XEROX 6030 / 6050
Wide Format Copier/Printer
Version 3.3.06 Release Notes
December, 2005

Table of Contents
1Trademark Acknowledgements 3
2Release Content 4
3Updates in this release 5
3.1 New Release Features 5
3.2 Customer Issues Resolved 5
3.2.1 GDI Driver Support for 30 x 42 5
3.2.2 AutoCAD Wipeouts 5
4Installation 6
4.1 Embedded Controller firmware 6
4.2 Printer firmware 6
4.3 Windows Driver Installation 6
5Finishing Operation 7
5.1 Supported Folder Models 7
5.2 Limitations 7
5.2.1 GFI Compliance 7
5.2.2 Automatic Title Block Placement 7
6Known Issues 8
2 Xerox 6030/50 V3.3.06 Customer Release Notes

1 Trademark Acknowledgements
XEROX®, The Document Company, and the identifying product names and numbers herein are
trademarks of XEROX CORPORATION. All other product names mentioned herein are
trademarks of their respective companies. All rights reserved.
Windows, Windows® 2000, Windows® XP Pro are registered trademarks of Microsoft
Corporation.
AutoCAD is a registered trademark of AutoDesk, Inc.
HDI is an acronym for Heidi Device Interface. Heidi is a registered trademark of AutoDesk, Inc.
WinZip is a registered trademark of Nico Mak Computing, Inc.
Xerox 6030/50 V3.3.06 Customer Release Notes 3

2 Release Content
The following components are new in this release:
•Xerox 6030/50 embedded controller version 3.3.06
•Xerox 6030/50 printer firmware version 3.2.04
•Windows 2000/XP GDI driver v3.1.1 (English, French, Italian, German, Spanish and
Portuguese)
The following components remain unchanged in this release:
•BT-PlotAssistant version 3.3.01(English, French, Italian, German, Spanish and
Portuguese)
•TWAIN version 3.2.02 (English, French, Italian, German, Spanish and Portuguese)
•Windows 98 GDI driver with TCP/IP Direct Print Utility v3.1.0 (English and Portuguese)
and v3.0.0 (French, Italian, German, and Spanish)
•ADI driver for R14 v3.1.0 (English and Portuguese)
•ADI driver for R14 v3.0.0 (French, Italian, German and Spanish)
•HDI drivers for AutoCAD 2000, 2000i, 2002 and 2004 v3.1.0 (English and Portuguese)
•HDI drivers for AutoCAD 2000, 2000i, 2002 and 2004 v3.0.0 (French, Italian, German
and Spanish)
4 Xerox 6030/50 V3.3.06 Customer Release Notes

3 Updates in this release
3.1 New Release Features
This release includes the following new features:
•Support for both inches and millimeters on the copier user interface
•Improved messages on the printer user interface for “out of media” conditions
•Pass through of Xerox Generic Finishing Interface (GFI) title block information from an
external controller such as Accxes.
3.2 Customer Issues Resolved
3.2.1 GDI Driver Support for 30 x 42
The GDI print driver for Windows 2000 and Windows XP now supports 30 x 42 in all languages.
3.2.2 AutoCAD Wipeouts
The GDI print driver for Windows 2000 and Windows XP implement correct behavior for
AutoCAD 2004, 2005 and 2006 in which plots using a rotated textmask with the wipeout style are
printed with a large white rectangle behind the text. (Software Problem Action Request
#868400220)
Xerox 6030/50 V3.3.06 Customer Release Notes 5

4 Installation
4.1 Embedded Controller firmware
This SW can only be installed by a service technician.
On Copier / Printer models, the Copier UI text must be downloaded by the service technician as
well.
User list, extension list, and Web Administrator password will be returned to factory default state
as a result of this upgrade.
4.2 Printer firmware
This SW can only be installed by a service technician.
To enable 30 inch size detection, the technician must change NVM setting 20-022 to a value of 1.
If a finisher is attached, the technician must change NVM setting 20-003 to a value of 2.
4.3 Windows Driver Installation
For Windows 2000 and XP, please refer to chapter 1 of the Xerox 6030/6050 Wide Format
Windows Driver User Guide for detailed installation instructions. These instructions are on the
documentation CD that arrived with the product or available on www.Xerox.com under Support &
Drivers.
For Windows 98, updated installation instructions for the driver and TCP/IP Direct Print Utility are
in the Readme.txt file included with the software.
6 Xerox 6030/50 V3.3.06 Customer Release Notes

5 Finishing Operation
5.1 Supported Folder Models
As of the writing of this document, the 6030/50 operates with the following folders which
implement the Xerox Generic Finishing Interface (GFI):
•Tameran PrintFold 2510
•Gera Mondial B2
5.2 Limitations
5.2.1 GFI Compliance
The 6030 and 6050 Printers do not yet fully comply with the Xerox GFI specification. As a result,
some system features, such as Automatic Title Block Placement are not supported. The user
must manually locate the title block for proper fold orientation.
For a more complete folding solution, a configuration using the Accxes controller, a 6050 Printer,
and one of the supported folders listed in the previous section is suggested.
5.2.2 Automatic Title Block Placement
Enhanced Automatic Title Block Placement is available in AccXES controller equipped 6030 and
6050 configurations. However, some C-size and A2-size folds are still not supported due to a
lack of rotation support by the 6030/6050 embedded controller.
For a more complete folding solution, a configuration using the Accxes controller, a 6050 Printer,
and one of the supported folders listed in the previous section is suggested.
Xerox 6030/50 V3.3.06 Customer Release Notes 7

6 Known Issues
Paper sizes as viewed in the Web Administrator’s Tool:
30 x 42 printing has been implemented by re-defining JIS-B series in the America’s to support
this paper size. The artifact of doing this is there are sizes of 3F to 3A now listed in the Web
Administrator’s Tool. 3E, the long length, and user defined length of this size (3EL and U3E) are
the only sizes that are really relevant. The others should be ignored.
Canceling jobs takes a long time:
When canceling a job, every sheet in the job is an entity in the queue and is canceled individually.
The canceling operation works a little smoother if the printer is taken off-line first by pressing the
[Menu] button before the [Job Cancel] button is pressed.
