Xantech EN85K Ensemble User manual

INSTALLATION INSTRUCTIONS
EN85K
Ensemble
Surface Mount / TV Mount / Flush Mount/ Shelf Mount
Plasma LCD / LED / CFL Friendly
Convertible IR Receiver Kit
PRELIMINARY
COPY
PRELIMINARY
COPY

®
2
DESCRIPTION
The EN85K Ensemble is a convertible IR Receiver Kit that can be adapted to
almost any surface mount, ush mount or shelf mount application. It includes
all of the parts necessary for installing a single-room IR Repeater System for
controlling a TV, Audio/Video Receiver, Blu-ray player, Cable Box, Satellite Re-
ceiver...just about any IR controlled A/V home entertainment device.
The kit includes an IR Receiver that can be attached to the front of a TV, or
extended from behind on at panel TVs that have a minimal frame around the
display area. The receiver can also be adapted to a low-prole shelf-top case
or cabinet door adapter for controlling IR components hidden in an equipment
cabinet.
The EN85 IR Receiver adapts and connects in minutes! Please read the instruc-
tions in this manual carefully to enjoy arm chair control of your favorite audio/
video components!
FEATURES
• IRReceivershelfmount,ushmount,surfacemountandTVmountadapt-
ers allow installation almost anywhere
• IRReceivercompatiblewithmostPlasma,LCDandLEDTVs
• IRReceivercompatiblewithmostCFLlightbulbs
• SystemtestingredTalkbackLED
• Includesone789-44ConnectingBlock,one781ERGPSPowerSupply,and
four 283D IR Emitters for easy system installation
SPECIFICATIONS
• Infraredcarrierfrequencybandwidth:25-60kHz
• Receptionrange:Upto80feet*
• Receptionangle:+/-60º
• Cablerequirements:Seesection:Extending The Receiver Wire
• Max.Transmissionlength:1mileusing18gaugewire
• Maximumcurrentoutput:100mA
• IRReceiverDimensions:.55”diameter(14mm)
• Powerrequirements:+12VDC,10mA
*Dependingonremotecontroloutputstrengthandambientconditions.

®
3
WHAT’S INCLUDED
1-EN85IRReceiver 1-TabletopAdapter
1-FlushMountAdapter 1-TVMountAdapter
1-789-44ConnectingBlock 4-283DIREmitters
1-781ERGPSPowerSupply
The unique design of the EN85K allows the EN85 IR Receiver to be adapted to
almost any surface mount, ush mount or shelf mount application using the in-
cluded adapters. The EN85 can be mounted directly to at panel TVs, placed on
a shelf or mounted in a cabinet door for convenient armchair control of hidden
audio/video components.

®
4
READ THIS BEFORE YOU DO ANYTHING!
FOUR IMPORTANT CONSIDERATIONS
1. Where is the IR Receiver going to be located? The IR Receiver must be
‘line-of-sight’ to the remote control being used to be able to control the
system audio/video components. This location should be in a convenient
spot in front of the user when seated in a typical location for watching TV
or listening to music. This will determine how the IR Receiver is going to be
mounted.
2. How is the IR Receiver going to be mounted? The IR Receiver can be
surface mounted directly to the frame on the front of some at panel TVs.
For TVs that do not have a wide enough frame, the TV Mount Adapter
can be used to extend the IR Receiver out from the back of the TV. If the
IR Receiver is going to be mounted in a cabinet door, the Flush Mount
AdapterwillmounttheIRReceiverinan11/16”holeinthecabinetdoor.
If the IR Receiver is going to be placed on a shelf or on top of a cabinet,
the Tabletop Adapter provides an attractive, low prole case for that
application.
3. Where are the audio/video components that are going to be controlled?
TheIRReceiver,EmittersandPowerSupplyallconnecttothe789-44
Connecting Block. The Connecting Block should be in the same location
as the audio/video components. If the A/V components are in a wall unit or
cabinet in the same room and within a few feet of the IR Receiver, then once
the IR Receiver has been mounted, nd a convenient location that allows
access to the Connecting Block for making connections and then simply
connecttheIRReceiver,EmittersandPowerSupply.(TheIRReceiverhas
atotalwirelengthof6feet,8inches,andtheEmittershaveawirelengthof
10feet,usuallyenoughwiretomakeconnectionsinatypicalcabinetorwall
unit.)
If the IR Receiver is going to be mounted across the room or in a different
room from the A/V components, the wire length of the IR Receiver can
beextendedtoaccommodatethosesituations.Pleaseseethesection:
Extending the Receiver Wire for additional information.
4. IMPORTANT NOTE - Placement - The IR Receiver should be located so
that it is not directly facing a light source such as sunlight, lamps or video
displays(CRT,LCD,andPlasma).Whenmountednearadisplay,itshould
be ush to the display and away from light reections that may occur.
Withanswerstothesethreeimportantquestions,you’rereadytoinstallyour
EN85K IR Receiver...So let’s go!

®
5
INSTALLING THE IR RECEIVER
SURFACE MOUNT
The rst, and easiest, option is to mount the IR Receiver on the front frame of a
at panel TV. This application can also be used to surface mount the IR Receiver
to other objects.
1. Select a location on the TV frame to mount the IR Receiver. Be sure the
receiver will not be blocked by any object to allow ‘line-of-sight’ to the
remote control in normal use.
2. WiththeIRReceiver8”RibbonCabledirectedtowardtheedgeoftheTV,
using one of the included adhesive strips, carefully attach the IR Receiver to
the TV frame. Figure 1
3. Carefullyattenandwrapthe8”RibbonCablearoundtothebackofthe
TV. The Ribbon Cable can be secured to the TV with tape or a wire holder if
necessary. Do not block any TV vents.
4. Usingoneoftheincludedadhesivestrips, carefully attach the Electronics
Module to the rear of the TV. Do not block any TV vents.
5. Carefully run the plug end of the Ribbon Cable into the cabinet with the A/V
components to where the Connecting Block will be located. Be careful not
to pinch or strain the Ribbon Cable. The Ribbon Cable can be secured to
the back of the TV with tape or a wire holder. Do not block any TV vents.
Ifthisisyourapplication,whennished,proceedtosection:Typical
Connections.
Figure 1 - Surface Mount - Flat Panel TV
Front of TV
EN85
IR Receiver
EN85
Electronics Module
To Connecting
Block
RCVR Jack
Attach with
Adhesive
Attach with
Adhesive
8” Ribbon Cable

®
6
TV MOUNT ADAPTER
The TV Mount Adapter allows mounting the IR Receiver on an
extension attached to the rear or side panel of a at panel TV that does
not have a frame on the front that is wide enough to directly mount the
IR Receiver. This application can also be used to mount the IR Receiver
in just about any position on just about any object.
Both ends of the TV Mount Adapter rotate and swivel allowing the
Adapter and IR Receiver to be manipulated into different positions as
shown in Figure 4.
1. Select a location on the TV to mount the TV Mount Adapter. Be
sure that once mounted, the IR Receiver will not be blocked by any
object to allow ‘line-of-sight’ to the remote control in normal use.
2. Usingoneoftheincludedadhesivestrips,attachtheatendofthe
TV Mount Adapter to the TV frame. Figures 2 & 3 & 5
3. Withthe8”RibbonCablealignedtotheWireGapontheridged
end of the TV Mount Adapter, (Figure 5) using one of the included
adhesive strips, attach the IR Receiver to the TV Mount Adapter.
Figures 2 & 3
4. Carefullyattenandwrapthe8”RibbonCablearoundtotheback
of the TV. The Ribbon Cable can be secured to the TV with tape or
a wire holder if necessary. Do not block any TV vents.
5. Usingoneoftheincludedadhesivestrips,attachtheElectronics
Module to the rear of the TV. Do not block any TV vents.
Figures 2 & 3
6. Carefully atten and wrap the plug end of the Ribbon Cable into
the cabinet with the A/V components. Be careful not to pinch or
strain the Ribbon Cable. The Ribbon Cable can be secured to the
back of the TV with tape or a wire holder. Do not block any TV
vents.Ifthisisyourapplication,whennished,proceedtosection:
Typical Connections.
Front of TV
EN85
IR Receiver
EN85
Electronics Module
To Connecting
Block
RCVR Jack
Attach with Adhesive
Attach with Adhesive
8” Ribbon Cable
EN85
TV Mount Adapter
Flat
End
Ridged End
Figure 2 - TV Mount Adapter -
Rear Mount
Front of TV
EN85
IR Receiver
EN85
Electronics Module
To Connecting
Block
RCVR Jack
Attach with
Adhesive
Attach with Adhesive
8” Ribbon Cable
EN85
TV Mount Adapter
Attach with
Adhesive
Flat EndRidged End
Figure 3 - TV Mount Adapter -
Bottom/Side Mount
Flat End
Ridged End
Wire
Gap
360°
180°
Figure 4
Figure 5

®
7
Figure 6 - Tabletop Adapter -
Insert IR Receiver
Figure 7 - Tabletop Adapter -
Insert Electronics Module
TABLETOP ADAPTER
The Tabletop Adapter allows mounting the
IR Receiver in an attractive low-prole case
creating an IR Receiver that can be placed
on any shelf or tabletop.
1. Remove the Tabletop Adapter Base by
rotating it counter-clockwise as shown
in Figure 8.
2. Position the Tabletop Adapter top so
the lens is facing down as shown in
Figure 6.
Lens
IR Receiver
Ribbon Cable
Pass-Through
8” Ribbon Cable
Tabletop Adapter
Top Inside
To Connecting
Block RCVR Jack
Lens
IR Receiver
Ribbon Cable
Pass-Through
Wide Gap
At Top
Tabletop Adapter Base - Inside
Base Lock
Base Lock
Base Lock
Base Locks
Base Lock
Electronics
Module
Socket
Electronics
Module
‘Bottom Notch’
Figure 8 - Tabletop Adapter -
Remove/Tighten Base
To Connecting
Block RCVR Jack
Lens
Rotate Clockwise
to Tighten
Rotate Counter-clockwise
to Remove
3. Withthe8”RibbonCableontheIRReceiverfacingup,carefullyinsertthe
IR Receiver into the socket on the backside of the lens as shown in
Figure 6. The receiver should snap into place when properly inserted.
4. Withthe‘bottomnotch’oftheElectronicsModulefacingyou,carefullyslide
the module onto the post in the Electronics Module Socket as shown in
Figure 7.
5. Carefullywrapthe8”RibbonCablearoundtheElectronicsModuleand
extend the plug end of the Ribbon Cable out of the Tabletop Adapter case
via the Ribbon Cable Pass Through as shown in Figure 7.
6. Align the Adapter Base to the Adapter Top with the ‘wide gap’ aligned at the
top with the IR Receiver as shown in Figure 7. Tighten the base to the top
as shown in Figure 8.
Ifthisisyourapplication,whennished,proceedtosection:Typical
Connections.

®
8
FLUSH MOUNT ADAPTER
The Flush Mount Adapter allows mounting the IR Receiver in an equipment
cabinet door. This allows IR controlled audio/video components to be controlled
with the cabinet door closed.
Thisapplicationrequiresdrillingan11/16”(17.4mm)holeinthecabinetdooras
shown in Figure 9. It is recommended that the IR Receiver be mounted closer to
the hinged side of the cabinet door so the Electronics Module can be mounted
to an inside wall rather than the door.
1. Select a location on the cabinet door to mount the Flush Mount Adapter.
Besurethereisatleastoneinchofclearancefromthebackofa5/8”thick
cabinet door to the front of the A/V components to allow room for the
Adapter Locks with the door closed. (Figure 11) Also be sure that once
mounted, the IR Receiver will not be blocked by any object to allow ‘line-of-
sight’ between the remote control and the IR Receiver in normal use.
2. Drillan11/16”(17.4mm)diameterholeinthecabinetdoor.Figure 9
3. Pinch the Adapter Locks together and carefully slide the adapter through
theholeuntiltheadapterbezelispressedagainstthefrontofthecabinet
door.Besuretoalignthethicksectionsofthebezelat12and6o’clockfor
bestlefttorightoff-axisperformance.(Itwilllookbetterthatwayaswell.)
Figure 10
4. Carefullypullthe8”RibbonCablestraightbackfromtheIRReceiverand
with the receiver lens oriented to match the orientation of the mounted
adapter(thicksections12and6o’clock)pushtheIRReceiverintotheback
of the mounted adapter until it snaps into place. Figure 12
DO NOT ALLOW THE RIBBON CABLE TO BE PINCHED BETWEEN THE
RECEIVER AND THE ADAPTER LOCKS.
Cabinet Door
11/16” (17.4mm)
Diameter Hole
5/8” (15.9mm)
Door Panel
Figure 9 - Flush Mount Adapter -
11/16”Hole
Cabinet Door
11/16” (17.4mm)
Diameter Hole
Pinch Adapter Locks together
so they will slide through hole
in cabinet door.
Adapter Bezel
Figure 10 - Flush Mount Adapter -
Install Adapter

®
9
5. NOTE: It is recommended that the
Electronics Module be mounted
to an inside wall of the cabinet. If
attached with adhesive, there is some
possibility that if mounted to the door,
in time, the module could come loose
from the action of the door opening
and closing and ultimately fall off,
potentially damaging the IR Receiver
the Electronics Module or both.
 Usinganappropriatelengthwoodscrew
(notincluded)attachtheElectronics
Module to an inside wall of the cabinet.
Useascrewthatwillsecurethemodule
but will not penetrate the outside wall of
the cabinet. Do not overtighten the screw
to avoid damaging the Electronics Module
case. Figure 13 OR...
 Useoneoftheincludedadhesivestrips
to attach the Electronics Module to the
inside of the cabinet.
6. Carefully run the plug end of the Ribbon
Cable to where the Connecting Block
will be located. Be careful not to pinch or
strain the cable.
If this is your application, when nished,
proceedtosection:Typical Connections.
Cabinet Door
Allow ~1” (25mm) clearance behind the back of a 5/8” (15.9mm)
thick cabinet door for the Adapter Locks with the cabinet door closed.
Figure 11 - Flush Mount Adapter -
Adapter Installed
Cabinet Door
Flush Mount
Adapter Bezel
Insert IR Receiver into
Flush Mount Adapter until it snaps into place
Ribbon Cable
Ribbon Cable
Figure 12 - Flush Mount Adapter -
Install IR Receiver
Cabinet Door
Flush Mount
Adapter Bezel
8” Ribbon Cable
To Connecting
Block
RCVR Jack
Use wood screw or
adhesive to attach
Electronics Module to
back of cabinet door or
inside wall of cabinet.
Electronics
Module
Figure 13 - Flush Mount
Adapter -
Secure Electronics Module

®
10
TYPICAL CONNECTIONS
SINGLE ROOM - EQUIPMENT CABINET
WiththeIRReceiverconguredandinstalledinasurfacemount,TVmount,
ush mount or tabletop application as described on the previous pages, install
the Connecting Block and then connect the IR Receiver, Emitters and Power
Supply to the Connecting Block as described below.
1. Find a convenient location in the equipment cabinet to mount the
 789-44ConnectingBlock.Thislocationshouldalloweasyaccessfor
making connections and be located so the IR Receiver, Emitter and
Power Supply wires can all be connected without modication. Attach the
Connecting Block to a cabinet wall or shelf with the included adhesive strips
orappropriatehardware(woodscrews-notincluded.Besurescrewsare
long enough to secure the block but not so long that they extend out of the
sideofthecabinet).
2. ConnecttheIRReceivertothe“IRRCVR”jackonthe789-44Connecting
Block.(ConnecttheredIRReceiverplugtotheredConnectingBlockjack.)
3. Carefully position the 283D IR Emitters over the IR Eye on each audio/
videocomponenttobecontrolled.(Iftheeyeisnotobvious,shineasmall
ashlight into the front panel of the component to locate the eye, or refer to
thecomponent’sowner’smanual.)
4. Position the IR Emitter so the mini-wire is positioned toward the nearest top
or bottom edge on the component being controlled.
5. Carefully wrap the Emitter mini-wire around to the back of the component
and run the Emitter wire to the Connecting Block, being careful to not pinch
the wire between components.
To 120 V AC
(unswitched)
781ERGPS
789-44
Connecting Block
MAIN ROOM
A/V Receiver
DVD
Satellite Receiver
283D Emitter
12VD C
+12 VDC
GND
STATUS
IR IN
EMITTERS
IR
RCVR
789-44
CONNECTING BLOCK
®
283D Emitter
283D Emitter
Hand Held
Remote
IR Photodiode &
Red Talkback LED
EN85 Micro Receiver
mounts directly on a
flat panel TV frame or
to one of the included
TV, Tabletop or Flush
Mount Adapters
Electronics Module
3.5mm
Mini Plug
To extend wire length,
cut here.
Figure 14 - Typical Connections

®
11
EXTENDING THE RECEIVER WIRE
In some applications it may be necessary to extend the IR Receiver wire. Typical
examples would be if the IR Receiver is going to be located across the room
from the Connecting Block and A/V components or if the IR Receiver is going
to be located in a remote room. This will give the user the ability to control IR
controlled audio/video components from a location where the remote control no
longer has direct line-of-sight to the equipment.
To extend the IR Receiver wire, cut the Ribbon Cable between the Electronics
Module and the 3.5mm stereo mini plug. To extend the wire run to the
Connecting Block, use a terminal strip to connect the IR Receiver wire to the
wirerunningtotheConnectingBlock.(Figure 17)Useunshielded3-conductor
stranded wire for the extension as detailed on the next page.
IMPORTANT NOTE: DO NOT EXTEND THE WIRE LENGTH BETWEEN THE
IR RECEIVER AND THE ELECTRONICS MODULE.THISWILLREDUCE
THESENSITIVITYOFTHEIRRECEIVERANDVOIDTHEWARRANTY.IFITIS
NECESSARYTOEXTENDTHEWIRELENGTHTOTHECONNECTINGBLOCK,
EXTENDTHEWIRETHATRUNSBETWEENTHEELECTRONICSMODULEAND
3.5MMMINIPLUG.Figure 15
6. ConnecttheEmitter(s)totheConnectingBlock.(ConnecttheyellowIR
EmitterplugtooneoftheyellowConnectingBlockjacks.)Repeatforall
Emitters.
7. Connectthe781ERGPSPowerSupplytothe12VDCjackonthe789-44
ConnectingBlock.ConnectthePowerSupplytoanUNSWITCHEDAC
outlet.
8. To test, point an IR Remote at the EN85 IR Receiver. Press a specic
functionbuttonontheremote(Cable/SatelliteON/OFFforexample).The
IR Receiver and all connected Emitters should ash red, and the selected
componentshouldrespondtothecommand(Cable/SatelliteON/OFF).
If any of that didn’t happen, check IR system connections and try again. If
the system still hasn’t responded, check the Troubleshooting section at the
end of this manual.
Do not cut to extend wire length Cut this section to extend wire length
Electronics Module
Figure 15 - Only Extend The Plug End of the IR Receiver Ribbon Cable

®
12
Useunshielded,3conductorstrandedwire,perthetablebelow,whenextending
theplugendoftheIRReceiverRibbonCable.(4conductorprovidesanextra
wireforback-upifoneoftheconductorsgetsdamaged.)
IR WIRE LENGTH IR WIRE GAUGE
UPTO200’(61m) 24AWG
UPTO600’(183m) 22AWG
UPTO2000’(610m) 20AWG
UPTO5000’(1524m) 18AWG
EN85
IR Receiver
White
Stripe
To 120 V AC
(unswitched)
781ERGPS
789-44
Connecting Block
REMOTE ROOM MAIN ROOM
3-Terminal Block (not included)
3-Conductor
Extension Cable
(unshielded)
A/V Receiver
DVD
Satellite Receiver
283D Emitter
12VD C
+12 VDC
GND
STATUS
IR IN
EMITTERS
IR
RCVR
789-44
CONNECTING BLOCK
®
IR OUT
+12V
GND
283D Emitter
283D Emitter
8” Ribbon Cable
(Do Not Add Length!)
6’ Ribbon Cable
(OK to Add Length)
Electronics Module Hand Held
IR Remote
Whenaddingwirelength,conrmthattheIRSignal,+12VDCandGNDwires
areproperlyconnectedtoboththeIRReceiverandConnectingBlock(Signalto
Signal;+12to+12;GNDtoGND).Improperconnectionwillaffectperformance
andpossiblydamagetheIRReceiver.TheEN85KWarrantydoesnotcoverthis
type of damage.
Connections must be made as illustrated. To extend the Emitter wires to a more
distant location, you may splice in 2-conductor wire, in the wire gauges shown
above, as needed.
WhileitispossibletomakewiredconnectionswithouttheConnectingBlock,it
is not recommended. The Connecting Block reduces installation time, helps to
eliminate errors, allows easy troubleshooting and permits easy system upgrades
later, if needed.
Figure 16 - 3.5mmStereoMiniPlug&WirePin-Out
Figure 17 - Extending the Plug End of the IR Receiver Ribbon Cable

®
13
MULTI-ROOM APPLICATION
Another application is multi-room IR control. If an audio receiver is being used to
drive speakers in multiple rooms, it may be desirable to place an IR Receiver in
some or all of those rooms. In many cases, this same application can be used to
controlthemainzoneandsecondzoneofatwo-zoneA/VReceiver.
This will allow a user to turn the system ON/OFF with an IR remote via the IR
Receiver(s)intheremoteroom(s).Thesystemcanalsobecontrolledfromthemain
room with an IR remote using the IR Receiver in the main room.
Installation combines the connections described in the previous Single Room
and Extending the Wire sections. The Main Room IR Receiver gets connected
usingthered,3.5mmmini‘IRRCVR’jackonthe789-44ConnectingBlockand
themulti-roomreceiver(s)getconnectedtothescrewterminalsontheConnecting
Block. Figure 18
XantechmanufacturesavarietyofIRReceiversfordifferentapplications.Please
visit xxx.xantech.com to nd the IR Receiver that best ts your application.
EN85
IR Receiver
To 120 V AC
(unswitched)
781ERGPS
789-44
Connecting Block
REMOTE ROOM
MAIN ROOM
3-Terminal Block (not included)
3-Conductor
Extension Cable
(unshielded)
A/V Receiver
DVD
Satellite Receiver
283D Emitter
12VD C
+12 VDC
GND
STATUS
IR IN
EMITTERS
IR
RCVR
789-44
CONNECTING BLOCK
®
IR OUT
+12V
GND
283D Emitter
283D Emitter
Electronics Module Hand Held
IR Remote
Hand Held
IR Remote
EN85
IR Receiver
Electronics Module
Figure 18 - Multi-Room Application

®
14
IR Troubleshooting Guide
NOTE: Due to the many variables in a given installation, the troubleshooting
measures you may need to take can vary in different situations.
Each installation is different due to the number of IR Receivers, length of wire
runs, type of wire, amount of ambient IR noise present, etc….
Therefore, your troubleshooting measures for a particular job can range from
nothing at all, to any combination of the solutions listed below.
Symptom #1: DIM or NO Talkback LED during IR reception or reduced
operational range.
Cause Solution
1. Weakbatteriesintransmitting
remote.
Replace batteries.
2. Bad Emitter or no Emitter
plugged into Connecting Block.
Test Emitter and verify wiring.
3. Signal wire between IR Re-
ceiver and the Connecting
Block is open.
Recheck wiring.
4. Power Supply not putting out
proper voltage.
Verifysupplyisa12VDCregulated
supplyreadingbetween11.5to
13VDCunderload.Usetheincluded
PowerSupply,Model781ERGPS
(12VDCRegulated,200mA)or
782ERGPS(12VDCRegulated,
1.2A)
5. Output from the IR Receiver/
Connecting Block is connected
to a high impedance IR input
jack on a component.
If you are using a passive Con-
nectingBlock,suchasa789-44,
and the system is not working, try
the amplied Connecting Block,
model791-44.Putoneofthesmall
plastic case jumpers supplied with
the block on the pins next to the
Emitter jack. This will provide the
IR-in jack on the component with a
hotter signal.
6. IR Receiver is inoperable. Replace IR Receiver.

®
15
Symptom #2: Talkback LED on IR Receiver (and/or Emitters) dimly lit or
flickering.
Cause Solution
1. Signal and ground wires are
reversed or shorted either at
the Connecting Block or IR
Receiver.
Recheck wiring.
2. Defective Emitter. Replace Emitter.
3. Relatively high levels of ambient
light noise. This can be due to
anyofthefollowing:sunlight,
orescent lighting or Plasma
Displays.
Reposition the IR Receiver away
from the light source or eliminate
the light source.
4. EMIinducednoise(electromag-
neticinterference).Thiscanbe
due to light dimmer controls
or other radiating electronic
devices(PC’soranypoorly
shieldedelectronicdevice).
Reposition the IR Receiver and/or
cabling away from emitting device.
Youcanalsoplacea470-ohm
resistor in parallel with the IR Signal
andGNDconnectionsontheCon-
necting Block. This will also help
alleviate any stray capacitance in
the cable.
5. Plasma Interference. Plasma interference can be re-
ected off of any item it comes into
contact with within approx. 3 feet
of the front of the display. Keeping
this in mind, make sure that the IR
Receiver is free from any object that
might reect Plasma interference
into the receiving eye.

®
16
Symptom #3: Talkback LED on IR Receiver (and/or Emitters)
constantly on.
Cause Solution
1. Plasma Interference Plasma interference can be re-
ected off of any item it comes into
contact with within approx. 3 feet
of the front of the display. Keeping
this in mind, make sure that the IR
Receiver is free from any object that
might reect Plasma interference
back into the receiving eye.
2. VoltageandGroundwiresare
reversed at the Connecting
Block or IR Receiver
Recheck wiring.
3. Relatively high levels of ambi-
ent noise. This can be due to
anyofthefollowing:sunlight,
orescent lighting or Plasma
Displays.
Reposition the IR Receiver or elimi-
nate the light source.
4. EMIinducednoise(electromag-
neticinterference).Thiscanbe
due to light dimmer controls
or other radiating electronic
devices(PC’soranypoorly
shieldedelectronicdevice).
Reposition the IR Receiver and/or
cabling away from emitting device.
Youcanalsoplacea470-ohm
resistor in parallel with the IR Signal
andGNDconnectionsontheCon-
necting Block. This will also help
alleviate any stray capacitance in
the cable.
5. Power Supply not putting out
proper voltage.
Verifysupplyisa12VDCregulated
supplyreadingbetween11.5to
13VDCunderload.
Symptom #4: Talkback LED on IR Receiver blinks but 283D Emit-
ters do not.
Cause Solution
1. There may be a short, such
as a staple driven through the
SignalandGNDwiresoftheIR
Receiver and/or the Emitter.
Recheck wiring.
2. Emitter may be shorted inter-
nally
Replace Emitter or use TEST EMIT-
TER to check circuit.

®
17
Symptom #5: Intermittent IR control (i.e. buttons on remote
need to be pressed multiple times)
Cause Solution
1. Plasma Interference. Plasma interference can be re-
ected off of any item it comes into
contact with within approx. 3 feet
of the front of the display. Keeping
this in mind, make sure that the IR
Receiver is free from any object that
might reect Plasma interference
back into the receiving eye.
2. Relatively high levels of ambi-
ent noise. This can be due to
anyofthefollowing:sunlight,
orescent lighting or Plasma
Displays.
Reposition the IR Receiver or elimi-
nate the light source.
3. LongWireRuns–shieldedwire
typicallyof100feet(30meters)
or longer causes a lter effect
due to accumulated capaci-
tance of the wire. Intermittent,
or no IR control, could actually
be because of the longer wire
runs.
Puttinga470-ohmresistorinparal-
lel at the Connecting Block between
signal and ground will effectively
discharge the capacitance of the
wire. This will allow the signal to
travel farther on shielded wire.
Adding a resistor between the input
and ground of the Connecting Block
will drop the IR level down some-
what. Passive Connecting Blocks,
suchasthe789-44,maynothave
enough signal output for consistent
controloftheequipment.Youmay
have to upgrade to an amplied
Connecting Block to bring the IR
level back to normal. In these
cases,the791-44wouldbeanideal
ConnectingBlockforsinglezone
systemswhilethe795-20would
workbestfora2-4zonesystem.
4. Low batteries in Remote Replace batteries.

®
18
Symptom 6: Emitters function but some (or all)
components do not respond.
Cause Solution
1. Emitter placement is incorrect. Reposition the Emitter so that it is
directly over the component’s IR
eye. Shine a small ashlight into the
front panel of the component to lo-
cate the eye or consult the compo-
nent’s owner’s manual for the exact
location of the IR eye.
2. Emitter placement is correct but
the signal is overpowering the
unit or there is bleed-through
from other Emitters close by.
Reposition the Emitter so it is not
directly over the IR eye to reduce
the amount of IR signal the IR eye
on the component being controlled
‘sees’. If the components do not
need to be controlled directly
without an IR Repeater system
(componentsarelocatedinan
equipmentcloset),placeaMouse
Emitter Shield cover over the
Emitter(PN#MS1).Therounded
(non-stick)sideoftheEmitterisa
hi-output side and can reect off
other devices and overpower some
components’ IR Sensors.

®
19
Symptom #7: Absolutely No Functionality
(How to determine which component is at fault)
Component to Test Instructions
1. Verify Power Supply WithaMultimeter,measuretheDCVoltageof
the Power Supply while it is connected to the
Connecting Block. Put the negative lead of the
meterontheterminalmarkedGNDandthe
positiveleadontheterminalmarked12VDC(or
V).Youshouldgetareadingbetween11.5VDC
and13.0VDC.Ifnot,removethesupplyfrom
the Connecting Block and measure again -
this time directly on the 2.5mm coaxial plug.
Ifitreadsbetween11.5VDCand13VDC,the
Power Supply is most likely good. Reconnect
to the Connecting Block and proceed to Step
2. NOTE: In most cases this will indicate the
Power Supply is good but in some cases the
PowerSupplycanstillbebad(i.e.readsgood
when not plugged in but may not be able to
handlethecurrentloadofthesystem.)
2. VerifyEmitter.(283D
or286DBlinkStyle
ONLY)
Remove the Power Supply from the Connecting
Block and all Emitters from the output. Place a
jumper wire on the Connecting Block between
IRand+12V.ReconnectthePowerSupplyand
one Emitter. The Emitter should light bright and
solid. Repeat for all Emitters.
3. Verify IR Receiver. Remove the Power Supply from the Connect-
ing Block and all Emitters from the output.
Place a jumper wire on the Connecting Block
betweenIRSignalandGND.Reconnectthe
PowerSupply.Withaknowngoodhand-held
remote, shoot a constant IR Command at the
IR Receiver and verify the Talkback LED on the
IR Receiver ashes.

®
20
Limited Warranty
Xantech®warrants its products to be free of defects in materials or workmanship.
This is a Limited Lifetime warranty from the date of purchase by the original
consumer.AnyproductsreturnedtoXantechandfoundtobedefectiveby
Xantechwithinthewarrantyperiodwillberepairedorreplaced,atXantech’s
option,atnocharge.Xantechwillnotberesponsiblefortheactualcostof
installation or removal of the product, nor for any incidental or consequential
damages. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you.
Thiswarrantygivesyouspeciclegalrights.Youmayhaveadditionallegalrights
that vary from state to state.
Core Brands, LLC, A Nortek Company
1800SouthMcDowellBlvd.,Petaluma,CA994954|Xantech.com
InstallationInstructions,EN85K©2014CoreBrands,LLC
Document #08905311A
This document is copyright protected. No part of this manual may be copied or
reproducedinanyformwithoutpriorwrittenconsentfromXantechCorporation.
XantechCorporationshallnotbeliableforoperational,technical,oreditorial
errors/omissions made in this document.
