xG Technology CN3200 User manual

G7603 - Release 2.0

2
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
Product features and specifications are subject to change without prior notice.
xG® and xMax® are registered trademarks of xG Technology, Inc.
All other trademarks used herein are property of their respective owners.
For the latest product documentation and software
updates, please refer to our Web site at
www.xGTechnology.com/support
xG Technology, Inc.
240 South Pineapple Avenue, Suite 701
Sarasota, FL 34236
[phone]
www.xGTechnology.com

3
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
Table of Contents
Introduction ...............................................................................................................5
About this Product....................................................................................................................5
About this Book ........................................................................................................................5
Hardware Overview..................................................................................................................5
Powering the CN3200 Modem .................................................................................................6
Important Safety and Installation Notices...................................................................7
FCC Part 15 Requirement .........................................................................................................7
Hazard.......................................................................................................................................7
FCC Compliance ........................................................................................................................7
RF Exposure ..............................................................................................................................8
Connecting the CN3200 Dual Band Routing Modem to the xMax Network .................9
Connecting Wireless Devices to the xMax Network ..................................................10
Wired Internet Connectivity and Setting Up a WiFi Hotspot......................................11
Wired Internet Connectivity...................................................................................................11
Technical Specifications ............................................................................................12
Warranty ..................................................................................................................13
Limited Warranty....................................................................................................................13
SCOPE OF THE WARRANTY.............................................................................................................. 13
ADDITIONAL PROVISIONS OF THE WARRANTY ............................................................................... 14
OBTAINING SERVICE AND SUPPORT UNDER WARRANTY............................................................... 15
EXCLUSIVITY OF THE WARRANTY.................................................................................................... 15

4
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
THIS PAGE INTENTIONALLY LEFT BLANK

5
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
The CN3200 Dual Band Routing Modem is a ruggedized subscriber device. It is waterproof and made
to handle wide temperature ranges. While primarily designed for use in fixed locations, it may also be
used in vehicular applications. It enables any Internet-ready device to connect to the xMax network,
when paired with a WiFi access point either wirelessly or through a wired Ethernet connection.
This manual provides basic instructions for installation and configuration of the CN3200 Modem. It
also describes how to connect to the xMax Network and then connect Internet-enabled wireless
devices to the xMax Network.
The CN3200 Dual Band Routing Modem is a self-contained IEEE 802.11b/g access point which
provides any device connected to its Ethernet port access to the xMAX network. When paired with a
WiFi hotspot it provides access to the xMAX network to WiFi enabled devices. The CN3200 Modem is
totally protected against dust and moisture.
IMPORTANT: The CN3200 is professionally installed.

6
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
The CN3200 Modem is a Power-over-Ethernet (PoE+) device.
The IEEE 802.3at PoE+ standard enables transmission of both data and the power to operate a
device over a single Cat5/5e/6 cable connection.
The CN3200 Modem REQUIRES a PoE++ adaptor, as supplied.
The device will NOT operate with a low-power PoE switch or adaptor.
IMPORTANT: BEFORE YOU CONTINUE
Antennas or dummy loads MUST be connected to the two top Tx RF ports.
Both Tx RF ports MUST be properly terminated
before power is applied to the unit.
Applying power without proper RF port
termination might damage the unit
and void the product warranty.

7
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
These notices apply to the CN3200 Dual Band Routing Modem.
Be sure to read, understand and follow these instructions.
Heed all warnings.
Only use accessories and attachments specified by xG Technology.
Keep a copy of these instructions for future reference.
The CN1300 xMax 2.4 GHz Access Point MUST only be installed by a professional installer. It is the
responsibility of the installer to adjust the transmit power level to ensure that the output power plus
antenna gain does not cause the device to exceed FCC Part 15 output power regulations.
ous situation, which if not avoided,
could result in death or serious injury.
All antennas MUST either be located on the exterior of a vehicle or mounted on a pole.
Every antenna MUST be separated from users by more than 25 cm (0.82 ft) at all times.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio technician for help.

8
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of
25 cm (0.82 ft) between the radiator and your body. This transmitter must not be co-located
or operating in conjunction with any other antenna or transmitter.

Changes or modifications to this device not expressly approved
by xG Technology could void the user’s authority to operate
the equipment and void the product warranty.

9
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
IMPORTANT
Before you begin this step, it is assumed that the CN3200 Dual Band Routing Modem has been
configured as described in the CN3200 Dual Band Routing Modem Installation Guide. This was
completed by the device installer.
These steps connect the CN3200 Modem to an xMax network.
1. Connect the PoE++ Power Supply power cable to a 110 to 240 VAC power source.
2. If the CN3200 Modem is within range of an xMax Network, it connects within 2 minutes.
3. The CN3200 Dual Band Routing Modem is now fully functional.
NOTES
If the CN3200 Modem fails to connect to an xMax network after two minutes have elapsed,
ensure that the power indicator on the Power Supply is glowing GREEN.
If the CN3200 Modem is within range of an operating xMax Network, but not connecting,
follow these steps to restart the CN3200 Modem:
Power off the CN3200 Modem by disconnecting the AC cord from the Power Supply.
Wait 60 seconds.
Reconnect the AC cord to power on the CN3200 Modem.
If the CN3200 Dual Band Modem still does not connect to the xMax Network, call the service
provider to report your problem.

10
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
When within range of a WiFi router connected to the CN3200 Dual Band Routing Modem, any
Internet-ready device has the ability to securely connect to the Internet through the xMax Network.
These steps connect WiFi devices to the xMax Network.
1. Configure a WiFi-enabled device for Internet Protocol Version 4 (TCP/IPv4) and DHCP operation.
2. Enter the SSID and password to match that of the user-supplied WiFi router that is connected to
the CN3200. This information should have been provided by the installer.
Once connected, the device can be used for any common Internet function.

11
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
A properly configured device, such as a PC or laptop computer, can be wired directly to the
CN3200 Dual Band Routing Modem for Internet access.
1. Configure the device network interface for DHCP operation.
2. Using an Ethernet cable, connect the device to the CN3200 Dual Band Routing Modem.
The CN3200 Modem can be used to create a WiFi hotspot.
1. Using an Ethernet cable, connect a WiFi router to the CN3200 Modem.
2. Configure the WiFi router according to the manufacturer instructions.

12
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
xMax RADIO
Tx Power Output AVG:
RANGE: 5 to 24 dBm in 1 dB steps
Receiver Sensitivity
-100 dBm BPSK / -90 dBm QAM64
2.4 GHz RADIO
Tx Power Output AVG:
Tx Power Output AVG:
8.5 to 21 dBm in 1 dB steps
Receiver Sensitivity
-93 dBm BPSK / -74 dBm QAM64
SYSTEM OVERVIEW
Frequency Band 1:
904.2 to 925.8 MHz
Channel size:
1.44 MHz
Modulation:
Adaptive BPSK / QPSK / QAM16 / QAM64
Spectral Efficiency:
Up to 4.25 Bits/Hz
PHY Protocol:
Proprietary OFDM, 2x4 MIMO
Mobility:
Up to 100 MPH
Raw Data Rate :
Up to 6 Mbps
Frequency Band 2:
2412-2462 MHz
Channel size:
20 MHz
Modulation:
Adaptive BPSK / QPSK / QAM16 / QAM64
Spectral Efficiency:
Up to 3.61 Bits/Hz
PHY Protocol:
OFDM
Mobility:
Fixed
Raw Data Rate :
Up to 72.2 Mbps
ANTENNA CONNECTORS
Four N-type female (xMax), one TNC-type female (2.4 GHz)
POWER
PoE++ (Power over Ethernet Plus)
PHYSICAL DESCRIPTION
Size:
8.5” x 7.5” x 3.5” (21.59 cm x 19.05 cm x 8.89 cm)
Weight:
5 lbs (2.27 kg)
ENVIRONMENTAL
Operating Temp:
-40° F to 122° F (-40° to 50° C)
Water/Dust:
IP67
Humidity:
0-100% condensing
ESD:
ESD ±30 kV
REGULATORY
EMC:
FCC CFR 47 Part 15 Class B
Vibration and Shock:
MIL-STD 810F Method 514.5 Vibration (constant acceleration),
MIL-STD 810F Method 516.5 Shock

13
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
CN3200 Dual Band Routing Modem
xG Technology, Inc. (“xG”)
240 South Pineapple Avenue, Suite 701
Sarasota, FL 34236
SCOPE OF THE WARRANTY
Unless a different period is specified for a particular hardware Product, or in a sales agreement
between xG and customer, or in the published specification sheet for the hardware Product, xG's
hardware Products are generally warranted against defects in workmanship and materials for a
period of twelve (12) months from the date of original purchase, provided the Product remains
unmodified and is operated under normal and proper conditions. Unless otherwise so provided the
warranty period for computer programs in machine-readable form included in a hardware Product,
which are essential for the functionality will be coincident with the warranty period of the
hardware Product. Software patches, bug fixes or workarounds do not extend the original warranty
period. For Software sold by xG and run outside the hardware Product (e.g. xMCC), the warranty
term is 90 days from date of original purchase. All accessories (e.g. antennas, cables, power supply,
POE) carry a warranty term of 90 days from date of original purchase.
The Limited Warranty extends only to the original purchaser of the Product from xG, or its
authorized Resellers, and is not assignable or transferable to any subsequent purchaser or end-
user.
xG’s warranty applies only to a Product that is manufactured by or for xG Technology and is
identified within xG’s price book at time of purchase . Any products not covered by xG’s warranty,
but supplied under the customer's Purchase Order with xG as part of the delivered equipment, are
covered under that manufacturer's standard warranty and any warranty claims should be handled
directly with that manufacturer.
xG’s warranty shall not apply: (i) to any Product subjected to accident, misuse, neglect, alteration,
acts of God, improper handling, improper transport, improper storage, improper use or application,
improper installation, improper testing or unauthorized repair; (ii) use of parts or accessories not
approved or supplied by xG, or failure to perform operator handling and scheduled maintenance
instructions supplied by xG or (iii) to cosmetic problems or defects that result from normal wear
and tear under ordinary use, and do not affect the performance or use of the Product.
If the Product develops a covered defect within the warranty period, xG will, at its option, either
repair or replace the Product found by xG to be defective or not in conformity with material
specifications, provided that the Product is returned during the warranty period.

14
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
Customer is responsible for shipment to xG (or authorized service provider) and assumes all costs
and risks associated with this transportation; return shipment to the Customer will be at xG’s
expense. Customer shall be responsible for return shipment charges for Product returned where xG
determines there is no defect ("No Defect Found"), or for Product returned that xG determines is
not eligible for warranty repair. No charge will be made to customer for replacement parts for
warranty repairs.
Product that has been repaired or replaced may consist of refurbished equipment that contains
used components, some of which have been reprocessed. The used components comply with xG
Product performance and reliability specifications. The repair services provided are warranted
against defects in workmanship and materials on the repaired component of the product for a
period of 30 days from the shipment date of the repaired product, or until the end of the original
warranty period, whichever is longer.
xG is not responsible for any damage to or loss of any software programs, data or removable data
storage media, or the restoration or reinstallation of any software programs or data other than the
software, if any, installed by xG during manufacture of the Product or shipped with Product. xG’s
sole obligation for software that when properly installed and used does not substantially conform
to the published specifications in effect when the software is first shipped by xG, is to use
commercially reasonable efforts to correct any reproducible material non conformity (as
determined by xG at its sole discretion) by providing Customer with: (a) telephone or e-mail access
to report non conformance so that xG can verify reproducibility; (b) a software patch or bug-fix, if
available, or a workaround to bypass the issue, if available; and (c) where applicable, replacement
of damaged or defective external media, such as a CD-ROM disk, on which the software was
originally delivered. xG does not warrant that the use of the software will be uninterrupted, error-
free, free of security vulnerabilities, or that the software will meet Customer’s particular
requirements. Customer’s sole and exclusive remedy for breach of this warranty is, at Seller's
option, to receive (i) suitably modified software, or part thereof, or (ii) comparable replacement
software or part thereof.
ADDITIONAL PROVISIONS OF THE WARRANTY
Because it is impossible for xG to know the purposes for which the purchaser acquired this Product
or the uses to which this Product will be put, the purchaser assumes full responsibility for the
selection of the Product for its installation and use. While every reasonable effort has been made
to insure that the purchaser will receive a Product that can be used and enjoyed, xG does not
warrant that the functions of the Product will meet the purchaser’s requirements or that the
operation of the Product will be uninterrupted or error-free. xG is not responsible for problems
caused by the interaction of the Product with any other software or hardware.

15
Dual Band Routing Modem - Quick Start Guide - G7603 - Release 2.0
OBTAINING SERVICE AND SUPPORT UNDER WARRANTY
To obtain warranty service or technical support, please contact the party from whom you
purchased the product. If you purchased the product directly from xG, contact your xG Sales
Representative or call 754-206-4800. To take advantage of this Limited Warranty Purchasers are
required to supply an original point of purchase receipt. Returned Product must be accompanied by
the purchaser’s sales receipt or comparable substitute proof of sale showing the date of purchase,
the serial number of Product, and the sellers’ name and address (if purchased through a authorized
xG reseller).
EXCLUSIVITY OF THE WARRANTY
This Limited Warranty Policy shall be the sole and exclusive remedy of the purchaser with respect
to xG’s Products. xG's sole liability on any claim arising out of the sale of the Product or xG's
replacement of defective product, whether in contract, warranty, tort, or otherwise shall be limited
to the purchase price of the goods that prove defective or nonconforming. In no event shall xG be
liable for, and purchaser shall hold xG harmless from, any damages, direct, indirect, or
consequential, whether resulting from xG's negligence or otherwise, arising out of, in connection
with, or resulting from the goods sold to the Purchaser (including, without limitation, damages, for
loss of business profits, business interruption, loss of information, or any other pecuniary loss), and
any and all claims, actions, suits, and proceedings which may be instituted in respect to the
foregoing, including those made by subsequent owners and users of the goods. In no event shall xG
be liable for damages from alleged negligence, breach of warranty, strict liability, incidental or
consequential damages, or any other theory, other than the Limited Warranty set forth herein.
xG neither assumes nor authorizes any of its dealers, representatives, or any other person or entity
to assume for it any other obligation or liability beyond that which is expressly provided for in this
Limited Warranty.
xG MAKES NO WARRANTY OTHER THAN THE LIMITED WARRANTY REFERRED TO HEREIN. THIS
LIMITED WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER EXPRESS OR IMPLIED
WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, AND IT CONSTITUTES THE ONLY WARRANTY MADE WITH RESPECT TO THE
GOODS COVERED BY THESE TERMS AND CONDITIONS. xG SHALL UNDER NO CIRCUMSTANCES BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.

G7603 - Release 2.0
© Copyright xG Technology, Inc. 2014. All Rights Reserved.
xG Technology, Inc.
240 South Pineapple Avenue, Suite 701
Sarasota, FL 34236
[phone]
www.xGTechnology.com
