Operator’s & Parts Manual
“Express” Water Wagon
“Express” Water Skid
Fire Control Wagon
Arena Express Water Wagon
Printed In The USA — Specications & Design Subject To Change Without Notice!
6-15-18 01-027R16

This is a limited warranty. It covers products manufactured by WYLIE Mfg. Co. The Warrantor is WYLIE Mfg. Co., 702 E. 40th
St., Lubbock, Texas 79404 USA. The duration of the warranty for WYLIE manufactured equipment and products (excluding
polyethylene tanks) is for one year from date of delivery to the carrier. The Warrantor warrants to the Buyer that the product(s)
sold hereunder are free from defects to material and workmanship, under normal use and service, in the hands of the original
buyer.
If goods are defective, the defective goods will be replaced with identical goods. If identical goods are not available, the Buyer
may elect to receive a refund of the purchase price for the defective goods, or the Buyer may order similar goods. The damage
for defective goods shall not exceed the purchase price of the defective goods. No allowance shall be made for labor
or expense or repairing goods without prior approval in writing by the Warrantor. The Buyer’s remedy under this warranty
does not include incidental or consequential damages.
For products not manufactured by the Warrantor, the Warrantor warrants these products to the extent of the warranties of their
respective manufactures. There are no warranties which extend beyond this limited warranty, including the implied
warranty of merchantability. Dealers or representatives shall not make any representation in regard to particular goods except
as authorized by the Warrantor through a written warranty accompanying those particular goods.
WYLIE Mfg. Co., and its divisions, “Wylie Spray Centers,” in each location, requires as a condition of sale and coverage by its
LIMITED WARRANTY that all equipment sold by it be used in accordance with the instructions and specications of the Warrantor.
This requirement is in addition to the LIMITED WARRANTY.
Polyethylene and berglass tanks – These tanks are warranted for the storage and transport of water, herbicide solutions
(on farm), liquid fertilizer and liquid feed. Such tanks should not be used for the storage of any bulk herbicide (undiluted). Any
such use will render this warranty void.
In addition, the Warrantor makes no warranty with regard to bulkhead tank ttings used in connection with tanks containing bulk
herbicides and the use of any such ttings sold by the Warrantor or any WYLIE dealer in connection with tanks containing bulk
herbicides is improper.
Chemical Incompatibility – The Warrantor does not make any recommendations or warranties regarding chemical compatibility.
WYLIE shall not be liable for any damages due to chemical incompatibility, and any Buyer or user should rely solely on written
information furnished by the chemical manufacturer regarding chemical compatibility.
No employee of WYLIE Mfg. Co., or its representatives, agents or dealers, is authorized to vary the terms of this limited
warranty.
This equipment was carefully designed and manufactured to give you dependable service. To insure e󰀩cient operation of
this equipment, please read this operator’s manual carefully. Check each item and acquaint yourself with the adjustments
required to maintain optimum performance and operation. Remember, this equipment’s performance depends on
how you operate and care for it!
At the end of each season, thoroughly clean and inspect your equipment. Preventive maintenance saves time and pays
dividends. Your nearest Wylie Spray Center has original equipment parts which assure proper t and best performance.
Record your equipment’s model and serial numbers and the date you purchased this equipment in the space below.
Have this information available when you order parts or attachments.
Model Number:
Serial Number:
Date Purchased:
A Message To The Owner And Operator
Limited Warranty
Disclaimer of Warranty
Warranty Information

Date of Purchase
Model Number
Frame Serial Number
Tank Serial Number
Wylie Invoice Number
Owner’s Name
Address
City State Zip
Phone
Email
Dealer
Owner’s Signature
Must be returned within 10 days to validate the warranty.
Wylie Manufacturing Company
702 E. 40th St.
Lubbock, TX 79404
Ph. 888-788-7753
“Express” Water Wagon or Skid
Type of Applicator:
Express Arena
Fire Control
Trailer Capacity
500 1,025
800 1,600
Skid
500
Owner Registration
-- Or Register Online --
Go to: www.wyliesprayers.com

.

1
Table of Contents
Table Of Contents
Safety Issues ...........................................................................................................................................................2 - 3
Reporting Safety Defects.............................................................................................................................................. 3
Safety Decals & Placement .....................................................................................................................................4 - 6
Introduction ................................................................................................................................................................... 7
Inspection & Setup ..................................................................................................................................................8 - 9
Operation - “Express” Water Wagon (and w/Pressure Washer) ............................................................................9 - 13
- Optional Hose Reel Kit ..................................................................................................................... 14 - 15
- Fire Control Trailer ...........................................................................................................................16 - 19
- Arena Express Water Wagon ...........................................................................................................19 - 21
Maintenance, Lubrication ....................................................................................................................................21 - 22
Tip Chart ..................................................................................................................................................................... 22
Troubleshooting Guidelines ........................................................................................................................................ 23
Tire Safety Information ........................................................................................................................................24 - 34
Repair Parts.........................................................................................................................................................35 - 59
Express Water Wagons ........................................................................................................35 - 51
500 Gallon Trailer Assembly ............................................................................................. 36
800 Gallon Trailer Assembly ............................................................................................. 37
1,025 Gallon Trailer Assembly .......................................................................................... 38
1,600 Gallon Trailer Assembly .......................................................................................... 39
500 Gallon Trailer Assembly w/ pressure washer ............................................................ 40
Pressure Washer Plumbing .............................................................................................. 41
Axles & Hubs .................................................................................................................... 42
Lighting ............................................................................................................................. 43
Trailer Pump & Plumbing.................................................................................................. 44
Suction Plumbing ............................................................................................................. 45
Spray Bar Assembly ......................................................................................................... 45
Skid Assembly .................................................................................................................. 47
Skid Pump & Plumbing ..............................................................................................48 - 49
Suction Kit, Fire Hose, Side Watering Kit , Anti-Siphon Fill Kit, Garden Hose,
Hose Reel Kit ............................................................................................................50 - 51
Fire Control Trailers .............................................................................................................52 - 55
500, 800 Gallon Trailer Assembly ..................................................................................... 52
1,025 Gallon Trailer Assembly .......................................................................................... 53
Torsion Axles .................................................................................................................... 54
1,025 Gallon Fire Control Plumbing .................................................................................55
Arena Express Water Wagons .............................................................................................56 - 57
500, 1,025 Gallon Trailer Assembly .................................................................................. 56
Arena Express Plumbing .................................................................................................. 57
Tsurumi Pump................................................................................................................................58
Banjo Pump ...................................................................................................................................59

2
Safety Issues
Be alert when you see the above symbol in the manual. It warns of a hazard
which might lead to injury. It means: Attention! Become alert! Your safety is
Involved!
Three (3) words (Danger, Warning, and Caution) are associated with this symbol.
DANGER – Indicates a hazardous situation, which, if not avoided, will result in death or serious injury. This signal word
is to be limited to the most extreme situations.
WARNING – Indicates a hazardous situation, which, if not avoided, could result in death or serious injury.
CAUTION – Indicates a hazardous situation, which, if not avoided, may result in minor or moderate injury.
NOTICE – Indicates information considered important, but not hazard-related (e.g., messages relating to property damage).
SAFETY INSTRUCTIONS - Indicates a type of safety sign where specic safety-related instructions or procedures are described.
Before Use
Do not operate trailer until this manual has been read and understood!
• Thoroughly read and understand all instructions before operating this trailer. If you have questions,
please contact Wylie Manufacturing, 702 E. 40th St., Lubbock, TX 79404, [phone].
You can also contact your nearest Wylie Spray Center.
• Make sure that the trailer is properly attached to the tow vehicle, including lights, safety chains, hitch and
breakaway brake cable.
• Check lug bolts for tightness and tires for wear.
• Adjust hitch height as needed to assure that trailer is level when fully loaded.
• Always wear safety goggles, chemical resistant apron and rubber gloves when handling chemicals.
• Read and understand the chemical manufacturer’s safety guidelines on handling, mixing and application.
During Use
• Do not allow anyone to ride on trailer during operation. Falling can cause injury or death.
• Reduce speed when crossing uneven or rough terrain.
• Always turn o󰀨 tow vehicle engine before making adjustments or repairs to an attached trailer.
• Do not point the spray wand toward any person, animal or body part. The extreme pressure can cause severe
bodily injury. (Pressure Washer model)
Safety Precautions

3
Safety Issues
• Inspect trailer for wear or damage.
• Ensure that all fasteners and ttings are tight.
• Flush tank and pump with fresh water if chemicals are used. Dispose of ush water using
appropriate means.
• Carry out maintenance and/or lubrication procedures as outlined in this manual.
• Keep hands, feet and clothing away from moving parts and high pressure spray pattern.
• Wear protective clothing and gloves when working with chemicals.
• Assure that the hitch is attached to the proper size ball.
• Attach the safety chains and breakaway brake cable to the tow vehicle.
• Plug the lights into the tow vehicle.
• When possible, avoid operating the tow vehicle near ditches, embankments and holes.
• Reduce speed when turning, crossing slopes and on rough, slick or muddy surfaces.
• Do not permit others to ride.
• Operate tow vehicle smoothly – no jerky turns, starts and stops.
• Hitch only to the hitch points recommended by the tow vehicle manufacturer.
• When tow vehicle is idle, engage brakes and park lock securely.
• Tighten lug bolts before transporting the rst time and maintain proper torque.
• Check lights and wiring daily. Service and replace to maintain proper operation.
After Use
Always
Operator’s Instructions
Wylie Manufacturing, 702 E. 40th St., Lubbock, TX 79404
Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should
immediately inform the National Highway Tra󰀩c Safety Administration (NHTSA) in addition to notifying Wylie
Manufacturing.
If NHTSA receives similar complaints, it may open an investigation, and if it nds that a safety defect exists in a
group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in indi-
vidual problems between you, your dealer, or Wylie Manufacturing.
To contact NHTSA you may either call the Auto Safey Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153);
go to http://www.safercar.gov; or write to:
NHTSA
U. S. Department of Transportation
12000 New Jersey SE
Washington, DC 20590
You can also obtain other information about motor vehicle safety from the http://www.safercar.gov.

4
Safety Decals & Placement
Safety Issues
Decal #V9020
“Express” Water Wagon
Contact us at [email protected] or 888-788-7753 to order safety decal
or manual replacements.
Decal #V9029 Decal #V9056

5
Safety Decals & Placement
Safety Issues
Fire Control Trailer
Decal #V9020
Decal #V9048
Contact us at [email protected] or 888-788-7753 to order safety decal
or manual replacements.
Decal #V9029

6
Safety Decals & Placement
Safety Issues
Decal #V9020
Arena Express Water Wagon
Decal #V9048
Decal #V9019
Contact us at [email protected] or 888-788-7753 to order safety decal
or manual replacements.

7
The Wylie “Express” Water Wagon and Skid are the result of years of testing and eld proven experience. They are
built of the nest materials and expert workmanship to provide you with years of reliable service. The “Express” Water
Wagon is a DOT approved trailer with a 500, 800, 1,025, or 1,600 gal. tank. Features include a Tsurumi transfer pump
powered by a Honda engine, spray bar, re hose and nozzle, discharge and suction manifold, lights, brakes and fenders.
The “Express” Water Wagon is designed for many uses such as dust abatement, construction site preparation, remote
watering, and concrete saw lubrication.
The “Express” Water Skid features a 500 gallon elliptical tank as well as the same pump, motor, spray bar, re hose
and suction manifold found on the Water Wagon. All of the functions of the “Express” Water Skid are very similar to the
Water Wagon and can be easily adapted from the instructions in this manual.
The Fire Control Trailer is a non-DOT approved trailer available with a 500, 800, or 1,025 gallon black opaque tank. The
Fire Control Trailer is equipped with a spray bar and re hose. It is designed for ghting grass, hay or cotton gin res as
well as controlling dust.
The Arena Express Water Wagon is a non-DOT approved trailer available with a 500 or 1,025 gallon tank. It is designed
to control dust in arenas, stalls and alleys. It is useful for trailer wash-out and controlling a hay or grass re.
This manual explains where and how to make necessary adjustments to your “Express” for safe and proper operation.
Thoroughly read and understand the contents of this manual before operating your sprayer. If you have questions or do
not understand particular items, contact your nearest Wylie Spray Center or call Wylie Manufacturing at [phone].
Please keep this manual handy to answer questions you may have as they arise.
Pay Particular Attention To All Safety Suggestions – Their purpose is to assure safe operation of the sprayer and
prevent injury or damage to yourself or the unit.
Introduction
Introduction
500 Gal. “Express” Water Wagon
1,025 Gal. Arena Express Water Wagon 500 Gal. “Express” Water Skid
800 Gal. “Express” Water Wagon
500 Gal. Fire Control Trailer

8
Inspection & Setup
Inspection & Setup
Your “Express” Water Wagon, Fire Control Trailer, and
Arena Express Water Wagon is delivered ready for
operation. However, it is suggested that you check fas-
teners for tightness such as lug nuts. Check the motor
to assure that it has the proper oil level (see the motor
operator’s manual for details). Make a visual inspection
to assure that nothing was damaged in shipping. Report
any problems to your dealer or to Wylie Mfg.
Attaching To Pickup
“Express” Water Wagon & Fire Control Trailer
The 500 gallon trailer is equipped with a 2” hitch while the
800, 1,025, and 1,600 gallon trailers are equipped with a
2 5/16” hitch. Make sure that the pickup or tractor has the
proper ball. Engage the locking trigger and rotate the hitch
lock to open the hitch. Lower the hitch on the ball. Close
the hitch by rotating the hitch lock until it locks in place.
Attach the safety chains and plug in the lights. DOT
regulations require that the safety chains cross as
they are attached. Surge and electric brake trailers
have an emergency brake cable that activates the trailer
brakes if the trailer becomes unhitched from the pickup
while travelling. Hook the brake cable to the safety chain
eyelet.
Figure A1
Attaching Express Water Wagon To Pickup
Figure A2
Remove Hitch To Prevent Theft
Check to make sure that the ball and hitch are the
same size. Attaching a 2 5/16” hitch to a 2” ball
could allow the trailer to become unhitched during
transport resulting in serious bodily injury.
The “Express” Water Wagon is equipped with a height
adjustable hitch. Remove the bolts and move the hitch so
that the trailer will travel level when the tank is full.
The bolted hitch can be removed to help prevent theft of
the trailer.
Arena Express Water Wagon
The Arena Express Water Wagon is equipped with a clevis
style hitch. The hitch can be removed to help prevent theft.
The Arena trailer is a non-DOT approved trailer. It is not
equipped with brakes or lights.
Figure A3
Attaching Arena Express to Pickup

9
Note: Open the ball valves by turning the handle parallel
to the ow. Close the valve by turning the handle perpen-
dicular to the ow.
Figure A5
Coupler Cap Lockpins
< Cap Lockpin
Inspection & Setup
The Arena Express is equipped with a ratchet valve to
control the spray bar. Tie a rope through the ratchet valve
handle with enough length to reach the tractor seat.
The “Express” is equipped with cam-lock caps over the
quick couplers. They must remained locked in place except
when attaching a suction hose. The caps are secured with
pins as shown in Figure A5.
Figure A4
Arena Express Ratchet Valve & Pull Rope
Pull Rope >
Ratchet Valve >
Operation -- “Express” Water Wagon
The “Express” Water Wagon features a suction and
discharge manifold. The suction manifold contains the
valves and ttings for lling the tank, supplying the pump
and a gravity feed faucet. The discharge manifold has
valves controlling the bypass, re hose, pressure hose
and spray bar.
Figure B1
Water Wagon Suction and Discharge Manifolds
< Main Tank
Valve
Bypass >
Valve
Anti-Siphon Fill >
Figure B2
Water Skid Valves
< Fire Hose Valve
< Pressure Hose Bibb
Gravity >
Hose
Bibb
Suction >
Manifold
< Discharge
Manifold
< Fill Hose
Anti-Siphon
Fill Tube >

10
Figure B3
Filling Tank Through Anti-Siphon Fill
Filling The Tank
The water tank on the “Express” Water Wagon can be
lled by three means: (1) through the anti-siphon ll tube
(2) drawing water through the pump (3) through the quick-
ll tting.
To ll the tank through the anti-siphon ll, remove the
tank lid, couple the ll hose to the anti-siphon coupler
and turn the water source on as shown in Figure B3. A
re hydrant adapter is provided that couples to the end
of the ll hose.
If the tank is to be lled through the quick-ll tting, couple
the hose to the quick-ll coupler as shown in Figure B4.
Open the main tank valve, then open the water source.
Figure B4
Filling Tank From Pressurized Source
< Quick Fill Coupler
< Main Tank
Valve Open
< Gravity Hose Bibb Closed
Operation -- “Express”
Figure B5
Filling Trailer From Tank
In order to ll the tank with the transfer pump as shown
in Figure B5, close the main tank valve and attach the ll
hose to the suction manifold quick-ll coupler. Open the
bypass valve on the discharge manifold. Set the end of the
ll hose in the pond, tank or other water source with the
suction screen coupled to the end of the hose. See Figure
B5. Be sure that the suction hose bibb is closed. A partially
open hose bibb will let air into the suction manifold, causing
cavitation in the pump and not build pressure.
Start the engine to pump water from the water source to the
tank. If this is the rst time to use the pump, it may be neces-
sary to pour water in the top of the pump to prime it. Once
the pump has water in it, it is self-priming thereafter.
Bypass Valve
The bypass valve is located on the discharge manifold and
is useful for lling the tank through the pump, circulating
water through the tank when the pump is turned on but no
water is being discharged, and mixing any chemicals that
are added to the water.
Figure B6
Open Bypass Valve
Open Bypass Valve >

11
Spray Bar
The Spray Bar is controlled by the spray bar valve. Open
the main tank valve and close the bypass valve.
Start the engine and increase to full throttle. Open the spray
bar valve. Use the pickup speed to control the rate that
water is applied. The amount of water owing through the
spray bar can be controlled by partially closing the spray
bar valve or slightly opening the bypass valve. Do not close
the main tank valve. Pump damage can result.
The spray bar covers a maximum swath of 25’. Common
uses include controlling dust on roads and parking lots,
compacting roads and building sites.
Fire Hose
The 25’ re hose couples to the re hose valve on either
side of the trailer. Remove the re hose coupler cap and
quick couple the re hose. Open the main tank valve,
close the bypass and spray bar valves. Open the re hose
valve on the side that the hose is attached. The re nozzle
adjusts from wide spray to straight stream by rotating the
body of the nozzle.
Figure B8
Spray Bar Nozzles
Operation -- “Express”
Figure B7
Spray Bar Valve
Bypass Valve >
Closed
Spray Bar
Valve Open >
Main Tank
Valve Open >
Figure B9
Operating Spray Bar
Figure B10
Fire Hose Connection
< Main Tank Valve Open
< Fire Hose Valve Open
Fire Hose Coupler >
< Alternate Fire
Hose Valve
Do not direct the spray from the re hose or
pressure hose at electrical connections,
boxes or lines.
Electrical shock could cause serious
bodily injury or death.
Spray Bar Nozzles

12
The re hose and nozzle can be used for spot watering to
control dust and compact building sites. Other uses include
watering remote landscape and ghting grass res.
Side Watering Nozzle
The discharge manifold can be tted with an optional side
watering nozzle. Quick couple the nozzle to the re hose
coupler and open the re hose valve.
Pressure Hose
To operate the pressure hose, attach the pressure hose to
the pressure bibb, open the main tank valve and start the
engine. All of the ball valves on the discharge manifold should
be closed. Open the bibb and engage the trigger gun.
Figure B11
Operating Fire Hose
Operation -- “Express”
Figure B12
Side Watering Nozzle
< Side Watering
Nozzle
Figure B14
Pressure Hose Connection
Pressure Hose >
Pressure Bibb >
Suction Manifold Bibb
A second bibb is located on the suction manifold and is
useful for gravity feeding water to concrete saws and other
low volume applications. With the engine turned o󰀨, attach
the pressure hose to the gravity bibb and remove the trigger
gun. Open the main tank valve and the gravity bibb. The
outlet of the hose must be lower than the level of the water
in the tank for the water to gravity ow through the hose.
Figure B15
Gravity Flow Hose Connection
Main Tank Valve Open >
Gravity Bibb >
Figure B13
Pressure Hose Watering
Pressure Hose >

13
Operation -- “Express”
Pressure Washer
One model of the “Express” Water Wagon (EXP-500L-SDP)
is equipped with a cold pressure washer in addition to the
dust abatement pump. The pressure washer model has
all the functionality of the regular Water Wagon along with
the high pressure washer.
Attach the pressure washer suction hose to the suction
manifold hose bibb. Open the main tank valve and open
the hose bibb to supply water to the pressure pump.
Figure B16
Express Water Wagon w/Pressure Washer
Dust Abatement >
Pump
< Pressure Washer
< Pressure Hose Reel
Main Tank Valve Open >
Hose Bibb >
< Pressure
Washer
Suction Hose
Pressure Washer >
Suction
Figure B17
Pressure Washer Valve Setting
Couple the spray gun to the pressure hose. Remove the
lock pins to allow the hose reel to swivel to the desired
angle. Loosen the set screws on both sides of the hose
reel. Unroll the desired amount of pressure hose.
The cold pressure washer is equipped with its own oper-
ating manual. The manual is located in the same storage
sleeve as this manual. Refer to the supplied manual for
detailed operating instructions for the pressure washer.
The pressure washer manual will include instructions on
safety procedures, the engine fuel systems, procedures for
applying soap, and the proper way to manage the water
pressure.
Follow all safety and operating instructions to ensure a safe
and e󰀨ective workplace.
Do not point the spray gun at any person, animal
or body part. Never put your hand, ngers or body
directly in front of the spray nozzle. The pressure
washer generates up to 3,000 psi.
Serious injury or death could result.
Figure B18
Swivel Hose Reel
< Spray Gun
< Pressure Hose
Set Screw >
Swivel Hose Reel >
< Lock Pins
< 180º Swivel Mount

14
Bolt the hose reel to the mounting plate with ½”x1” bolts.
Insert the bent pull pins in the swivel bracket.
Bolt the handle to the reel arm. Apply thread sealant to the
hose threads and screw into the hose reel tting. Roll the
hose onto the hose reel. Attach the re nozzle. Lock the
hose reel in position with the spring loaded lock pin.
The Express Water Wagon can be equipped with a stan-
dard pump with a 4 hp engine or a high pressure pump
with a 5.5 hp engine. Choose the plumbing instructions
depending of the pump your unit is equipped with.
Optional Hose Reel
Optional Hose Reel
The Express Water Wagon can be tted at the factory or
as an aftermarket option with a hose reel for a 1” hose
and re nozzle.
Aftermarket Set-up
Loosely attach the crossmember to the frame just below
the hose hangers. Set the A-frame on the trailer frame and
under the swivel frame. Attach the A-frame with U-bolts.
Mark holes through the A-frame mount brackets. Drill ½”
holes through the trailer frame. Secure the A-frame mount
brackets with the ½”x1” bolts. Tighten all mounting bolts.
Set the hose reel mounting plate in the swivel bracket with
a nylon washer above and below the swivel frame. Se-
cure with the ½”x4½” bolt.
Crossmember >
< Hose Hanger
< A-Frame
< Swivel Frame
< A-Frame Mount Bracket
½”x1” Bolts >
Figure B19
Hose Reel Frame Mounting
Figure B20
Hose Reel Mounting Plate
< Nylon Washer
Swivel Frame >
< Hose Reel Mounting Plate
< ½”x4½” Bolt
Figure B21
Hose Reel Attached to Mounting Plate
< Hose Reel
Reel Mounting Plate >
Bent Pull Pin >
< Reel Handle
1”x50’ Hose Assembly >
Fire Nozzle >
Figure B22
Rolling Hose on Hose Reel
< Lock Pin
< Nylon Washer

15
High Pressure Pump Plumbing
Remove the cap from the pump tee. Install the ball
valve and 1” hose to connect the pump to the reel.
< Hose Reel
< High Pressure Pump
< Pump Cap
Ball Valve >
< 1” Hose
Figure B23
Hose Connection on High Pressure Pump
Hose Reel Operation
Remove the bent pull pins (see Figure B21) and swivel
the hose reel to the desired direction. Rotate the reel lock
pin to the unlock position (see Figure B22). Unroll the
hose to the desired length.
Open the Main Valve, close the Spray Bar Valve, Return
Valve and Auxiliary Valve. Open the Hose Reel Valve.
Start the engine and rotate the re hose nozzle to open
the nozzle to the desired pattern; from wide fan to straight
stream.
Closed Spray >
Bar Valve
Open Main Valve >
Open Hose Reel Valve >
Closed Return Valve >
Closed Auxiliary Valve >
Figure B25
Valve Setting for Hose Reel Operation
Optional Hose Reel

16
Filling The Tank
The water tank on the Fire Control Trailer can be lled by
three means: (1) through the tank llwell (2) through the
quick-ll tting (3) drawing water through the pump.
Before lling through the llwell, check local codes to see
if it is lawful to insert a hose or tube into the tank. If not, an
optional fender and anti-siphon ll kit are available.
If the tank is to be lled through the suction manifold/quick-
ll tting, couple the hose to the quick-ll coupler as shown
in Figure B21/22. Open the main tank valve, then open the
water source.
Operation -- Fire Control
Operation -- Fire Control Trailer
The 500 and 800 gallon Fire Control Trailers feature a suc-
tion and discharge manifold. The suction manifold contains
the valves and ttings for lling the tank, supplying the
pump and a gravity feed faucet. The discharge manifold
has valves controlling the bypass, re hose, pressure hose
and spray bar.
The 1,025 Fire Control Trailer is equipped with a quick-ll
and bypass system as well as a re hose and spray bar.
Note: Open the ball valves by turning the handle parallel
to the ow. Close the valve by turning the handle perpen-
dicular to the ow.
Figure B28
Filling Through Suction Manifold (500/800 Gal.)
< Main TankValve
Bypass >
Valve
< Gravity Bibb
Suction >
Manifold
Discharge >
Manifold
< Fill Hose
< Pressure Bibb
< Spray Bar Valve
< Fire Hose Valve
Figure B26
500/800 Gallon Fire Control Trailer Valves
Figure B27
1,025 Gallon Fire Control Trailer Valves
Figure B29
Filling Through Quick Fill (1,025 Gal.)
Open Main Tank Valve >
Fill Hose >
Bypass Valve >
< Fire Hose Valve
< Spray Bar Valve
< Main Tank Valve
Quick Fill Valve >
Sight Gauge Valve >
Fill Hose >
Open Main Tank Valve >
Open Quick Fill Valve >
