Xiaomi Smart Camera C200 User manual

Xiaomi Smart Camera C200 User Manual
22

Package Contents: Xiaomi Smart Camera C200, charging cable,
wall mounting kit (base, wall plug × 2, screw × 2), user manual,
warranty notice
Product Overview
Read this manual carefully before use, and retain it for future
reference.
Note: Illustrations of product, accessories, and user interface in the
user manual are for reference purposes only. Actual product and
functions may vary due to product enhancements.
The nameplate is marked on the bottom of the camera.
1
Front View Rear View
Loudspeaker
Micro-USB
Power Port
MicroSD Card Slot
(visible when
the lens is facing
upward)
Reset Button
(visible when
the lens is facing
upward)
Indicator
Lens
Microphone
Reset

How to Install
The camera can be placed on flat surfaces, such as desks, dining
tables, and coffee tables. It can also be mounted on a wall.
Mounting the Camera on a Wall：
1. First use a pencil to mark the positions for the base mounting holes
on the wall, then drill two holes at the marked positions. The diameter
of each hole is approximately 6 mm, and the depth is approximately
30 mm.
2. Insert the plastic wall plugs into the drilled holes.
3. Place the side of the base with arrows facing forward, and then
align the holes. Insert the screws and then tighten them into the wall
plugs with a Phillips head screwdriver.
4. Align the grooves on the bottom of the camera with the raised part
on the base, and then turn it clockwise until it locks into place.
2

The wall must be able to support at least three times the total
weight of the camera.
How to Use
Precaution for Mounting the Camera on a Wall
Installing a MicroSD Card
Make sure the camera is unplugged. Adjust the lens upward until the
microSD slot is revealed, then insert the microSD card into the slot
(the side with contact points must be facing down).
Note: Unplug the camera when installing or removing the microSD
card. Please use a genuine microSD card manufactured by a
qualified supplier (The microSD card needs to be purchased
separately and the maximum supported capacity is 256 GB). It is
recommended that the microSD card has a read/write speed of no
less than U1/Class 10.
WARNING
To prevent possible injury, the camera must be securely fixed to
the ceiling or wall according to the installation instructions.
3

Turning On
Indicator
Blue light on: Connected successfully/Working normally
Blinking blue: Network error
Blinking orange rapidly: To be connected
Blinking orange slowly: Updating
Plug the charging cable into the Micro-USB port on the back of the
camera, the camera automatically turns on, and the indicator quickly
blinks orange.
Note: When the camera is working, do not turn the lens of the
camera nor force it to rotate. If the positioning of the lens is
inaccurate, please calibrate it in the Mi Home/Xiaomi Home app.
Note:
Please use a power adapter with 5 V/2 A output from a qualified
manufacturer.
4
MicroSD
Reset

Connecting with the Mi Home/Xiaomi Home App
Restoring Factory Settings
This product works with the Mi Home/Xiaomi Home app*. Control
your device with Mi Home/Xiaomi Home app.
Note: The version of the app might have been updated, please follow
the instructions based on the current app version. Make sure the
camera turns on and the network connection is stable during
connecting. The indicator is blinking orange rapidly when waiting for a
connection, and turns into blue once the camera is successfully
connected.
In case the network the camera is connected to, or the Xiaomi
Account the camera is paired with has to be changed, use a pin to
press and hold the reset button for about five seconds to restore
factory settings. Then reconnect the network and the Mi Home/Xiaomi
Home app with the camera.
Note: Restoring factory settings will not delete the content on the
microSD card.
Scan the QR code to download and install the app.
You will be directed to the connection setup page
if the app is installed already. Or search for
"Mi Home/Xiaomi Home" in the app store to
download and install it.
Open the Mi Home/Xiaomi Home app, tap "+" on
the upper right, and then follow the instructions
to add your device.
* The app is referred to as Xiaomi Home app in Europe (except for
Russia). The name of the app displayed on your device should be
taken as the default.
5
2CCD476E

Real-time Surveillance
Playback
Infrared Night Vision
In the camera's plugin of the Mi Home/Xiaomi Home app, you can view
the real-time surveillance screen, adjust the sharpness of the image,
adjust the horizontal angle of the camera, capture and record the
screen, and make remote calls.
The camera can automatically switch to night vision mode at night
according to the change in ambient light. With built-in infrared night
vision lights, the camera can clearly capture images/videos in the dark.
The playback feature of the camera is only available when a
compatible microSD card is installed.
The camera will automatically start recording video once a microSD
card is installed and the camera is turned on. In the camera's plugin
in the Mi Home/Xiaomi Home app, tap the playback button to enter
the playback interface, then drag the timeline to select the time
period to be played back. The maximum supported playback speed
is 16×.
6

When the home surveillance assistant is enabled, the camera will
record videos if it detects human movement and changes in
real-time within its monitored area. Then you will receive
notifications on the app.
You can enable or disable the function of home surveillance
assistant in the camera's plugin in the Mi Home/Xiaomi Home app.
You can set surveillance of all-day, daytime, nighttime, or any other
time meeting your demands. Alert sensitivity and alert time intervals
can also be customized in the app.
Automatic Surveillance
Video Sharing
In the camera's plugin in the Mi Home/Xiaomi Home app, you can
select the device sharing option in the settings menu to share the
camera with others. The person the camera is shared with needs to
download the Mi Home/Xiaomi Home app and sign in with a Xiaomi
Account.
7

The operating temperature range for this camera is between -10°C
and 40°C. Do not use the camera in environments with temperatures
above or below the specified range.
The camera is a precision electronic product. In order to ensure its
normal operation, do not install the camera in environments with
high humidity levels nor allow water to get into it.
To improve the camera's performance, do not place its lens facing or
next to a reflective surface, such as glass windows or white walls, as
this will cause the image to appear overly bright in areas close to the
camera and darker in areas further away, or cause the camera to
produce white images.
Make sure the camera is installed in an area with a strong Wi-Fi
signal. Do not place the camera near the objects that may affect its
Wi-Fi signal, such as metal objects and microwave ovens.
Under normal use of condition, this equipment should be kept a
separation distance of at least 20 cm between the antenna and the
body of the user.
Specifications
Cautions
Name: Xiaomi Smart Camera C200
Model: MJSXJ14CM
Input: 5 V 2 A
Aperture: F2.1
Item Dimensions: 109 × 75 × 75 mm
Operating Temperature: -10°C to 40°C
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Storage: MicroSD card (up to 256 GB)
Resolution: 1080p
Net Weight: Approx. 256 g
Video Codec: H.265
8

WEEE Information
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU) which
should not be mixed with unsorted household waste. Instead,
you should protect human health and the environment by
handing over your waste equipment to a designated collection point
for the recycling of waste electrical and electronic equipment,
appointed by the government or local authorities. Correct disposal and
recycling will help prevent potential negative consequences to the
environment and human health. Please contact the installer or local
authorities for more information about the location as well as terms
and conditions of such collection points.
EU Declaration of Conformity
Hereby, Shanghai Imilab Technology Co., Ltd. declares that the
radio equipment type Xiaomi Smart Camera C200 is in
compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:
http://www.mi.com/global/service/support/declaration.html
9

Hereby, Shanghai Imilab Technology Co., Ltd. declares that the
radio quipment type Xiaomi Smart Camera C200 is in
compliance with Radio Equipment Regulations 2017. The full
text of the UK declaration of conformity is available at the following
internet address:
https://www.mi.com/uk/service/support/declaration.html
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Shanghai Imilab Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang
District, Shanghai, China
For further information, please go to www.mi.com
User Manual Version: V1.0
10
UK Declaration ofConformity
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
