Wybron Transition Optic User manual

TRANSITION
CMY Fiber Optic Illuminator
CMY with TW -White light with WT -White light
Transition
User Manual

2
Table of Contents
Declaration of Conformity………………………………………………..3
Safety Notice………………………………………………………………4
Introduction to Transition…………………………………………………7
Transition Quick Start configuration…………………………………….8
Transition Specifications…………………………………………………9
Fixture Setup and Configuration……………………………………..…10
DMX / RDM Setup and Operation……………………………………...12
Display Messages………………………………………………………..13
Service…………………………………………………………………….15
Flash Reprogramming…………………………………………………...17
Warranty Information……………………………………………………..18
Figure 2.1 Figure 1.2………………………………………………….….19

3

4
Safety Notice
SAVE THESE INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
This manual gives step-by-step instructions for preparation, setup, and operation of the
Transition TM Fiber Illuminator.
There is a potential risk of fire, electric shock or injury to persons if the product is not
used as instructed.
The Transition Fiber Illuminator is to be used in an indoor environment only.
WARNING: When using electrical appliances, use basic precautions,
including:
Read this manual before connecting power.
Use supervision around children.
Do not touch moving parts.
Only use attachments recommended or sold by Wybron.
Use in a dry location only.
Product Modification Warning
Wybron, Inc. products are designed and manufactured to meet the requirements of
United States and International safety standards. Modifications to the products could
affect safety and render the product non-compliant to relevant safety standards.

5

6
Intro to the Transition

7
Transition Product Introduction
Wybron is pleased to announce the introduction of the Transition fiber illuminator.
Contained within a small easy to integrate package and ultra bright fiber optic
illuminator, the Transition brings quality and durability to your venue. In addition,
the Transition is designed to be an integral component of Wybron’s industry
leading Infotrace system.
The Transition is a high specification performance fiber optic illuminator in a
small easy to integrate package. The Transition produces a high lumen output
with a CRI of greater than 85 by using an efficient 150 UHI source. The UHI lamp
has a rated life span of 10,000 hours minimizing maintenance concerns. The
precision-engineered lamp housing and reflector allow for lamp changes and no
in-the-field lamp optimization. With its dichroic-coated borosilicate cold mirror
reflector and hexagonal color integration element, the Transition isolates the fiber
bundle from heat and UV radiation. Additionally the Transition is engineered so
that it will not burn PMMA fiber.
The Transition fiber illuminator features a color module capable of producing
millions of colors. The Transition uses four channels of DMX control; cyan,
magenta, yellow and a mechanical dimmer. Transitions colors are mixed by
using durable dichroic coated borosilicate glass, the colors will not fade over the
expected lifetime of the device. Precision control allows for smooth subtle fades
or near instantaneous jumps to new colors.
As previously noted, the Transition fibber illuminator is compatible with and can
be incorporated into Wybron’s InfoTrace, a 2-way DMX / RDM (Remote Device
Management) communication and management system.
The heart of the InfoTrace (IT) system is InfoGate — specialized hardware &
software that uses the bi-directional communications protocol, Remote Device
Management (RDM), to communicate with potentially every piece of equipment
mounted on a lighting rig.
RDM packets are interleaved with DMX-512 data packets. These RDM
command / response packets allow configuration, control, interrogation and
response.
Figure 1 - DMX & RDM signal packet diagram

8
Transition Quick Start Configuration
1. Connect the Equipment
a) Connect fiber bundle common end to the Transition output port.
b) Connect the Transition to a DMX source with a 5-pin cable
c) Connect to AC power (110 – 240 VAC 50/60Hz)
2. Control Transition with DMX
Leave Transition addressed at channel 1 (factory default)
DMX channel 1 controls Cyan (0% = no color, 100% = full saturation)
DMX channel 2 controls Magenta (0% = no color, 100% = full
saturation)
DMX channel 3 controls Yellow (0% = no color, 100% = full saturation)
DMX channel 4 controls Dimmer (0% = no output, 100% = full output)
DMX channel 5 controls Twinkle wheel (Transition TW model
only)
3. Control Transition using Demo Mode
a) Press ‘Menu’ until display reads ‘dEn
b) Press ‘Enter’, display will read ‘OFF’
c) Press ‘+’ or ‘-‘ to scroll through demo mode options
d) Press ‘Enter’ at the desired demo mode. Transition will
immediately begin executing the demo loop.

9
Transition Specifications
Model 8670: Transition CMY Fiber Illuminator
Features:
No lamp optimization
required
Rubber feet for cabinet or
countertop installation
Durable all metal
construction
Output supports fiber
bundles ranging from 17 –
30 mm dia.
High output 150W UHI
compact arc source
Legendary Wybron
Reliability
Dimensions:
Height: 7.750”
Width: 5.625”
Length (including fiber port): 13.500”
Weight: 8.75 pounds
Electrical Specifications:
CAUTION: RISK OF FIRE
Use MAX 150 watt, type M142 lamp
Power: 4A @110-120V ~ 50/60Hz or
2A @ 220-240V ~ 50-60Hz
Isolate electrically before re-lamping
Environmental Specifications:
Maximum Ambient Temperature: 40˚C / 104˚F
Maximum Exterior Surface Temperature: 90˚C / 194˚F
Minimum Air Space Sides: 2”
Minimum air space top: 6”
CAUTION: Risk of exposure to ultraviolet (UV) radiation. Do not operate without
complete lamp enclosure in place.

10
Fixture Setup and Configuration
Installing the Lamp
DANGER: Disconnect fixture from line voltage before replacing
lamp.
CAUTION: Lamp and lamp mounting surfaces are hot! Allow lamp to
cool 10 minutes before replacing
Lamp Specifications
Lamp socket / base: G22
Part#
UHI-S150DW/A/UVP Lamp, Eurospot UHI Series 3000K 150W
UHI-S150DM/A/UVP Lamp, Eurospot UHI Series 4200K 150W
CDM150/T6/830 Lamp, CDM 150W with UV Fade Block 3000K
CDM150/T6/942 Lamp, CDM 150W with UV Fade Block 4200K
Figure 1.1
Disconnect fixture from AC power.
Remove lamp plate by unscrewing mounting screws and pulling the
lamp assembly straight back from the illuminator.
Grasping lamp by the base remove old lamp from the socket.
Insert new lamp into base. Lamp is fully seated when spring clips snap
over lamp base.
CAUTION: Touching the glass lamp envelope can reduce lamp life.
Handle new lamps with a clean cloth. Fingerprints can
be cleaned off the lamp envelope with alcohol and a
clean cloth.
Locating the Fixture
The Transition CMY fiber illuminator is designed to be surface mounted,
located in a cabinet or closet, or hung from mounting pipe with the optional
pipe bracket.
Surface Mounting
The Transition may be surface mounted on a hard surface table,
counter top, or floor (wood, laminate, metal, tile).
Do not mount the Transition on soft surfaces such as carpet, linoleum,
cushions, or fabric.
