ENC400
Operation Manual
RGB to NTSC and S-Video Encoder
MicroImage Video Systems
division of World Video Sales Co., Inc.
P.O. Box 331
Boyertown, PA 19512
610-754-6800
Fax [phone]
[email protected]
www.mivs.com
Page 2
Contents
Specifications
Specifications ............................... Page 2
Unpacking .................................. Page 3
Connections ................................ Page 3
Power ................................ Page 3
Video Connections ....................... Page 3
In case of difficulty ........................... Page 3
Warranty .................................. Page 4
Returns .................................... Page 4
Rev 0 01-28-1999
Input level (RGB) 1.0 Vpp Composite, 75 Ùterminated
(S) 5.0 Vpp max 75 Ùterminated
Output level (Y & Video) 1 Vpp typical into 75 ohm
(C) 0.28 Vpp burst typical into 75 ohm
Connectors (R, G, B, S, Video) BNC female
(S-Video) 4 pin mini DIN F
Resolution Greater than 400 lines
Modulation R-Y, B-Y Axes
Genlock Combination Analog & Digital Synthesis
Sync Internal (sync on green) or External (default)
Video System NTSC, RS170
H & V Frequency 15.754 Khz (H), 59.94 Hz (V)
Chroma Frequency 3.579545 Mhz
Temperature
Operating 0E-40EC (32E-104EF)
Storage -40E-60EC (-40E-140EF)
HumidityOperating 10% -90% (non-condensing)
Storage 5% -95% (non-condensing)
Power 110 -125 VAC, 60Hz , 6W max
Size Size 6.3" (w) x 5.1" (D) x 1.9" (H)
160 mm (w) x 130 mm (D) x 48 mm (H)
Weight 12 oz.
Manufactured in USA by MicroImage Video Systems

Page 3
Unpacking
Connections
In case of difficulty
The ENC400 package includes the following items:
ENC400
12V wall plug transformer
This operation manual
Please inspect all items carefully and report damaged or missing
items to your dealer or MicroImage Video Systems.
Power
The ENC400 uses a 12 VDC wall plug transformer which is
included with the unit. Connect to a source of 120VAC, 60Hz.
Video Connections
Connect the video source (i.e. camera) to the RGBS IN connectors
on the VDA unit. Connect the OUTPUT signals (Video or S-Video)
from the ENC400 unit to the video displays as required.
The ENC400 is set from the factory to work with external sync. An
internal jumper can be changed to select internal (sync on green).
The RGB signal source must meet NTSC RS-170(A) specifications
(H & V frequency) for this product to work properly.
If you are experiencing problems with your MicroImage product,
you can contact us in one of the following ways.
Mail MicroImage Video Systems
a division of World Video Sales Company, Inc.
P.O. Box 331 #Boyertown, PA 19512
Phone [phone]
Fax [phone]
Email [email protected]
Web www.mivs.com
Page 4
Warranty
Returns
MicroImage Video Systems warrants that each ENC400 is free from
defects due to faulty materials or improper workmanship for a period of
one (1) year. MicroImage Video Systems further warrants that any part
which proves defective in materials or workmanship within one (1) year,
will be replaced or repaired at no cost to the user. Labor to replace
defective parts will be done without charge, provided the equipment is
returned to MicroImage Video Systems prepaid, insured and properly
packaged. Prior return authorization must be obtained from MicroImage
Video Systems.
NOTE
This warranty covers the MicroImage ENC400 only.
CONDITIONS
This warranty is void if the warranted part has been altered or subjected
to abuse or misuse. Defective parts must be returned to MicroImage
Video Systems.
SOLE WARRANTY
This Warranty is in lieu of all other warranties expressed or implied
including, without limitation, any implied warranty or any implied
warranty of fitness for a particular purpose. MicroImage Video Systems
shall have the final right to determination as to the existence and cause
of any defect and its appropriate adjustment in accordance with the
terms of this warranty. In no event shall MicroImage Video Systems be
liable for any consequential or collateral damages.
All returns MUST have an RMA number. Please call, fax or email
for an RMA form. The RMA form will have the proper shipping
address for returns.
Phone [phone]
Fax [phone]
Email [email protected]
