X-keys XK-1283-UJS3-R User manual

Contact Us
USA Sales
[e-mail]
Phone: [phone]
www.xkeys.com
USA Technical Support
[e-mail]
Phone: [phone]
www.xkeys.com/support.php
USA Shipping Address
P.I. Engineering
101 Innovation Parkway
Williamston, MI 48895-
1663
UK Sales
[e-mail]
Tel [phone]
www.x-keys-uk.com
UK Technical Support
www.x-keys-uk.com
[e-mail]
Tel [phone]
UK Shipping Address
Keyboard Specialists Ltd
Unit 44-45, Salisbury
Street Darlaston West
Midlands WS10 8XB
United Kingdom
Limited Warranty
For all X-keys products purchased and installed in the United States, Canada and the United
Kingdom, P.I. Engineering warrants that the X-keys product will be free from defects in materials
and workmanship under normal use and service, and will meet the specifications presented by
P.I. Engineering at the time of original purchase, for one year as evidenced by a copy of the
purchase receipt. Under this warranty, P.I. Engineering will, at its sole option, repair or replace
any X-keys product which is defective, provided that you are responsible for (i) the cost of
transportation of the product to P.I. Engineering or its designated service facility, and (ii) any loss
or damage to the product resulting from such transportation.
Upon discovery of a defect in the product within the Warranty Period, you should notify
P.I. Engineering Technical Support to obtain an RMA (return authorization number) and
instructions for shipping the product to a service location designated by P.I. Engineering. You
should send the product, shipping charges prepaid, to the designated location, accompanied by
the return authorization number, your name, address, and telephone number, proof of purchase,
and a description of the defect. P.I. Engineering will pay for return of product(s) to the customer.
P.I. Engineering shall have no responsibility to repair or replace the X-keys product if the failure
has resulted from accident, abuse, mutilation, misuse, or repair/modification performed by any
entity other than P.I. Engineering.
THIS WARRANTY IS EXCLUSIVE OF ALL OTHER WARRANTIES, WHETHER EXPRESSED, IMPLIED, OR STATUTORY.
P.I. ENGINEERING DOES NOT WARRANT THIS X-keys PRODUCT FOR FITNESS FOR A PARTICULAR PURPOSE OR
MERCHANTABILITY. P.I. ENGINEERING AND ITS EMPLOYEES SHALL NOT BE HELD LIABLE FOR ANY CONSEQUENTIAL,
INDIRECT, OR INCIDENTAL DAMAGES, EVEN IF ADVISED OF THEIR POSSIBILITY, ARISING OUT OF THE USE OR
INABILITY TO USE THIS PRODUCT. SOME STATES DO NOT ALLOW FOR THE EXCLUSION OR LIMITATION OF CERTAIN
LIABILITIES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER LEGAL RIGHTS WHICH VARY FROM STATE TO STATE.
In the event that the above limitations are held unenforceable, P.I. Engineering’s liability for any damages to you or to any party
shall not exceed the purchase price you paid, regardless of the form of any claim.
This limited warranty is valid for and only applies to products purchased and used inside the United States (and its territories),
Canada, and the United Kingdom.
This limited warranty is governed by the laws of the United States of America and the state of Michigan.
X-keys Electronic design: P.I. Engineering, Inc., Patent # 4964075
© 2019 P.I. Engineering, Inc. All rights reserved.
Y-mouse, Y-see two, Y-key key, X-keys, and the “P.I. Eclipse” are trademarks of P.I. Engineering, Inc.
PS/2 is a registered trademark of International Business Machines, Inc.
All other trademarks are property of their respective owners.
USA: www.piengineering.com ◘ www.xkeys.com
UK: www.x-keys-uk.com
PI Part# 1283
USB 3 Switch Interface
Product Manual
Part Number XK-1283-UJS3-R
3 Switch Ports
Made, Sold, and Supported in the USA
From P.I Engineering, The No Slogan Company
USA: www.xkeys.com
UK: www.x-keys-uk.com
Box Contents
This package contains:
1- X-keys Switch Interface
1- Product Manual
Quick Start for Windows
1. Download and install MacroWorks 3.1 (MW3) from:
http://xkeys.com/PISupport/SoftwareMacroWorks.php.
2. Plug in the X-keys Switch Interface and wait for Windows to recognize it.
3. MW3.1 will display an icon in your Windows Taskbar. Click on the icon and
select the Switch Interface.
4. Press any switch connected to the Switch Interface (or double-click on the
port image) to begin recording a macro.
5. Type keystrokes or select text, shortcut, or function. Multiple lines of
keystrokes, text, shortcuts, and functions may be entered on a single switch.
6. Press the switch again (or click Save) to complete programming.
7. When finished, close the programming window.
To quickly learn how to use MW3.1 watch the brief tutorials on our website.
Consult the MW3.1 help file for complete instructions and tips on programming
and using your X-keys.
NOTE: Mouse and joystick commands are found in the Functions menu.

Hardware Mode Programming
The X-keys XK-3 has an internal memory for storing hardware macros like
keystrokes, mouse actions, game controller (joystick) or multi-media
commands. To program these macros, use MacroWorks 3.1 in “Hardware
Resident Mode.” (under the Mode menu). Once programmed, the XK-3 will
send macros to any computer or USB enabled device with no software
installation required.
Connecting Switches
The port on the XK-3 is a TRRS (Tip-Ring-Ring-Sleeve) jack designed to
accept our three button trigger switch. Any switch wired to a standard 3.5mm
plug may be plugged into the port and the XK-3 will recognize it. Splitter
cables are available to connect two or three switches to the port. Splitters and
adapters may be combined to connect multiple switches in parallel to trigger
the same action from the switch interface.
This image illustrates how the three types of 3.5mm (1/8”) plug are recognized
by the Switch Interface.
Support
Should you encounter difficulty with the installation or programming, please
open the MW3.1 or ControllerMate Help File or check the troubleshooting
guide on our web site. You may also contact technical support.
USA: [e-mail] | Phone: [phone]
UK: [e-mail] | Tel [phone]
Compatibility
X-keys USB devices are programmed with MacroWorks 3.1 for Windows XP
through 8 and ControllerMate for Mac OS X. Developers may also use
software development kits for Windows, Linux and Android to integrate X-keys
into their applications. Additionally, the USB 12 Switch Interface has a
hardware programming feature which allows a user to emulate keyboard,
mouse, joystick, or multimedia messages on any USB-enabled operating
system. For more information about any of these options, see our web site or
contact our Technical Support Department ([e-mail]).
Compatible Accessories
Please visit the Accessories page on our website for details on the following.
X-keys Port Splitter – add more switches to the Switch Interface
Wired Foot Pedals
Wired Switches – available in a wide array of styles and colors
X-keys USB Extender – up to 150 feet via CAT5 cable
Other Products from P.I. Engineering
X-keys XK-24 – 24 programmable keys
X-keys XK-60/XK-80 – 60 or 80 programmable keys
X-keys XK-128 – 128 programmable keys
X-keys XK-12 Joystick – 12 keys with a precision joystick
X-keys XK-12 Jog & Shuttle – 12 keys with jog & shuttle
X-keys XK-3 Foot Pedal – three programmable pedals
X-keys XK-4/XK-8/XK-16 Stick – a single row of 4, 8, or 16 keys
X-keys XK-68 Joystick - 68 keys with a precision joystick
X-keys XK-68 Jog & Shuttle – 68 keys with jog & shuttle
X-keys USB 12 Switch Interface – 12 switch ports
X-keys Encoder Board – 128 switch points
FCC Declaration of Conformity
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful
interference when the equipment is operated in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and if not installed and used in
accordance with the instruction manual may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio TV technician for help.
Any changes or modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
CE Declaration of Conformity
We, P.I. Engineering, Inc., declare that the X-keys is in conformance with:
EMC Directive 2014/30/EU, tested in accordance with EN 55032:2012 and
55024:2010/A1:2015
Certificate of compliance on file at P.I. Engineering, 101 Innovation Pkwy,
Williamston, MI 48895
