Xiaomi MI Electric Shaver S101 User manual

Electric Shaver S101 User Manual

01
Suitable for cleaning
under an open water tap
Safety Instructions
WARNINGS
CAUTIONS
Keep the appliance dry.
Detach the hand-held part from the supply cord before
cleaning it in water.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
Use only with <A520-050100U-EU1> supply unit.
This appliance contains batteries that are non-replaceable.
For the purposes of recharging the battery, only use the
detachable supply unit provided with this appliance.
The plug must be removed from the socket-outlet before
cleaning or maintaining the appliance.
Appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Cleaning and user maintenance shall not be made by children
without supervision.
Do not charge this shaver in humid environments.
Do not disassemble the body to replace the battery.
Do not modify or repair this shaver yourself.
The appliance is not suitable for use in a bath or shower.
Do not expose the appliance or battery to excessive temperatures.
Be aware of the risk of terminals of the battery-operated appliance
or battery being short circuited by metal objects.

02
Protective
Cover
Shaver Body
Shaving Head
On/Off Button
Product Overview
Shaving Head
Holder
(Non-detachable)
User
Manual
Charging
Cable
Power
Adapter
Note: Illustrations of product, accessories, and user interface in
the user manual are for reference purposes only. Actual product
and functions may vary due to product enhancements.
Travel Lock Indicator
Battery Level Indicator
Warranty
Notice
Charging Port
(Keep Dry)

03
How to Use
Do not pull the shaving head holder as it is non-detachable.
Note:
It is recommended to clean the shaving head before first
use.It is normal for the skin to be slightly irritated after the first
few shaves. It is recommended to regularly use the shaver (at
least 3 times a week) for 3 weeks to allow the skin to adapt as
quickly as possible.
Press the on/off button to turn on/off the shaver.
Apply gentle pressure while shaving your face slowly in
circular motions.
Shave dry for optimal result. When shaving the hard-to-shave
areas such as the chin and neck, it is recommended to move
the shaver against the direction of the beard growth.
Improper use of this shaver can easily cause damage to the
shaving head. Please check whether the shaving head is intact
before use. Immediately stop using the shaving head if any
damage is found.
Notes:

04
Battery Level Indication
Note: The shaver supports Pass Through Charging. When the
low, you can use the shaver during charging.
CAUTION: Never plug in or use the shaver in the shower or when
the charging port is wet.
Battery Level
While Charging
0%–40%
100%
40%–100%
Blinking orange
Keeping white
Blinking white
Plug the charging cable into the charging port and connect it to
a power outlet to start charging. Description of the battery level
indicator status is as below:
Battery Level
Indicator
Battery Level
While Working
Charging Port
(on the back of
the shaver)
<10%
40%–100%
20%–40%
10%–20%
Quickly blinking
orange three times
(unable to turn on)
Keeping white
Keeping orange
Blinking orange
Indicator Status
Indicator Status
battery is

05
When the shaver cannot be turned on due to a low battery, it will
take about 90 minutes to fully charge it. The shaver can be used
for about 60 minutes after a full charge. Please charge the
shaver when its battery is low. Fully charge the shaver at least
once every 6 months if it will not be used for an extended period
of time.
Travel Lock
This shaver is equipped with a travel lock to prevent it from
accidentally being turned on while it is inside the luggage.
Enabling the travel lock: When the shaver is turned off, press
and hold the on/off button for 2.5 seconds until the motor
stops to enable the travel lock. Once it is enabled, the travel
lock indicator will keep on for 3 seconds and then go off.
Disabling the travel lock: Press and hold the on/off button for
2.5 seconds until the motor runs to disable the travel lock.
Travel lock
enabled
Note: When the travel lock is enabled, if you press the
on/off button, the travel lock indicator will blink.

06
Care & Maintenance
1. Make sure the shaver is turned off and is not being
charged before cleaning it.
To ensure optimal functionality, please clean the shaver
after each use.
Note: The shaver can be cleaned under a faucet (to keep
the charging port dry, make sure it is firmly covered).
3. Pull the shaving
head and remove
it from the holder.
4. Rinse or use the
cleaning brush to
clean the shaving
head holder.
Note: Use the
protective cover to
cover the charging
port while cleaning
the shaver. Make
sure the charging
port is dry when
plugging in the
cable to charge.
5. Turn the shaving
head upside-down
and clean the
inside under a
faucet (do not use
a towel or paper
towel to clean the
shaving head).
6. Thoroughly dry
off the shaver,
then install the
shaving head back
onto the holder.
2. Rinse the
shaving head
under a faucet.
To ensure the performance of the shaver, it is recommended
to replace the shaving head every half a year. Please go to
www.mi.com to purchase a replacement.

07
Environmental Protection
When the shaver reaches the end of its service life, please
remove, dispose of, or recycle the built-in battery in accordance
with local laws and regulations of the country or region where
the shaver is used. If the battery cannot be removed, dispose of
it in strict accordance with local regulations on household
waste management in your area.
This shaver contains a non-replaceable battery.
Do not expose the battery to fire to prevent it from exploding
or releasing toxic and hazardous substances.
Do not short-circuit the battery to prevent it from combusting
and causing fire.
The battery must be removed from the appliance before it is
scrapped.
The appliance must be disconnected from the supply mains
when removing the battery.
The battery is to be disposed of safely.
Do not disassemble the shaver unless you want to dispose of
it; otherwise, the shaver will be damaged.
Make sure to operate in a safe manner and unplug the shaver
before removing the battery.
WARNINGS:

08
Shaver not
working after
pressing the
on/off button
The shaving head
(including blade
mesh) is damaged
or worn out.
The shaving head
is clogged up with
stubbles.
The travel lock is
enabled.
Press and hold the
on/off button for 2.5
seconds to unlock.
Connect the charging
cable to charge.
Contact the after-sales
service team.
The battery is
depleted.
The on/off button
does not function.
It takes a certain
period of time for
your skin to adapt
to the shaver.
Skin irritation will
fade after 2–3
weeks of use.
Charge in an ambient
temperature between
5°C and 35°C.
Contact the after-sales
service team.
Reconnect the charging
cable.
The charging port
contact is poor.
The charger may be
damaged.
The charging
ambient temperature
is too low or too high.
Irritated skin
after shaving
Troubleshooting
Issues Possible Causes Solutions
Poor-quality
shaving
Charging
error
Replace with a
genuine shaving head.
Thoroughly clean
the shaving head.
Replace the charger.
The shaver is
damaged.

09
Usage time
less than 60
minutes after
being fully
charged
The load on the
motor is increased
as the shaving head
hasn't been cleaned
for a long time.
Thoroughly clean the
shaving head.
Shave in a
normal way.
It may be caused by
the shaving method
and beard density.
Specifications
Name: Xiaomi Electric Shaver S101
Model: S101
Input: 5 V 1 A
IP Rating: IPX7
Charging Port: Type-C
Charging Time: Approx. 90 min
Operating Voltage/Power: 3.7 V /3 W

Use only with <A520-050100U-EU1>
supply unit.
Read operator's manual.
A520-050100U-EU1
10
Power Adapter
Efficiency at
Low Load (10%) %64.588
Average Active
Efficiency %73.77
No-load Power
Consumption W0.075
Output Power W5.0
Output Current A1.0
Output Voltage 5.0
Input AC
Frequency Hz
50/60
lnput Voltage V~
100–240
lnput: 100–240
V~, 50/60 Hz, 0.2
Output: 5.0 V 1.0 A,
5.0 W
Model ldentifier —
—
A520-050100U-EU1
lnformation
Published
UnitValue and
Precision
Jiangxi Jian Aohai
Technology Co., Ltd.
Manufacturer's
Name
V

11
We, Shenzhen Soocas Technology Co., Ltd., hereby, declares
that this equipment is in compliance with the applicable
Directives and European Norms, and amendments. The full text
of the EU declaration of conformity is available at the following
internet address:
http://www.mi.com/global/service/support/declaration.html
Europe-EU Declaration
of Conformity
WEEE Disposal and
Recycling Information
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU)
which should not be mixed with unsorted household
waste. Instead, you should protect human health and the
environment by handing over your waste equipment to a
designated collection point for the recycling of waste
electrical and electronic equipment, appointed by the
government or local authorities. Correct disposal and
recycling will help prevent potential negative
consequences to the environment and human health.
Please contact the installer or local authorities for more
information about the location as well as terms and
conditions of such collection points.

12
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Shenzhen Soocas Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 401, 402, 1101, 1102, 1103, 1104, Building 2
Chongwen Area, Nanshan iPark, No. 3370 Liuxian Avenue,
Fuguang Community, Taoyuan Subdistrict, Nanshan District,
Shenzhen, China
For further information, please go to www.mi.com
Made in China
User Manual Version: V1.0
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
