X-Loupe Primary kit C101 User manual

The following settings are for the CASIO EX-ZR65 camera,
and refer to the camera manual for setup.
(1) Align the 3 contact pins on the back of objective lens to the 3 holes
on the front side of module. (fig. )
(2) Rotate the lens spiral tooth clockwise until it is tight. But do not over-tighten!
(3) Open the battery cover on the bottom of module (press and slide the battery
cover in the direction indicated by the arrow), and fill in fully-charged
NB-4L Li-ion battery. (fig. )
(4) Turn on module power. It will light up if the assembly operation is correct.
SET
MODE
Magnifying Glass
4
BEST SHOTBS
★ Notice and Preparation for Photography ★
(1)Press [MODE], use ▲/▼/◄/► to select the top-right corner of
[BS] (BEST SHOT), and press [SET], this will display a menu of
BEST SHOT scenes; then once again select the top-right corner
of [Magnifying Glass].
(2)Shooting with this Scene, the settings will automatically be
selected as follows:
Flash setting → Flash Off / Optical zoom → Full wide angle
Focusing → Marco focus / AF metering area → Spot
Product Assembly
Step1 Mount objective lens to module
*Please ensure that you read and understand the safety precautions. Please refer to product instruction.
If failure to observe instructions on the use cause the damage to product is excluded from the warranty.
Red Dot
Turn 30 degrees clockwise
Digital Still Camera
Microscope module
Objective Lens
On(Red dot) / Off switch
LED
Illumination Control
(White LED)
★
The diagrams in this manual are based on model C101;
the appearance is slightly different from model A500,
but both models take the same assembly operation and using method.
Front of Objective Lens
Magnifying Glass
Step2 Confirm the completion of the camera settings
Make sure to follow the "Notice and preparation for Photography"
to complete the camera mode setting.
Before making the combination of module and camera,
the camera must be in the mode of [Magnifying Glass] (correspond
this mode, the length for camera lens as it extends will be locked out).
Note:
Follow the direction
to fill in battery
(1) Align the mount positioning on the mount ring (at the rear of module)
with the red dot above the camera mount. (fig. )
(2) Attach module to camera and turn 30 degrees clockwise
until both bodies are firmly combined. (fig. )
(3) Turn on the camera and module power. The image will appear on LCD screen if the handling
is correct. If the lens barrel can not extend properly, or error code shows on camera monitor,
please refer to the troubleshooting section.
Step3 Mount module to camera
MODE
SET
Control Panel
Camera Back
Back of Objective Lens
If unable to solve, please immediately contact your distributor for assistance.
DO NOT try to modify X-Loupe®product by yourself in any way.
Front of Module
Back of Module
Pogo pin
Pogo pin
Mount adapter
X-Loupe®Portable Microscope Camera System User Guide Primary kit C101 / A500
Each model contains two interchangeable lens
with the magnification distinguished by color.
C101 / 80X → Green; 160X → Light Blue
A500 / 60X → Red; 150X → Blue

Distributor
C101A500E
U
031417
11653 台北市文山區萬和街8號7樓
7th Floor, No. 8, Wanhe St., Wenshan District,
11653 Taipei City, Taiwan, R.O.C.
TEL:[phone] FAX:[phone]
e-mail:[email protected]
http://www.x-loupe.com http://www.lumos.com.tw
Troubleshooting & Storage
(1) About the troubleshooting of camera, please refer to the Camera User Guide.
(2) The LED of lens barrel is not on:
①Check the battery power.
②Remove the lens and assemble it back to the module again.
Make sure that the assembling of the lens and module is correct.
③Check the brightness index of module lighting is not set to zero. If it is, set back to “entire bright” or the suitable brightness.
(3) Error code shown on camera display - the lens barrel of camera can not stretch out or retract:
①Turn off the camera, the lens should be automatically retracted, then remove the module, check the setting for shooting mode.
Note: If the shooting mode is set incorrectly, it will cause the camera lens over extend to touch the module,
which may cause the damage to the camera lens.
②If the problem is not solved, contact your local distributor; never try to fix the camera lens by force.
(4) Out of Focus:
①Adjust the direction or posture while shooting.
②Press the shutter halfway and adjust the distance between the subject and lens to reach the best focus.
③X-Loupe®is a contact-based digital microscope; therefore, do not take the picture out of its short working distance.
④Whether the camera setting has been varied? The changes in setting may lead to the function of micro photography is ineffectual.
(5) Keep product in the dry environment such as a dry box, and get some desiccants inside the storage case / box if necessary.
It is advised to use the optional “X-Loupe® specialized carrying case”.
Attention / Warning for the Battery Charging
Please use the included charger to charge the battery.
(1) Charging Signal will light on. -- Red: Charging; Green: Charging complete.
(2) After full charge, remove the battery from charger. Do not leave a fully charged battery connected to a charger, since overcharging
may shorten the battery life. Unplug the charger from the electrical plug when not in use.
(3) DO NOT use the battery charger in humid circumstances.
(4) Please recycle when possible. DO NOT dispose as household waste.
Safety Notice
(1) Before using this product, please make sure that you have read and understood the manual thoroughly.
(2) Keep this product away from chlidren.
(3) This product equipped high-brightness LEDS. The LED light can be intense enough to injure eyes.
For eyes safety, DO NOT look directly into LED at close range; also DO NOT aim the light at people.
(4) DO NOT use any flammable reagent or liquid containing alcohol, benzene, or dilutant to clean X-Loupe®.
(5) Damages caused by any inadequate operation such as dropping, collision, or plummet are NOT covered in the warranty.
(6) DO NOT have X-Loupe®closed to any tinder or throw it into the flame.
(7) DO NOT throw X-Loupe®into any liquid. In case of any liquid droplet on the surface of X-Loupe®,
please wipe it out immediately.
(8) Please DO NOT discard X-Loupe®into the trash can.
Disclaimer
．Thank you for using this product. While every effort has been made to ensure that the
information contained in this guide is accurate and complete, no liability can be accepted
for any errors or omissions.
．We (Lumos Tech.) reserves the right to change the specifications described herein at
anytime without prior notice.
．No part of this guide may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form, by any means, without the prior
written permission of Lumos Technology Co., Ltd.
Trademark Acknowledgments
．CASIO EX ZR65 are either registered trademarks or trademarks of CASIO in Taiwan and/or other
countries.
．X-Loupe®is a registered trademark of Lumos Technology Co., Ltd. You are not authorized to use
such trademark and service marks for any purpose unless you receive specific written permission
from us (Lumos Tech.) We reserve the trademark or other intellectual property rights.
After Reading, Keep the User Guide Handy for Future Reference
★In the interest of continually improving products, Lumos Tech. reserves the right to update or modify information contained in this manual without prior notice.
★Product image of this manual is for reference only and actual product appearance may vary.
