Ltech LT-DMX-8020 User manual

1
LT- 8020 DMX512 Decoder Manual LT- 8020 DMX512 Decoder Manual
LT-DMX-8020
DMX-SPI Signal Decoder Manual
LT- 8020
1. Product parameter
Input voltage
Input Signal
Output signal
Decoding Channels
Output Grey Scale
DMX512 Connector
Product Dimension
Package Size
Working temperature
Weight (G.W)
DC5V～DC24V
DMX512/1990
SPI(TTL)
96 channels/unit
128 levels
Standard XLR-3 Connector
L125×W52×H40mm
L135×W70×H50mm
-30 -65
℃ ℃
300g
The LT-8020 DMX512 Data Decoder adopted the advanced decoding
technology to convert the international standard DMX512/1990 signal into
standard SPI (TTL) signal to control LED lights based on 74HC595, MB5026,
DM134, DM135, SC16722, ZQ9712, or similar chips, each decoder has 96
DMX output channels, and the output channels can be expanded by adding
decoders, therefore, most of LED lights can be controlled via the signal
convertion, such as widely used pixel light, digital tube light, spot light,
floodlight, pixel screen, dancing floor light etc.
RoHS
COM PLIAN T
warranty
3 years
ISO9 001:2008
2
SPI(TTL) Output Port
2. Configuration Diagram
1 2 3 4 5 6 7 8 9 10
ONDIP
DMX input port
Example 1:
“1” The rest to “0” as the below figure, In this connection, the summation from 1 to 9 is 1+4+32, Namely ,
The DMX512 initial address code is 37.
Like figure 2, Set initial address to 37, Set the “1st”,”3rd “,”6th”, bit of the DIP switch down to
DATA CLK LAT
MODEL : LT-8020
DMX512 DECODER
DC5V-DC24V
96 CHANNEL
GND
3. Output Port definition
No. Silk screen Function
1
2
3
4
5
6
Power supply
input port
Output port
Connect LED
LED power supply input anode
LED power supply input cathode
Register Clock
Clock cable
Ground wire (DC-)
DC+
DC-
DATA
CLK
LAT
GND
Warning: the power cable can’t connect the data port, otherwise it will damage the
decoder!
4. Address Setting
Data cable
This decoder can decode 128 DMX addresses, adopted Dip switch to set the address, the
Dip switches from 1 to 9 are a kind of binary value coding switches, the 1st bit is LSC, the
9th bit MSC, can set 511 addresses totally.
DMX512 initial address code is equal to the total amount of the Dip switches’ numbers from
1 to 9, press Dip switch downward (ON: at position “1”), you can get the number of its
position, if press upward (at position “0”), the value of its position is 0.
Accept DMX512 signal only when the DIP switch FUN(10)=OFF(at position “0”)
Figure 1
Example 2: Set DMX512 original address code as 385: Set the 9th, 8th, 1st bit of the DIP switch
downward to “1”, the rest to “0” (as Figure 2), the total sum from 1 to 9 is 256+128+1, so the DMX512
original address code is 385.
4
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
Figure 2
4
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD. WWW.LTECHONLINE.COM
[e-mail]
Tel: [phone] Fax: [phone]
LTECH LTECH

1
1
12
2
23
3
34
4
45
5
56
6
67
7
78
8
89
9
910
10
10
ON
ON
ON
DMX512 OUT
DMX512 OUT
DMX512 OUT
DMX512 IN
DMX512 IN
DMX512 IN
DATA
CLK
LAT
GND
DC5V 24V
96 CHANNEL
DMX512 DECODER
LT SYSTER 8020
DC5V 24V
96 CHANNEL
DMX512 DECODER
LT SYSTER 8020
DC5V 24V
96 CHANNEL
DMX512 DECODER
LT SYSTER 8020
DATA
CLK
LAT
GND
DATA
CLK
LAT
GND
SPI（T TL）SP I（TT L）SPI（T TL）
Pow er adap ter
Input Power
DC5V -24V
Outp ut
Sig nal O ut put
Pow er adap ter
Input Power
DC5V -24V
Sig nal O ut put
Inpu t OutputInp ut Output
Pow er adap ter
Input Power
DC5V -24V
Sig nal O ut put
DMX Da ta Inpu t
DMX S igna l Out put
DMX 512
CON TROL SY STEM
IP- DMX
DMX5 12
PC SOF TWARE
USB -DM X
Data C onver tor Dat a Conve rtor
pixel lamp pixel lamppixel lamp
CON NECT PO WER
SUP PLI ER
CON NECT PO WER
SUP PLI ER
CON NECT PO WER
SUP PLI ER
LT- 8020 DMX512 Decoder Manual LT- 8020 DMX512 Decoder Manual
3
2. T esting function:
5. Configuration Diagram
1. LED point source conjunction diagram
The 10th DIP switch is FUN, acting as the function key.
DMX512 Decoder works when FUN is at OFF, receiving DMX512 signals.
Decoder testing mode works when FUN is at position” ON” as Figure 3:
SWITCH1-9 OFF: BLACK
SWITCH1 IS ON: lighten 6 channels
SWITCH2 IS ON: lighten 12 channels
SWITCH3 IS ON: lighten 18 channels
SWITCH4 IS ON: lighten 24 channels
SWITCH5 IS ON: lighten 30 channels
SWITCH6 IS ON: lighten 36 channels
SWITCH7 IS ON: lighten 42 channels
SWITCH8 IS ON: lighten 48 channels
SWITCH9 IS ON: the ground color is dark, then light from the 1st channel individually to
all until lighten all channels.
4
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
Figure 3
See Figure 4, if multi dip switches are on, the function is subject to the last switch.
4
1 2 3 4 5 6 7 8 9 10
ON
0
1
OFF
ON
Figure 4
4
2. LED wall washer conjunction diagram
24V
1
1
12
2
23
3
34
4
45
5
56
6
67
7
78
8
89
9
910
10
10
ON
ON
ON
DMX512 OUT
DMX512 OUT
DMX512 OUT
DMX512 IN
DMX512 IN
DMX512 IN
outp utinput out put
powe r DCSV
DATA
CLK
LAT
GND
DC5V 24V
128 CHANNEL
DMX512 DECODER
LT SYSTER 8020
DC5V 24V
128 CHANNEL
DMX512 DECODER
LT SYSTER 8020
DC5V 24V
128 CHANNEL
DMX512 DECODER
LT SYSTER 8020
DATA
CLK
LAT
GND
DATA
CLK
LAT
GND
SPI（TTL）
sig nal out put
SPI（TTL）SPI（TTL）
DMX sig nal input
DMX s ignal input
DM X 51 2 c o ns o le
IP- DMX
DMX512
PC software
power
USB
hi-power floodlight hi-power floodlight
power
adapdter
pow er adapdte r
24V
powe r DCSV
sig nal out put
power
hi-power floodlight hi-power floodlight
power
hi-power floodlight hi-power floodlight
sig nal out put
24V
powe r DCSV
input output
powe r adapdter
NOTE: Acoording to DMX512 protocol, in order to ensure a steady data transmission, you should add a
metalster(Metal Thin Film resistor，90-120Ω 1/4 W )at the end of each layout of DMX data
cable(between Foot 2 and Foot 3, Data + and Data -), please also refer to your dmx console manual to
select a correct resistor
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD. WWW.LTECHONLINE.COM
[e-mail]
Tel: [phone] Fax: [phone]
LTECH LTECH
5. Attention
6. Warranty Agreement
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please
ensure it is mounted in a water proof enclosure.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any LED power supplies used comply with the working voltage of the product.
5. Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector to avoid the accidents due to overheat and
poor contact on the wire.
6. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights.
7. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
1. We provide lifelong technical assistance with this product:
A 3 year warranty is given from the date of purchase. The warranty is for free repair or replacement and covers
manufacturing faults only.
For faults beyond the 3 year warranty we reserve the right to charge for time and parts.
2. Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
3. Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Ltech shall not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
4. Any amendment or adjustment to this warranty must be approved in writing by Ltech only.
★ This manual only applies to this model. Ltech reserves the right to make changes without prior notice.
