Xilinx Ml507 User manual

© Copyright 2010 Xilinx

ML507 QuickStart

May 2010

Overview

ML507 Setup

Bootload

Applications

–Slideshow

–Web Server

– Simon

–Board Diagnostics

–USB Keyboard

–My ACE

–Ringtone

References

Note: This presentation applies to the ML507

ML507 BSB Hardware

The ML507 PPC440 design

hardware includes:

–PPC440MC DDR2 Interface

–External Memory Controller (EMC)

•ZBT SRAM

– BRAM

–Networking

–UART

–Interrupt Controller

–System ACE CF Interface

–GPIO (IIC, LEDs and LCD)

–PLB Arbiter

Note: Presentation applies to the ML507

ML507 Setup

Connect the Xilinx Platform

Cable USB to the

ML507 board

Connect the RS232 null

modem cable to the

ML507 board

Note: Presentation applies to the ML507

Hardware Setup

The ML507 uses a DVI video

interface

Connect a DVI monitor

or

Use a DVI/VGA adapter

to connect a VGA monitor

–http://www.belkin.com

Note: Presentation applies to the ML507

Hardware Setup

USB Keyboard

–www.dell.com

Note: Presentation applies to the ML507

Factory CompactFlash

The CompactFlash shipped with the ML507 board has the following

ace files preloaded:

Note: Presentation applies to the ML507

ML507 Setup

Set ML507 Jumpers for GMII

–Set both J22 and J23 to positions 1-2 (as shown)

Note: Presentation applies to the ML507

ML507 Setup

Insert the Factory CompactFlash into the ML507 board (1)

Set the Front DIP switches (SW3) to 00010101 (1 = ON) (2)

Set the Rear DIP switches (SW6) to 11001010 (3)

Power-up the ML507 board

Note: Presentation applies to the ML507

1

23

ML507 Setup

Start the Terminal Program:

Note: Presentation applies to the ML507

Additional Setup Details

Refer to ml505_overview_setup.ppt for details on:

–Software Requirements

–ML505/506/507 Board Setup

–Equipment and Cables

– Software

–Network

Terminal Programs

–This presentation requires the

9600-8-N-1 Baud terminal setup

Note: Presentation applies to the ML507

Bootload

The system_bootload.ace loads:

Note: Presentation applies to the ML507

Bootload

The terminal window also reflects the bootload application

Use the left/center/right buttons to choose an application or type a

number in the terminal window

After each demo, push the SysACE reset to return to bootload

Note: Presentation applies to the ML507

Slideshow

Type 1, to launch the slideshow application in Configuration 1

The slideshow loads the presentation into memory then presents it

Note: Presentation applies to the ML507

Slideshow

The slideshow app will present a series of slides on the Monitor:

Note: Presentation applies to the ML507

Web Server

Type 2, to launch the web server application in Configuration 2

–Note: You may need to turn off your browser's proxy and specify a direct

connection to the Internet in your browser options

Note: Host IP is 192.168.1.1, subnet mask is 255.255.255.0

Web Server

Open a web browser to address 192.168.1.10

Note: Presentation applies to the ML507

Web Server

Click the Toggle LEDs button; view change on ML507

Note: Presentation applies to the ML507

Simon

Type 3, to launch the Simon application in Configuration 3

Note: Presentation applies to the ML507

Board Diagnostics

Type 4, to launch the XROM application in Configuration 4

Note: Presentation applies to the ML507
