Xcruiser XS9900D User manual

XS9900D
© COPYRIGHT 2011 XCRUISER CORPORATION KOREA
- Please read this manual carefully before using
your Satellite Finder for the first time.
- The technical specifications and operating
methods included in this manual are subject to
changes without notice. In case of any inquires
after a period of usage, please contact the
manufacturer.
- Please charge the battery before using your
meter for the first time. (Recommend 5 hours)

XS9900D

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 4
Table of Contents
Description ...................................................................................................... 6
Safety instructions .......................................................................................... 7
Safety of persons .............................................................................................. 7
General information .......................................................................................... 8
Appropriate Usage .......................................................................................... 9
Delivery range ................................................................................................. 9
Device overview ............................................................................................ 10
Start of operation .......................................................................................... 13
Battery ............................................................................................................. 13
Switch-on the Device ...................................................................................... 13
Lithium-ions-battery ..................................................................................... 14
Charging the battery ....................................................................................... 14
Storing of the batteries .................................................................................... 15
System setting .............................................................................................. 15
Timer ............................................................................................................... 17
Delete channels .............................................................................................. 17
Factory reset ................................................................................................... 17
Software Version ............................................................................................. 17

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 5
Factory reset ................................................................................................. 19
Satellite finding ............................................................................................. 21
Finding channels manual ................................................................................ 21
Lining satellite aerial up .................................................................................. 22
Satellite setting ............................................................................................. 24
Automatic search .......................................................................................... 30
Angle calculation .......................................................................................... 32
Spectrum Analyzer ....................................................................................... 36
Adjustment ...................................................................................................... 36
Disposal ......................................................................................................... 36
Technical specifications .............................................................................. 41
Warrenty ........................................................................................................ 43
Declaration of conformity ........................................................................... 43

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 6
Description
The Satellite Meter is a handy digital antenna measuring device for a quick and easy alignment of satellite antennas. If
a satellite is found, the meter shows it on the display and emits a audible signal. Signal strength and quality are
displayed as numerical values and bar graphs. Another measurement value is the forward error correction (FEC) and
the bit error rate (BER). In addition, the picture quality can be revised on the high-resolution 3.5-inch TFT LCD screen.
Many satellites are pre-programmed in order to a quick antenna adjustment.
The scope of supply contains, among the charger, a USB cable which allows you to update software.
A carrying case serves as protection and for the transport. It cares for better readability of the display at sunshine.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 7
Safety instructions
Attention!
Please read the safety instructions carefully before operating the device.
Please follow all warnings and instructions on the equipment and in the operating manual.
Safety of persons
Ensure that nobody can be hurt by falling tools or parts of the satellite antenna during the adjustment and installation
of the antenna. For your own security use a rope on sloping roofs.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 8
General information
Attention!
The devise should only be operated with the supplied AC adapter at the mains.
Do not open the meter or the included AC adapter. There is danger of life through electric shock!
Wrong usage of the ports can lead to the destruction of the measuring device.
Proceed carefully with the measuring device:
• Avoid low temperature (below 0 °C) or to high humidity.
• The TFT display can be damaged by mechanical impacts.
• Avoid excessive input voltages. Please refer to the technical data starting from page 35.
Do not operate with the device:
• if it has visible damage,
• if there are loose parts in the device,
• if the device was located outdoors or in damp rooms a extended period of time.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 9
Appropriate Usage
The measuring device meter was developed to measure signals of digital satellite antennas and satellite systems. It is
exclusively for this purpose and should only be used for this purpose. Use the equipment only for the purpose, which
is described in this manual.
Follow all information in this manual, particularly the safety instructions on page 5.
Any other usage is rated as not properly and can result in damage or even injury.
There will be no liability for damages caused by a non-intended use.
Delivery range
Please check if the delivery is complete.
Included in delivery:
• device meter,
• a carrying bag with sunshade,
• a PC connection cable with RS-232- and USB plug (Type A),
• a car adapter cable 12 V,
• an extern charger,
• a power cable.
• an user manual,
• an AV in/out cable
• a CD-ROM including the Software
If the above packing list was incomplete, contact your specialist dealer.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 10
Device overview
Figure 1 : Front of the meter

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 11
No Description
1 LNB-IN Digital satellite signal input
3 LC-Display Display of the TV picture, the menu and the measured values
18 POWER-LED Display of the energy state:
Operation:
red: the measuring devise is switched on.
Off: the measuring devise is switched off.
In charge:
Green: The battery is charged
Red: The battery is full charged
19 LOCK-LED LED lights when a signal is received.
4 FUNCTION keys F1: toggle the Display
F2: Mute
F3: Additional information about the current program
F4: switch between radio/TV mode
5 22K/13V/18V-LEDs Lights if 22K/13V/18V signals are received
6
Navigation-cross
OK - button
Navigation through menus, switching programs ▲, ▼volume control ◄, ►
OK button: confirmation of a selection
11 Numeric keys Direct enter of numbers
7 FIND-button FIND menu: for a quick and easy alignment of a satellite antenna
12 Menu-button Display the main menu
17 EXIT-button Leave the current menu, cancel operation
8 ANGLE-button Display the calculation menu
10 SYSTEM-button Configuration of all system parameter.
Display current software version.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 12
16 POWER-button Switch devise on/off
13 SCAN-button Display the auto scan menu
21 AC adapter port Low volt port – for power supply connection
20 USB-Port USB port for PC connection
9 SPTRUM button Display the menu of spectrum
14 AV button Press for AV in and out
2 AV port AV input / output
15 SAT button Press for the satellist
22 Speaker Sound

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 13
Start of operation
Battery
Before the first operation with the measuring device charge the battery completely. (see also chapter “Lithium-Ion battery”
on page 11).
Load the accumulator during the first loading procedure at least 5 hours.
The maximum battery charging time is approximately 12 hours.
Switch-on the Device
� Press 2 seconds the red power button on the meter.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 14
Lithium-ions-battery
Explosion danger!
Never the two poles (+ and -) connect with each other!
Attention!
Storing or operating accumulator no more than 40°C.
Not burning or damaging accumulator.
Not taking accumulator to contact with water.
Charging the battery
The maximum battery charging time is approximately 12 hours.
A charging circuit in the measuring device provides an optimal charge of the battery. The device is charged if it is switched
off.
� Turn the device off, if it is not already off.
� Connect the Euro-main cable with the external AC adapter.
� Connect the external AC adapter to the power grid.
� Connect the AC adapter to the low-voltage port at the bottom.
� The battery is charged as soon as you connect the AC adapter to the meter

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 15
The Power-LED shows the battery status:
• Green: the battery is charged.
• Red: the battery is completely loaded.
Storing of the batteries
Storing the batteries between 0° Celsius and 40° Celsius.
Loading the accumulator at a longer storage every two weeks to avoid a depth discharge.
System setting
� Press the MENU button.
� Select the point system setting.
� Confirm your selection using the OK button.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 16
Figure 2: System setting
Menu language setting
Press the SYSTEM button to change the menu language.
� Select the point Language select.
� Choose your desired language using the ◄- or ►- button.
� After your selection press the EXIT button and follow the instructions on.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 17
Timer
Through this setting you can select the satellite meter LCD shut off time.
� Press the SYSTEM button.
� Press the ◄- or ►- button to set the timer.
� At least press the EXIT button and follow the instructions on the display.
Delete channels
You can delete single channels from your channel list in this menu.
� Press the SYSTEM button to retriever the menu system settings.
� Select the menu item delete channels
� Select the channels you would like to delete. Press respectively the OK button. Next to channels you would like to
delete should appear an “x”.
Press the key EXIT and obey to the instruction on the display.
Factory reset
This menu item is described on page 15.
Software Version
 Press the SYSTEM button.
 At software version you can read the topical software state of the Satellite meter.
 How to update the software is described on page 26.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 18
Note!
In the support area at http://www.xcruiser.net, you have got the option to download the topical software.

XS9900D
XS9900D Xcruiser Satellite-Meter ENG- 19
Factory reset
Figure 3: Factory reset
In this menu item, you could put your equipment back to the delivery status.
� Press the SYSTEM button to display the System setting menu.
� Select the point factory reset.
� Note the instructions on the display and confirm your selection with the OK button or cancel it using the EXIT button.
�
