1. Overview
The Full HD Multiple Streams Compact Fixed Dome IP TIGER, Camera is
capable of serving real-time streaming and makes image quality more smoothly.
In addition to MJPEG real time streaming, this camera develops H.264 codec to
apply for high resolution digital broadcast. With compact and sophisticated
mechanical design, the Full HD Multiple Streams Compact Fixed Dome IP
Camera is easy installed and aesthetic.
1.1 Features
Progressive Scan CMOS Sensor
Quad Stream Compression-
H.264 Baseline / Main / High Profile + MJPEG
Multi-language Support
Tampering Alarm
Wide Dynamic Range
Motion Detection
Privacy Masks
Smart Picture Quality / 3D Noise Reduction
Vertical View Mode (Image rotation by 90 degrees)
Network Failure Detection
Weatherproof Dongle Cable*
Weatherproof (IP66 international)*
MicroSD Support
ONVIF Support
(*) Optional

3
1.2 Package Contents
Please check the package contains the following items listed below.
Indoor Camera /
Rugged Camera (with Cable)
Rubber Washer (x1, Casing)
Rubber Washers (x3, Baseplate)
(Rugged Camera only)
Self-tapping screws (x3)
Plastic Anchors (x3)
Security Torx
Quick Guide
CD
NOTE: The supplied self-tapping screws are for soft substances /
materials such as wood. For other installation environments such as
cement wall, it is required to pre-drill and use plastic anchors before
fastening the supplied self-tapping screw on the wall.

4
1.3 Dimensions
The dimensions of the camera are shown below.

5
1.4 Installation (For Rugged Camera)
Please follow the steps below to install the rugged camera.
Step 1:
Loosen the two security screws of the
camera and detach the dome cover.
Step 2:
At the two sides of the base plate, place
a rubber washer on the screw hole
shown in the right figure.
Step 3:
Place the camera at the installation
location. Then attach the camera to the
ceiling by fastening the supplied screws
to the screw holes with the rubber
washers.
Step 4:
Refer to section Connectors and chapter Camera Cabling for camera lens
adjustment and cable connection.

6
Step 5:
Attach the dome cover back to the
camera and fasten the two security
screws.

7
1.5 Connectors
The diagram below shows the reset button, lens, microSD card slot and various
adjusting screws of the camera. Definition for each will be given as follows.
No.
Designation
Description
1
Reset Button
Press the button with a proper tool for at least 20
seconds to restore the system.
2
Lens
Rotate the lens right/left to adjust focus
3
Focus Fixed Screw
Loosen the screw to adjust the lens
4
Tilt Fixed Screw
Loosen the screw to adjust tilt angle
5
microSD Card Slot
For video recording storage
NOTE: It is not recommend to record with the microSD card for 24/7
continuously, as it may not be able to support long term continuous data
read/write. Please contact the manufacturer of the microSD card for
information regarding the reliability and life expectancy.

8
2. Camera Cabling
Before users connect cables, make sure that all cables and the power adaptor
are placed in dry and well-waterproofed environments, e.g. waterproof boxes.
The purpose is to prevent moisture accumulation inside the camera and
moisture penetration into cables, which might lead to device breakdown. Please
follow the instructions below to complete camera connection.
2.1 Connect Ethernet Cable
Refer to the type of camera and follow the instructions below to connect
Ethernet cable.
2.1.1 Indoor Camera
The Ethernet connector of the indoor camera is shown as below.
PoE Connection
Connect one end of the Ethernet cable to the RJ-45 connector of the indoor
camera, and plug the other end to a PSE switch. Check the status of the link
indicator and activity indicator LEDs. If the LEDs are unlit, please check the LAN
connection.
NOTE: Please use an Ethernet cable without the boot cover to connect
the indoor camera. Otherwise, the dome cover cannot be installed.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.

9
2.1.2 Rugged Camera
The RJ-45 cable of the rugged camera is either IP66 RJ-45 cable or RJ-45 lite
cable. Refer to the cable type and follow the instructions below to connect
Ethernet cable and waterproof connector.
IP66 RJ-45 Cable
RJ-45 Lite Cable
IP66 RJ-45 Cable 1 / IP66 RJ-45 Cable 2
For IP66 RJ-45 cable, please use an RJ-45 IP66 plug for connection to prevent
water damage. Follow the steps below for cable connection.
Step 1:
Take out the supplied connector from the
RJ-45 IP66 plug. Loosen the thread-lock
sealing nut on the plug. Then thread the
Ethernet cable through the thread-lock
sealing nut and the plug. If the Ethernet cable
is already attached to a connector, please
remove it first.
Step 2:
Carefully remove a section of rubber coating
from the end of the Ethernet cable to reveal
the wires. Inset the wires to the correct pins
of the connector. Plug the Ethernet cable to
the connector of IP66 RJ-45 cable.
Step 3:
Fasten the RJ-45 IP66 plug to the connector
of the IP66 RJ-45 cable. Lastly, tighten the
thread-lock sealing nut to the plug.
