USER MANUAL
XC / XD SERIES TENTS
QUICK USER
GUIDE

4X GLOO® • Windeckstr. 4 • 83250 Marquartstein • Deutschland
1. TECHNICAL DATA
XC 3 XD 4 XD 5 XD 6
Exterior side length 3,0 m 4,0 m 5,0 m 6,0 m
Entrance height 1,95 m 2,0 m 2,5 m 3,0 m
Total height 2,6 m 2,38 m 3,0 m 3,57 m
Tube diameter 20,0 cm 25,0 cm 31,0 cm 37,0 cm
Weight without Walls 9,32 kg 13,3 kg 18,8 kg 22,5 kg
COVERED AREA
without Side Walls 5,6 m 7,23 m 11,3 m 16,27 m
with 4 Canopies - 23,0 m 35,7 m 51,34 m
SETUP
Hand Pump 10 min 15 min 25 min 30 min
Electric Pump 3-5 min 3-5 min 7-10 min 10-15 min
Operating pressure* 0,35 bar/ 0,35 bar/ 0,26 bar/ 0,26 bar/
5,1 PSI 5,1 PSI 3,8 PSI 3,8 PSI
*This data serves primarily as information, since the operation of the overpressure valves is automatic.
All dimensions are approximate.
Entrance height
Total height
Tube
diameter
Covered area
Exterior side length
Exterior side length
2

5Tel: [phone] - 60 • xgloo.com • [e-mail]
2. CONTENTS OF
DELIVERY
XC 3
1x Anchoring line set (1)
1x Repair kit (2)
1x Hand pump (3)
1x User manual and
quick user guide (4)
1x Allen key (5)
XD 4
1x Anchoring webbing set (1)
3x Repair kit (2)
1x Hand pump (3)
1x User manual and
quick user guide (4)
1x 5 mm Allen key (5)
1x 4 mm Allen key (5)
1x cable tie (6)
1x Valve wrench (7)
1x Valve adapter (8)
1x Replacement bladder (9)
XD 5/6/7
1x Anchoring line set (1)
3x Repair kit (2)
1x Hand pump (3)
1x User manual and
quick user guide (4)
1x 5 mm Allen key (5)
1x 4 mm Allen key (5)
1x cable tie (6)
1x Valve wrench (7)
1x Valve adapter (8)
1x Replacement bladder (9)
1x Closing rod (10)
3
4
1
7
8
6
9
5
2
4
10
3

6X GLOO® • Windeckstr. 4 • 83250 Marquartstein • Deutschland
3. SETUP
3.1 LAY OUT THE TENT
Take the tent out of the supplied transport bag and
spread it out at your setup location with the roof facing
up. It helps to arrange the tent so that the tube ends
are laying approximately where they will be when the
tent is inflated. This can make the setup process much
easier.
In order to reduce the risk of soiling / damaging the
tent during the setup process, it is recommended to
first spread out the Protection Foil, which can be
purchased from X GLOO as an optional accessory..
Remove the protective covers from the tube ends.
PLEASE NOTE: The removable protective covers on the
tube ends protect the tent from damage. Therefore, in
order to prevent leaks, it is strongly recommended to
reattach the protective covers before folding up the tent..
3.2 INFLATION - DEFLATION -
VALVES - RAISING
The valve for inflation/deflation consists of the socket that
is permanently welded to the inner tube and a screw-on
valve housing with attached protective cover.
3.2.1. INFLATION: XD 4/5/6/7
To inflate the tent, the valve housing, which can be
found on the inner side of each tube, must be screwed
firmly into the socket. A backflow preventer (red button)
in the valve housing prevents the air from escaping
again. For it to function properly, the backflow
preventer must be in the up position, which may have
to be activated by pushing down on it (the same
principle as with a ballpoint pen).
XC 3
XD 4/5/6/7
4

7Tel: [phone] - 60 • xgloo.com • [e-mail]
Connect one end of the hose to the pump and the
other end, with the valve adapter, to the valve by
turning it slightly. After inflation is complete, close the
valve with the protective cover.
PLEASE NOTE: If small folds form in the tube during
inflation, it is helpful to shake the tube and bladder. This
movement helps bring the bladder back into the optimal
position in the tube, allowing it to be inflated to maximum
capacity and therefore achieve full stability..
To deflate, press the backflow preventer (red button) in
the valve housing on each tube until it clicks into place.
This allows the air to escape completely..
PLEASE NOTE: After deflating, it is recommended to return
the backflow preventer to the up position by pushing it
again. This ensures that the tent is ready for inflation next
time you want to use it.
3.2.2. INFLATION: XD 4/5/6/7
WITH ONE-PUMP SYSTEM
PLEASE NOTE: Before inflating, be sure that the backflow
preventers on the valves, found on the inner side of each
tube, are closed/in the up position.
To inflate, use the central inflation hose, which can be
found on the outer side of one of the four tubes.
Connect one end of the hose to the pump and the
other end to the inflation hose by means of the valve
adapter by turning it slightly (bayonet valve system).
When disconnecting the pump after inflation, it is
normal for the excess air in the inflation hose to escape.
Finally, close the valve with the protective cover.
To deflate, please refer to 3.3.1.
3.2.2. INFLATION: XC 3
To inflate, the valve housing must be first screwed
tightly into the socket. The backflow preventer in the
valve prevents the air from escaping.
To deflate, unscrew the entire valve housing from the
socket..
3.2.3 OVERPRESSURE VALVE: XC 3 | XD 4/5/6/7
On each tube there is a red overpressure valve that
automatically opens as soon as the maximum air
Inflate
Inflate
Deflate
5

8X GLOO® • Windeckstr. 4 • 83250 Marquartstein • Deutschland
pressure in the tube has been reachedThe overpressure
valve prevents the tube from bursting if the air pressure
inside is too high, and because it is a safety-related
part, special attention should be given to it.
Before inflation, every overpressure valve should be
checked to ensure that it is functioning properly. To do
this, unscrew the valve housing from the socket and
check to make sure that the spring can be pressed in.
Make sure that the valve is properly screwed closed
again after testing.
Sand or dirt can jam the spring and valve, which may
prevent the valve from functioning correctly.
3.2.4 RAISING: XC 3 | XD 4/5/6/7
PLEASE NOTE: Raising the tent from the ground requires
some assistance. Before the tubes are fully inflated, the
middle of the tent — where the tubes intersect — must
be actively lifted o the floor. This prevents the tent from
possibly being damaged from being inflated invertedly.
When setting up the tent in sandy terrain, make sure
that no grains of sand get into the hoses or pumps
through valve openings, which could lead to damage
or leaks.
For the tent to appear optically perfect, the tubes
should be aligned by hand after inflation and the roof
readjusted on the tubes if necessary.
PLEASE NOTE: The specified maximum air pressure must
not be exceeded and is reached when the overpressure
valves open and the excess air beings to escape.
6
