Xqisit B06 User manual
Getting started:
Please follow these simple steps to start using your mini Bluetooth Speaker:
charging, please remove the cable from the speaker.
• Make sure the mini Bluetooth speaker and your compatible Bluetooth enabled device are no more than 1 metre
away for the initial pairing process.
• Once paired, there will be a 10 metre Bluetooth sensing distance.
Note:
a) Charge indication: when charge is in process, the charging indicator will be red. When compete, the charging
b) Low battery indication: you will be promoted with a voice alert “low battery”.
Warning:
Do not charge the speaker with other unsuitable AC/DC power adapters. The speaker must be charged either via
USB port or by a USB AC/DC adapter.
Input AC100-240V, 50-60Hz
Output DC 5V 500mA
Press and hold the button for 4 seconds. You will hear a voice alert saying “Power on”. The standby
To pair:
Prior to using your Bluetooth speaker for the 1st time, you must pair it with a
Bluetooth enabled device. Please follow these simple steps:
b) Place your Bluetooth speaker and device no more than 1 metre apart.
c) Press and hold the button for 4 seconds. You will hear a voice alert saying “Power on”. The standby
alternately. It is now ready for pairing.
e) Activate your device’s Bluetooth function, and select Mini BT Speaker from the search list. Select OK to pair
the speaker.
f) If required, the pass key is ‘0000’ and press OK.
g) When pairing is complete, you will hear a voice alert “connected”. The speaker is ready for use and in standby
Speaker functions:
a) Play / Pause music
You can control via your device, or by pressing the button.
b) Adjust the volume
Press and hold the reduce volume button or increase volume button repeatedly to achieve the required
level.
c) Play next / previous song
Quick press the button for previous song, and press button for the next song.
d) Answer a call
Wait for the speakerphone to ring, then short press the button to accept the call, or answer the call on
your Smartphone in the normal way.
e) End a call
Short press the button to end the call, or you can end the call via your smartphone in the normal way.
f) Last number redial:
When in standby more, short press two times for last number redial.
• Micro USB
charging cable
• Audio jack • Lanyard
• Function control buttons
• Standby indicator
• Microphone
• Charging indicator
PLAY
PLAY
PLAY
Disconnect the speaker and smartphone:
Press the button for 5 seconds.
Or disconnect the speaker via the Bluetooth options on your smartphone
Connection with 3.5 mm audio cable:
You canalso connect to portable speaker with a 3.5mm audio cable to listen tomusic if you do not want to use
Bluetooth. Simply connect the cable to the headphone socket of the audio source, and plug the 3.5mm cable back
to the speaker.
Maintenance:
a) Do not charge the speaker with other unsuitable AC/DC power adaptors.
The speaker should be charged via USB port or by a USB AC/DC adapter with Input:
AC 100-240 V, 50-60 Hz
b) Do not expose the speaker to liquid, moisture or humidity.
c) Do not expose the speaker to high temperature.
d) Do not use abrasive cleaning solvents to clean the speaker.
e) Do not attempt to disassemble the speaker.
Safety Notice:
a) Check local laws regarding use of a mobile handset and speakerphone while driving.
b) Never mount or store over any air bag deployment area.
c) Not suitable for children as small parts may be a choking hazard.
Trouble Shooting:
If you are unable to connect your speaker and smartphone, please try the following:
a) Ensure your smartphone’s Bluetooth feature is activated
b)Ensure the speaker is within a maximum of 10 metres of your mobile device and there are no obstructions
Signal / Noise ratio: > 80 dB
Driver: 4 oHm 3 Watt
Rating Power: 3 W
Line in: 3.5 mm
Rechargeable battery: 300 mAH lithium ion
Battery voltage: 3.7 V
Full charging time: 3 hours
Talk time: 3 hours
Standby time: 12 hours
Version 3.0, Class 2, 10 Metres
Power input: Micro USB (5 V / 500 mA)
Weight: 42 g
Dimensions: 37x34 mm
Voice alert:
Switch on “Power On“
Pairing mode “Pairing mode“
Devices connected “Connected“
Pairing Disconnected “Disconnected“
Receive incoming call “Call from ...“
Already Max Volume “Maximum Volume“
Already Min Volume “Minimum Volume“
Re-dial Last call “Redial“
Low battery “Low battery“
PLAY
PLAY
B06 Mini Portable Speaker user manual
Easy to carry around and ideal for travel, you can enjoy your music anywhere
with your friends. Use as an external speaker for your smartphone, laptop or
media player.
Warning
Please read these safety warnings and cautions carefully to ensure your personal
safety and prevent property damage.
Fire and Electric Shock Hazard
• Do not expose your xqisit xqisit B06 to liquid, moisture, humidity, or rain.
Do not use the xqisit xqisit B06 near a bathtub, sink, sauna, pool, or steam room.
Exposure of the xqisit xqisit B06 to moisture could result in electric shock.
• Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave,
incinerate, paint, or insert foreign objects in to the xqisit xqisit B06 . Such actions
could result in electric shock.
• Clean the xqisit xqisit B06 only with a dry cloth.
• Do not expose your xqisit xqisit B06 to extremely high or low temperatures.
• Do not leave your xqisit xqisit B06 in direct sunlight for extended periods of time.
• Do not leave your xqisit xqisit B06 near open ames such as cooking burners,
candles, or replaces.
• Do not block any ventilation openings.
Battery/Charger Hazard
• Do not dispose of your xqisit xqisit B06 in a re. The battery could explode causing
injury or death.
• Only charge the battery in accordance with the user instructions supplied with the
xqisit xqisit B06 .
• Do not attempt to disassemble the xqisit xqisit B06 or force open the built-in
battery because this may result in electric shock.
• Do not charge the xqisit xqisit B06 in damp areas or in extremely high or low tempe
ratures because this could result in electric shock.
• Do not clean the xqisit xqisit B06 when it is being charged. Always unplug the
charger rst before cleaning the xqisit B06 .
Automobile Accident Hazard
• Do not leave or store the xqisit xqisit B06 or any of its accessories near or over
your automobile’s air bag because serious injury may result when an airbag deploys.
Fall Hazard
• Do not place the xqisit xqisit B06 on high surfaces such as shelves. During music
playback the xqisit xqisit B06 may move which could cause the xqisit xqisit B06 to
shi and fall o of the edge.
Caution
• Do not use abrasive cleaners to clean your xqisit xqisit B06 because this could
cause scratches and damage.
• Do not bring your xqisit xqisit B06 in to contact with any sharp objects because this
could cause scratches and damage.
• Do not insert anything into your xqisit xqisit B06 unless otherwise specied in the
user instructions. This may damage the internal components.
• Do not attempt to repair, modify, or disassemble your xqisit xqisit B06 yourself, it
does not contain any user-serviceable components.
• Do not attempt to replace your xqisit xqisit B06 battery, it is built-in and is not
changeable.
• Observe all signs and displays that require an electrical device or RF radio product
to be switched o in designated areas.
• Turn o your xqisit xqisit B06 prior to boarding an aircra. Do not use the xqisit
xqisit B06 inside an aircra unless allowed by your airline.
• Dispose of the xqisit xqisit B06 and the xqisit xqisit B06 ’s battery in accordance with
local regulations. Do not dispose of the battery with regular household waste.
We, STRAX GmbH, declare under our sole responsibility, that the product
xqisit B06 (Model-Nr 90-071B),
conforms with the provisions of the following Directives: 1999/5/EC;
2004/108/EC and 2006/95/EC.
Distributor: STRAX GmbH, Belgische Allee 52+54, 53842 Troisdorf,
Germany, www.strax.com
WEEE Directive 2002/96/EC Art.11(2)
The use of the symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly you will help prevent potential
negative consequences for the environment and for human health, which could other-
wise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local council oce or
your household waste disposal service.
