Xerox D1015 User manual

Xerox Disc Duplicator
User Guide
Disc Duplicator
User Guide
Version x.10

Xerox Duplicator 3
Table of Contents
Safety Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Notices and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Marks, Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FCC Notices For The USA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operational Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operational Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Disconnect Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Emergency Power Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maintenance Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Safety Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Certifications in Europe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Product Recycling & Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
USA & Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
European Union . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Xerox EH&S Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operation 12
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Controls and Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
LCD Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Tutorial Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Making Disc-to-Disc Copies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Making Hard Drive-to-Disc Copies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Loading a CD-ROM/DVD Master onto the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . 23
Loading a Master Disc Image from the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . 27
How to make a Copy from the Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
How to Select the Duplication Speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
How to Rename a Hard Drive Partition Name from the Front Panel . . . . . . . . . . . . . . . 37
How to Rename a Hard Drive Partition Name from the Computer. . . . . . . . . . . . . . . . . 39
How to Delete an Existing Hard Drive Partition Permanently . . . . . . . . . . . . . . . . . . . . . . 40
How to Change the Setup Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Audio CD Editing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Introduction to the Account Management Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Account Management Feature Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Using Autocopy. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Setup Guide 56
Menu Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Troubleshooting 61
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Software Installation Guide for Accessing the Hard Drive on a Computer 66
Minimum Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Operating System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Installing the File System Driver and Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Using the File System Utility: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Accessing the Hard Drive on the Duplicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Creating an ISO DVD/CD Image file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Xerox Duplicator 4
Safety Introduction
Notices and Safety
Please read the following instructions carefully before operating the ma-
chine and refer to them as needed to ensure the continued safe operation
of your machine.
Your Xerox product and supplies have been designed and tested to meet
strict safety requirements. These include safety agency evaluation and cer-
tification, and compliance with electromagnetic regulations and estab-
lished environmental standards.
The safety and environment testing and performance of this product have
been verified using Xerox materials only.
WARNING: Unauthorized alterations, which may
include the addition of new functions or connection
of external devices, may impact the product certifi-
cation.
Please contact your Xerox representative for more information.
Marks, Labels
Symbols
All warnings and instructions marked on or supplied with the product
should be followed.
WARNING: This symbol alerts users to areas of
the equipment where there is the possibility of per-
sonal injury.

5 Xerox Duplicator
FCC Notices For The USA
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a partic-
ular installation. If this equipment does cause harmful interference to ra-
dio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
■Consult the dealer or an experienced radio/TV technician for help.
(Reference CFR 47 Part 15 Section 15.21)
Changes or modifications to this equipment not specifically approved by
the Xerox Corporation may void the user’s authority to operate this equip-
ment.

Xerox Duplicator 6
Operational Safety Information
Operational Safety Information
Your Xerox equipment and supplies have been designed and tested to
meet strict safety requirements. These include safety agency examination,
approval, and compliance with established environmental standards.
To ensure the continued safe operation of your Xerox equipment, follow
these safety guidelines at all times:
Do These
■Always follow all warnings and instructions that are marked on or
supplied with the equipment.
■Before cleaning this product, unplug the product from the electrical
outlet. Always use materials specifically designated for this product,
the use of other materials may result in poor performance and cre-
ate a hazardous situation.
WARNING: Do not use aerosol cleaners. Aerosol
cleaners can be explosive or flammable when used
on electromechanical equipment
■Always exercise care when moving or relocating equipment.
■Always locate the machine on a solid support surface (not on plush
carpet) that has adequate strength to support the weight of the ma-
chine.
■Always unplug this equipment from the electrical outlet before
cleaning.
Do Not Do These
■Never use a ground adapter plug to connect the equipment to a
power outlet that lacks a ground connection terminal.
■Never attempt any maintenance function that is not specifically de-
scribed in this documentation.
■Never obstruct ventilation openings. They are provided to prevent
overheating.
■Never remove covers or guards that are fastened with screws. There
are no operator serviceable areas within these covers.
■Never locate the machine near a radiator or any other heat source.
■Never push objects of any kind into the ventilation openings.
■Never place this equipment where people might step on or trip on
the power cord.

7 Xerox Duplicator
Electrical Safety Information
1. The power receptacle for the machine must meet the requirements stat-
ed on the data plate on the rear of the machine. If you are not sure that
your electrical supply meets the requirements, please consult your local
power company or an electrician for advice.
2. The socket outlet shall be installed near the equipment and shall be eas-
ily accessible.
3. Use the power cable that is supplied with your machine. Do not use an
extension cord or remove or modify the power cord plug.
4. Plug the power cable directly into a correctly grounded electrical outlet.
If you are not sure whether or not an outlet is correctly grounded, consult
an electrician.
5. Do not use an adapter to connect any Xerox equipment to an electrical
outlet that lacks a ground connection terminal.
6. Do not place this equipment where people might step or trip on the
power cable.
7. Do not place objects on the power cable.
8. Do not push objects into slots or openings on the machine. Electrical
shock or fire may result.
9. Do not obstruct ventilation openings. These openings are used to pro-
vide proper cooling to the Xerox machine.
Electrical Supply
1. This product shall be operated from the type of electrical supply indict-
ed on the product’s data plate label. If you are not sure that your electrical
supply meets the requirements, please consult a licensed electrician for ad-
vice.
WARNING: This equipment must be connected to
a protective earth circuit. This equipment is supplied
with a plug that has a protective earth pin. This plug
will only fit into an earthed electrical outlet. This is a
safety feature. If you are unable to insert the plug into the out-
let, contact a licensed electrician to replace the outlet.
2. Always connect equipment to a correctly grounded power outlet. If in
doubt, have the outlet checked by a qualified electrician.

Xerox Duplicator 8
Disconnect Device
The power cable is the disconnect device for this equipment. It is attached
to the back of the machine as a plug-in device. To remove all electrical pow-
er from the equipment, disconnect the power cable from the electrical out-
let.
Emergency Power Off
If any of the following conditions occur, turn off the machine immediately
and disconnect the power cable(s) from the electrical outlet(s). Contact
an authorized Xerox Service Representative to correct the problem:
■The equipment emits unusual odors or makes unusual noises.
■The power cable is damaged or frayed.
■A wall panel circuit breaker, fuse, or other safety device has been
tripped.
■Liquid is spilled into the machine.
■The machine is exposed to water.
■Any part of the machine is damaged
Maintenance Information
■Any operator product maintenance procedures will be described in
the user documentation supplied with the product.
■Do not carry out any maintenance on this product which is not de-
scribed in the customer documentation
Warning: Do not use aerosol cleaners. Aerosol
cleaners can be explosive or flammable when used
on electromechanical equipment.
■Use supplies and cleaning materials only as directed in the Operator
section of this manual.
■Do not remove covers or guards that are fastened with screws. There
are no parts behind these covers that you can maintain or service.

9 Xerox Duplicator
Product Safety Certification
This product is certified by the following Agency using the Safety
standards listed
Regulatory Information
Certifications in Europe
CE Mark (European Union)
The CE mark applied to this equipment symbolizes Xerox’s declaration of
conformity with the following applicable Directives of the European Union
as of the dates indicated:
2006/95/EC
December 12, 2006 Council Directive 2006/95/EC as amended. Approxi-
mation of the laws of the member states related to low voltage equip-
ment.
2004/108/EC
December 15, 2004 Council Directive 2004/108/EC as amended. Approx-
imation of the laws of the member states related to electromagnetic com-
patibility.
A full declaration of conformity, defining the relevant directives and refer-
enced standards, can be obtained from your Authorized local dealer.
Warning: In order to allow this equipment to oper-
ate in proximity to Industrial Scientific and Medical
(ISM) equipment, the external radiation from the
ISM equipment may have to be limited or special
mitigation measures taken.
Agency Standard
Underwriters Laboratories Inc. UL60950-1
Underwriters Laboratories Inc. CSA C22.2 No. 60950-1-03
SPORTON International Inc. EN 55022:1998/A1:2000/A2:2003 Class B,
EN 61000-3-3:1995/A1:2001,
EN 55024:1998/A1:2001/A2:2003

Xerox Duplicator 10
Product Recycling & Disposal
USA & Canada
Xerox operates a worldwide equipment take back and reuse/recycle pro-
gram. Contact your Xerox sales representative (1-800-ASK-XEROX) to de-
termine whether this Xerox product is part of the program. For more
information about Xerox environmental programs, visit www.xerox.com/
environment.html.
If you are managing the disposal of your Xerox product, please note that
the product may contain lead, mercury, Perchlorate, and other materials
whose disposal may be regulated due to environmental considerations.
The presence of these materials is fully consistent with global regulations
applicable at the time that the product was placed on the market. For re-
cycling and disposal information, contact your local authorities. In the
United States, you may also refer to the Electronic Industries Alliance web
site: http://www.eiae.org/.
European Union
WEEE Directive 2002/96/EC
Some equipment may be used in both a domestic/household and a profes-
sional/business application
Professional/Business Environment
Application of this symbol on your equipment is confir-
mation that you must
dispose of this equipment in compliance with agreed na-
tional procedures. In accordance with European legislation, end of life
electrical and electronic equipment subject to disposal must be managed
within agreed procedures.
Domestic/Household Environment
Application of this symbol on your equipment is confir-
mation that you should not dispose of the equipment in
the normal household waste stream. In accordance with
European legislation, end of life electrical and electronic equipment sub-
ject to disposal must be segregated from household waste.
Private households within EU member states may return used electrical
and electronic equipment to designated collection facilities free of charge.
Please contact your local disposal authority for information.

11 Xerox Duplicator
In some member states, when you purchase new equipment, your local re-
tailer may be required to take back your old equipment free of charge.
Please ask you retailer for information.
Prior to disposal, please contact your local dealer or Xerox representative
for end of life takeback information.
Xerox EH&S Contact Information
Contact Information
For more information on Environment, Health, and Safety in relation to
this Xerox product and supplies, please contact the following customer
help lines:
USA: 1-800 828-6571
Canada: 1-800 828-6571
Europe: [phone]
www.xerox.com/about-xerox/environment/enus.html
(Product Safety information for US)
www.xerox.com/about-xerox/environment/eneu.html
(Product Safety information for EU)

Xerox Duplicator 12
Chapter 1: Operation
The Xerox CD/DVD Duplicator is a reliable, high performance, high speed,
standalone manual tower duplicator. With its professional industrial de-
sign and simple beginner user interface, it will make your duplicating expe-
rience easier than ever.
Before You Start
Before using this duplicator, read the following to ensure proper operation:
■Duplicator Limitations
The duplicator will not copy any CD or DVD discs that have Copy Pro-
tection encoded inside. Typically, the movies you purchase or rent
from the store will contain copy protection.
In addition to the copy protection limitations, the duplicator cannot
copy across formats. This means that you cannot copy a DVD master
onto a recordable CD. In addition, you cannot copy the same for-
mats if the discs have different maximum capacity limitations. This
means that you cannot copy a single-layer DVD disc onto a double/
dual-layer disc or vice versa. The recordable blanks must be the same
format and maximum capacity as the master disc you intend to du-
plicate.
■Temperature Warning
If the duplicator was stored in a location where the temperature
dropped below 32°F (0°C) within the past 24 hours, please leave the
duplicator in a warm room with temperatures at least 65°F (19°C) for
four hours prior to powering it on for the first time. Failure to do so
may cause irreparable harm and prevent the duplicator from func-
tioning.
■Maintenance
It is very important to operate and keep the duplicator in a dust free,
clean environment since dust is the number 1 killer for CD/DVD re-
cording devices. Failure to do so may severely damage your duplica-
tor. We strongly suggest you place an Air Cleaner next to the
duplicator and constantly use the Air Duster (Can Air) to clear off any
dust on the surface of the duplicator.
Note: Do not try to use the air duster to clean the duplicator
while the reader or writer trays are open. In doing so, you may
inadvertently blow dust into the recording device and damage
the recording device.

13 Xerox Duplicator
■Proper Shutdown
To avoid possible system failures, you need to shutdown the duplica-
tor properly. To shutdown the duplicator, you need to press the up or
down button to select “16. Shutdown”, then press the >>Ent key.
Then follow the instructions on the screen to shutdown the duplica-
tor properly. Turning off your duplicator without performing this
function will increase the risk of damaging your duplicator.
Notice:
While specific drive manufacturers, sizes, and part numbers are shown in
this manual, the market place for drives is constantly changing. We install
the best drives that are available at the time of manufacture, so the actual
drives in your system may be different than the ones shown in this manual.
This also applies to the hard disk and the drive speed options. The hard disk
size shown reflects the size of the disk actually installed in your duplicator.
The drive speed options shown reflect the capabilities of the drives in-
stalled in your duplicator. Please take this into consideration when using
this manual.
Notice:
If you purchased a Xerox Duplicator with Blu-ray drives, the operation in-
structions for your unit will mirror those contained in this user manual for
the CD and DVD duplication procedures.

Xerox Duplicator 14
Controls and Display
Figure 1-1 shows the controls and display found on the Xerox Duplicator.
Actual size will vary based upon the model you purchase.
Figure 1-1 CD/DVD Duplicator Controls and Display
The components shown in Figure 1-1 are:
1. Power Button
2. CD/DVD Writers
3. CD/DVD Reader
4. Eject Button
5. Keypad
6. LCD Screen
7. Rear Power Switch
8. Ventilation Fans
9. Power Supply Fan
10. USB Connection
11. Duplicator Ventilation Vents
12. Stability Feet (not available on all models)
10
12
11
1
2
5
6
3
7
9
8
4

15 Xerox Duplicator
LCD Front Panel
Figure 1-2 shows the front panel for the duplicator.
Figure 1-2 Front Panel
Table 1-1 Front Panel Controls
Control Name Function
Up Scroll up through the menu or list.
Down Scroll down through the menu or list.
Enter Execute the function. Also called OK in the Menus.
ESC Go back to the previous function
Copy
Shortcut key to make a copy.
Pressing the shortcut key takes you to the Autocopy
menu and automatically performs the Copy action.
Test
Shortcut key to make a simulation of the copy process.
Pressing the shortcut key takes you to the Test menu
and automatically performs the Test action.
Speed
Shortcut key to change the duplication speed.
Pressing the shortcut key takes you to the Speed
menu and allows you to select the Burn Speed.
Source
Shortcut key to change the master Reading Source.
Pressing the shortcut key takes you directly to the
Reading Source menu

Xerox Duplicator 16
Tutorial Guide
Making Disc-to-Disc Copies
This process will copy your master disc on to several blank discs simulta-
neously. Due to its simultaneous nature, a good condition master disc and
lower recording speed is recommended for high success rates and good
quality duplications.
For a disc-to-disc copy, the Copy Source can be either of these devices:
■The Reader Drive: The Reader Drive is the source that is typically
used when making disc-to-disc copies.
■Any of the Writer Drives: One of the Writer Drives can also be used
as the copy source when making disc-to-disc copies. This option is
typically only used when the reader drive is either bad or unable to
read the disc master.
Selecting the Copy Source
When you turn on your duplicator, after it has booted up, you should see
the following signifying your duplicator is ready.
Step 1: Use the up or down arrow buttons to navigate to the Select
Source screen.
Step 2: Press >> to enter the Select Source menu and you should see a
screen similar to this:
Step 3: If you plan to use the Reader Drive as the source, use the up or
down buttons to locate Drive 0 and press >> to select it.
If you would like to use one of the Writer Drives as the source, use the up
or down buttons to locate Drive 1 and press >> to select it:
XEROX 2.14
1.Copy
XEROX 2.14
8.Select Source
Drive 0 Port 1.0
ASUS DVD-E616A3

17 Xerox Duplicator
Making Copies from the Source
Step 1: Start the Copy Process
Use the up or down arrow button to navigate to the Copy screen.
Step 2: Press the >> button to enter the Copy menu. You should then
see the Counter Selection menu.
The Counter Selection menu will let you choose how many copies you want
to make for your project. This Counter Selection feature allows the duplica-
tor to count the number of copies you’ve made and prompt you when the
desired number of copies has been made.
Note: The Counter feature is for your convenience only, and will
allow you to make more copies than the number set, if so re-
quired.
You can select “No Counter” if you prefer to copy continuously with no in-
terruption. (It will still count the number of copies, but it will not notify you
when to stop.) To select No Counter, simply press the >> button when you
see the screen above.
Or, you can select “Specify Counter” between 1 to 9999 by pressing the up
or down navigation button to the following screen.
Step 3: Then press the >> button to submit, and you should then see
the following screen.
Drive 1 Port 2.0
Pioneer DVD-RW DVR
XEROX 2.14
1.Copy
Counter:
No Counter
Counter:
Specify Counter
Specify Counter:
[0] OK?

Xerox Duplicator 18
To specify the number of copies for your project, you need to enter/input a
four-digit number. If you are planning to specify a number that is less than
four digits, please fill the leading spaces with 0s (any leading zero will be
skipped). An example of that 4-digit number could be 0234 (Two hundred
and thirty four), or 0010 (ten). Remember, the beginning zeros are skipped,
therefore, “0010” means ten, which is the number ten.
To enter the number, you need to use the up or down button to select the
number for each digit and use >> or << button to move the cursor position
right or left, once you’ve finished, move the cursor to OK and press >>. For
example, if you want to specify a counter value of 21, the four-digit value
would be 0021. To input the desired quantity, do the following, making
sure the cursor is located at the first position.
Press the down button repeatedly until 0 is displayed.
Press the >> button once to move the cursor to the next position.
Press the down button repeatedly until 0 is displayed.
Press the >> button once to move the cursor to the next position.
Press the down button repeatedly until 2 is displayed.
Press the >> button once to move the cursor to the next position.
Press the down button repeatedly until 1 is displayed.
Now, 0021 is displayed, press >> once and the cursor moves to OK. Then,
press >> once to submit your counter value, and you should see the follow-
ing screen.
or
Note: If either one of the above two screens is displayed for
more than two minutes, check your master disc or blank discs
for quality.
Specify Counter:
[X] OK?
Preparing
Waiting for Master
Preparing
Waiting for Blanks

19 Xerox Duplicator
Allow 5 to 10 seconds for the duplicator to detect your master and blank
discs. After your master disc and blank discs have been recognized, you will
see the following screen
Note: By default, the Auto Start setting is set to Auto. There-
fore, if your duplicator is not completely filled with blank discs
and there is no activity within 30 seconds, or if all the drives are
filled and the duplicator detects this, the duplicator will start
automatically.
Note: Once the number of blank discs you inserted matches
the number of discs detected on the screen, press >> (if you are
not using auto start or wish to speed up the process) to confirm
and the following processing screen will appear.
If the number of blank discs you inserted does not match the number of
discs detected on the screen, allow 10 to 15 seconds for the duplicator to
recognize all of your blank discs.
Step 4: After two to three seconds of processing time, one of the follow-
ing Copy Progress screens will appear. The left-hand screen is shown when
“No Counter” is selected, and the right-hand screen is shown when
“Counter” is selected.
Preparing
7 Disc Detected, Go?
■7 indicates there are seven discs
recognized by the Writer tray.
The actual quantity may be dif-
ferent depending upon your
machine.
Processing
Please Wait

Xerox Duplicator 20
Note: It is normal to see the progress indicator staying at 0-
10% and 100% for approximately 30 seconds for CD duplica-
tion and up to 1 minute for DVD duplication. That is caused by
the initializing and finalizing stages.
Once the duplication run is completed, the successful copies will be ejected
and you should see the following screen.
Remove the successful copies and refill the trays with additional blank me-
dia to continue making more copies. You can also press << to terminate
your project and go back to the Main menu.
If you’ve specified a counter value for your project and your project is com-
pleted, you should see the following screen.
Copying 4012MB
0 12% 481MB or Copying 4012MB 0/21 12% 481MB
■4012MB indicates the capacity
of the master disc.
■0 indicates that no copies have
been made so far.
■12% indicates the current
progress of the duplication.
■481MB indicates the current
progress of the duplication in
terms of MB.
■4012MB indicates the capacity
of the master disc.
■0/21 indicates you have a
project size of 21 copies and
you have made 0 copies thus
far.
■12% indicates the current
progress of the duplication.
■481MB indicates the current
progress of the duplication in
terms of MB.
Pass 7 Fail 0(7)
Waiting for Blanks
■Pass 7 indicates you have just
made seven successful copies.
■Fail 0 indicates you have no fail-
ures in this run.
■7 indicates you have just made
seven copies thus far.
21 Discs Copied
Press OK to Finish
