Xiaomi Electric Shaver S301 User Manual

Safety Instructions
WARNINGS
Keep the appliance dry.
Detach the hand-held part from the supply cord before cleaning
it in water
This appliance is not intended for use by persons (including
children) with reduced physical senosry or mental capabilities
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
Use only with <A520-050100U-EU1> supply unit.
This appliance contains a battery that is non-replaceable.
WARNING: For the purposes of recharging the battery, only use
the detachable supply unit provided with this appliance.
The plug must be removed from the socket-outlet before cleaning
or maintaining the appliance.
Appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or nstruction concerning use of the appliance in
a safe way and understand the hazards involved.
CAUTIONS
Cleaning and user maintenance shall not be made by children
without supervision.
Do not charge this shaver in humid environments.
Do not disassemble the body to replace the battery.
Do not modify or repair this shaver yourself.
The appliance is not suitable for use in a bath or shower.
Do not expose the appliance or battery to excessive temperatures.
Be aware of the risk of terminals of the battery-operated appliance
or battery being short circuited metal objects.
Suitable for cleaning under an open water tap
Use only with <A520-050100U-EU1>
supply unit.
Read operator‘s manual.

Do not expose the appliance or battery to excessive temperatures.
Be aware of the risk of terminals of the battery-operated appliance
or battery being short circuited metal objects.
Product Overview
Protective
Cover
Shaving Head
Shaving Head
Holder
User Manual Cleaning
Brush
Warranty Notice
Shaver
Indicators
Extra Speed
Travel Lock
Clean/Error
Battery Level
On/Off & Lock
Button
Charging Port
(Keep Dry)
Note: Illustrations of product, acessories, and user interface in the
user manual are for reference purposes only. Actual product and
functions may vary due to product enhancements.
Power
Adapter
Charging
Cable

How to Use
Notes:
It is normal that the skin is slightly irritated after the first few shaves.
It is recommended to regularly use the shaver (at least 3 times a
week) for 3 weeks to allow the skin to adapt as quickly as possible.
Improper use of this shaver can easily cause damage to blade
meshes and shaving head. Please check whether the blade meshes
and shaving head are intact before use. Immediately stop using the
shaver if any damage is found.
Turning on/off:
Turning on/off: Press the on/off button.
Once the shaver is turned on, the clean/error, travel lock, and
extra speed indicators will turn on and off in sequence, and the extra
speed indicator will light up again or remain off according to the
speed settings enabled. The battery level indicator will show the
current battery level. Once the shaver is turned off, all indicators will
go off.
Adjusting the speed settings:
The first time the shaver is turned on, by default it is set to smart
speed. The next time it is turned on, by default the speed settings will
be the same as it was last time the shaver was turned off.
While the shaver is turned on, press and hold the on/off button for
1 second to switch the speed settings between extra speed (extra
speed indicator is on) and smart speed (extra speed indicator is off).
Smart speed: Once selected, the shaver usually works at the normal
rotation speed. When the working load on the motor increases, the
shaver will automatically increase the rotation speed and maintain
a high rotation speed for 10 seconds.
Extra speed: Once selected, the shaver will maintain a high rotation
speed throughout the shave. This is good for shaving dense beard
quickly.
Note:
Apply gentle pressure and shave your face slowly in circular motions.
It is not necessary to repeatedly shave the same area to achieve
a clean shave. Shave dry for an optimal result.

Travel Lock
This shaver is equipped with a travel lock to prevent it from
accidentally being turned on while it is inside the luggage.
Enabling the travel lock: When the shaver is turned off, press and
hold the on/off button for 2,5 seconds until the motor stops to
enable the travel lock. Once it is enabled, the travel lock indicator
will blink for 3 seconds and then go off.
Disabling the travel lock: Press and hold the on/off button for
2,5 seconds. The travel lock indicator will blink for 3 seconds and then
go off, and the motor will run, indicating that the travel lock is disabled.
Note: When the travel lock is enabled, if you press the on/off button,
the travel lock indicator will blink, but the motor will not be activated.

Battery Level Indication
To charge the shaver, connect the USB end of the charging cable to
the charger and the Type-C end to the charging port of the shaver.
While charging the battery level indicator will breathe and the number
will increase. Once the shaver is fully charged, the battery level
indicator will remain at 100 %.
Operating
Charging
When the shaver cannot be turned on due to a low battery, it will take
about 2 hours to fully charge it. The shaver can be used for about
1,5 hours after a full charge. Please charge the shaver when its battery is
low. Fully charge the shaver at least once every 6 months if it will not
be used for an extended period of time.
Note: The shaver supports plug-and-play. When the battery is low, you
can use the shaver during charging.
CAUTION: Never plug in or use the shaver in the
shower or when the charging port is wet.
Battery Level Indicator Status
Keeping on
Blinking
Unable to turn on
Breathing
Keeping on
100 %
0 % - 99 %
0 %
6 % - 100 %
Ƶ

Cleaning & Maintenance
If the clean/wrror indicator blinks for 5 seconds and then goes off
while the battery level indicator is on after the shaver is turned on,
please clean the shaver. The clean/error indicator will automatically
blink for 5 seconds once every 15 minutes of use to remind the user to
regularly clean stubble buildup from the shaver.
1.Make sure the shaver is turned off and is not being charged before
cleaning it.
2. Rinse the shaving
head under a faucet
(warm water is
recommended).
3. Pull the shaving
head and remove
it from the holder.
4. Rinse or use the
cleaning brush to
clean the shaving
head holder.
5. Turn the shaving
head upside-down and
clean the inside of the
shaving head under a
faucet. Warm water is
recommended. Do not
use a towel or paper
towel to clean the
shaving head.
6. Thoroughly dry off
the shaver, then
install the shaving
head back onto the
holder.
Note: Use the
protective cover to
cover the charging
port while cleaning
the shaver. Make
sure the charging
port is dry when
plugging in the
cable to charge.
The shaver can be cleaned under faucet. To Keep the
charging porty dry, make sure it is firmly covered.
Note: To ensure the performance of the shaver, it is recommended to
replace the shaving head once every 2 years. Please go to www.mi.com
to purchase a replacement.

Environmental Protection
When the shaver reaches the end of its service life, please remove,
dispose of, or recycle the built-in battery in accordance with local laws
and regulations of the country or region where the shaver is used.
If the battery cannot be removed, dispose of it in strict accordance with
local regulations on household waste management in your area.
WARNINGS:
Do not expose the battery to fire to prevent it from exploding or
releasing toxic and hazardous substances.
Do not short-circuit the battery to prevent it from combusting and
causing fire.
Do not disassemble the shaver unless you want to dispose of it;
otherwise, the shaver will be damaged.
Make sure to operate in a safe manner and unplug the shaver before
removing the battery.
The battery must be removed from the appliance before it is
scrapped.
The appliance must be disconnected from the supply mains when
removing the battery.
The battery is to be disposed of safely.
Removing the battery:
Note: Make sure the battery is completely depleted before removing it.
1.Use a small flathead screwdriver to pry open the bottom cover and
remove the on/off button of the shaver. These parts cannot be
restored once they are disassembled.
Bottom Cover On/Off Button

Troubleshooting
Issues Causes Solutions
The shaving quality
is poor.
The shaving head is
damaged or worn out.
Replace with genuine
shaving head.
The shaving head is
clogged up with stubble.
Thoroughly clean the
shaving head.
The battery is low or
depleted.
Connect the charging
cable to charge.
The shEver does not
work after pressing
the on/off button.
The on/off button does
not function.
Contact the after-sales
service team.
The travel lock is enabled. Press and hold the
on/off button for 2,5
seconds to unlock.
The indicators do
not work normally
or do not light up.
The shaver needs to be
charged due toPS[
battery.
Charge the shaver.
The circuit board is
damaged.
Contact the after-sales
service team.
The skin is irritated
after shaving.
The shaving head is
damaged or worn out.
Replace with genuine
shaving head.
The shaver does
not charge.
The shaver is damaged . Contact the after-sales
service team.
It takes a certain period of
time for your skin to adapt
to the shaver.
The skin irritation will
fade after 2-3 weeks
of use.
The charging ambient
temperature is too low
or too high.
Charge in an ambient
temperature between
5 £C and 35 °C.
The usage time is
less than 60
minutes after being
fully charged.
The load on the motor is
increased as the shaving
head hasn‘t been cleaned
for a long time.
Thoroughly clean
the shaving head.
There is an issue with
the shaver battery.
Contact the after-sales
service team.
The clean/error
indicator blinks for
5 seconds after
turning on the
shaver.
The shaving head hasn‘t been
cleaned for a long time.
Thoroughly clean the
shaving head.
The shaving head is not
properly installed.
Reinstall the
shaving head.
08

Specifications
Name: Xiaomi Electric Shaver S301
Model: S301
Operating Voltage: 3,7 V
Operating Power: 3 W
IP Rating: IPX7
Charging Port: Type-C
Input: 5 V 1A
Charging Time: Approx. 2h
Power Adapter
Input: 100-240 V
50/60 Hz, 0.2 A
Output: 5.0 V 1.0 A,
5.0 W
Information
Published
Value and Precision Unit
Manufacturer‘s
Name
Jiangxi Jian Aohai
Technology Co., Ltd.
Model Identifier A520-050100U-EU1
Input Voltage 100-240
Input AC
Frequency 50/60
V
Hz
V
Output Voltage 5.0
Output Current 1.0 A
Output Power 5.0 W
Average Active
Eficiency 73,77 %
Eficiency at Low
Load (10 %) 64,588 %
No-load Power
Consumption 0,075 W
09

Europe-EU Declaration of Conformity
We, Shenzhen Soocas Technology Co., Ltd. hereby, declares that this
equipment is in compliance with the applicable Directives and European
Norms, and amendments. The full text of the EU declaration of conformity is
available at the following internet address:
http://www.mi.com/global/service/support/declaration.html
WEEE Disposal and Recycling Information
All products bearong this symbol are waste electrical and electronic
equipment (WEEE as in directive 2012/19/EU) which should not be mixed
with unsorted household waste. Instead, you should protect human
health and the environment by handing over your waste equipment to
a designated collection point for the recycling of waste electrical and
electronic equipment, appointed by the government or local authorities.
Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. Please contact
the installer or local authorities for more information about the location
as well as terms and conditions of such collection points.
Importer:
Beryko s.r.o.
4SH:MRMGIQM4P^I˶
www.beryko.cz
Manufactured for: Xiaomi Communications Co., Ltd
Manufactured by: Shenzhen Soocas Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 401, 402, 1101, 1102, 1103, 1104, Building 2 Chongwen
Area, Nanshan iPark, No. 3370 Liuxian Avenue, Fuguang Community,
Taoyuan Subdistrict, Nanshan District, Shenzhen, China
For further information, please go to www.mi.com
Made in China
User Manual Version: V1.0
10
