Wunda Smart Connection Box v2.0 User manual

Welcome to WundaSmart

Welcome to your Smart Connection Box
Status Lights
Setup/Pairing Button
Output Test Button
5A Fuse
Mains Input 230V~
Pump
Heat Source / 2 Port Valve
Actuators 1-12
Wire Clamping Area
Actuator Cable Channel
DIN Mounting Rail Clamp
Wall Fixing Holes
Antenna
For more information please visit:
www.wundasmart.com/ support
Quick install guide
A. First ensure your choice of Hub is set up and your App
is installed.
B. Mount the Connection Box near the manifold
C. Connect the actuators to terminal
D. Connect power , pump and heat source
E. Launch your App and choose Devices , then Add
device and choose Smart Connection Box.
F. Hold the Setup Button  and wait until it shows the
device has been successfully paired.
G. The Output Test Button is used to test the electrical
output and the connection to the devices. Hold the
Test Button for 5 seconds or until the light begins
to blink rapidly. Press the Test Button again to
move right along the outputs and press the Setup
Button to move left. To nish the test hold
the Test Button for 5 seconds.
H. Congure Your installation in App Need our help?
Our designated support staff
are on hand to answer all your
questions
[email protected]
0800 083 2677
