XPOtool 61963 User manual

Operation Manual
Waste Water Pump
61963, 61964, 61965
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps, and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

https://www.XPOtool.com Item 61963, 61964, 61965 Page 2
The Tool Experts
05 2022-1
The information contained in this document may alter at any time without previous notice. It is prohibited
to copy or spread any parts of this document in any way without prior written allowance. All rights re-
served.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless, and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
To return orders for exchange, repair, or other purposes, please use the following address. Attention!
To allow for a smooth execution of your complaint or return, it is important to contact our customer
service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]

https://www.XPOtool.com Item 61963, 61964, 61965 Page 3
The Tool Experts
05 2022-1
Introduction
Thank you for purchasing this quality product. To minimise the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Safety instructions
Attention!
In standing waters, garden and swimming ponds, and in their vicinity, the use of the device is only
permitted with a residual current circuit breaker with a tripping rated current of up to 30 mA (according
to VDE 0100 parts 702 and 738).
The device is not suitable for use in swimming pools, paddling pools of any kind of waters in which
people or animals may stay during operation. Operation of the device while people are in the danger
area is not permitted. Ask a qualified electrician!
This device is not intended for use by persons (including children) with limited physical, sensory, or
mental capabilities or lack of experience and/or knowledge unless they are supervised by a person
responsible for their safety or instructed by him/her on how to use the device. Children should be super-
vised to ensure that they do not play with the device.
Danger!
•Perform a visual inspection of the device before each use. Do not use it if safety components
are damaged or worn. Never override safety devices.
•Only use the device in accordance with the intended use specified in these operating instruc-
tions.
•You are responsible for the safety in the work area.
•If the cable or the plug is damaged due to external influences, never repair them yourself! The
cable must be exchanged for a new one, a job that should only be carried out by a qualified
electrician.
•The alternating voltage of 230 V indicated on the nameplate of the device must march the ex-
isting mains voltage.
•Never lift, transport, or fasten the device by the power cord.
•Make sure that the electrical plug connections are protected from flood or moisture.
•Pull the power plug before working on the device.
•Avoid exposing the device to direct water jets.
•The user is responsible for compliance with local safety and installation regulations. If neces-
sary, ask a qualified electrician.
•The user must take appropriate measures (e.g., installation of an alarm system, reserve pump,
etc.) to exclude consequential damage caused by the flooding in case of device malfunctioning.
•If the device fails, repairs may only be carried out by a qualified electrician.
•Never let the device run dry or be operated with the suction line fully closed.
•Never operate the device in swimming pools.
•Never install the device in the drinking water system.
Warning!
Read all safety warnings and instructions. Failure to follow the safety instructions can result in electric
shock, fire, and/or serious injury. Keep all safety information and instructions at hand for future refer-
ence.

https://www.XPOtool.com Item 61963, 61964, 61965 Page 4
The Tool Experts
05 2022-1
Resistance
•The maximum temperature of the pumped liquid should not exceed +35 ℃ in continuous oper-
ation.
•Never transfer flammable, gassing, or explosive liquids with this pump.
•Never use the pump for other liquids, especially engine fuels, cleaning agents, and other chem-
ical products!
Electrical connection
•The electrical connection is made to a 230 V ~ 50 Hz protective contact socket. Fuse protection
at least 10 A.
•The indicator lamp inside the switch lights up when the engine is switched on.
•The motor is protected against overloading or blocking by the thermal motor protection built-in.
In case of overheating, the overheating protection of the motor switches the pump off automat-
ically. After cooling down, the pump automatically switches on again.
Installation
The pump is installed as follows: either in a fixed position with fixed piping or in a fixed position with
flexible piping.
Please note!
•When installing, make sure that the pump does not hang loose on the pressure line or the power
cable. The submersible motor pump must be hung up on the supplied handle or rest on the floor
of the shaft.
•To ensure that the pump functions properly, the bottom of the shaft must always be free of
sludge or other dirt.
•If the water level is too low, the sludge in the sump can dry up quickly and prevent the pump
from starting. It is therefore necessary to check the submersible motor pump regularly by per-
forming a start-up test.
•The float switch is set so that it can be put into immediate operation.
Note: The pump shaft should have at least the dimensions of 40×40×50 cm so that the float switch can
move freely.
Mains connection
This waste water pump is already provided with a safety plug. The pump is intended for connection to a
safety socket with 230 V ~ 50 Hz. Make sure that the socket is adequately fused (at least 6 A) and
functional. Insert the pump plug into the socket, the pump is ready for operation.
Important: If the power cord or plug is damaged due to external influences, never repair them yourself!
The cable must be replaced with a new one, a job that should only be carried out by a qualified electri-
cian.
Functionality
The pumps are equipped with an open or closed impeller mounted at the end of the drive shaft. They
are surrounded by a large, circular chamber and a base plate with a mechanical interior. The suction
opening inside the base plate is in direct contact with the liquid to be pumped. The rotating impeller
transfers kinetic energy centrifugally into the circular chamber, where part of the kinetic energy is

https://www.XPOtool.com Item 61963, 61964, 61965 Page 5
The Tool Experts
05 2022-1
converted into pressure energy. The specific design of the rotary impeller optimises the hydraulic effi-
ciency without impairing the performance of the pump in processing muddy liquids with solids and short
fibres without the risk of clogging.
Technical specifications
Item №
Flow rate
(ℓ⁄h)
Discharge
head (m)
Speed
(r⁄min)
Energy
supply
Outlet con-
nection (㎝)
Material
61965
15,000
10
3,000
230 V,
50 Hz
5.08 (2″)
Pump body/rotation
impeller: cast iron;
mechanical seal:
stainless steel; shaft:
C45 steel or stainless
iron
61963
10,000
8
61964

https://www.XPOtool.com Item 61963, 61964, 61965 Page 6
The Tool Experts
05 2022-1
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registered in the German registry EAR under the WEEE-
registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European Un-
ion and other European countries with a separate col-
lection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equipment.
By contributing to the correct disposal of this article you
protect the environment and the health of your fellow
men. Environment and health are threatened by inap-
propriate disposal.
Material recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal waste
disposal facilities, or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part, of this instruction
manual require the written permission of WilTec Wildanger Technik GmbH.
