Redmi Buds 3
User Manual

Product Overview
Illustrations of product, accessories, and user interface in the user manual
are for reference purposes only. The actual product and functions may
vary due to product enhancements.
Wearing
Gently place the earbud into your ear canal, then adjust it to a
comfortable position.
During calls, make sure to point the primary microphone towards
your mouth for clearer calls.
EarbudsCharging Case
Charging
Indicator
Charging
Case Buon
Charging
Port Charging
Contact Points
Secondary
Microphone
Primary
Microphone
Multi-function
Touch Area
Read this manual carefully before use, and retain it for future reference.
01

Charging
Turning On
When the buds are in the charging case, open the lid to
automatically turn them on.
When puing the earbuds into the charging case while they are
turned o, the earbuds will be automatically turned on.
Before use, please remove the protective film from the contact points
on both earbuds and fully charge the charging case and the buds.
Connect the charging cable to the charging case and keep the
earbuds inside the case to charge simultaneously.
When the charging case is not fully charged, its indicator is white.
When it is fully charged, its indicator is o.
02
Protective Film

Connection
First time connection
Both earbuds will enter the awaiting connection mode when the charging
case's lid is opened. Aer enabling the phone's Bluetooth, search for
and tap 'Redmi Buds 3' to connect the earbuds to the phone.
Reset Earbuds
If the earbuds cannot connect properly, please follow the below
steps to reset them.
Open the lid of the charging case and place both earbuds in the case.
Press and hold the charging case buon for 10 seconds, and the
charging case's indicator will blink white for 3 seconds and turn o,
indicating the earbuds have been reset successfully (the connection
records between the le and right earbuds, and the earbuds and the
phone have been cleared).
Note: If the earbuds cannot be connected, place them back into the
charging case, close the lid and repeat the above operation.
03
Press and hold for 10 seconds

Function Overview
Answer/End calls
Double tap the le/right earbud's multi-function touch area to answer
a call; and tap the le/right earbud's multi-function touch area three
times to decline or hang up the call.
Play/Pause Music
Method 1: Remove the earbuds to pause the music and wear the earbuds
to start playing the music.*
Method 2: Press and hold the le/right earbud's multi-function
touch area to pause/play the audio.
Play next track/previous track
When playing audio, double tap the earbud's multi-function touch
area to play the next track; and then tap the earbud's multi-function
touch area three times to play the previous track.
Answer a Second Call
Double tap the le/right earbud's multi-function touch area to put
the ongoing call on hold and answer the incoming call, and tap the
le/right earbud's multi-function touch area three times to hang up
the current call and answer the call on hold.
* Aer manually pausing the music, the music will not play automatically when you
remove and wear the earbuds again.
04
Multi-function Touch Area

Switch between single/dual bud mode
When both buds are connected successfully, they are in dual-bud
mode. If place one of the buds back into the charging case and close
its lid, the other bud will automatically enter the single-bud mode.
When removing the second bud from the charging case, the
dual-bud mode will automatically be restored again.
When the earbuds are in the charging case, opening the lid of the charging
case will automatically connect the earbuds to the most recently used
Bluetooth device. If the earbuds are not connected to any device, they
will automatically enter the awaiting connection state.
Automatic connection
Fast Pairing
Place the earbuds into the charging case and close its lid. Make
the sure the Mi/Redmi phone's Bluetooth is enabled and hold it
close to the charging case, then open the case's lid and follow the
on-screen instructions to connect the phone to the earbuds.
Note: To use the feature to quickly connect, please update your
Mi/Redmi phone to the latest stable version. Then open Additional
seings in your phone's Bluetooth seings to enable Pair compatible
devices. This feature is currently only supported by some Mi/Redmi
phones.
05

The built-in optical sensor can detect the earbud's wearing state in
real-time, it can detect when the earbud is in the ear. For example, if
the device the earbuds are connected to is paused, wearing the earbuds
will start the music, and removing the earbuds will pause the music.
Wearing detection
Note: Once the weather is cold outdoors and your hands become dry,
the buds may not function when touching them.
06

Specifications
Name: Wireless Earphones
Model: M2104E1
Frequency Band: 2402–2480 MHz
Max RF Output Power: < 20 mW
Earbuds
Dimensions: 40.7 × 16.9 × 18.7 mm
Net Weight (per earbud): Approx. 4.47 g
Wireless Range: 10 m (in an obstacle-free environment)
Cell Capacity (per earbud): 35 mAh
Input: 5 V
= 70 mA
Cell Type: Lithium-ion polymer cell
Wireless Connectivity: Bluetooth 5.2
Charging Case
Model: M2104E1
Dimensions: 49.6 × 49.6 × 24.5 mm
Baery Capacity: 310 mAh
Input: 5 V
= 500 mA
Output: 5 V
= 150 mA
Baery Type: Lithium-ion polymer baery
Storage Temperature: 0 °C to 45 °C
Operating Temperature: 5 °C to 40 °C
Service Life: 1 year
07

Important Safety Information
Do not aempt to disassemble, repair or modify the product, as this
may cause fire or even completely damage the product.
Keep the product's indicator away from the eyes of children and
animals while the product is in use.
Do not use this product during thunderstorms. Thunderstorms may
cause the product to malfunction and increase the risk of electric
shocks.
Do not disassemble, puncture or crush the product nor expose it to
fire.
Please stop using the product immediately and seek medical assistance
if the contact area on your skin shows signs of redness or swelling.
To prevent possible hearing loss, do not use high volume for
long periods of time.
This product is not a toy and may contain small parts. Please keep
them out of the reach of children.
Disposal of a baery into fire or a hot oven or water or other liquids
or mechanically crushing or cuing of a baery, that can result in an
explosion.
Leaving a baery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
flammable liquid or gas.
A baery subjected to extremely low air pressure that may result
in an explosion or the leakage of flammable liquid or gas.
Product information and certification marks are located in the Charging
Case.
Do not put the baery in trash that is disposed of in landfills. When
disposing of the baery, comply with local laws or regulations.
Replacement of a baery with an incorrect type that can defeat a
safeguard (such as catching fire, explosion, leakage of corrosive
electrolyte etc).
= The symbol indicates DC voltage.
This device is equipped with a built-in baery that can not be removed
or replaced. Do not disassemble or modify the baery by yourself.
Only use certified chargers supplied by qualified manufacturers.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
08

Hereby, Dongguan Yingsheng Electronic Technology Co., Ltd.
declares that the radio equipment type M2104E1 is in compliance
with Radio Equipment Regulations 2017. The full text of the UKCA
declaration of conformity is available at the following internet
address: hps://www.mi.com/uk/service/support/declaration.html
EU DECLARATION OF CONFORMITY
Hereby, Dongguan Yingsheng Electronic Technology Co., Ltd.
declares that the radio equipment type M2104E1 is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address:
hp://www.mi.com/global/service/support/declaration.html
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU) which should
not be mixed with unsorted household waste. Instead, you should
protect human health and the environment by handing over your
waste equipment to a designated collection point for the recycling of
waste electrical and electronic equipment, appointed by the
government or local authorities. Correct disposal and recycling will
help prevent potential negative consequences to the environment
and human health. Please contact the installer or local authorities for
more information about the location as well as terms and conditions
of such collection points.
WEEE Information
09

Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Dongguan Yingsheng Electronic Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Suite 204, 4th Block, No. 86 Hongtu Road, Nancheng
District,Dongguan, Guangdong, China.
For further information, please go to www.mi.com
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz
User Manual Version: V1.0
Complles With
IMDA Standards
DB106135
75323/SDPPI/2021
9003
10
CIDF15000056
