Xiaomi Smart Tower Heater Lite User manual

Smart Tower Heater Lite User Manual
*This product is only suitable for well insulated spaces or occasional use.

1
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without
supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
• The heater must not be located immediately below a socket outlet.
• Do not use this fan heater in the immediate surroundings of a bath, a
shower or a swimming pool.
• Do not use this heater if it has been dropped.
• Do not use if there are visible signs of damage to the heater.
• Use this heater on a horizontal and stable surface.
• Children of less than 3 years should be kept away unless continuously
supervised.
• Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed
in its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children aged from 3
years and less than 8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
Safety Precautions
Read this manual carefully before use, and retain it for future reference.

2
Some parts of this product can become very hot and cause burns.
Particular attention has to be given where children and vulnerable
people are present.
CAUTION
WARNINGS
• Do not rinse the heater with water.
• Do not immerse the heater in water.
• Do not spill any water into the heater.
• Do not use the heater in greenhouses or construction sites.
• In order to avoid overheating, do not cover the heater.
• Do not use this heater in small rooms when they are occupied by
persons not capable of leaving the room on their own, unless constant
supervision is provided.
• To reduce the risk of fire, keep textiles, curtains, or any other flammable
material a minimum distance of 1 m from the air outlet.
• This heater is intended for indoor use only. During use, stably place the
heater on a level surface, and do not tilt or tip it over.
• Do not come into physical contact with the heater with bare skin to
avoid burns.
• Do not touch the heater with wet hands. Do not use it to keep animals
and plants warm.
• Do not touch the heater during or right after using it to avoid scalds.
• To prevent the risk of overheating or fire, never use an extension cord.
• Only use the heater in a well-ventilated environment. Make sure no
foreign objects get into or block the air inlet or the air outlet of the
heater.
• Do not insert any wires or other foreign objects into any opening of the
heater so as to avoid electric shocks.
Usage

3
• Do not place or use the heater near flammable and explosive
materials such as gasoline and paint, nor near objects that are easily
deformed, discolored, or deteriorated by heat, nor in places with
heavy dust like garages or workshops.
• During using this heater, do not share the same electrical circuit with
other devices to avoid overloading the circuit.
• Do not disassemble the heater by yourself to avoid safety hazards. If
the heater malfunctions, contact the after-sales service team.
• The natural mode function of the heater cannot completely replace
the fan function.
• Do not disconnect the heater from power when it has not cooled
down completely. Otherwise, the heater may automatically turn off to
ensure safety. The heater will resume normal operation after it cools
down thoroughly.

4
Product Overview
Tower Heater
Control Panel
Scheduled On/Off Button
Temperature/
Scheduled On/Off Indicator
Temperature Button
On/Standby Button
Oscillation Button
Constant Temperature
Mode
Hot Mode
Warm Mode
Natural Mode
Mode Indicator
Mode Button
Wi-Fi Indicator
Control Panel
Handle
Air Inlet
Power Button
Air Outlet
Base
Power Cord
Front View Rear View
Note: Illustrations of product, accessories, and user interface in the user manual are for reference
purposes only. Actual product and functions may vary due to product enhancements.

5
How to Use
Before Use
On/Standby
Scheduled Standby
Enabling/Disabling Oscillation
Enabling/Disabling the Child Lock
• Check if the heater is in good condition, and make
sure the power cord is not damaged or broken.
• Use a 220–240 V AC electrical outlet with a rated
current of at least 10 A. It is recommended to plug
the power cord into a wall socket, and do not share
the same power strip with other appliances.
• Press the power button on the back of the heater
before use. When the heater makes a notification
sound, it is connected to power.
• This heater is an electric appliance for close use.
When using the heater to blow air directly, it is
recommended to place it one to two meters away
from you for optimal heating performance.
• Press the on/standby button to turn on the heater.
• Press the on/standby button when the heater is
on, the heater will dissipate heat for 30 seconds,
then enter standby mode.
Note: After the heater has been running in the
natural mode for 30 seconds, pressing the on/
standby button can make the heater directly enter
standby mode.
• Press the on/standby button when the heater
is dissipating heat, the heater will return to the
previously used settings.
Note: When planning not to use the heater for a long
time, make sure the heater is in standby mode and
then turn off the heater and unplug the power cord.
• Press the scheduled on/off button to cycle
through the scheduled standby times: one hour,
two hours, four hours, eight hours, and off.
• If no operation is performed within three seconds
after the scheduled standby time is selected, the
indicator will display the expected temperature. If
no expected temperature is set, the indicator will
go out.
• After the scheduled standby time is selected, the
indicator will show the remaining time once you
press the scheduled on/off button. You can press
the button again within three seconds to cycle
through the scheduled standby times.
Note: If the room temperature is higher than
the expected temperature in the constant
temperature mode, the heater may switch to the
natural mode.
• Press the oscillation button to enable or disable
the oscillation mode.
• To enable or disable the child lock function, press
and hold the oscillation button and the mode
button simultaneously for seven seconds.
• The child lock function can also be disabled by
turning on the heater again after disconnecting it
from power or unplugging the power cord.
Switching the Mode
Adjusting the Expected Temperature
• Press the mode button to cycle through the modes
of constant temperature, hot, warm, and natural.
• Press the temperature button to cycle through the
expected temperatures of 22°C, 24°C, 26°C, and
28°C.
• After the expected temperature is set, the heater
will automatically enter the constant temperature
mode. Other modes do not support the settings of
the expected temperature.
Enabling/Disabling the Wi-Fi
• To enable or disable Wi-Fi, press and hold the
scheduled on/off button and the oscillation
button simultaneously for seven seconds.
Resetting the Wi-Fi
• Press and hold the scheduled on/off button
and the temperature button simultaneously
for seven seconds. When the heater enters the
network configuration mode, the Wi-Fi is reset
successfully.

6
Wi-Fi Indicator Status Description
Heater Status Wi-Fi Indicator Status
Awaiting connection
Network connected successfully
Reconnecting automatically after
a disconnection
Updating the firmware
Network connection function
disabled
Blinking slowly (on for 0.2 seconds, then off for 0.8
seconds, repeatedly)
Blinking quickly (on for 0.1 seconds, then off for 0.2 seconds,
repeatedly)
Blinking (on for 0.05 seconds then off for 0.1 seconds, and
on for 0.05 seconds then off for 0.8 seconds, repeatedly)
Off
On
Care & Maintenance
• Before cleaning the heater, turn it off and unplug it and wait for it to cool down completely.
• Use a clean, soft, and damp cloth to wipe the heater. Do not drip water into the heater during cleaning.
• Do not disassemble the heater during care and maintenance.
• After cleaning, ensure the heater is completely dry before using or storing it.
• Avoid bumping or scratching the heater to prevent its surface coating from being damaged and rusting.
• When planning not to use the heater for a long time, store the heater in its original packaging in a dry place.
Scan the QR code to download and install the app. You will be
directed to the connection setup page if the app is installed
already. Or search "Mi Home/Xiaomi Home" in the app store to
download and install it.
Open Mi Home/Xiaomi Home app, tap "+" on the upper right,
and then follow prompts to add your device.
* The app is referred to as Xiaomi Home app in Europe (except
for Russia). The name of the app displayed on your device
should be taken as the default.
Notes:
• The version of the app might have been updated, please
follow the instructions based on the current app version.
• If you fail to scan the heater's QR code, search for its name
to add it.
This product works with Mi Home/Xiaomi Home app*.
Control your device with Mi Home/Xiaomi Home app.
Connecting with Mi Home/Xiaomi Home App
99EE4FEC

7
Specifications
Name: Fan Heater
Model: LSNFJ02LX
Rated Voltage: 220–240 V~
Rated Frequency: 50–60 Hz
Rated Power: 2000 W
Natural Mode Power: 12 W
Item Dimensions: 184 × 184 × 500 mm
Net Weight: Approx. 2.2 kg
Operation Frequency: 2400–2483.5 MHz
Maximum Output Power: < 20 dBm
Troubleshooting
Issue Possible Cause Solution
The heater is not
connecting to
power.
The heater does
not work.
The heater cannot
be found in the
app.
The power cord is not plugged in
properly.
Check whether the plug and the power cord are
plugged in properly.
Press the power button to turn the heater on.The heater is not turned on.
Press the on/standby button on the control
panel to start the heater.
The heater is not started.
The network connection fails. Reset the Wi-Fi.
Keep the phone and the heater close to the
Wi-Fi signal source.
The Wi-Fi signal is weak.
The child lock function is enabled. Disable the child lock.
Keep the air inlet and the air outlet clear and
unobstructed, and restart the heater after it
cools down.
The temperature is too high, and
the heater automatically turns off to
ensure safety.
The heater is not placed steadily. Place the heater steadily on a level surface.
Plug the heater in properly and turn it on again.
The power cord is not plugged in
properly.
The heater makes
unusual sounds
when it is moved
or shaken.
Under normal use of condition, this equipment should be kept a separation distance of at least 20 cm between the
antenna and the body of the user.
Place the heater on a level surface steadily and
avoid shaking it violently.
The steel ball in the anti-tilt switch
rattles.

8
□
Regulatory Compliance Information
EU declaration of conformity
WEEE Disposal and recycling information
Hereby, Hangzhou Lexiu Electronic Technology Co., Ltd. declares that the radio equipment type LSNFJ02LX is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following
internet address: http://www.mi.com/global/service/support/declaration.html
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which
should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by
handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic
equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential
negative consequences to the environment and human health. Please contact the installer or local authorities for more
information about the location as well as terms and conditions of such collection points.
For detailed e-manual, please go to www.mi.com/global/service/userguide
Model Identifier(s):
Item
Nominal Heat
Output
Minimum
Heat Output
(indicative)
Maximum
Continuous
Heat Output
Manual heat charge control, with
integrated thermostat
Manual heat charge control with room
and/or outdoor temperature feedback
Electronic heat charge control with room
and/or outdoor temperature feedback
□
□
□
□
□
□
□
2.0
1.4
2.0
kW
kW
kW
Yes
Yes
Yes
Yes
No
No
No
No
P
P
P
nom
min
max,c
Symbol Value Unit Item Unit
Heat Output
Auxiliary Electricity Consumption
Type of heat output/room temperature control
(select one)
Fan assisted heat output
Type of heat input, for electric storage local
space heaters only (select one)
At Nominal
Heat Output
At Minimum
Heat Output
In Standby
Mode
Single stage heat output and no room
temperature control
Two or more manual stages, no room
temperature control
With mechanic thermostat room
temperature control
With electronic room temperature
control
Electronic room temperature control
plus day timer
Electronic room temperature control
plus week timer
□
□
□
□
□
□
□
□
□
□
□
□
0.000
0.000
0.001
kW
kW
kW
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
el
el
el
max
min
SB

9
Other control options (multiple selections possible)
Room temperature control, with
presence detection
Room temperature control, with open
window detection
With distance control option
With adaptive start control
With working time limitation
With black bulb sensor
□
□
□
□
□
□
□
□
□
□
□
□
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
Model Identifier(s):
Description Symbol
F
P
SV
PSB
LWA
c
Value
7.4
5.6
1.3
1.04
53
0.9
IEC 60879:1986 +cor1:1992
Unit
m3/min
W
(m3/min)/W
W
dB(A)
meters/sec
Maximum Fan Flow Rate
Fan Power Input
Service Value
Standby Mode Consumption
Fan Sound Power Level
Maximum Air Velocity
Measurement Standard For Service Value

10
WARRANTY NOTICE
THIS WARRANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY HAVE OTHER RIGHTS CONVEYED BY LAWS OF
YOUR COUNTRY, PROVINCE OR STATE. INDEED, IN SOME COUNTRIES, PROVINCES OR STATES, CONSUMER
LAW MAY IMPOSE A MINIMUM WARRANTY PERIOD. OTHER THAN AS PERMITTED BY LAW, XIAOMI DOES
NOT EXCLUDE, LIMIT OR SUSPEND OTHER RIGHTS YOU MAY HAVE. FOR A FULL UNDERSTANDING OF YOUR
RIGHTS WE INVITE YOU TO CONSULT THE LAWS OF YOUR COUNTRY, PROVINCE OR STATE.
1. LIMITED PRODUCT WARRANTY
XIAOMI warrants that the Products are free from defects in materials and workmanship under normal use and
use in accordance with the respective Product user manual, during the Warranty Period.
The duration and conditions related to the legal warranties are provided by respective local laws. For more
information about the consumer warranty benefits, please refer to Xiaomi's official website
https://www.mi.com/en/service/warranty/.
Xiaomi warrants to the original purchaser that its Xiaomi Product will be free from defects in materials and
workmanship under normal use in the period mentioned above.
Xiaomi does not guarantee that the operation of the Product will be uninterrupted or error free.
Xiaomi is not liable for damages arising from non-compliance with the instructions related to the use of the
Product.
2. REMEDIES
If a hardware defect is found and a valid claim is received by Xiaomi within the Warranty Period, Xiaomi will either
(1) repair the product at no charge, (2) replace the product, or (3) refund the Product, excluding potential shipping
costs.
3. HOW TO OBTAIN WARRANTY SERVICE
To obtain warranty service, you must deliver the Product, in its original packaging or similar packaging providing
an equal degree of Product protection, to the address specified by Xiaomi. Except to the extent prohibited by
applicable law, Xiaomi may require you to present proofs or proof of purchase and / or comply with registration
requirements before receiving warranty service.
4. EXCLUSIONS AND LIMITATIONS
Unless otherwise stipulated by Xiaomi, this Limited Warranty applies only to the Product manufactured by or for
Xiaomi and identifiable by the trademarks, trade name or "Xiaomi" or "Mi" logo.
The Limited Warranty does not apply to any (a) Damage due to acts of nature or God, for example, lightning
strikes, tornadoes, flood, fire, earthquake or other external causes; (b) Negligence; (c) Commercial use; (d)
Alterations or modifications to any part of the Product; (e) Damage caused by use with non-Xiaomi products;
(f) Damage caused by accident, abuse or misuse; (g) Damage caused by operating the Product outside the
permitted or intended uses described by Xiaomi or with improper voltage or power supply; or (h) Damage caused
by service (including upgrades and expansions) performed by anyone who is not a representative of Xiaomi.
It is your responsibility to backup any data, software, or other materials you may have stored or preserved on the
product. It is likely that the data, software or other materials in the equipment will be lost or reformatted during
the service process, Xiaomi is not responsible for such damage or loss.
No Xiaomi reseller, agent, or employee is authorized to make any modification, extension, or addition to this
Limited Warranty. If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining
terms shall not be affected or impaired.
Except as prohibited by laws or otherwise promised by Xiaomi, the after-sales services shall be limited to the
country or region of the original purchase.
Products which were not duly imported and/or were not duly manufactured by Xiaomi and/or were not duly
acquired from Xiaomi or a Xiaomi’s official seller are not covered by the present warranties. As per applicable law
you may benefit from warranties from the non-official retailer who sold the product. Therefore, Xiaomi invites you
to contact the retailer from whom you purchased the product.
The present warranties do not apply in Hong Kong and Taiwan.

11
5. IMPLIED WARRANTIES
Except to the extent prohibited by applicable law, all implied warranties (including warranties of merchantability
and fitness for a particular purpose) will have a limited duration up to a maximum duration of this limited
warranty.Some jurisdictions do not allow limitations on the duration of an implied warranty, so the above
limitation will not be applied in these cases.
6. DAMAGE LIMITATION
Except to the extent prohibited by applicable law, Xiaomi shall not be liable for any damages caused by accidents,
indirect, special or consequential damages, including but not limited to loss of profits, revenue or data, damages
resulting from any breach of express or implied warranty or condition, or under any other legal theory, even if
Xiaomi has been informed of the possibility of such damages. Some jurisdictions do not allow the exclusion or
limitation of special, indirect, or consequential damages, so the above limitation or exclusion may not apply to
you.
7. XIAOMI CONTACTS
For customers, please visit the website: https://www.mi.com/en/service/warranty/
The contact person for the after-sale service may be any person in Xiaomi's authorized service network, Xiaomi's
authorized distributors or the final vendor who sold the products to you. If in doubt please contact the relevant
person as Xiaomi may identify.
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Hangzhou Lexiu Electronic Technology Co., Ltd.
(a Mi Ecosystem company)
Address: 2006-2010, Building 1, 501, 2nd Baiyang Street, Qiantang New District, Hangzhou, 310018 Zhejiang, China
For further information, please go to www.mi.com
User Manual Version: V1.0
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
