XMLite LM285 User manual

LEDMOVING HEAD WASH
LM285
Weight 12.0KG
Power 400W
Color RGBW

Menu
1.Content........................................................................................02
2.Safety Information........................................................................03
3.Parts Introduce.............................................................................04
4.product size .................................................................................04
5.product information......................................................................05
6. ControlPanelOperate..................................................................06
7. DMX ControlChannelMode........................................................10

2
.SAFETYINFORMATION
SafetyWarning:Thisproductisonlysuitableforprofessionaluse, and doesnotapplytosecurity
forotherpurposes.When you gotthe lights,pleasecheck the package whetherhavean
caused bytransportation. Ifthereisanydamage, do notusethisfixture, and pleasecontactthe
dealerormanufacturerassoon aspossible.Thisproductisonlysuitableforindoor,IP20
protection class.Lampsshouldbe keptdrytoavoidMoistu
Preventlampscome into contactwith wateroranyotherliquid. The use ofthisproductshould pay
attention to:fire, heat, electric shock, ultravioletradiation, the lamp to explode orShedding caused
seriousorfata
linjury.Pleaseread the instructionsbeforeuseenergized orinstalling. Follow
through the operation ofsecuritymethodsand payattention tothe warning signson the
specification and equipment.
2.1 ANTI-
HIGH TEMPERATURE
ta=40 C
Pleasedon tuse th
e equipmentif the temperature above 40
2.2 TOPREVENT FALLINGWOUNDING
When Hang the fixture, please mustverifythatthe facilitiesto be able to withstand atleast10
timesormore weightoffixtures.
Pleasemake surethe Mounting hardwareisstrong
the safetyrope asauxiliarysecurityfixed inotherfacilitieswill need toverifybeforeinstallation.
Installing orremoving the equipment, tomake the pulleybelowthe work location
2.3 UA PROTECTION
Forbid st
raightviewpointwith exposed bulbsto avoid UVdamage to the eyes;
Do notuse the equipmentwithoutthe lensscreen and the lid;
The lensand the lighthead covers should be timelyreplaced if anydamage to rupture.
2.4 PREVENTIONOFELECTICSHOCK
The
electricalconnection mustonlybe carried outwith corresponding qualifications;
Beforeinstalling, make sureyou usethe powervoltage lampsmustcomplywiththe
identified power, voltage and have an overload orleakage protection;
Each fixture mustbe
properlygrounded, installed in accordance with the relevantstandards;
Cutoffthe powerwhenstall orreplace the lamp and the fuse;
Forbid using t
he fixture in stormorwetenvironment.
2.5 TOPREVENT BURNINGORFIRE
1. Thefixture can'tbe moun
ted directlyon the surface ofordinarycombustiblematerial.
2. Theequipmentmustbe installed awayfrominflammable and explosive materials.
.SAFETYINFORMATION
SafetyWarning:Thisproductisonlysuitableforprofessionaluse, and doesnotapplytosecurity
forotherpurposes.When you gotthe lights,pleasecheck the package whetherhavean
ydamage
caused bytransportation. Ifthereisanydamage, do notusethisfixture, and pleasecontactthe
dealerormanufacturerassoon aspossible.Thisproductisonlysuitableforindoor,IP20
protection class.Lampsshouldbe keptdrytoavoidMoistu
re, overheating ordustyenvironment.
Preventlampscome into contactwith wateroranyotherliquid. The use ofthisproductshould pay
attention to:fire, heat, electric shock, ultravioletradiation, the lamp to explode orShedding caused
linjury.Pleaseread the instructionsbeforeuseenergized orinstalling. Follow
through the operation ofsecuritymethodsand payattention tothe warning signson the
HIGH TEMPERATURE
e equipmentif the temperature above 40
℃
2.2 TOPREVENT FALLINGWOUNDING
When Hang the fixture, please mustverifythatthe facilitiesto be able to withstand atleast10
Pleasemake surethe Mounting hardwareisstrong
enoughnoanydamage, and insurance for
the safetyrope asauxiliarysecurityfixed inotherfacilitieswill need toverifybeforeinstallation.
Installing orremoving the equipment, tomake the pulleybelowthe work location
raightviewpointwith exposed bulbsto avoid UVdamage to the eyes;
Do notuse the equipmentwithoutthe lensscreen and the lid;
The lensand the lighthead covers should be timelyreplaced if anydamage to rupture.
2.4 PREVENTIONOFELECTICSHOCK
electricalconnection mustonlybe carried outwith corresponding qualifications;
Beforeinstalling, make sureyou usethe powervoltage lampsmustcomplywiththe
identified power, voltage and have an overload orleakage protection;
properlygrounded, installed in accordance with the relevantstandards;
Cutoffthe powerwhenstall orreplace the lamp and the fuse;
he fixture in stormorwetenvironment.
2.5 TOPREVENT BURNINGORFIRE
ted directlyon the surface ofordinarycombustiblematerial.
2. Theequipmentmustbe installed awayfrominflammable and explosive materials.
SafetyWarning:Thisproductisonlysuitableforprofessionaluse, and doesnotapplytosecurity
ydamage
caused bytransportation. Ifthereisanydamage, do notusethisfixture, and pleasecontactthe
dealerormanufacturerassoon aspossible.Thisproductisonlysuitableforindoor,IP20
re, overheating ordustyenvironment.
Preventlampscome into contactwith wateroranyotherliquid. The use ofthisproductshould pay
attention to:fire, heat, electric shock, ultravioletradiation, the lamp to explode orShedding caused
linjury.Pleaseread the instructionsbeforeuseenergized orinstalling. Follow
through the operation ofsecuritymethodsand payattention tothe warning signson the
When Hang the fixture, please mustverifythatthe facilitiesto be able to withstand atleast10
enoughnoanydamage, and insurance for
the safetyrope asauxiliarysecurityfixed inotherfacilitieswill need toverifybeforeinstallation.
The lensand the lighthead covers should be timelyreplaced if anydamage to rupture.
electricalconnection mustonlybe carried outwith corresponding qualifications;
Beforeinstalling, make sureyou usethe powervoltage lampsmustcomplywiththe
properlygrounded, installed in accordance with the relevantstandards;
ted directlyon the surface ofordinarycombustiblematerial.

3. Thehighesttemperature is40 °Cwhen the equipmentisin stable state.
4. Theequipmentcan nothave an obstacle atleastin the range of0.5 meters.
5. Do notreplacethe non-originalparts.
3.Product parts
4. Size
01 —body
02 —arm
03 —lens
04 —handle
05 —basebottom
03
05
02
04
01

5. Specification
1.specification
Channelsmode 14/25/90 CH
Lamp:OSRAM/TAIWAN 15WRGBW4in1 LED;
power: 110-240V,50/60Hz;
Totalpower: 400W;
Display:LCD screen display, can reverse 180°;
Lens:French lens, 8 degree;
Zoomangel:7.9-38°;
Dimmer:0-100%linearadjustment;
Pan :540°;8Bit/16Bit ;
Tilt :270°;8Bit/16Bit ;
3-phase motorforPan/Tilt fastmoving speed &noiseless;
IPRate:IP20;
Flightcase :740x400x490 mm;carton :460x305x420 mm;
Netweight:12 KG;
Can make the clearspotwhen beamangelin7.9 degree, wash effectwhen in big angle
2.Luminous diagram

6.CONTROLPANELMENU OPERATE
LM285 LCD DISPLAYCONTENTS
MainMenu Submenu 1 Submenu2 Function SET Functiondescription
DMX
ADDRESS
<< 001-512 address minimumvalue 1
<address +1
>address -1
<< address maximumvalue 512
SAVE
save date and back to main
interface
ESCback to main interface
FEATURES
SETTING
Run Mode: DMX DMX
Wire inactive
Aoto inactive
Channel
Mode:
14CH 14CH
25CH 25CH
90CH 90CH
Pan Reverse:
Off Pan Scan Normal
On Pan Scan Reverse
Tilt Reverse:
Off Tilt Scan Normal
On Tilt Scan Reverse
OptoCheck:
Off
Pan/Tilt opticalsensortesting
off
On
Pan/Tilt opticalsensortesting
on
PTSpeed:
Noml
Pan/Tilt Scan Speed setting
normal
Slow
Pan/Tilt Scan Speed setting
slow
Fast
Pan/Tilt ScanSpeed setting
fast
SinglClear: Off keep signaldata
On clearsignaldata
ADV. enteradvanced function
RST. resetand back to main interface

SAVE
save date and back to main
interface
ESCback to main interface
ADVANCED
FUNCTION
Redress
ZEROSETTING
Pan: 0-255 Motorzero calibration
Tilt:
Focus:
SAVE
save date and back to last
interface
>the currentvalue +1
<the currentvalue -1
ESC back to lastinterface
ChanlDef inactive
FactSett
UseManage
Limit LimitTime inactive
limitCont inactive
DefConfig YES
restore default and exit from
the currentinterface
NO exit fromthe currentinterface
FacConfig
SAVE
save factoryconfiguration ,exit
fromcurrentinterface
EPRT
export factoryconfiguration
exit fromcurrentinterface
ESC exit fromcurrentinterface
ESC back to lastinterface
UNLOCK
Verify1:
0-255 unlocking code
Verify2:
KEY
password to enterthe next
interface, Otherwise the exit
fromthe currentinterface
ESC exit fromcurrentinterface
MANUAL
LAMP
REST
ALLMOTER all motors
XYMOTER function inactive
PART MOTER function inactive
YES Resetthe selected motor
ESC back to lastinterface
TESTRUN
AUTO auto
SOUND sound control

ESC back to lastinterface
SMULATE
DMX
BeamStrobe:
0-255 manualcontrol
BeamDimmer:
Focus:
Pan:
Pan Fine:
Tilt:
Tilt Fine:
Function:
BeamMacro:
BeamRed:
BeamGreen:
BeamBlue:
BeamWhite:
ColourGrad:
Gobo:
Shape Selection:
Shape Speed:
Shape Fade:
Shape R:
Shape G:
Shape B:
Shape W:
Shape Dim:
Background Dim:
Reserved:
>currentvalue +1
<currentvalue -1
ESC back to lastinterface
ESC back to main interface
SYSTEM
INFO
DMX
VALUE CH00-CH25 0-255 DMXvalue number
RESTINFO
Pan:
Right/Erro Motorresetstate
Tilt:
Focus:
PanOpto:
Tilt Opto:
ESC back to lastinterface
OTHER
INFO Run Time: 0-9999
fixture running howmany
hours

Run Count: 0-9999 fixture running times
Residue T: Most running hours unlimited
Residue C: Most running time unlimited
Type: LM285 lightmodel
Temp: xxx led temperature
Fan 1: 0-9999 Fan 1 rotate speed
Fan 2: 0-9999 Fan 2 rotate speed
Lamp brand: CN/OSM LEDbrand
DisVersion: Vxxx Panelsoftware version number
XYVersion: Vxxx
XYDriversoftware version
number
M1 Version: Vxxx M1 software version number
ESC back to lastinterface
ESC back to main interface
DISPLAY
SETTING
LightSet: 1-7Lev Backlightbrightness Settings
LightOff:
On backlightkeepson
1Min backlightoff in 1 minutes
2Min backlightoff in 2 minutes
3Min backlightoff in 3 minutes
Menu Back:
Off
close menu to return
automatically
1Min The menu returnsin 1 minute
2Min
The menu returnsafter2
minute
3Min
The menu returnsafter3
minute
LightFlash:
Off Closing backlightflashing
On open backlightflashing
TouchCali:
Off Close touchcalibration
On open touch calibration
SAVE
save the date and back to main
interface
ESC back to main interface
DIMMER
SETTING
Dimmer
Mode:
Fast fast
Noml smooth

Balance
SW:
Off The white balance off
On The white balance on
Balance
Red:
0-255
The white balance red
Balance
Green: The white balance green
Balance
Blue: The white balance blue
Balance
White: The white balance white
7. DMXControlChannel Mode
LM285 channellist
14CH 25CH 90CH Function DMX
value Description
1 1 1 Strobe
0-19 Strobe OFF
20 -24 Strobe ON
25 -64 Strobe Fast-Slow
65 -69 Strobe ON
70 -84 SlowinputStrobe Fast-Slow
85 -89 Strobe ON
90 -104 SlowoutputStrobe Fast-Slow
105-109 Strobe ON
110-124 RandomStrobe Fast-Slow
125-129 Strobe ON
130-144 RandomSlowinputStrobe Fast-Slow
145-149 Strobe ON
150-164 RandomSlowoutputStrobeFast-Slow
165-169 Strobe ON
170-184 Pulse Strobe Fast-Slow
185-189 Strobe ON
190-204 RandomPulse Strobe Fast-Slow
205-209 Strobe ON
210-224 Strobe Fast-Slow
225-229 Strobe ON
230-244 ExposureStrobe Fast-Slow

245-255 Strobe ON
2 2 2 Dimmer 0-255 LinearDimmerDark-Bright
3 3 3 Focus 0-255 LinearFocus
4 4 4 Pan Rotation 0-255 0~540 degree
5 5 5 Pan Fine 0-255 Pan Fine
6 6 6 Tilt Rotation 0-255 0~270 degree
7 7 7 Tilt Fine 0-255 Tilt Fine
8 8 8 Function set
0-9 No function
10 -14 Whole lightReset
15 -39 No function
40 -44 XYNormalmode
45 -49 XYFastmode
50 -54 XYSlowmode
55-255 No function
9 9 9
Color
tempera
ture or
color
0-9 No function
10 -14 Moroccan Pink
15 -19 Pink
20 -24 SpecialrosePink
25 -29 FolliesPink
30 -34 Fuchsia Pink
35 -39 SurprisePink
40 -44 Congo Blue
45 -49 Tokyo Blue
50 -54 Deep Blue
55 -59 JustBlue
60 -64 MediumBlue
65 -69 Double CTBlue
70 -74 State Blue
75 -79 Full CT Blue
80 -84 Half CTBlue
85 -89 SteelBlue
90 -94 LighterBlue
95 -99 LightBlue
100-104 MediumBlue Green
105-109 DarkGreen
110-114 PrimaryGreen
115-119 Moss Green
120-124 Fern Green
125-129 JASGreen

130-134 Lime Green
135-139 Spring Yellow
140-144 Deep Amber
145-149 Chrome Orange
150-154 Orange
155-159 GoldAmber
160-164 MillenniumGold
165-169 Deep Golden Amber
170-174 Flame Red
115-179
180-201 Colorclockwise run fromfastto slow
202-207 Stop
208-229 Coloranticlockwise run fromslowto fast
230-234 No function
235-249 RandomcolorFast-Slow
250-255 No function
10 10 10 Red beam0-255 Red DimmerDark-Bright
11 11 11 Green beam 0-255 Green DimmerDark-Bright
12 12 12 Blue beam0-255 blue dark -bright
13 13 13 White beam 0-255 whitedark-bright
14 14 14 Colorslow
change
0-7 --F82
8-39 Red toYellow
40 -71 Yellowto Green
72 -103 Green toCyan
104-135 Cyan to Blue
136-167 Blue to Magenta
168-199 Magenta toRed
200-231 Red toWhite
232-255 Colorchange slow-fast
15 LEDgobo
0-4 -F91
5-9 Gobo 1
10 -14 Gobo 2
15 -19 Gobo 3
20 -24 Gobo 4
……
185 -189 Gobo 37
190 -194 Gobo 38
195 -199 Gobo 39
200 -204 Gobo 40

205 -224 Gobo clockwise run fromfastto slow
225 -234 Stop
235 -255 Gobo anticlockwise run fromslowto fast
16 Built-in
effects
0-4 No function
5-14 LEDbuilt-in effect1
15 -24 LEDbuilt-in effect2
25 -34 LEDbuilt-in effect3
35 -44 LEDbuilt-in effect4
……
155-164 LEDbuilt-in effect16
165-174 LEDbuilt-in effect17
175-184 LEDbuilt-in effect18
185-194 LEDbuilt-in effect19
195-255 Switch Auto. after1 minute
17 Effectspeed0-255 LEDbuilt-in effectspeed Slow-Fast
18 Effectslow
input 0-255 LEDbuilt-in effectsGradientOverlay
19 Effectred 0-255 Red DimmerDark-Bright
20 Effectgreen0-255 Green DimmerDark-Bright
21 Effectblue 0-255 Blue DimmerDark-Bright
22 Effectwhite0-255 White DimmerDark-Bright
23 Effect
Dimmer 0-255 DimmerDark-Bright
24 Effect
backlight 0-255 DimmerDark-Bright
25 Reserve 0 -255
15 R1Dimmer0-255 R1DimmerDark-Bright
16 G1Dimmer0-255 G1DimmerDark-Bright
17 B1Dimmer0-255 B1DimmerDark-Bright
18 W1Dimmer0-255 W1DimmerDark-Bright
………
87 R19Dimmer0-255 R19DimmerDark-Bright
88 G19Dimmer0-255 G19DimmerDark-Bright
89 B19Dimmer0-255 B19DimmerDark-Bright
90 W19Dimmer 0-255 W19DimmerDark-Bright
