XOTIC EFFECTS BBP-MB User manual

The BBP-MB takes the renowned BB-preamp to the next level. We’ve supplement the BBP-MB with a mid-boost control,
adding more aggressive "bite" to your sound and up to +12dB of mid-treble boost. The MB version capable of covering
all the tones that can be obtained with the standard BB Preamp by setting the mid control at 9 o’clock.
Specs:
Dimensions (W/D/H): 4.39" x 2.38" x 1.98"
(110mm X 60mm X 50mm)
Weight: 0.6 lbs. (270g)
True Bypass Switching
Power Consumption: 9VDC/15mA (max)
Approx. 40hrs continuous use with alkaline battery
Battery Type: 9VDC (006P) x 1
AC Adapter (Optional): 9VDC
Negative Tips (Regulated recommended)
Boss PSA, Ibanez AC109, Dunlop Brick, Voodoo Labs, 1-spot etc
Input Impedance: 1M ohm
Output Impedance: 2K ohm
Input Jack
(nominal input -20db)
Unplug when it’s not in use
for a longer battery life
DC Jack
2.1mm x 5.5mm
9VDC - negative center
when an external power
supply is used,
the battery is disconnected
from the circuit
remove four screws from the
bottom plate to access battery
On/Off switch
(True Bypass)
Output Jack
Gain control knob
On/Off status led
1 of 1
XOTIC EFFECTS USA
14920 Calvert Street
Van Nuys, CA 91411 USA
E-mail: [e-mail]
Mid Boost knob
Volume knob
Two Band EQ
Treble and Bass Control Range
15db
-15db
90hz
500hz
1.5khz
10khz
