Xexun xt107 User manual

GPS TRACKER
USER MANUAL
UUPreface
Thank you for purchasing GPS Tracker. This manual shows how to operate the device smoothly and
correctly. Make sure to read this manual carefully before using this product. Please note that
specification and information are subject to changes without prior notice in this manual. Any change
will be integrated in the latest release. The manufacturer assumes no responsibility for any errors or
omissions in this document.
1

2
Content
1 Summary ------------------------------------------------------------------------------------------------- 3
2 Application ------------------------------------------------------------------------------------------------ 3
3 Hardware Description -------------------------------------------------------------------------------- 3
3.1 Front Face ------------------------------------------------------------------------------------ 3
3.2 Rear Face -------------------------------------------------------------------------------------- 4
3.3 Interior --------------------------------------------------------------------------------------- 4
4 Specifications ---------------------------------------------------------------------------------------- 5
5 SIM Card Installation ------------------------------------------------------------------ 6
6 Startup ------------------------------------------------------------------------------------- ----------- 7
7 Usage --------------------------------------------------------------------------------------------------- -- 7
8 Track Modes ---------------------------------- --------- -------- ---------------------------------------- 7
8.1 Initialization ---------------------------------- --------- -------- 7
8.2 Password Setting ---------------------------------- --------- -------- 7
8.3 Authorization ---------------------------------- --------- -------- 8
8.4 Auto-Track ---------------------------------- --------- -------- 9
8.5. Tlimit Function---------------------------------- --------- -------- 10
8.6. GPS refurbish setting---------------------------------- --------- -------- 10
8.7 Reboot remotely---------------------------------- --------- -------- 10
8.8 Geo-fence ---------------------------------- --------- -------- 10
8.9 Movement Alert ---------------------------------- --------- -------- 11
8.10 Overspeed Alert ---------------------------------- --------- -------- 12
8.11 IMEI Checking ------------------------------ --------- -------- 13
8.12 Time differences setting ----------------------------------------------------------------- 13
8.13 SOS Function --------------------------------- --------- -------- 13
8.14 SMSLINK --------------------------------- --------- ----------------------------------- 14
8.15 SMSONE -------------------------------------------------------------------------- 14
8.16 Low Battery Alert -------- -------- --------------------------- --------- -------- 14
8.17 SMS Center -------- -------- ------------------------------ --------- -------- 14
8.18GSMID ------------------------------------------------------------------ 15
8.19 Motion Sensor -------- -------- ------------------------------ --------- -------- 15
8.20 SD Card Function -------- -------- ------------------------------ --------- -------- 15
8.21 Switch on/off -------- -------------------------------------- --------- -------- 16
9 Monitoring Mode -------- -------------------------------------- --------- -------- 16
10 Talking Mode -------- -------------------------------------- --------- -------- 16
11 GPRSSetting -------------------------------------------------------------------- 17
12 Cautions --------------------------------------------------------------------- 18

13 Faults & Solutions --------------------------------------------------------------------- 18
1 Summary
Working based on existing GSM/GPRS network and GPS satellites, this product can locate and
monitor any remote targets by SMS or GPRS,and guard against theft of Vehicle.
2 Applications
zVehicle rental / Fleet management,etc.
zProtect the child / the elder / the disabled / pet,etc.
zBusinessmen safety.
zPersonnel management.
zCovert tracking.
3Hardware Description
3.1 Front Face
USB Port,for charging and
u
pg
rade the firmware
Speaker
Necklace holder
SOS Button
Calling Button
3
GSM indicator light
Working modes indicator
GPS indicator light
Microphone

3.2 Rear Face
back cover
4
3.3 Interior
SD Card
SIM Card
Battery

5
4 Specs.
Content Specs.
Dim. 80MM*56MM*22MM
Weight 50g
Network GSM/GPRS
Band 850/900/1800/1900Mhz
GPS chip SIRF3 chip
GSM/GPRS
module SIM900
GPS sensitivity -159dBm
GPS accuracy 5m
Time To First Fix
Reacquisition 0.1s
Cold status 45s
Warm status 35s
Hot status 1s
Power DC5V input
Battery Chargeable changeable 3.7V 860mAh Li-ion battery
Standby 100hours
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +55°C
Humidity 5%--95% non-condensing
5 SIM card installation
Make sure that there is no call transfer and call display is on, and PIN code off.
Step:
1. Open the back cover
2.Open the SIM card slot and SD card slot,and put one SIM card and one SD card

Push ownwards to
open the cover
Pull leftwards and
insert the sim card
6
Fasten downwards ,make sure the SD
card is mounted
SD card is mounted ，then
f
asten the sim card ri
g
htwards
Fasten the cover
upwards
Put the battery

6 Startup
zPut the SIM card and SD card in place,insert the battery and the tracker is on.
The green led in the middle is power indicator, yellow led on left side is GSM indicator and blue led
on right side is GPS indicator. Green indicator will be flashing quickly, yellow indicator will be on for 2
seconds and blue led does not flash when the tracker is on. Green indicator will be on for one second
and off for three seconds in 20-30 seconds and yellow indicator will be on in 3 seconds’ interval which
means the tracker gets GSM signal already.
zBlue indicator will be flashing in 40-90 seconds which depends on the gps signal. Better gps signal
makes the blue indicator flash in short time and poor gps signal make it flash in longer time. Blue
indicator will not flash without gps signal.
7 Usage
The tracker has three working modes: TRACKING，MONITOR, double-way Communication.
8 Track Mode
8.1 Initialization
Send “begin+password” to the product, it will reply “begin ok” and initialize all the
settings
TO:13188888888
begin123456 From:13188888888
begin ok
8.2 Password Setting
Send SMS “password+old password+space+new password” (default password: 123456), it will
reply “password ok”
7
TO:13188888888
password123456 888999 From:13188888888 password ok

8.3 Authorization
8.3.1 Send SMS “admin+ password+ space+ cell phone number”to set the first authorized
number, it will reply “admin ok”, The other authorized numbers should be set by the first authorized
number.(PS: There are only 5 numbers able to be authorized)
TO:13188888888
admin123456 13751187524 From:13188888888 Admin ok
8.3.2 Send SMS noadmin+password+space+authorized number to cancel the authorized number.
8.3.3 When an authorized number send SMS or dials up the unit, it will reply as below:
Lat: 22.566901 long: 114.051258 speed: 0.00 14/08/09 06.54 F:3.85V,1,Signal:F
imei:354776031555474 05 43.5 460 01 2533 720B
Lat: 22.566901 long: 114.051258== Coordinate
0.00 === speed
14/08/09 06.54== Date&Time
F:3.85V == battery power
1 == charging 0 means no charging
Signal:F ==== Full GPS signal L means weak GPS signal
354776031555474== IMEI
05=quantity of satellites ( from 3 to 12 )
43.5=Altitude
460 = MCCMobile Country Code
01 == MNCMobile Network Code
2533= LAC Location area code
720B= Cell ID
8

8.4 Auto-Track
This function can make the tracker to send sms or gprs data in fixed interval for fixed times
8.4.1 Set up: Send SMS t030s005n+password to the unit, it will report the Geo-info at 30s’ interval
for 5 times.(s: second, m: minute, h: hour).You will receive a reply as “t030s005n OK” if the setting is
successful.The setting must be in 3 digits and at maximum 255 times
9
TO:13188888888
T030s005n123456
From:13188888888
T030s005n ok
8.4.2 Send SMS t030s***n+password to the unit, it will reply sms or gprs data for unlimited times.
You will receive a reply as “t030s***n OK” if the setting is successful.
TO:13188888888
T030s***n123456
TO:13188888888
T030s***n ok
8.4.3 Cancel: Send notn+password to delete the this function and it will reply “notn ok”.
Remark: the interval must not be less than 5s.
TO:13188888888
Notn123456
TO:13188888888
Notn ok

8.5 Tlimit Function
8.5.1 Send “tlimit+password+ 50” (50M is the distance, 1-6000M set), reply “tlimit ok” (note: this
function is for auto-tracking function only. If the later position is 50M away with the position before, it
will send sms or gprs data. If less than 50M, it will not send in order to save SMS or gprs fee
8.5.2 Send” tlimit+password+ 0” to cancel this function, the tracker will “tlimit ok”.
8.6 GPS-refresh setting
Send SMS “GpsAutoSearch+password+space+120”，it will reply “GpsAutoSearch ok”. The tracker
will search gps signal in 120s interval after setting this.
The refreshing time is between 120-600 seconds(120<interval <600)
Longer standby time for longer refreshing time and shorter standby time for shorter refreshing time.
8.7 Reboot remotely
Restart+passwored can be sent to the tracker to make the CPU restart when GPRS is stopped. The
tracker will turn off and restart in 3 minutes after sending this command.
8.8 Geo-fence
Set up a geo-fence around of the tracker and it will send message to the authorized numbers when the
tracker goes out of the area .
Notes: This function will be invalid if the unit moves outside of the district. You need to re-set it if you
want this function again. But if the tracker is in this district again, it will send alert again.
8.8.1 Send SMS stockade+password+space+longitude,latitude;longitude,latitude to the unit to
set the restricted district.
Remark :The first longitude & latitude is coordinate of the top left corner of the Geo-fence, while the
second longitude & latitude is the coordinate of the bottom right corner. It will reply stockade ok.
TO:13188888888
stockade123456
114.124845e,22.56718
5n;114.777888e,22.555
666n
From:13188888888
stockade ok
