All XFX graphics cards listed are Vista ready.
* See XFXforce.com for the complete model number and package contents. All XFX graphics cards include a Serial Number
Door Hanger or Card for convenient reference. Game bundles may be included with certain models/packing during promotional periods.
** Optimal memory speed. Actual speed may vary. The HD 5970 Black Edition reference GPU and memory clock are set at 725 MHz and 4 GHz respectively.
Its overclock performance will depend on the graphics card, system and environmental conditions.
*** Specications subject to change without notice. See XFXforce.com for the latest information.
www.XFXforce.com
Engine
Engine
Memory
Memory
Model Number Chipset Version Clk(MHz) Bus Type Type Size Speed•• Stream Cooling HDMI Outputs Profile Features CrossfireX
HD-597X-ENF(*) HD 5970 Black 850 PCI-E 2.1 DDR5 4GB 4.8GHz 3200 Fansink ∆¤Double X, S, D11,EF 3
HD-597A-CNB(*) HD 5970 Black up to 1GHz PCI-E 2.1 DDR5 2GB up to 6Ghz 3200 Fansink ∆♦,♠Double X, S, D11,EF 3
HD-597A-CNF(*) HD 5970 Standard 725 PCI-E 2.1 DDR5 2GB 4Ghz 3200 Fansink ∆♦,♠Double X, S, D11,EF 3
HD-587X-ZNB(*) HD 5870 Black 900 PCI-E 2.1 DDR5 1GB 5GHz 1600 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-587X-ZND(*) HD 5870 XXX 875 PCI-E 2.1 DDR5 1GB 5GHz 1600 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-587X-ZNE(*) HD 5870 XT 865 PCI-E 2.1 DDR5 1GB 5GHz 1600 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-587X-ZNF(*) HD 5870 Standard 850 PCI-E 2.1 DDR5 1GB 4.8GHz 1600 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-585A-ZNB(*) HD 5850 Black 765 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-585A-ZND(*) HD 5850 XXX 755 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-585A-ZNF(*) HD 5850 Standard 725 PCI-E 2.1 DDR5 1GB 4GHz 1440 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-585X-ZAB(*) HD 5850 Black 765 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-585X-ZAD(*) HD 5850 XXX 755 PCI-E 2.1 DDR5 1GB 4.5GHz 1440 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-585X-ZAF(*) HD 5850 Standard 725 PCI-E 2.1 DDR5 1GB 4GHz 1440 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-583X-ZNF(*) HD 5830 Standard 800 PCI-E 2.1 DDR5 1GB 4GHz 1120 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-583X-ZAD(*) HD 5830 XXX 840 PCI-E 2.1 DDR5 1GB 4.5GHz 1120 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-583X-ZAF(*) HD 5830 Standard 800 PCI-E 2.1 DDR5 1GB 4GHz 1120 Fansink Yes ♦,▲,♠Double X, S, D11,EF 3
HD-577A-ZND(*) HD 5770 XXX 875 PCI-E 2.1 DDR5 1GB 5.2GHz 800 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-577A-ZNE(*) HD 5770 XT 865 PCI-E 2.1 DDR5 1GB 5GHz 800 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-577A-ZNF(*) HD 5770 Standard 850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-577A-ZHF(*) HD 5770 Standard 850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-577X-Z5F(*) HD 5770 Standard 850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink ∆¤Standard X, S, D11,EF 2
HD-577X-ZMD(*) HD 5770 XXX 865 PCI-E 2.1 DDR5 1GB 5.1GHz 800 Fansink ∆♦, ¤Standard X, S, D11,EF 2
HD-577X-ZMF(*) HD 5770 Standard 850 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink ∆♦, ¤Standard X, S, D11,EF 2
HD-577X-ZNE(*) HD 5770 XT 800 PCI-E 2.1 DDR5 1GB 5.1GHz 800 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-577X-ZNF(*) HD 5770 Standard 800 PCI-E 2.1 DDR5 1GB 4.8GHz 800 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-575X-ZND(*) HD 5750 XXX 740 PCI-E 2.1 DDR5 1GB 4.8GHz 720 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-575X-ZNF(*) HD 5750 Standard 700 PCI-E 2.1 DDR5 1GB 4.6GHz 720 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-575X-YHF(*) HD 5750 Standard 700 PCI-E 2.1 DDR5 512MB 4.6GHz 720 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-567X-ZNF(*) HD 5670 Standard 775 PCI-E 2.1 DDR5 1GB 4GHz 400 Fansink Yes ♦,▲,♠Double X, S, D11,EF 2
HD-567X-YNF(*) HD 5670 Standard 775 PCI-E 2.1 DDR5 512MB 4GHz 400 Fansink Yes ■,▲,♠Standard X, S, D11,EF 2
HD-557X-YNF(*) HD 5570 Standard 650 PCI-E 2.1 DDR3 512MB 1.6GHz 400 Fansink Yes ■,▲,♠Low S, D11, EF --
HD-557X-ZHF(*) HD 5570 Standard 650 PCI-E 2.1 DDR2 1GB 1GHz 400 Fansink Yes ■,▲,○ Standard S, D11 --
HD-557X-ZNF(*) HD 5570 Standard 650 PCI-E 2.1 DDR3 1GB 1.6GHz 400 Fansink Yes ■,▲,♠Low S, D11, EF --
HD-555X-ZAF(*) HD 5550 Standard 550 PCI-E 2.1 DDR5 1GB 4GHz 320 Fansink Ye s ■,▲,♠Standard S, D11, EF --
HD-555X-YHF(*) HD 5550 Standard 550 PCI-E 2.1 DDR5 512MB 4GHz 320 Fansink Yes ■,▲,♠Standard S, D11, EF --
HD-555X-ZNF(*) HD 5550 Standard 550 PCI-E 2.1 DDR2 1GB 1GHz 320 Fansink Yes ■,○,▲Standard S, D11, EF --
HD-555X-YNF(*) HD 5550 Standard 550 PCI-E 2.1 DDR3 1GB 1.6GHz 320 Fansink Yes ■,▲,♠Standard S, D11, EF --
HD-545X-ZNF(*) HD 5450 Standard 650 PCI-E 2.1 DDR2 1GB 1GHz 80 Fansink Ye s ■,○,▲Low S, D11 --
HD-545X-ZHF(*) HD 5450 Standard 650 PCI-E 2.1 sDDR3 1GB 1.6GHz 80 Fansink Yes ■,○,▲Low S, D11 --
HD-545X-YNH(*) HD 5450 Standard 650 PCI-E 2.1 DDR2 512MB 1GHz 80 Heatsink Ye s ■,○,▲Low S, D11 --
HD-545X-ZAF(*) HD 5450 Standard 650 PCI-E 2.1 sDDR3 1GB 1.6GHz 80 Fansink Yes ■,▲,♠Low S, D11, EF --
HD-487A-ZWF(*) HD 4870 Standard 750 PCI-E 2.0 DDR5 1GB 3.6Ghz 800 Fansink Yes ♦Double X, S, DX1 3
HD-485X-ZNF(*) HD 4850 Standard 625 PCI-E 2.0 DDR3 1GB 1.99GHz 800 Fansink ∆♦,● Double X, S, DX1 3
HD-485X-YNF(*) HD 4850 Standard 625 PCI-E 2.0 DDR3 512MB 1.99GHz 800 Fansink ∆■,○ Double X, S, DX1 3
HD-485X-YDF(*) HD 4850 Standard 625 PCI-E 2.0 DDR3 512MB 1.99GHz 800 Fansink ∆♦,● Double X, S, DX1 3
HD-467X-ZDF(*) HD 4670 Standard 750 PCI-E 2.0 DDR2 1GB 800MHz 320 Fansink ∆♦,● Standard S, DX1 --
HD-467X-YAF(*) HD 4670 Standard 750 PCI-E 2.0 DDR2 512MB 800MHz 320 Fansink ∆■,○,● Standard S, DX1 --
HD-467X-DDF(*) HD 4670 Standard 750 PCI-E 2.0 DDR3 1GB 1.6GHz 320 Fansink Yes ■,○,▲Standard S, DX1 --
HD-467X-YHF(*) HD 4670 Standard 750 PCI-E 2.0 DDR3 512MB 1.8GHz 320 Fansink Yes ■,○,▲Standard S, DX1 --
HD-465X-ZDF(*) HD 4650 Standard 600 PCI-E 2.0 DDR2 1GB 1GHz 320 Fansink ∆♦,● Standard S, DX1 --
HD-465X-YAF(*) HD 4650 Standard 600 PCI-E 2.0 DDR2 512MB 800MHz 320 Fansink ∆■,○,● Standard S, DX1 --
HD-457X-ZAF(*) HD 4570 Standard 650 PCI-E 2.0 DDR2 1GB 1GHz 80 Fansink ∆■,○,● Low S, DX1 --
HD-455X-ZAF(*) HD 4650 Standard 625 PCI-E 2.0 DDR2 1GB 800MHz 80 Fansink ∆■,○,● Low S, DX1 --
HD-455X-YAF(*) HD 4550 Standard 625 PCI-E 2.0 DDR2 512MB 1GHz 80 Fansink ∆■,○,● Low S, DX1 --
HD-435X-YAH(*) HD 4350 Standard 600 PCI-E 2.0 DDR2 512MB 800MHz 80 Heatsink ∆■,○,● Low DX1, M --
HD-435X-ZAH(*) HD 4350 Standard 600 PCI-E 2.0 DDR2 1GB 800MHz 80 Heatsink ∆■,○,● Low DX1, M --
HD-435X-YNH(*) HD 4350 Standard 600 PCI-E 2.0 DDR2 512MB 800MHz 80 Heatsink Yes ■,○,▲Low DX1, M --
HD-435X-UAH(*) HD 4350 Standard 600 PCI-E 2.0 DDR2 256MB 1GHz 80 Heatsink Yes ■,○,▲Low DX1, M --
Outputs - ○ VGA, □ DVI, ◊ Dual DVI, ● S-Video and HDTV, ■ DVI w/ Dual-link, ♦ Dual DVI w/ Dual Dual-link, ♥ DMS-59 Output, ▲ HDMI, ♠Display Port , ∆ Supports HDMI with Upgrade Kit,
Features - X=CrossFireX, S=Stream Technology, M=HyperMemory, DX1=DirectX10.1, D11=DirectX11, EF=Eyefinity
Model Number Chipset Version Clk(MHz) Bus Type Type Size Speed•• Stream Cooling HDMI Outputs Profile Features CrossfireX
HD-465X-ZPF(*) HD 4650 Standard 600 AGP DDR2 1GB 800MHz 320 Fansink ∆♦,● Standard DX1 --
HD-465X-YPF(*) HD 4650 Standard 600 AGP DDR2 512MB 800MHz 320 Fansink ∆■,○,● Standard DX1 --
Outputs - ○ VGA, □ DVI, ◊ Dual DVI, ● S-Video and HDTV, ■ DVI w/ Dual-link, ♦ Dual DVI w/ Dual Dual-link, ♥ DMS-59 Output, ▲ HDMI, ∆ Supports HDMI with Upgrade Kit
Features - X=CrossFireX, S=Stream Technology, M=HyperMemory, DX1=DirectX10.1
PCI-Express Products
XFX ATI
AGP Products
XFX ATI
Performance Main Stream
Enthusiast
Performance Main Stream
Enthusiast
www.XFXforce.com
All XFX graphics cards listed are Vista ready.
* See XFXforce.com for the complete model number and package contents. All XFX graphics cards include a Serial Number
Door Hanger or Card for convenient reference. Game bundles may be included with certain models/packing during promotional periods.
** Optimal memory speed. Actual speed may vary. The HD 5970 Black Edition reference GPU and memory clock are set at 725 MHz and 4 GHz respectively.
Its overclock performance will depend on the graphics card, system and environmental conditions.
*** Specications subject to change without notice. See XFXforce.com for the latest information.
Engine Memory
Model Number Chipset Version Clk(MHz) Bus Type Type Size Speed•• Shader Clk Cooling HDMI Outputs Profile Features SLI
GS-250X-ZSL(*) GF GTS 250 Standard 738 DDR3 1GB 2GHz 1836MHz Fansink ∆♦,● Double C, D10, P 3
GS-250X-YDF(*) GF GTS 250 Standard 738 PCI-E 2.0 DDR3 512MB 2.2GHz 1836MHz Fansink ∆♦,● Double C, D10, P 3
GT-240X-ZNF(*) GF GT 240 Standard 550 PCI-E 2.0 DDR3 1GB 1.6GHz 1340MHz Fansink Yes ■,○,▲Double C, DX1, P --
GT-240X-YAF(*) GF GT 240 Standard 550 PCI-E 2.0 DDR3 512MB 2GHz 1340MHz Fansink Yes ■,○,▲Double C, DX1, P --
GT-240X-YHF(*) GF GT 240 Standard 550 PCI-E 2.0 DDR5 512MB 3.4GHz 1340MHz Fansink Yes ■,○,▲Double C, DX1, P --
GT-220X-ZNF(*) GF GT 220 Standard 625 PCI-E 2.0 DDR2 1GB 800MHz 1335MHz Fansink Yes ■,○,▲Standard C, DX1, P --
GT-220X-ZHF(*) GF GT 220 Standard 625 PCI-E 2.0 DDR3 1GB 1.6GHz 1335MHz Fansink Yes ■,○,▲Standard C, DX1, P --
GT-220X-YHF(*) GF GT 220 Standard 625 PCI-E 2.0 DDR3 512MB 1.8GHz 1335MHz Fansink Yes ■,○,▲Standard C, DX1, P --
GM-210X-YNF(*) GF G 210 Standard 589 PCI-E 2.0 DDR2 512MB 800MHz 1402MHz Fansink Yes ■,○,▲Low C, DX1, P --
GM-210X-YAF(*) GF G 210 Standard 589 PCI-E 2.0 DDR2 512MB 800MHz 1402MHz Fansink Yes ■,○ Low C, DX1, P --
PV-T95G-ZAF(*) GF 9500 GT Standard 550 PCI-E 2.0 DDR2 1GB 800MHz 1375MHz Fansink ∆■,○,● Low C, D10, P 2
PV-T95G-YAJ(*) GF 9500 GT Standard 550 PCI-E 2.0 DDR3 512MB 1.6GHz 1700MHz Fansink ∆■,○,● Low C, DX1, P --
PV-T95G-YAR(*) GF 9500 GT Standard 550 PCI-E 2.0 DDR2 512MB 800MHz 1375MHz Fansink ∆■,○,● Low C, D10, P 2
PV-T94G-Y1S(*) GF 9400 GT Standard 550 DDR2 1GB 800MHz 1400MHz Fansink ∆■,○,● Low C, D10, P --
PV-T94G-YAJ(*) GF 9400 GT Standard 550 PCI-E 2.0 DDR2 512MB 800MHz 1400MHz Fansink ∆■,○,● Low C, D10, P --
PV-T94G-YHH(*) GF 9400 GT Standard 550 PCI-E 2.0 DDR2 512MB 800MHz 1400MHz Heatsink ∆■,○,● Standard C, D10, P --
PV-T94G-YRF(*) GF 9400 GT Standard 550 PCI-E 2.0 DDR2 512MB 800MHz 1400MHz Heatsink ∆■,○ Low C, DX1, P --
PV-T86S-WHL(*) GF 8400 GS Standard 567 PCI-E DDR2 256MB 800MHz 1350MHz Heatsink ∆□,○ Low D9 --
PV-T86S-YHL(*) GF 8400 GS Standard 567 PCI-E DDR2 512MB 800MHz 1350MHz Heatsink ∆□,○ Low D9 --
Outputs - ○ VGA, □ DVI, ◊ Dual DVI, ● S-Video and HDTV, ■ DVI w/ Dual-link, ♦ Dual DVI w/ Dual Dual-link, ♥ DMS-59 Output, ▲ HDMI, ∆ Supports HDMI with Upgrade Kit
Features - C=CUDA, D9=DirectX9, D10=DirectX10, P=PhysX, T=TurboCache, DX1=DirectX10.1
s = support up to
PCI-Express Products
XFX NVIDIA
Model Number Version Wattage +3.3V +5V +12V -12V +5VSB Input Voltage Input Current Input Frequency Modular Active PFC Cooling Fan
P1-850B-CAG9 Black 850W 24A 30A 70A 0.8A 3A 90-264 VAC 12A 47-63 Hz Yes Yes Yes
P1-850B-NLG9 Black 850W 24A 30A 70A 0.8A 3A 90-264 VAC 12A 47-63 Hz Yes Yes Yes
P1-750B-CAG9 Black 750W 24A 30A 62A 0.8A 3A 90-264 VAC 10A 47-63 Hz Yes Yes Yes
P1-750B-NLG9 Black 750W 24A 30A 62A 0.8A 3A 90-264 VAC 10A 47-63 Hz Yes Yes Yes
P1-650X-CAG9 XXX 650W 24A 30A 52A 0.8A 3A 90-264 VAC 10A 47-63 Hz Yes Yes Yes
P1-650X-NLG9 XXX 650W 24A 30A 52A 0.8A 3A 90-264 VAC 10A 47-63 Hz Yes Yes Yes
P1-650X-CAH9 XXX 650W 24A 30A 52A 0.8A 3A 90-264 VAC 10A 47-63 Hz Yes Yes Yes
P1-650X-NLH9 XXX 650W 24A 30A 52A 0.8A 3A 90-264 VAC 10A 47-63 Hz Yes Yes Yes
* Specications subject to change without notice. Power supply appearance may vary. XFX power supplies come with a 5-year Limited Warranty, subject to registration. See XFXforce.com
for details and latest product information.
PSU Products
Model Number Description Platform Input Available Outputs Contents
MA-BK01-LP2K XFX Low Profile Bracket Kit Low Profile PC -- DVI, VGA, S-Video 3 Selectible Low Profile Brackets, 1 VGA Port Cable
MA-BK01-LP1K XFX Low Profile Bracket Kit Low Profile PC -- HDMI, DVI, VGA, S-Video 3 Selectible Low Profile Brackets, 1 Dual Slot Low Profile Bracket, 2 VGA Port Cables
MK-HDMI-UP1K HDMI Upgrade Kit HDMI Capable Graphics cards -- -- HDMI Cable, DVI to HDMI Adapter, SPDIF Cable
Accessories
