-1-
10/100BASE-TX TO 100BASE-FX
MEDIA CONVERTERS
NC-300D Series
InstallationGuide
DOC.060215-NC-300D

-2-
The information contained in this document is subject to change without
prior notice.Copyright (C) All Rights Reserved.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
FCC NOTICE
This device complies with Class B Part 15 the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received including the interference that may cause.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to
the EMC directive of the European Community. Such marking is indica-
tive that this equipment meets or exceeds the following technical stan-
dards:
EMC Class B
EN 50081-1/1992 : EN55022, EN61000-3-2, EN61000-3-3
EN 50082-1/1998 : EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5,
EN61000-4-6, EN61000-4-8, EN61000-4-11

-3-
Table of Contents
1. Introduction.........................................................4
1.1 Key Features ................................................................................. 4
1.2 Specifications ................................................................................ 5
1.3 Optical Specifications.................................................................... 8
1.4 Special Functions........................................................................ 10
2. Installation.........................................................12
2.1 Unpacking .................................................................................... 12
2.2 Mounting the Device .................................................................... 12
2.3 Applying Power ............................................................................ 13
2.4 Making TP Port Connection ......................................................... 14
2.5 Making FX Port Connection ......................................................... 14
2.6 LED Indicators ............................................................................. 16
3. Optional Configuration Settings......................17
3.1 User Inaccessible Jumpers........................................................ 17
3.1.1 Forwarding Mode Setting JP1 .................................................. 18
3.1.2 802.3x Function Setting JP2..................................................... 19
3.1.3 FXDuplex Setting JP3 .............................................................. 19
3.2 JP1-JP3 Factory Default Settings ................................................ 19

-4-
1. Introduction
The 10/100BASE-TX to 100BASE-FX media converter series provides a
mediaconversionallowinghigh-speedintegrationoffiberopticandtwisted-
pair segments.With 10BASE-Tand 100BASE-TX support, the converters
provideseamlesstranslationbetweenEthernetandFastEthernetnetworks.
A complete set of LEDs allows for quick status verification.
1.1 Key Features
The media converters also provide the following key features:
• Convert speed and media type
• Support full wire speed conversion
• Support 10Mbps and 100Mbps speed on TP connections
• Auto MDI/MDI-X detection function on the TP port
• Auto-negotiation function on the TP port
• Link fault pass through function
• Provide manual configuration settings for TP port to support
connection to non-auto-negotiation devices
• Transparent to 802.1Q VLAN tagged packets
• Far End Fault function on FX port
• Support wide range of fiber options on the FX port
• Support media converter center chassis installation
• Support center chassis management
• Provide user-inaccessible settings for specific system applications
• Low power consumption

-5-
1.2 Specifications
Twisted-PairInterface(TPPort)
Connector ShieldedRJ-45
Pin Assignments Auto MDI/MDI-X detection
SignalCompliance IEEE802.310BASE-T,802.3u100BASE-TX
Data Speed 10Mbps or 100Mbps
Duplex Mode Half-duplexor Full-duplex
Configuration Auto-negotiation capable and optional
forced manual settings
Cable Types 10Mbps - Category 3, 4, or 5 UTP
100Mbps - Category 5 UTP
Supported Link Distance Up to 100 meters

-6-
FiberOpticInterface(FXPort)
SignalCompliance IEEE802.3u100BASE-FX
Connector SC,ST,MT-RJ,VF-45,LCor SingleSC
Data Speed 100Mbps
Duplex Mode Full-duplex and optional half duplex
Cable Types Multimode(MMF)-50/125,62.5/125µm
Singlemode(SMF)-9/125µm
Supported Link Distance MMF up to 2km
SMFupto100km
Single SMF WDM up to 40km
Eye Safety compliance IEC825Class1
UserAccessibleSettings(SW)
NO. SETTING STATE FUNCTION
SW1 TPPortConfiguration OFF Auto-negotiation (default)
ON Forcedmode
SW2 TPPortDuplex OFF Fullduplex(default)
ON Halfduplex
SW3 TP Port Speed OFF 100Mbps(default)
ON 10Mbps
SW4 Link Fault Pass Through OFF Disable(default)
ON Enable
SW5 Reserved
OptionalSettings(UserinaccessibleJP1-JP3onboard)
NO. SETTING STATE FUNCTION
JP1 Forwardingmode Open Store-and-forward(default)
Short Smart-forwardmode
JP2 802.3xfunction Open Enable(default)
Short Disable
JP3 FX port duplex Open Fullduplexmode(default)
Short Halfduplexmode

-7-
LEDIndicators
LED DISPLAY STATE INTERPRETATION
PWR Power status ON Power on
OFF Power off
TPLINK TP port link status ON Link up and no traffic
OFF Linkfault
Blink Rx/Txactivities
TP100M TP port speed status ON 100Mbps
OFF 10Mbps
TP FDX TP port duplex status ON Fullduplex
OFF Halfduplex
Blink Collisions on half duplex
FXLINK FX port link status ON Link up and no traffic
OFF Linkfault
Blink Rx/Txactivities
FXOL FX port optical link ON Optical signal is detected
OFF No optical signal
DCPowerInput
DC Input Jack D6.3mm D2.0mm
Operating Input Voltages +4.75V~+12.6V
Power consumption 2Wmax.(0.27A@+7.5V)
Power Supply Options External AC-DC poweradapters
RatedAC120V/60HzDC7.5V1A
RatedAC230V/50HzDC7.5V1A
RatedAC100V/50-60HzDC7.5V1A
RatedAC100V/50-60HzDC5V1A
RatedAC240V/50HzDC7.5V1A
CenterConnector
Connector Futurebus 6x4
Function Center chassis installation
Signals Power inputs
Ground
Management interfaces

-8-
BasicInformation
Forwarding Throughput Fullwire speed at 100M full duplex
10Mbps - 14,880 pps at 64-byte packets
100Mbps - 148,800pps at 64-byte packets
Packet Types Transparent and no modification for
-IEEE802.3 standard packets
-IEEE802.1Q VLANtaggedpackets
Packet Length Upto1522 bytes at store-and-forward mode
Nolimitat smart-forwardmode100to100
FlowControl Back-pressure for half-duplex mode
802.3xpause-framebaseforfullduplexmode
Mechanical
Dimension H23mmxW72.5mmxD108mm
Housing Enclosed metal with no fan
Mounting Desktop, Wall mount, Center chassis
Weight 210g
Environmental
OperatingTemperature -5oC~50oC
-20oC~60oC(forNC-300D-ECmodel)
StorageTemperature -20oC~85oC
RelativeHumidity 5%~ 90%
Certificate
FCC Part 15 Class B
CE/EMC EMIEN50081-1ClassB,EMSEN55024
CE/LVD EN60950
1.3 Optical Specifications
The media converter series provides the following fiber options:

-9-
DuplexFiberSeries
Model Port Fiber Wavelength TxPower RxSensitivity
300D-T ST MMF 1310nm -19~-14dBm -31dBm
300D-C SC MMF 1310nm -19~-14dBm -31dBm
300D-EC SC MMF 1310nm -20~-14dBm -31dBm
300D-JM MT-RJ MMF 1310nm -19~-14dBm -31dBm
300D-VM VF-45 MMF 1310nm -20~-14dBm -31dBm
300D-SA2 SC SMF 1310nm -15~-8dBm -31dBm
300D-SL2 SC SMF 1310nm -15~-8dBm -32dBm
300D-SL3 SC SMF 1310nm -15~-8dBm -34dBm
300D-SL4 SC SMF 1310nm -5 ~ 0dBm -34dBm
300D-SL6 SC SMF 1310nm -5 ~ 0dBm -35dBm
300D-SL7 SC SMF 1310nm -3 ~ +3dBm -37dBm
300D-SL9 SC SMF 1310nm 0 ~ +5dBm -37dBm
300D-SL10 SC SMF 1550nm -3 ~ +3dBm -37dBm
300D-SL12 SC SMF 1550nm 0 ~ +5dBm -37dBm
Single FiberBi-Di WDM Series
Model Port Fiber Wavelength TxPower Rx Sensitivity
300D-W3515 SC SMF Tx1310nm -14~-8dBm -31dBm
Rx1550nm
300D-W5315 SC SMF Tx1550nm -14~-8dBm -31dBm
Rx1310nm
300D-W3540 SC SMF Tx1310nm -8~0dBm -34dBm
Rx1550nm
300D-W5340 SC SMF Tx1550nm -8~0dBm -34dBm
Rx1310nm
CWDMSeries
Model Port Fiber Wavelength TxPower Rx Sensitivity
300D-CxxW40 SC SMF Tx1xx0nm -5 ~ 0dBm -35dBm
Rx1100-1650nm
300D-CxxW80 SC SMF Tx1xx0nm 0 ~ +5dBm -37dBm
Rx1100-1650nm

-10-
1.4 Special Functions
AutoMDI/MDI-XFunction
This function allows the TP port to auto-detect the twisted-pair signals
and adapts itself to form a valid MDI to MDI-X connection with the
remote connected device automatically.
Auto-negotiationFunction
When TP port is set on Auto-negotiation mode (SW1:ON), it is featured
with auto-negotiation function and full capability. It performs a negotia-
tion process for the speed and duplex configuration with the connected
device automatically when each time a link is being established.
FarEndFaultFunction
The FX port is facilitated with this function, which conforms to IEEE
802.3u 100BASE-FX specifications. When the FX port detects a link
failure on its receiving circuitry, it will send out an FEFI (Far End Fault
Indication) signal to the remote connected device to indicate a remote
fault is detected. It also is capable to receive FEFI signal sent from the
remote link partner. Upon receiving an FEFI signal, it indicates a link
failure occurred on the transmitting path. This function allows the con-
verter to report a fiber link fault even when a link failure occurred on
transmitting fiber cable.

-11-
LinkFaultPassThroughFunction
When this function is enabled, a link fault detected on the TP port will
forcealinkdownontheFXport.Similarly, a link fault detectedontheFX
port will also force a link down on the TP port. As illustrated in the
following figure, this function allows to pass TP link fault to the remote
link partner and makes the converter like aTPcable extender.

-12-
2. Installation
2.1 Unpacking
Check that the following components have been included:
• Installation guide (or contained in the product CD)
• 10/100MediaConverter
• OneAC power adapter
Ifanyitemisfound missing or damaged, please contact yourlocalreseller
forreplacement.
2.2 Mounting the Device
DesktopMounting
The media converter can be mounted on a desktop or shelf. Make sure
that there is proper heat dissipation from and adequate ventilation around
the device. Do not place heavy objects on the device.
WallMounting
The media converter also can be mounted on a wall. On bottom of the
device, wall mounting hole is provided for wall mounting.
InstallationintoCenterChassisKC-1300
Themedia converter also can be installed in KC-1300 center chassis.The
center chassis provides the power supply to the converter. Up to 16 units
can be installed in one chassis. Unscrew and remove the cover of the
center connector before inserting the converter into the chassis. Refer to
the operation manual of center chassis KC-1300 for more information.

-13-
2.3 Applying Power
Before you begin the installation, check the AC voltage of your area. The
ACpower adapterwhichis usedtosupplytheDC powerfortheunitshould
have the AC voltage matching the commercial power voltage in your area.
TheACPowerAdapterSpecifications
AC input power: AC power voltage of your area, options -
RatedAC120V/60HzDC7.5V1A
RatedAC230V/50HzDC7.5V1A
RatedAC100V/50-60HzDC7.5V1A
RatedAC100V/50-60HzDC5V1A
RatedAC240V/50HzDC7.5V1A
Steps to apply the power to the converters are:
1. Connect power adapter DC plug to the DC input jack located on the
back of the converter before connecting to the AC outlet.
2. To ensure against accidental disconnection, tie theDC cable with
the cable tie located the back of the converter.
3. Connect the power adapter to the AC outlet.
4.CheckPower LED indication.

-14-
2.4 Making TP Port Connection
TP port is featured to support connection to :
•Auto-negotiation devices
•Auto-negotiation incapable 10BASE-T devices
•Auto-negotiation incapable 100BASE-TX devices
NetworkCables
10BASE-T: 2-pairUTPCat. 3,4,5,EIA/TIA-568100-ohm STP
100BASE-TX: 2-pairUTPCat. 5,EIA/TIA-568100-ohmSTP
Link distance: Up to 100 meters
ConfigurationSetup
To make a proper connection, the following configuration settings are
recommended:
TP port link partner SW1 SW2 SW3
Auto-negotiation device Off: auto Off: full duplex Off: 100M
Fixed 10M half duplex device On: forced On: half duplex On: 10M
Fixed 100M half duplex device On: forced On: half duplex Off: 100M
Fixed 10M full duplex device On: forced Off: full duplex On: 10M
Fixed 100M full duplex device On: forced Off: full duplex Off: 100M
2.5 Making FX Port Connection
FX port operates on 100Mbps and full duplex (factory default). A variety
of fiber options is listed in Section 1.3

-15-
DuplexFiberSeries
Model Connector Wavelength Fiber Ref.distance
300D-T ST 1310nm DuplexMMF 2km
300D-C SC 1310nm DuplexMMF 2km
300D-JM MT-RJ 1310nm DuplexMMF 2km
300D-VM VF-45 1310nm DuplexMMF 2km
300D-SA2 SC 1310nm DuplexSMF 20km
300D-SL2 SC 1310nm DuplexSMF 20km
300D-SL3 SC 1310nm DuplexSMF 30km
300D-SL4 SC 1310nm DuplexSMF 40km
300D-SL6 SC 1310nm DuplexSMF 60km
300D-SL7 SC 1310nm DuplexSMF 70km
300D-SL9 SC 1310nm DuplexSMF 90km
300D-SL10 SC 1550nm DuplexSMF 100km
300D-SL12 SC 1550nm DuplexSMF 120km
Single FiberBi-Di WDM Series
Model Connector Wavelength Fiber Ref. Distance
300D-W3515 Bi-Di SC Tx 1310nm Single SMF 15 - 20km
Rx 1550nm
300D-W5315 Bi-Di SC Tx 1550nm Single SMF 15 - 20km
Rx 1310nm
300D-W3540 Bi-Di SC Tx 1310nm Single SMF 40km
Rx 1550nm
300D-W5340 Bi-Di SC Tx 1550nm Single SMF 40km
Rx 1310nm
Since the WDM single fiber media converters use different wavelengths
for transmission and receiving respectively, the link partner device lo-
cated on the remote end of the single fiber should match the wavelength
used on the single fiber converter.
CWDM Series
Model Connector Wavelength Fiber Ref. Distance
300D-CxxW40 SC TX 1xx0nm SMF 40km
RX 1100 - 1650nm
300D-CxxW80 SC TX 1xx0nm SMF 80km
RX 1100 - 1650nm

-16-
2.6 LED Indicators
LinkFaultPassThroughFunctionisdisabled
LED Display Status Interpretation
PWR Power status On Power on
Off Poweroff
TPLINK TP port link status On Link up and no traffic
Off Linkfault
Blink Rx/Txactivities
TP100M TP port speed status On 100Mbps
Off 10Mbps
TPFDX TP port duplex status On Fullduplex
Off Halfduplex
Blink Collisions on half duplex
FXLINK FX port link status On Link up and no traffic
Off Linkfault
Blink Rx/Txactivities
FXOL FX port optical link On Optical signal is detected
Off No optical signal is detected
LinkFaultPassThroughFunctionisenabled
TPLINK FXLINK FXOL Interpretation
On On On Both TP and FX ports link up
Off Off On (1) TP port link fault or
(2) FX port received FEFI signal
(FXport Tx path failed.)
Off Off Off (1) TP port link fault or
(2)FXportRxlinkfailuredetected

-17-
3. Optional Configuration Settings
The media converter provides additional configuration settings which
are user-inaccessible. The settings are built on the board inside the prod-
uct case. The settings are provided for technical installers to adapt the
converter to fit some specific application needs.
3.1 User Inaccessible Jumpers
The setting jumpers are not accessible by users generally. For accessing
these jumpers, the upper case must be removed from the product. Re-
moving the case must be performed by an authorized and experienced
technical person. The setting jumper block is located on the position
shown below:
The setting functions are as follows:
JP1 Forwarding mode setting Open - Store-and-forward mode
Short -Smart-forwardmode
JP2 802.3x function setting Open -Enable
Short - Disable
JP3 FX port duplex setting Open -Full duplexmode
Short -Half duplex mode

-18-
3.1.1 Forwarding Mode Setting JP1
The following table lists the forward method used in different TP to FX
conversions:
JP1 Setting TPportto/fromFXport Forwardmethod
Store-and-forward 10BASE-Tto100BASE-FX Store and forward
100BASE-TXto100BASE-FX Store and forward
Smart-forward 10BASE-Tto100BASE-FX Store and forward
100BASE-TXto100BASE-FX Direct conversion
On smart-forward mode, the converter can change to direct conversion
automatically when it detects same speed on both TP port and FX port.
Direct conversion method converts the signal between TP port and FX
port without storing the received packet on one port then forwarding to
another port. The media converter operates with the minimum latency.
Note:
1. In direct conversion, be sure both devices connected to the TP port
and FX port have same duplex mode for proper transmission.
2. In direct conversion, 802.3x function is disabled and the media
converter will not generate pause frame, but just forwards the
received pause frame directly from one port to another port.
3. In direct conversion, the media converter is not limited to the
maximal length of the receiving packets.

-19-
3.1.2 802.3x Function Setting JP2
IEEE 802.3x function is the flow control method used for full duplex op-
eration on TP port and FX port under store and forward mode. This
method uses pause frames for one port to stop further transmission from
its link partner.
3.1.3 FX Duplex Setting JP3
This setting is used to set the duplex mode of the FX port.
3.2 JP1-JP3 Factory Default Settings
The factory default settings for JP1, JP2, and JP3 are as follows:
JP1 Open Store-and-forward mode
JP2 Open 802.3x function is enabled
JP3 Open FXportfullduplex
