CHANGING THE DRONES SHELL
The drone has a removable shell that you can replace if damaged. You can also change the color of
your drone with a new shell (Sold Separately). Follow the directions to change the drone shell.
Remove the battery first. Focus on one
side of the drone at a time. Push in on
the sides of the drone shell so that the
tabs slide out of the drone tabs.
Once the shell tabs are all released
take the shell off by pulling up and
back towards the rear of the drone.
This will allow you to slide the tab out
the front of the drone.
Insert the new shell’s front tab into the
front of the drone at an angle.
Push the shell back into place and
make sure the side tabs are clipped
back in and secure.

7
FLYING THE DRONE
BASIC FLYING CONTROLS
Before flying the drone for the first time please read
the instructions carefully and make sure you fully
understand how to control your drone.
Turn Left
Turn Right
Turn Left /Turn Right
Move Right/Move Left
Front
Back
Throttle
Move Forward/Backward
Move RightMove Left

8
FLYING THE DRONE - SPECIAL FUNCTIONS
LAUNCH TOSS TAKE OFF
Built-in 6-axis gyro technology allows you to throw a successfully readied drone straight into the air to
fly. After the drone is paired to the transmitter, pick it up, toss it into the air and press up on the
throttle. The drone will right itself and level out in midair.
FLIP STUNT MODE
Hover the drone at least 10 feet off the ground. Press the Flip Stunt Mode
button and push the right joystick in the direction you want the drone to
perform a single flip. Normal function will resume after the flip.
SPEED CONTROL
The drone has 3 speed settings: Low, medium and high speed. The drone will always default to the
low speed when you first turn it on. Press the SPEED CONTROL button once and you will hear 2
beeps, meaning it is now on medium speed. Press the SPEED CONTROL button again and you will
hear 3 beeps, meaning it is now on high speed. Press the button again to cycle back to low speed.

9
ADJUSTING THE TRIM
When the drone moves without transmitter input, adjust the trim controls until hovering is stable.
Drone is turning
to the right.
Move Right
Trim
Push the TURN
LEFT TRIM button
until the drone stops
turning.
Push the BACKWARD
TRIM button until the
drone stops.
Turn Left
Trim
Drone is moving
forward.
Drone is turning
to the left.
Push the TURN
RIGHT TRIM button
until the drone stops
turning.
Turn Right
Trim
FRONT
BACK
Push the FORWARD
TRIM button until the
drone stops.
Forward
Trim
Drone is moving
backward.
FRONT
BACK
Push the MOVE
RIGHT TRIM button
until the drone stops.
Drone is moving
to the left.
Move Left
Trim
Push the MOVE
LEFT TRIM button
until the drone stops.
Drone is moving
to the right.
Backward
Trim
FRONT
BACK
FRONT
BACK

10
REPLACING THE ROTORS
The rotors may become damaged during a
collision. The drone comes with 4 spare rotors.
Please replace damaged rotors immediately.
The drone comes with 2 A rotors and 2 B rotors.
The A and B rotors must be installed on specific
locations on the drone for it to fly properly. Check
the bottom of each rotor to see if it’s labeled
either A or B. Use the illustration to the right to
install them in the correct location.
FRONT
BACK
A B
B A
The rotor is held by friction so tools are
not needed. Hold the drone and rotor
firmly with each hand and remove the
damaged rotor by pulling upward.
Once removed find the matching new
rotor to replace it with. Match the letter
“A” or “B” on the underside of the
rotors.
Place the correct A or B rotor on top of
the peg. Hold the drone and rotor
firmly with each hand and push the
rotor onto the motors peg.
Repeat the process for any other
rotors that need replacing.
POST FLIGHT
After you are done flying the drone make sure the battery pack is disconnected and the transmitter
power is turned off. If you are not going to use the drone for a long period of time, please remove the AA
batteries from the transmitter to prevent them from draining or leaking.

11
RACING RINGS ASSEMBLY
Two of the included racing rings have LED
lights that are each powered by a battery box.
To start, remove the single screw on each of
the battery covers and then slide them off
towards the plug and switch. Next install 2 AA
batteries with the correct polarity into each
battery box. Finally replace the battery covers
and screw them in place. The boxes are now
ready to be connected to the red and blue
racing rings.
The three racing rings are easily assembled using the 4 parts shown below. The red and blue racing rings
have a small black power plug sticking out from the side, do not pull on the plug or damage to the LED lights
may occur. The checkered flag racing ring is identical to the red and blue ring but it does not have any
electronics. Follow the steps below to assemble each of the racing rings.
Battery Cover
2 AA Batteries
(Not included.)
1 2
Lay the base piece on a flat surface
and insert the racing ring into the two
slots.
Insert the two side pieces by lining
them up with the slots on the racing
ring as shown.

12
RACING RINGS ASSEMBLY CONTINUED
Once you have assembled the racing rings connect the battery boxes to the red and blue racing rings
as shown. Turn on each battery box via the switch located next to the battery boxes power port. Finally,
place the battery box next to the ring or on the flat base of the racing ring.
LANDING PADS ASSEMBLY
The two landing pads are easily assembled using the 5 parts shown below. The feet of the landing pads
are all the same and can be used on any slot of the circular pad. Insert any 4 landing pad legs into each
landing pad as shown below and you are ready to race.
Power Switch
Power Port
1

13
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Drone is unresponsive. The
Transmitter light keeps flashing.
Drone is unresponsive.
Transmitter light is ON. Drone is
unresponsive.
Drone’s rotors spins
but doesn’t take off.
Drone is shaking when flying.
Drone still moves forward after
adjusting the trim.
Drone moves while hovering
without transmitter input. Trim needs to be adjusted. Adjust the trim.
Gyroscope midpoint is off. Turn off both transmitter and drone.
Go through power on process and make
sure you place the drone on a flat
surface before taking off.
Transmitter batteries are
installed incorrectly.
Transmitter and or drone
is not powered ON.
Turn both transmitter and drone ON.
Transmitter batteries are drained.
Drone’s battery pack
is drained.
Rotor blades are damaged. Replace the damaged rotor blades.
Rotor blades are damaged. Replace the damaged rotor blades.
Drone is not on a
flat surface.
Place the drone on a flat surface
before attempting to take off.
Charge the drone’s battery pack.
Drone’s battery pack is drained. Charge the drone’s battery pack.
Install fresh batteries to the transmitter.
Install the batteries with the
correct polarity.
Transmitter is not syncing with
drone.
Repeat the power up process.
NOTES:

14
NOTES:
Website: www.worldtechtoys.com
Email: [email protected]
Phone: [phone]
Monday - Friday / 8:00AM - 5:00PM / Pacific Time
WWW.WORLDTECHTOYS.COM
MADE IN CHINA
SPECIFICATIONS,
COLORS AND CONTENT
MAY VARY FROM ILLUSTRATIONS
