Xiaomi Stick for Yi Camera User manual

Stick for Yi Camera
4. Using of the monopod
1.Standard Accessories
Remote control
Manual
Monopod
Direction down - open the lock
Direction upwards - close the lock
Fixing Camera
Make sure that you have turned
the rotation pointer, then you can
adjust the length of the monopod.
Otherwise there will be problems
with regulation of the length of
the monopod. After selecting
the required length, rotate the
monopod to lock it.
2.Using of the remote control
Pair
Double click
sound, and then the blue LED will light up. Log in
connection mode via Bluetooth.
Indicator
Shutter button
After this, you no longer need to re-connect to the remote
control. One click on the shutter button - and you can
begin to use the camera. The red light indicates an error in
pairing of two devices.
Press the shutter button, then you will hear sound, and
at the same time illuminates a blue LED that indicates
successful pairing.
3. Shooting
Shoot
Switch button
Camera mode: press the shutter button.
Video mode: press the shutter button to start/stop shoot
video.
5. Setting the remote controller to a monopod
Open the
clamping set
Install/ remove
controller

Stick for Yi Camera
Name: Stick for Yi Camera
Contents: monopod, remote control
CMIIT ID: 2015DJ2029
Material: aluminum, spring steel, silicone, plastic alloy
Model: LYZPG01XY
The current standard is: Q31 / 0115000160C002
Q31 / 0115000160C003
Producer: «Yi Technology Shanghai»
Address: Shanghai, district Phudun, Dzinkhe st, 2889, pl
Chhanthay, Ezdanie, 6th Floor
Phone service: 400 100 5678
Version: CHYKQ -0527-1
4. Changing the batteries
Remove the rubber rim
Rotate the back panel
Turn up the back cover ... .. and then change the battery.
You can use a coin so that you can easily turn the back
cover, and then remove it.
Guarantee
The list of circumstances (including, but not limited to),
under which compensation is not possible:
- The end of maintenance period, fall, neglect, abuse,
liquid ingress, accident, broken or slipped the label and
marking device;
- The warranty period is ended;
The presence of toxic and hazardous
substances
There are no any of elements of Pb,Hg,Cd,Cr6+, P,
BB, PBDE in product or its presence is lower than
the limit value according to SJ / T11363-2006
requirements.
Terms of Service
within 7 days after the purchase (after signing a
guarantee of 7 days)
2. Return of goods is only possible with its package
3. In the event of a problem, you can return within 7
days after the signing of the guarantee
4. Return of goods is only possible with its package
in case of a problem, goods can be replaced within
15 days after the signing of the guarantee
In the event of problems, possible free warranty
repair of the goods within 1 year after the signing of
the guarantee
Warranty service is carried out in accordance with the law
on «the rights of consumers of China» and «Law of the PRC
on the quality of products.» The warranty service includes:
During the warranty period you have the right to repair,
exchange or return an item. For repair, replacement or
return of goods you need to present a receipt.
