X10 Add-on Audio Video Receiver VK42A Manual

ConnecttheAudioReceivertoYour
Stereo(MP3Anywhereusers)
Thesestepswill guide you through
connecting the VR30Avideo receiverto
yourstereo.Here'showyou do it:
1.Connectthe red and whiteplugson the supplied
RCAcabletothe respectiveAudioInconnections
on the video receiver.Plug the otherendsofthese
intothe appropriateaudioinputson yourstereo.
2.Plug the PR30Apowersupplyintoany120VAC
outlet.
3.Plug the poweroutputofthe PR30Aintothe DC
12Vplug on the VR30A.
Tolisten toyourMP3audio,simplyselectthe correct
inputsetting on yourstereo tolisten toyourMP3
files.
Notes:
The VK42Aletsyou displayaudioand video fromX10
video sendersanywhereinyourhome.Withthe VK42A
you can listen toMP3Anywhereall overyourhome,
watchDVDAnywhereinthe living roomand on your
bedroomTV,ormonitoryourXCamAnywherefrom
morethan one TV.Tousethe VK40Ayou musthave
one ofthesekitsalready.
Configuring theVideoReceiver
The firststep insetting up yournewvideo
receiver(modelVR30A)isconfiguring itto
workwiththevideo transmitter(modelVT30A)
you shouldhavealreadyinstalled as
partofan X10 Anywherekit. Check the
"Channel"(A-D)setting on the bottom
ofyourVT30Aand setthe switchon
the newVR30Atomatch.Ifthese
settingsdo notmatch,youraudioor
video will notbe displayed correctly.
Connecting theVideoReceivertoyourTV
orVCR (DVD&XCamAnywhereand Video
Senderusers)
Thesestepswill guideyou throughconnecting
the VR30Avideo receivertoyourTVorVCR sothat
you can watchvideo pictureon yourTV.Here'show
you do it:
1.Plug the yellowvideo plug on the supplied RCAcable
(the one withyellow,red and whiteconnectorson both
ends)intothe Video Outjack on the VR30AVideo
Senderreceiver.Connectthe otherend intothe yellow
video inputjack on yourTVorVCR.
2.Connectthe red and whiteplugson the RCAcable
tothe respectiveAudioInconnectionson the video
receiver.Plug the otherendsoftheseintothe audio
inputson yourTVorVCR.
Note:IfyourTVorVCR doesn'thaveRCAvideo and
audioinputs,you can connectthe outputofthe receiver
tothe TVusing the provided coaxialcable.
3.Plug the PR30Apowersupplyintoany120VAC
outlet.
4.Plug the poweroutputofthe PR30Aintothe DC 12V
plug on the VR30A.
Add-on AudioVideoReceiver
Copyright1999 X10 (USA)Inc.
MODEL
NUMBER:
IN19A
