Xexun XT-009 User manual

XT-
009 Gps tracker user manual
1
GSM / GPRS / GPS
VEHICLE TRACKER
XT-009
Preface
Thank you for purchasing our GPS vehicle tracker. This manual shows how to operate the device
smoothly and correctly. Please read this manual carefully before using it. Please note that specification
and information are subject to changes without prior notice in this manual. Any change will be
integrated in the latest release. The manufacturer assumes no responsibility for any errors or omissions
in this document.

XT-
009 Gps tracker user manual
2
Index
1. Function summary------------------------------------------------------------------------------------------------------2
2. Application----------------------------------------------------------------------------------------------------------------3
3. Hardware description-----------------------------------------------------------------------------------------------------3
3.1 Outside -----------------------------------------------------------------------------------------------------------------3
3.2 Internal mainboard -----------------------------------------------------------------------------------------------------3
4. Wire connection ------------------------------------------------------------------------------------------------------------4
5. Specifications----------------------------------------------------------------------------------------------------------4
6. Battery and SIM Card installation-------------------------------------------------------------------------------5
7. Startup--------------------------------------------------------------------------------------------------------------------5
8. Usage---------------------------------------------------------------------------------------------------------------------7
9. Tracker mode-----------------------------------------------------------------------------------------------------7
9.1 Initialization-------------------------------------------------------------------------------------------------------7
9.2 Change the password-----------------------------------------------------------------------------------------7
9.3 Authorization number-----------------------------------------------------------------------------------------7
9.4 SMS format ------------------------------------------------------------------------------9
9.5 Auto tracking -------------------------------------------------------------------------------------------9
9.6 Tlimit function ---------------------------------------------------------------------------9
9.7 GEO fence -----------------------------------------------------------------------------------------9
9.8 Movement alert -------------------------------------------------------------------------------------------10
9.9 Overspeed alert -----------------------------------------------------------------------------------------------10
9.10 IMEI checking ---------------------------------------------------------------------------------------------------11
9.11 Firmware version checking -----------------------------------------------------------------------------------------12
9.12 Time zone setting ---------------------------------------------------------------------------------------------12
9.13 SOS button -----------------------------------------------------------------------------------------------------12
9.14 SMS LINK ----------------------------------------------------------------------------------------------------13
9.15 SMSONE ----------------------------------------------------------------------------------------------------13
9.16 Low battery alert --------------------------------------------------------------------------------------13
9.17 Message center ----------------------------------------------------------------------------------------14
9.18 GSM ID --------------------------------------------------------------------------------------------------14
9.19 Motion sensor -----------------------------------------------------------------------------------------------14
9.20 SD Card ------------------------------------------------------------------------------------- -----------13
9.21 ACC status alert --------------------------------------------------------------------------------------------------13
9.22 Remote oil &energy cut off function ----------------------------------------------------------------------15
9.23 OTA feature ----------------------------------------------------------------------------------------------------15
10. Monitor Mode--------------------------------------------------------------------------------------------------------15
11. GPRS setting------------------------------------------------------------------------------------------------------------16
12. Notes-----------------------------------------------------------------------------------------------------------------------17
13. Faults and solutions--------------------------------------------------------------------------------------------------17

XT-
009 Gps tracker user manual
3
1 . O v e r v i e w o f f u n c t i o n
l S M S / G P R S s e n d i n g d a t a
l M o v e m e n t / G e o f e n c e / S p e e d / L o w b a t t e r y a l a r m
l A C C a l a r m
l S O S a l a r m
l R e m o t e c u t - o f f e l e c t r i c i t y & o i l f u n c t i o n
l C o l l i s i o n v i b r a t i o n a l a r m ( C r a s h a l a r m )
l V o i c e m o n i t o r i n g
l M a i n p o w e r d i s c o n n e c t a l a r m
l S D c a r d s a v e G P R S d a t a s a v e - s a v e s
l R e m o t e l y u p d a t e f i r m w a r e U p d a t e f i r m w a r e r e m o t e l y
l D i s t a n c e l i m i t d a t a t r a n s m i s s i o n
l W a t e r p r o o f I P 6 7
2 . A p p l i c a t i o n
l V e h i c l e / s h i p / m o t o r c y c l e / r e n t a l / f l e e t m a n a g e m e n t
l C h i l d r e n / o l d e r l y / d i s a b l e d g u a r d i a n s h i p
l P e r s o n n e l s a f e t y
l P e o p l e m a n a g e m e n t
l T r a c k i n g a n o f f e n s e
3 . H a r d w a r e d e s c r i p t i o n
3 . 1 O u t s i d e
Microphone
SOS Button
Working LED
Power LED

XT-
009 Gps tracker user manual
4
3.2 Internal mainboard
4. Wires connection
SD card SIM card
Red: +12V
Black: -12V
Green connect
s
to ACC
White connects to Relay

XT-
009 Gps tracker user manual
5
5. Specification
Content specs
Dimention 73*46*24(mm)
Weigh 50g
Network GSM/GPRS
Band 850/900/1800/1900Mhz
GPS chip SIRF3 chip
GPS sensitivity -159dBm
GPS accuracy 5-10m
Start-up time
Cold status 45s
Warm status 35s
Hot status 1s
External power
supply
DC6-36V input
Battery 3.7V 1200mAh battery
Standby 120hous
Storage Temp -40°C to +85°C
Operation Temp -30°C to +80°C
Humidity 5%--95% non-condensing
6. Battery and SIM Card installation
Make sure SIM card have no call transfer, show calling ID is actived and PIN code request is off
1. Open two screws
2. Insert the SIM card and SD card
Open screws
Insert SIM card
Insert SD card

XT-
009 Gps tracker user manual
6
7.Startup
l Put the SIM card and SD card in right places,connect the battery to tracker or connect the tracker to
6-36Vcar/motorcycle battery. it will turn on automatically. the red light will on if connect tracker to
6-36V car/motorcycle battery, it will off if disconnect.
l The green light will blink 2 times per second after start up. after 20-30 seconds, the light will on 1
seconds, off 3 seconds, GSM signal working normal.
l It takes 40~90 seconds to receive the GPS signals, in order to get good GPS signals, please put the
tracker outdoor.
8.Usage
This product has two modes, tracker and monitor, the default mode is tracker mode, you can send SMS
monitor + password to switch to monitor mode and then send tracker + password to switch back to
tracker mode.
9. Tracker mode
9.1 Initialization
Send begin + password to the tracker, it will reply begin ok and initialize all settings.
Connect the battery
Close
s
the screws

XT-
009 Gps tracker user manual
7
TO:13188888888
noadmin123456 3166666666
TO:13188888888
noadmin ok
9.2 Changer password
Send SMS password+old password+space+new password, it will reply password OK.
the default password is 123456
9.3 Set authorized number
l Send SMS admin+password+space+cellphone number to set up the first authorized number.
it will reply admin ok. Other authorized numbers must be set by the first authorized number.
Max 5 authorized numbers.
l Send SMS noadmin+password+space+authorized number to cancel an authorizated number
From:13188888888
password ok
TO:13188888888
begin123456
TO:13188888888
password123456 888999
From:13188888888
begin ok

XT-
009 Gps tracker user manual
8
9.4 SMS format
You can see an example of SMS you receive from tracker:
Lat: 22.566901 long: 114.051258 speed: 0.00 14/08/09 06.54 F:3.85V,1,Signal:F imei:354776031555474
05 43.5 460 01 2533 720B
lat:[latitude] long:[longitude] speed:[speed] [date] [time] F:[battery voltage]V,[charging
status],Signal:[GPS signal status] [alarm message]* imei:[imei number] [number of fixed satellites]
[altitude] [MCC] [MNC] [LAC] [CellID]
[latitude] GPS received latitude
[longitude] GPS received longitude
[speed] GPS received speed
[date] GPS received date
[time] GPS received time
F:[battery voltage]V, battery voltage
[charging status] “1” in charge, “0” no charge
Signal:[GPS signal status]
“F” GPS fix, “L” no GPS fix
[alarm message] it indicates alarm type (help me!, moved, Speed etc.)
Just ignore this section if no any alarms
imei:[imei number] The identify number of GSM module
[number of fixed satellites]
GPS satellite fixed number
[altitude] GPS received altitude
[MCC] Mobile Country Code
[MNC] Mobile Network Code
[LAC] Location area Code
[Cell ID] GSM cell identities
9.5 Auto-track
l Send SMS t030s005n+password to the unit, it will report the Geo-info at 30s intervals for 5
times(s: second, m: minute, h: hour).
l The setting must be in 3 digits and at maximum 255 in value.

XT-
009 Gps tracker user manual
9
l Send SMS t030s***n+password to the unit, it will reply SMS heaps of times
l Cancel: Send notn+password to delete the “ auto track ”
Remark: the interval must not be less than 5s.
9.6 Tlimit function
l Set up: Send SMS tlimit123456 50 , it will reply “tlimit ok” , you also can change to the other
meters, like 100, 500 or 1000, the maximum is 6000meters, this function should use with
auto-track together.
If the tracker stop moving, it will not send any data to cellphone or server, until the distance is
more than 50 meter.
l Cancel : Send SMS tlimit123456 0 to cancel tlimit function
9.7 Geo-fence
l Setup: Send SMS stockade+password+space+longitude,latitude; longitude,latitude to the unit
to set the restricted district. The unit will send message to the authorized numbers when it
moves out of this district.
l Cancel: Send SMS “nostockade+password” to deactivate this function.
It will reply
“nostockade ok”。
l This function will be invalid if the unit move outside the district. You need to re-set it if you want
this function again.
l The first longitude & latitude is coordinate of the top left corner of the Geo-fence, while the
second longitude & latitude is the coordinate of the bottom right corner.
TO:13188888888
stockade123456
114.124845E,22.5671
85N;114.777888E,22.
555666
N
From:13188888888
T030s***n ok
From:13188888888
stockade ok

XT-
009 Gps tracker user manual
10
9.8 Movement alarm
This function is using for the owner to get alarm when the tracker moves out of a restricted district.
l Setup: Send SMS move+password to the unit to set the movement alert,it will reply move ok
l Cancel: Send SMS nomove+password to deactivate the movement alert,it will reply nomove ok
This function will be invalid after getting one movement alert
Response SMS format: :move!+geo-info. It will alarm one time in each setting.
9.9 Overspeed Alert
This function is used to control the user’s driving speed.
l Setup: Send SMS speed+password+space+ the speed, For example: speed123456 080,it will
From:13188888888
lat: 22.566923 long:
114.051331 speed: 0.00
28/11/10 03:33 F:4.32V,0,
Signal:F stockade
imei:359587011016261 05
41.5 460 01 2533 720B
From:13188888888
nostockade ok
TO:13188888888
nostockade123456
TO:13188888888
move123456
From:13188888888
move ok
